As Gas Chromatograph users will probably confirm, little has changed in the past decades in the way hydrogen gas is used in the laboratory. Now that picture is set to change, thanks to a remarkable multi-disciplinary gas generator manufactured by Parker Balston. Their new paradigm solution for generating hydrogen in laboratories is so easy to use that it could potentially save thousands of Euros a year in expensive downtime and installation costs.
Four different models have been upgraded to the 100, 165, 260 and 510 ml/min units producing high purity hydrogen, 99.9999% at up to 6.89 bar. Special features include an advanced PEM electrochemical cell protection system with microprocessor controls, a unique water hydration circulation purification system. This is also complimented by USB capability with software options for remote monitoring and control, blue intensity back lighted display for simple operator use with touch screen visuals for system status checks, Automatic water fill options, and data logging performance controls for preventative maintenance with reporting tools for use in regulated environments where system validations are required.
These generators will allow GC (Gas Chromatograph) users to supply, control, and automate all hydrogen gas supplies. A single generator can support up to as many as 13 instruments with high purity hydrogen.
Other applications include fuel gases for total hydrocarbon analyzers, supply gases for hydrogenation reactors, hydrogen for pilot scale fuel cells assays and hydrogen for collision reaction gases.
Each generator is available as standard with a two-year warranty emphasizing the quality and reliability
Parker Balston is the worldwide leader in separation and filtration technologies, and offers a broad range of analytical gas generators to meet your specific analytical instrument requirements. All products are backed by a fully staffed field sales and service organization.
|
|
| The combination of these technologies produces a continuous on-demand supply of pure nitrogen. Typical applications include nebulizer gases, curtain gases, source gases, chemical and solvent evaporation, instrument purge and supply, evaporative light scattering detector use and sparging. |
|
Dimensioning range from 26 Nm³/h up to 320 Nm³/h at purity
up to 99.5 %.
Due to the development of special fibres filtrating compressed
air very efficiently, this plant achieves unchanging purity grades.
The IMT-MN is a cost-saving alternative to the traditional supply
by gas-bundles or tank installations.
As an option these plants are available in stainless steel or ATEX
dessign. |
|
Oxygen from the socket.
Oxygen supply without extensive logistics at purity range up to 40 %.
These membrane generators provide a continuous supply in the
capacity range of 150 ltrs./min. up to 2000 ltrs./min. at O2 purity
grades from 30 - 40 %. |
|
Nitrogen generation up to 99,9999 / 6.0 purity with "Pressure Swing Adsorption".
The technology of Pressure Swing Adsorption provides for nitrogen provisioning at purity grades of up to 99,9999 % and capacities
ranging from 0,5 - 2.000 Nm³/h.
Following options are available amongst others:
- pressure booster up to 300 bar
- flow meter
- special voltage design
- pressure dew point indicator
- remote inquiry.
All units of the PN model range are equipped with touch panel
and USB port. |
|
| The Parker Balston NitroSource Lab nitrogen generator can produce up to 500 lpm of pure LC/MS grade nitrogen at pressures up to 10 bar. The generator is engineered to transform standard compressed air into a safe regulated supply of nitrogen with minimal operator attention. Pressure flow rates and purities are specifically designed to match the stringent requirements of all the latest LC/MS instruments. Typical applications include LC/MS, LC/MS/MS, nebuliser gases for APCI and ESI, ELSD, Turbo Vaps and chemical solvent evaporation. The Nitrosource Lab technology has been tried and tested by all the major LC/MS manufactures. |
|
‘Plug and Play’ Nitrogen Generator for LC/MS
The Parker Balston® NitroFlow Lab is a self contained generator that produces up to 32 lpm of pure LC/MS grade nitrogen at pressures up to 8 bar. It produces nitrogen by utilizing a combination of compressors, filtration, and membrane separation technologies. High and low pressure compressors carefully matched to hollow fibre membranes separate the clean air into a concentrated nitrogen stream.
The combination of these technologies produces a continuous on-demand supply of pure nitrogen. Typical applications include LC/MS/MS nebulizer gases for APCI and ESI, ELSD, Turbo Vaps and chemical solvent evaporation. The NitroFlow Lab has been tried and tested by all the major LC/MS manufactures.
The unique combination of the dual compressor generator ensures that the NitroFlow Lab has several unique technical advantages over all other existing LC/MS Nitrogen Generators.
Nitrogen is produced at low pressure and then compressed to 8 bar. This ensures minimal maintenance of the system with no compressed air filter replacements or condensate. The compressor life is guaranteed under the Parker Balston warranty for 8000 continuous running hours, the longest currently available on the market.
Parker Balston is the worldwide leader in separation and filtration technologies, and offers a broad range of analytical gas generators to meet your specific analytical instrument requirements. All products are backed by a fully staffed field sales and service organization.
|
|
Performance: max. 900 ltrs./h
Purity: max. 95 %
Supply pressure: 10 bar
Car tyres: max. 8 pces./h
Dimensions: 900x650x120cm (HxWxD)
Weight: 20 kg
- Industrial filters ensure adequate filtration of compressed air
- minimal compressed air consumption
- Installation operative after connection to compressed air! |
|
Parker Balston® SOURCE LCMS-5000 Series is now available for Applied BioSystems MDS Sciex API-LC/MS users
The Parker Balston® SOURCE-LCMS-5000 is a visually integrated and functionally modular LC/MS gas generation system which produces high purity nitrogen, zero air and exhaust pump gases for all Applied Biosystems – MDS Sciex LC/MS/MS instruments.
It produces nitrogen, zero air and pump exhaust air by utilizing a combination of a compressor with filtration, catalysts and membrane separation technologies. An integrated low-maintenance compressed air supply is filtered by high efficiency coalescing filters removing all contaminants down to 0.01 micron. Hollow fiber membranes subsequently divide the clean air into a concentrated nitrogen stream. The zero air is produced by catalytic oxidation which converts the hydrocarbons. A passive hollow-fiber dehydration membrane is used to create the exhaust pump gas.
The integrated Scroll compressor is ‘whisper’ quite at only 48 dBA and is supplied as standard with a 10,000 hour / 3 year warranty. Low maintenance and reliable this offers the best compressor warranty currently available on the market.
Parker Balston is the worldwide leader in separation and filtration technologies, and offers a broad range of analytical gas generators to meet your specific analytical instrument requirements. All products are backed by a fully staffed field sales and service organization.
|
|
Perfected nitrogen technology for permanent operation.
N2 purity up to 99,5 % using the reliable membrane technology.
Dimensioning range of this generator model line is from
0,10 Nm³/h up to 15,00 Nm³/h.
Advantages for the user:
- constant high quality of N2
- continous nitrogen availability at anytime
- low installation costs
- negligible running costs
- safe and easy operation
- no handling costs as for cylinders or gas bundles
- no handling safety hazard as for cylinders.
Following options are available:
ATEX, stainless steel version, analyser unit. |
|
Nitrogen generation plants designed for multiple industrial applications.
These plants, both standard and industry design are manufactured for capacity ranging from 50 Nm³/h up to 5.000 Nm³/h and ensure large
and continuous volumetric flow rates.
Following options are available:
redundant design, back-up system, operation-hous counter, alert function, booster, stailess steel or ATEX design, container installation mounted. |
|
Membrane technology in the range of nitrogen purity
of up to 99,9 %.
This generator type provides easy handling without specific
training resp. comprehensive operation manual.
When nitrogen consumption is stopped, the unit
automatically switches to stand-by mode.
Maintenance is indeed negligible, just the filter set
needs to be replaced.
Connection and start-up are actually very easy,
just by use of a standard 230V outlet, at rating of
1,5 kW up to 6 kW, depending on the production
capacity.
This model range HN provides N2 purity grades from
98,0 % up to 99,9 %, at capacity from 2,9 Nm³/h up to
103,0 Nm³/h, depending on the required purity grade. |
|
Oxygen PSA range
Oxygen production by use of "Pressure Swing Adsorption"
technology with purity rates up to 99,5 % and capacities
ranging from 0,5 - 2.000 Nm³/h.
Following options are available:
- alert function
- analyser units
- operation-hour counter
- pressure booster up to 300 bar
- touch panel
- SMS message system
- flow meter
- special voltage design. |
|
Wellman Furnaces, Inc. offers a complete line of Exothermic Gas Generators for rich and lean operation. Standard sizes range from 750 SCFH to 30,000 SCFH. Refrigerated Gas Coolers can be provided to reduce the product gas dewpoint to the 40°F to 50°F range. Atmosphere Gas Analysis Panels are available to monitor the exo gas composition and control an optional trim valve in the burner fuel gas line to maintain the desired CO analysis.
Wellman Exothermic Gas and Steam Co-Generators will give you the process atmosphere gas you need and the added benefit of Free Steam. Major savings in both fuel and cooling water can be realized by combining your exothermic gas generator and steam boiler into a single unit. Paybacks range from six months to two years - Returning Your Initial Investment!
Exo Gas and Steam Co-Generators are available in sizes from 4,000 to 100,000 SCFH of exothermic gas, producing 390 to 9,780 lb/hr of steam. |
|
There are three hydrogen generator models in the HG2000 Series, offering outputs of 200 to 600 Nml/min and gas purity ratings in excess of 99.9995%. Thanks to their compact dimensions, these units can easily be positioned near the analysers they feed.
These generators are equipped with a microprocessor control system, a liquid crystal display to inform the operator of generator status in real time, and a membrane keyboard for setting main gas delivery parameters. HG2000 Series hydrogen generators are also equipped with an effective alarm system to warn the operator of any system malfunctions.
|
|
Proton Exchange Membrane Compact
Hydrogen Generators
- High purity (99.999+ %)
- Process pressure
- Minimizes hydrogen inventory
- No caustic electrolytes, asbestos free
- Reliable, compact, automatic control
Production rates: .5 - 1 Nm3/h (19 to 38 scf/h)
Distributed Energy Systems makes Proton Exchange Membrane (PEM) hydrogen generators the new standard for on-site hydrogen production. Related PEM products are already recognized as the technology of choice for automotive fuel cells. HOGEN® hydrogen generators are available for broad commercial use.
|
|
The Peak Scientific Hydrogen Generator delivers high purity gas, with reliability and safety built in to every component.
The 'cylinderfree' systems have many unique features, making them the preferred choice of laboratories requiring reliability and quality.
Using ION exchange membrane technology, originally developed for NASA, the generator required only deionised water (loaded automatically) to produce a constant supply of hydrogen. |
|
TELEDYNE ENERGY SYSTEMS, INC. manufactures hydrogen generation systems designed for on-site, automatically controlled, ultra-pure hydrogen product gas generation. Delivery flows range from 1.1 nm3/hr (20 SLM) up to 56 nm3/hr (1,000 SLM) with 99.9998% purity. The generators also produce oxygen as a byproduct of the water electrolysis process.
The hydrogen generators are fully assembled, skid mounted and operationally tested prior to shipment to facilitate ease of installation and commissioning. System design can also be provided to include compression and storage solutions specific to your application.
TELEDYNE ENERGY SYSTEMS, INC. hydrogen generators are currently used in power plant, chemical plant, semiconductor, argon purification, metals processing, float glass, fiber optic, research laboratory, fuel cell testing, and hydrogen fueling applications throughout the world.
|
|
HGH-300 and HGH-500 Hydrogen Generator
HGH-300 and HGH-500 high purity hydrogen generators are based on the technology of astronautic fuel cells, in which hydrogen is produced by the electrolysis of water, and the produced oxygen is released to the atmosphere. The generator consists of electrolyzing/separating pool, power supply, pressure control, desiccation& purification, flow display, etc. The core part -- electrolyzing & separating pool, uses a tube shaped positive pole and a plate shaped negative pole. Both poles are made of stainless steel. The electrolyzing & separating pools can store electrolyte, produce hydrogen as well as release hydrogen at the same time.
The HGH series hydrogen generators have the advantages of large electrolyzing area, low temperature of the pool, better performance, high productability and high purity of hydrogen. The instrument has specially designed to prevent liquid from backflowing |
|
BENEFITS AND SAVINGS
- H2 production only on demand
- Ultra compact design
- Improved productivity and chromatography results
- Improved safety in the lab
- Extended column life
- Increased efficiency in the laboratory
- No caustic solutions required
- Recommanded by the major analytical instruments company
APPLICATION
Eliminate the high pressure H2 gas cylinders of the laboratory by generating a continuous source of pure H2 gas for the following applications:
- GC-FID, NPD, TCD, ELCD, HALL
- GC-Carrier gas
- THA
OPERATING MODE
These generators use the newest membrane technology for the electrolytic production of pure H2 gas. This technology was preferred over alternative hydrogen generating techniques because it is clean, requires less maintenance and there is no need to store chemicals to maintain operation. Hydrogen is produced by electrolysis of water through a polymer membrane. Only pure water, either distilled or deionised, is required to provide trouble free long term operation. A dessican t cartridge purifies the hydrogen.
Safety features :
The small contained volume(< 50 ml )makes the generator safe for operation in spaces where cylinder hydrogen is restricted. An auto shutt off procedure places the unit in standby in the event of an internal error, and selectable alarms allow the user to be informed whenever operating conditions vary from the set point. |
|
Claind’s nitrogen generators satisfy all laboratory analysis and industrial process needs with very few exceptions.
The range includes compact generators with built-in oil-free compressors, medium and high pressure generators for industrial applications, and special generators for OEM applications.
Claind’s nitrogen generators are based on PSA (Pressure Swing Adsorption) technology for maximum reliability and gas quality. Claind has also patented the Fast Purity system, the most significant innovation in the world of PSA technology in recent years. |
|
Hydrogen generator HG2000
There are three hydrogen generator models in the HG2000 Series, offering outputs of 200 to 600 Nl/min and gas purity ratings in excess of 99.9995%. Thanks to their compact dimensions, these units can easily be positioned near the analysers they feed.
These generators are equipped with a microprocessor control system, a liquid crystal display to inform the operator of generator status in real time, and a membrane keyboard for setting main gas delivery parameters. HG2000 Series hydrogen generators are also equipped with an effective alarm system to warn the operator of any system malfunctions.
|
|
| A full range of laboratory gas generators are available including UHP Hydrogen, Nitrogen, Zero Air and CO2 Free Air. |
|
HOGEN GC hydrogen generators provide ultra-pure (99.9999%) pure hydrogen for a wide variety of laboratory and small scale industrial applications such as:
- Carrier gas for Gas Chromatographs (GCs)
- Fuel gas for flame ionization detectors (FID¹s) used with GCs
- Fuel gas for Trace Hydrocarbon Analyzers
- Hall detector reaction gas
- Plus hydrogen for other precision instruments and chemical research |
|
Claind’s nitrogen generators satisfy all laboratory analysis and industrial process needs with very few exceptions.
The range includes compact generators with built-in oil-free compressors, medium and high pressure generators for industrial applications, and special generators for OEM applications.
Claind’s nitrogen generators are based on PSA (Pressure Swing Adsorption) technology for maximum reliability and gas quality. Claind has also patented the Fast Purity system, the most significant innovation in the world of PSA technology in recent years. |
|
The domnick hunter MAXIGAS range of nitrogen generators has been developed to allow users to produce their own supply of nitrogen gas on-site, without the need for traditional high pressure cylinder or liquefied gas supply.
A domnick hunter Maxigas nitrogen generator can very easily form the basis of a complete central nitrogen supply, furnishing multiple analytical instruments with clean, dry nitrogen.
The MAXIGAS generators produce nitrogen gas from a virtually free resource %u2013 air. Designed to operate from compressed air, the generators deliver a continuous, uninterrupted supply of nitrogen gas at purity from 97%-99.999%.
The MAXIGAS systems offer the safest, most convenient and economic source of nitrogen available. The compact, modular design allows easy upgrading of the system as production capacity expands.
At 10 ppm oxygen content flow rates vary from 1.3 Nm3/hr to 6.5 Nm3/hr. At 1% the corresponding flow rates available are 11.8 Nm3/hr %u2013 59.1 Nm3/hr.
|
|
KOFLOC Nitrogen Gas Generator MNT SERIES (2.5NL/min-20NL/min)
KOFLOC Nitrogen Gas Generator MNT SERIES is a small, low-cost nitrogen generator with a small compressor, allowing it to be used anywhere with just a 100 VAC power supply. The adsorbent (molecular sieving carbon selectively adsorb a large amounts of oxygen under high-pressure condition, quickly removing oxygen carbon dioxide and moisture out of air, leaving only the high purity nitrogen gas as the final product. The adsorbent material releases oxygen when depressurized. High-purity nitrogen gas can be produced continuously by PSA (pressure swing absorption), which is a method of alternately pressurizing 2 adsorption vessels.
FEATURES
♦ Fully automatic
♦ Compact
♦ 100 VAC power supply
♦ High-purity and dry (–55˚C or less) nitrogen gas can be obtained
♦ Aluminum pressure vessels
♦ Quiet operation
♦ Quick startup
♦ High purity (99.999%) is also available
APPLICATIONS
* Substitution for nitrogen gas cylinders
* For heat treatment processes
* Semiconductor processes
* CA storage gas for fruits and vegetables
* Non-oxidization seal gas
* Explosion-proof or rust-prevention gas
* Seal gas for shipping
* Blanket gas for synthetic fibers and melted spinning |
|
The NM20Z is a self contained Gas Station designed specifically for the API Analyser Range. It is a plug and play system, fully tried and tested. You will be operational in minutes and running analysis without interruption.
Features & Benefits
Three gas lines from one system
No more cylinders, regulators, re-ordering or safety issues
Quiet operation
Simple to install to any analyzer
No electrical requirements
Wall mountable
24 hour operation |
|
A-300/500 Combined Nitrogen and Air Generator
Model GTL-300 (500) combined with nitrogen, hydrogen and air generators is the latest generation product developed and designed for the requirements of the market. It is with the latest technology and offer the best working conditions for the users.
Fast gas generation, High purity gas;
Compact, small in size, and portable;
Multi-stage protective devices are installed, ensuring safety and reliable operation and low noise; |
|
|
