FNL – for an optimum connection of fieldbus and Ethernet networks up to 100 Mbit/s.
FNL allows the connection to all PROFIBUS DP networks based on RS485 (up to 12 Mbit/s) and supports DP Master class 1/2 on the basis of DP and DPV1 services as well as DP Slave.
The access to FNL is carried out through a TCP/IP socket interface. The interface is operating system independent, completely unfolded and because of its quickness convincing.
The Ethernet based operation mode as MODBUS TCP/IP Slave provides easy integration of FNL as PROFIBUS DP Master into a large number of visualisation and control systems. The PROFIBUS DP based diagnostics and IO data are dynamically compiled into the MODBUS TCP/IP structure and do not have to be configured additionally.
OPC Server
The OPC Server directly connects FNL to all OPC-client-capable Windows applications. OPC is supported by all common SCADA, control, visualization, and process control systems.
Programming Interface
The FNL TCP/IP socket interface provides the exchange of the DP Slaves' process and diagnostics data as well as all DP/DPV1 Master class 1/2 and DP Slave services. So FNL can be easily integrated in any operation systems.
FDT 1.2 Communication DTM
FDT allows the standardized configuration of fieldbus devices via different bus systems like HART-Bus, Foundation Fieldbus, PROFIBUS DP/PA or Ethernet.
LabVIEW Driver
The driver can be integrated in a simple manner into every LabVIEW version due to its standard TCP/IP socket interface. Ethernet and PROFIBUS DP configuration are generated via full graphical tools, included in the delivery. The package also includes LabVIEW sample VIs incl. source code.
|
|
|
|
|
|
Control architectures with I/O, PID control, acquisition and gateway modules
The Ascon’s deltadue DX and DY series of gateways, adapters and WebSCADA interface the PID control and acquisition modules with PLCs, PC based systems, SCADAs and Operator Panels to realize different architectures by connecting the modules to:
- A PLC or SCADA with MODBUS TCP protocol via an Ethernet network or the web.
- Any web browser for the configuration of HTML management pages and to MODBUS TCP SCADAs via an Ethernet network.
- A MODBUS TCP SCADA (via Ethernet network) and to a PLC (PROFIBUS DP or MODBUS RTU or DeviceNet) simultaneously.
- CANopen, PROFIBUS DP, DeviceNet networks.
- MODBUS RTU networks with different baud rate, parity and stop bits.
- Two masters, such as Operator Panels, SCADA, PACs, etc. simultaneously.
The DX also include the following Manager functions:
- Automatic learning and back up of the modules configuration data;
- Hot Swapping, automatic configuration and parameterisation of replaced modules;
- Offline configuration and parameterisation, the modules data are downloaded into the DX before they are mounted, when the modules are inserted into their housings, they are recognised, configured and parameters are downloaded;
- Diagnostic of the modules, the DX scans all the modules to verify if they are the correct ones and working properly.
The modules can work as independent units; no back planes or common modules are necessary. The DX is optional, it must be ordered only when the gateway or Manager functions are necessary.
|
|
|
|
|
|
UNIGATE IC
UNIGATE IC combines all analog and digital signals of the Fieldbus- or Ethernet-interface on a small space of 45 x 25 mm (DIL-32-housing).
The Deutschmann UNIGATE® IC is a complete single-chip bus-solution in a 32-DIL-housing. On a space of 45 x 25 mm only, the device contains all necessary components, such as microcontrollers, Flash, RAM, bus-chip and of course the analog components, such as optocoupler and bus driver. The UNIGATE® IC is connected to the microprocessor of the terminal equipment or it can be operated stand-alone. UNIGATE® ICs are certified and/or tested on the bus and through numerous applications, the problem-free operation with all marketable master systems has been proven. The integrated microprocessor processes the entire data traffic with the bus and consequently relieves the terminal equipment processor of this considerable effort. The protocol of the terminal equipment is converted via a Script in the UNIGATE® IC. With the free PC-tool "Protocol Developer" this Script is generated and optimally adapted to the final product and the requirements of the bus. Changes in the Firmware of the terminal equipment are not necessary and the microprocessor of the terminal equipment is not additionally loaded with communication- and bus-tasks. The hard- and software-interfaces of the Deutschmann UNIGATE® IC-series are standardized and functionally identical. As a result, the ex-changeability between the different UNIGATE® IC-versions of the device control electronics is guaranteed.
|
|
Controllers / Gateways
AS-i controllers, gateways, masters and repeaters are elementary components of AS-i networks. These components are most of the time placed in the control cabinet and ensure data communication, extension and power supply of the connected slaves, sensors and actuators.
|
|
|
|
|
|
Gateways
The intelligent Gateway for the connection of industrial networks - UNIGATE FB
Connecting incompatible networks
In the field of automatic control many different Fieldbuses and Industrial Ethernet became established worldwide. Again and again the task of interconnecting these incompatible networks comes up. The UNIGATE® FB-series was created exactly for that task. The series contains Fieldbus-Slave as well as Industrial Ethernet versions.The UNIGATE® FB is designed as DIN-rail module and contains the selected Fieldbuses or Ethernet in the mechanical variant carried out in the respective standard. Internally the product is realized by using two UNIGATE® IC-modules that are mounted on a carrier motherboard. By this modular structure all Fieldbus- and Ethernet-versions can be supplied, provided that the respective
IC-modules are available. The number of available versions is growing steadily by the continuous development of new IC-modules e. g. in the Industrial Ethernet field.
In case of the series UNIGATE® FB, the data exchange between the Fieldbuses or Ethernet is realized through a Script. With the free PC-tool "Protocol Developer" this Script is generated and optimally adjusted to the final product and the requirements.
|
|
|
|
|
|
The Anybus- X-gateway® family consists of over 180 certified and proven industrial gateways connecting almost any two industrial networks. The X-gateway is a simple, easy to use gateway connection real-time Ethernet networks to almost any fieldbus.
Real-time Ethernet protocols supported:
• EtherNet/IP scanner or adapter
• PROFINet IO Device
• Modbus TCP slave
• EtherCAT slave
• HTTP Server
• FTP Server
• Telnet Server
• SMTP Client
Fieldbusses supported:
• Profibus master or slave
• DeviceNet scanner or adapter
• AS-interface master
• CANopen slave
• ControlNet adapter
• CC-Link slave
• Modbus RTU slave
• Modbus Plus slave
• Interbus slave
• FIPIO slave
Slave to Slave Gateway:
Many applications need to take two disparate independent networks with each having its own master control and allow them to exchange data. This happens where two PLCs need to exchange information. The X-gateway helps to accomplish this by acting as an I/O slave device on the fieldbus and Ethernet networks. Each master/client writes to the output table of the X-gateway on its network and then the X-gateway maps this data to the input table of the opposite fieldbus or Ethernet network where it can be easily read by the other master/client.
Master to Slave Gateway:
Many applications needs to interface field I/O devices to a controller that has a different fieldbus or Ethernet protocol from the I/O. In these cases, the X-gateway serves as a fieldbus or Ethernet master on one side while acting as a fieldbus or Ethernet slave on the other. The I/O data is polled from the field devices then mapped into the I/O table of the controller.
|
|
|
|
|
|
The Anybus- X-gateway® family consists of over 180 certified and proven industrial gateways connecting almost any two industrial networks. The Anybus X-gateway is a simple, easy to use communications gateway that allows the user to connect almost any two fieldbus systems.
Fieldbus protocols supported are:
- Profibus master or slave
- DeviceNet scanner or adapter
- AS-Interface master
- CANopen slave
- ControlNet adapter
- CC-Link slave
- Modbus RTU slave
- Modbus Plus slave
- Interbus slave
- FIPIO slave
Building Automation Protocols supported are:
- Lonworks
Slave to Slave Gateway:
Many applications involve the need to take two different fieldbus networks with each having its own master control and allow them to exchange data. This happens commonly in applications where two Programmable Logic Controllers need to exchange information. The Anybus® X-gateway helps the user accomplish this by acting as an I/O slave device on each fieldbus. Each fieldbus master writes to the output table of the Anybus® X-gateway on its network and then the Anybus® X-gateway maps this data to the input table of the opposite fieldbus where it can be easily read by the other master.
Master to Slave Gateway:
There are many applications where the user needs to interface field I/O devices to a controller that has a different fieldbus from the I/O. In these instances, the Anybus® X-gateway serves as a fieldbus master on one side while acting as a fieldbus slave on the other. The I/O data is polled from the field devices then mapped into the I/O table of the controller.
|
|
|
|
|
|
FNL Proxy PN/PB
Integration of PROFIBUS DP systems into PROFINET IO networks
The 24 Volt hat rail module contains one PROFIBUS DP interface, four PROFINET IO RT interfaces as well as one RS232 service interface for commissioning and diagnostics.
The proxy integrates both existing and new PROFIBUS DP devices without any modification or adaptation into a PROFINET IO network. The PROFIBUS DP interface supports baud rates from 9.6 kbit/s to 12 Mbit/s.
The FNL Proxy PN/PB implements a plenty of PROFIBUS diagnostic functions as well as additional features, such as the configurable behaviour of the PROFIBUS DP Master in case of a break down of the PROFINET IO network or the detailed indication of error codes. Of course, it is also possible to combine several proxies.
COMSOFT‘s CONFIGURATOR II is available for compilation and download of the PROFIBUS configuration. The comfortable and full graphical tool compiles the PROFIBUS configuration via drag and drop mechanism. The integrated online mode allows direct commissioning and diagnostics of the connected PROFIBUS network via Ethernet.
The proxy implemented as PROFINET IO device and based on the Siemens ERTEC400 PROFINET IO controller supports PROFINET IO according to the current specification 2.0 and uses the modular mapping procedure. Input and output data as well as diagnostic data of the single DP Slaves are depicted through device modules (slots and sub-slots). Diagnostics are reported by a PROFINET IO alarm.
Furthermore SNMP diagnostics are included and the TFTP server based firmware update is supported.
|
|
|
|
|
|
|
Ethernet Direct Panda Series PROFIBUS DP products are in production technology as well as in the connection of distributed intelligence such as the networking of multiple controllers to one another. The data rates are up to 12Mbit/s on twisted pair cables and fiber optics are also possible. Panda Series PROFIBUS converter and gateways are designed for a wide range of applications, particularly in the fields of factory and process automation. It is suitable for both fast, time-critical applications and complex communication tasks with safety and stability when use in industrial applications. The Panda converters are designed specifically for the slave device of PROFIBUS DP protocol. It offers RS-232, RS-422 and RS-485 three kinds of communication way. With the Hybrid COM 1 design, users can readily choose one type of comport to use. By using this module, suers can put their RS-232/422/485 devices into PROFIBUS network very easily. The Panda Series gateways are also designed for the salve device of PROFIBUS DP protocol. It allows the PROFIBUS master to access the Modbus devices. These Modbus devices may be a PLC, a sensor, modules and other equipments. In addtion, Ethernet Direct also provides the utility software for users to configure the Panda gateways. By using this module, users can put their Modbus devices into PROFIBUS network very easily.
|
|
|
|
|
|
SNL2-E Ethernet/RS232/RS485 Gateway
SNL2-E – the optimal solution for connection of serial interfaces and Ethernet networks of up to 100 Mbit/s.
SNL2-E allows the connection of two serial end devices. The serial interfaces can be configured via software as RS232- or RS422/RS485 interfaces. Also, a mixed operation mode is possible.
In addition, for operating the RS485 bus, terminating resistors can be switched on via software. Operation in TTY mode can be realized by means of an external adapter.
Both interfaces support full duplex DMA mode operation. In synchronous operation mode, rates of up to 1 Mbit/s can be reached.
The protocol firmware is loadable. The serial interfaces can be run completely independent from each other. On every serial interface a different protocol driver can be loaded and run.
DF-compatible driver interface
For Windows, as well as UNIX operating systems the DF-board compatible interface allows the replacement of an existing DF-board by an SNL2-E module without any changes in the application software.
|
|
Industrial Ethernet
In this area all Ethernet Gateways, Protocol converters and All-In-One bus nodes are filtered out and displayed. We are already offering solutions for 4 of the more then 20 Industrial Ethernet-versions. Others will be added.
Additionally you will find the Routers in this area, such as the Powerlink-Router. With these devices you connect Industrial Ethernet networks with the "standard" Ethernet.
|
|
|
|
|
|
Anybus Communicator® is a family of certified and proven gateways, connecting automation devices via their serial interface to all major fieldbusses. The Communicator enables industrial devices without a network interface to connect to all major standard fieldbusses including Profibus, DeviceNet, CANopen, ControlNet, CC-Link, Modbus-RTU, Modbus-Plus, Interbus and FIPIO.
The Communicator performs an intelligent conversion between the serial protocol of the automation device and the chosen fieldbus network.
The Anybus Communicator supports RS-232, RS-422 and RS-485 serial electrical signals without any change in hardware. This allows for connectivity to a broad range of serial devices. Typical serial applications include variable frequency drives, sensors, actuators, human machine interfaces, barcode readers, RFID readers and industrial scales among others. It is much more than just a standard tunneling gateway and provides full flexibility and extended connectivity options.
The Anybus Communicator is configured using a very simple Windows%u2122 based software package that requires that the user simply fill in the blanks to match the protocol of the serial device it is connected to. Applications that require conversions from serial Modbus to fieldbus protocols are even easier as a built-in software wizard guides the user through each step of the configuration process.
|
|
|
|
|
|
Anybus Communicator® is a family of certified and proven gateways, connecting automation devices via their serial interface to all major real-time industrial Ethernet networks. The Communicator enables industrial devices without a network interface to connect to all major real-time Ethernet standards including EtherNet/IP, Profinet, Modbus-TCP and EtherCAT.
The Communicator performs an intelligent conversion between the serial protocol of the automation device and real-time industrial Ethernet network.
The Anybus Communicator supports RS-232, RS-422 and RS-485 serial electrical signals without any change in hardware. This allows for connectivity to a broad range of serial devices. Typical serial applications include variable frequency drives, sensors, actuators, human machine interfaces, barcode readers, RFID readers and industrial scales among others. It is much more than just a standard tunneling gateway and provides full flexibility and extended connectivity options.
The Anybus Communicator is configured using a very simple Windows™ based software package that requires that the user simply fill in the blanks to match the protocol of the serial device it is connected to. Applications that require conversions from serial Modbus to real-time Ethernet protocols are even easier as a built-in software wizard guides the user through each step of the configuration process.
|
|
Intelligent PROFIBUS DP - RS232/RS422 Gateway
This low-cost gateway allows you to integrate your serial devices quickly, easily and reliably into a PROFIBUS DP network.
All connected serial devices will work as usual, as our gateway depicts all send and receive sequences 1:1.
The data can be accessed swiftly and exactly. Moreover, our drivers facilitate a preprocessing of data within the gateway. Of course, our drivers can be customized according to your requirements.
XPS-E - extra performance at no extra expense!
|
|
|
|
|
|
COMETH Range
Instant & direct serial connection over Ethernet TCP/IP network
Available in dongle, din rail & printed circuit format
Ultra small & compact size, COMETH-EMBD "System on a Chip" : 20x63 mm, RJ45 included
RS232, RS422, RS485, TTL interfaces depending to models, up to 250 Kb/s or 350 Kb/s (COMETH-FIELD) sustained data rate
Direct connection to any DTE serial device (e.g. PC computer) without adaptation cable (COMETH dongle only)
Support for TCP Client/Server, DHCP Client, TELNET RFC2217 extension, Telnet Server, COM port re-director (VIP), multipoint or point to point virtual link over UDP modes and MODBUS/TCP Client/Server, MODBUS/RTU & MODBUS/ASCII protocols
Scanning I/O for all PLC's running MODBUS/RTU & MODBUS/ASCII
Virtual COM port redirection software for Windows 2000, NT & XP (VIP)
Easy administration through the serial link or Ethernet (TELNET)
Multiple configuration tool for deployment in volume
Remote firmware download for easy upgrade operations
External power supply or remote-power supply depending to models
15 kV ESD protection (except COMETH-EMBD)
Metallic case (except COMETH-EMBD), CE industrial standards
Ethernet / RS 1500 Veff isolation (except COMETH-EMBD)
This new range of Serial over Ethernet TCP/IP servers is intended to connect to any serial equipments.
The high level of integration and its built-in protection make the COMETH range extremely reliable and the world's smallest module.
COMETH's technical characteristics make it a universal product at a very attractive price.
|
|
|
|
|
|
UP for an industrial strength painkiller?
Enabling communication from factory floor devices to PLC controllers just got a whole lot easier. The DeviceMaster UP industrial Ethernet gateway offers a flashable solution that configures in minutes via the web, allowing you to support the major industrial Ethernet PLC networks – EtherNet/IP, PROFINET, or Modbus/TCP – on a single platform.
Whichever protocol you need, the DeviceMaster UP provides an RS-232/422/485 software-selectable connection to an industrial Ethernet network.
By accommodating multiple protocols, the DeviceMaster UP provides an adaptable and flexible platform device integrators and distributors need to thrive in rapidly changing markets. It's the pain-free Industrial Ethernet solution that simplifies supply chain management and reduces expenses for you and your customers.
It's power over protocol.
DeviceMaster UP Highlights
DualConnectPlus™ Technology – simultaneously connect both serial and Ethernet devices to PLCs and/or applications. String, RFID, and barcode data filtering eliminates redundant data while extracting the RFID and barcode parameters.
Provide PLC connectivity to standard serial devices with flashable protocol support for EtherNet/IP, PROFINET, Modbus/TCP, and TCP/IP
Compact and hardened form-factor — wide -37° to 74°C industrial temperature range
Variable power input eliminates need for power converters
PortVision® enables user to view status, update firmware and resolve issues remotely.
RoHS Directive 2002/95/EC compliant
|
|
|
|
|
|
Director
The Director (DS4) is an expandable Industrial Network Gateway built around Eurotech's APEX software core enabling both operational and financial data to be acquired, networked, transformed and utilised efficiently taking full advantage of the TCP/IP technologies and communication networks.
Features
Architecture Single boards
Processor/clock speed Intel 386EX CPU @ 25MHz
Memory 1MB SRAM with battery back-up and 1MB Flash
Operating system APEX
Configuration ACE
Size 4 1/8" x 6 1/2" x 4 3/8"
Mounting Panel mount
Watchdog Hardware with start-up or software trigger
Serial ports 3 x RS232 and 1 x RS232/RS485 selectable
Protocol Multiple protocol support
Power requirements 18 - 36V DC input range
Power consumption 3W (maximum, with standard board set only)
Operating Temperature -40 to 70°C at 25MHz
Humidity 0 to 95% relative, non condensing
Diagnostics Serial MMI or Telnet
Networking TCP/IP serially or RJ-45 10BaseT Ethernet
Calendar/Clock RTC with battery back-up
Input/output 3 available slots for PC/104 expansion modules
|
|
|
|
|
|
RFID-EC-IC
The RFID Edge Controller Industrial Compact Enclosure (RFID-EC-IC) is designed to be installed in harsh warehouse and factory floor locations where space is at a premium and co-location with remote RFID infrastructure is required. Eurotech's RFID Edge Controller (RFID-EC) works in conjunction with IBM's WebSphere RFID Premises Server to provide a complete end-to-end solution. The basic premise of the RFID-EC is to provide the hardware and software interfaces required by many of the individual devices (sensors, discrete I/O, PLC's, etc) within a customer's facility.
Features
Fitted with Eurotech's VIPER SBC
Input voltage range 10 - 36V DC (10 - 25V AC)
Battery backed operation for over 2 hours of normal operation
Operating temperature: 0°C to 55°C
Weight: 1.7Kg including VIPER, VIPER-UPS
Enclosure dimensions: 200mm x 210mm x 105.2mm including mounting feet
RJ45 Ethernet connector with activity and link LEDs
4 x RS232 on standard DB9
1 x RS485/422 on DB9
2 x USB host ports
CompactFlash (CF ) Socket
|
|
|
|
|
|
Solve most any Modbus conversion challenge with the MESR Modbus Gateway
MESR Modbus Gateways bridge devices on Modbus serial networks (RS-232, RS-422 or RS-485) with those on Modbus TCP networks, allowing seamless integration of any Modbus device. Each serial port is accessible over a LAN or WAN by up to 16 simultaneous Modbus TCP masters. All Vlinx™ MESR gateways feature auto detecting 10/100Base T copper and fiber optic connections.
Simple Installation and Setup
Removable terminal blocks simplify power and data connections
Slimline IP30 DIN mount enclosure minimizes footprint
Simple configuration through the built-in web server, or Windows configuration software
Built-in traffic monitor for instant verification of successful installation and simple network diagnostics
Optional pass-through Ethernet port eliminates need for additional Ethernet switch port
Optional Fiber Optic Ethernet connections for long-distance and total noise immunity
Features
Slim, Industrial Enclosure
Modbus Master/Slave Flexibility
Web Server Configuration Software
Complete Fiber Options Low Latency
High Throughput
Heartbeat Connection
Benefits
Save DIN rail space while maintaining industrial ratings
Modbus master or slave can be on any serial port or on the Ethernet port. Customizable to your application.
Program through web browser or local port. Same user interface; no training required
Connect to all fiber networks in your plant without converting to copper connections
View status in real time
Detects communication failures and automatically reconnects to keep the system online
|
|
|
|
|
|
MGate™ EIP3000 series products can be used to connect DF1 devices and EtherNet/IP devices to provide Allen Bradley PLCs with remote maintenance capability. By supporting PCCC objects on CIP, the MGate™ EIP3000 can communicate seamlessly with Rockwell Ethernet devices. The EIP3000 protocol gateways come with either 1 or 2 serial ports to allow users to select a suitable gateway depending on the size of the network. The EIP3000 series supports up to 8 Ethernet/IP clients and 8 Ethernet/IP servers simultaneously; each client can send up to 16 requests at one time. Moreover, each MGate EIP3000 gateway supports four virtual serial ports for remote control over an Ethernet connection. OPC servers and SCADA systems can use these virtual COM ports to communicate with EtherNet/IP devices or DF1 devices through the gateway.
Features:
ÿPCCC objects for Rockwell Automation networks supported
ÿProCOM provides a virtual serial port for multiple DF1 and ››EtherNet/IP device communication
ÿ16 simultaneous EtherNet/IP clients/servers with up to 16 ››simultaneous requests per client
ÿSerial redirector function provided
ÿEmbedded EtherNet/IP and DF1 protocol analyzer
ÿRedundant dual DC power inputs
ÿBuilt-in Ethernet cascading for easy wiring
|
|
Introduction
The MB3170 and MB3270 are advanced Modbus gateways that provide maximum flexibility for integrating industrial Modbus networks of all types and sizes. They are designed to integrate Modbus TCP, ASCII, and RTU devices in almost any master and slave combination, including serial master to serial slave, or simultaneous serial and Ethernet masters. A special priority control feature allows urgent commands to obtain immediate response. All models are ruggedly constructed, are DIN-rail mountable, and offer built-in optical isolation for serial signals as an option.
Features
• Configuration is exceptionally easy
• Slave mode supports 16 TCP masters and up to 62 serial slaves at the same time
• Master mode supports 32 TCP slaves at the same time
• Emergency request tunnels ensure QoS control
• Serial redirector function provided
• Embedded Modbus protocol analyzer
• Redundant dual DC power inputs
• Built-in Ethernet cascading for easy wiring
|
|
|
|
|
|
UP for an industrial strength painkiller?
Enabling communication from factory floor devices to PLC controllers just got a whole lot easier. The DeviceMaster UP offers a flashable solution that configures in minutes via the web, allowing you to support the major industrial Ethernet PLC networks – EtherNet/IP, PROFINET, or Modbus/TCP – on a single platform.
Whichever protocol you need, the DeviceMaster UP provides an RS-232/422/485 software-selectable connection to an industrial Ethernet network.
By accommodating multiple protocols, the DeviceMaster UP provides an adaptable and flexible platform device integrators and distributors need to thrive in rapidly changing markets. It's the pain-free Industrial Ethernet solution that simplifies supply chain management and reduces expenses for you and your customers.
It's power over protocol.
Highlights
DualConnectPlus™ Technology – simultaneously connect both serial and Ethernet devices to PLCs and/or applications. String, RFID, and barcode data filtering eliminates redundant data while extracting the RFID and barcode parameters.
Provide PLC connectivity to standard serial devices with flashable protocol support for EtherNet/IP, PROFINET, Modbus/TCP, and TCP/IP
Compact and hardened form-factor — wide -37° to 74°C industrial temperature range
Variable power input eliminates need for power converters
PortVision® enables user to view status, update firmware and resolve issues remotely.
RoHS Directive 2002/95/EC compliant
|
|
|
|
|
|
ACKSYS renews its serial to wireless solution offer by introducing the WLg-DONGLE, a compact wireless RS232 serial to WiFi Ethernet server with support for 2.4 GHz and 5 GHz radio bands.
WLg-DONGLE relies on the same technology used in the "WLg-xxx" series and thus profit from proven technology, device is very compact and is specially designed to satisfy the needs of the system integrator market.
Product rely on the IEEE 802.11 a/b/g/h standards (2.4 GHz & 5 GHz), it features an full high speed serial port (250 Kbps).
The radio link is made safe by using most modern methods of protection: WEP 64/128 bits, WPA-PSK, WPA2-PSK and authentification IEEE 802.1x (RADIUS).
The nominal range (open space) of the module is 300 m for a transmit power of +20 dBm and -92 dBm in reception (a/g modes) and -95 dBm (IEEE 802.11b mode).
This module supports the following modes : TCP Client / Server, TELNET RFC2217, COM port redirection, TELNET server, raw, point to point (virtual cable) and the serial MODBUS to MODBUS/TCP gateway.
Easy configuration and administration with your web browser, TELNET, SNMP and from the ACKSYS administration software NDM.
|
|
Segment couplers are configuration free and transparent: The segment coupler will “display” all devices connected to the PA network as if they were DP field devices. The communication speed on the PA side is independent of the DP side. All PA devices are configured on Master Class I and Class II as DP instrumentation. PA devices only “see” the PA master of the segment coupler, which simulates the DP Master.
Power Hub versions of the segment coupler are based on motherboards – with optional redundancy for both the power module and the gateway components. They connect up to four independent segments to one DP-Master. The basic models couple single PA segments to DP and provide power to the segment. All components are hosted in one small housing.
|
|
Connects your PROFIBUS to Ethernet
-Scalable from one PB channel to up to three PB channels per device
-Master or slave
-Ethernet 100BASE-TX / 10BASE-T, 100Mbits/s and 10 Mbits/s
-Application interface identical to Profibus interface cards
-PC drivers for Windows
-No fan
-OPC server available
-Suitable for use with DTM / FDT
|
|
The Westermo Fieldbus devices are industrial PROFIBUS DP modules. There are different types of slave modules and one Master module. PROFIBUS adapters that is able to transfer PROFIBUS DP I/O data via serial communication. I.e leased lines, dial up modems, Ethernet adapters, GSM modems or radio modems without any use of special drivers or special PLC bords. The FD-20, PROFIBUS DP Master module act the same way as the adapters on the serial side and act as a stand alone master on the PROFIBUS side. A combination with our Ethernet adapter gives the opportunity to connect PROFIBUS to Ethernet PROFIBUS DP converter to make a transparent connection for a different serial interfaces to a PROFIBUS DP network.
|
|
netLINK: The definitively smallest Ethernet Gateways
- Immediate Ethernet conncetion
- Easy operation
- Extremly compact
- Low Cost
- more
netTAP: The universal fieldbus Gateways
- Low space requirements
- Easy installation and configuration
- Numerous protocol conversions
- Customer-specific connection technology
- Exchangeable configuration memory
- Additional interface for start up and diagnostic
- more
Protocol Converter: The Control Component with fieldbus connection
- Inexpensive fieldbus conncetion for devices with serial interface
- Protocol conversion between different standard protocols such as 3964R, RK512, Modbus, Modnet, etc
- Simple implementation of customer-specific conversions
- Configuration via PC
- Loading of the configuration and the firmware via the diagnostic interface
- On-line diagnostic
- Status LEDs
- Robust metal housing for installation on DIN rails
- more
|
|
|
AS-Interface networks up to 62 field devices onto a single pair of wires that delivers both signal and power. Actuator Sensor Interface, or AS-Interface, was developed by a group of sensor manufacturers and introduced into the market in 1994. Since that time, it has become the de facto standard for discrete sensors in process industries throughout the world. AS-Interface may be used in hazardous process environments using explosion proof, tray cable, nonincendive and for nonincendive wiring protection concepts.
|
|
|
|
|
|
Ethernet Gateway - echochange connects Ethernet worlds
More and more Ethernet is being used in industry. Serveral protocols based on Ethernet are available: ISO (H1), ISO on TCP (RFC1006) or EtherNet/IP. Although these protocols are similar, communication between the corresponding networks is not that simple.
Echochange provides the solution:
This produces „relationships“ between plants that were previously incompatible. The gateway may be configured locally or remotely and supports up to 30 active connections. The configuration software provides comprehensive diagnosis functions.
Special Features:
Connects different controller worlds
▪ Siemens (S7, S5)
▪ Rockwell Automation
(Allen-Bradley)
▪ Schneider Electric (Modicon)
Separated Ethernet networks
are connected via specific
parameterized connections
Connection of TCP/IP computers
with ISO (H1) networks
Remote maintenance of PLCs in an ISO (H1) network via TCP/IP
Gateway between separated networks (protocols run at the same media)
Converter in a heterogeneous network (protocols run at the same media)
Easy configuration: Online via IP or ISO (H1), serial or offline for later transfer
|
|
Features:
- Version 3.0 Master, compatible with
all 2.0-3.0 slaves and 7.3 profile
analog modules
- Duplicate address detection
- AS-Interface peripheral fault
diagnositcs
- Serial Diagnostics Port: see 462008
for cable and software
- ETL approved Class I Division 2
|
|
|
|
