One idea, and numerous possibilities:
The individual components of Expresso's modular system are the basis for specific, application-oriented solutions that meet your special demands. It only depends on what must be transported.
Another advantage of the modular approach: should a worn part have to be replaced, no problem; every component is also available as a spare part. In this way, Expresso transport equipment is always kept in top condition, and its useful life is multiplied several times.
|
|
|
Tubular steel, welded and powder coated, surface durably protected, resistant to impact and scratches. Wheels optionally with solid-rubber or pneumatic tyres. Hubs with roller bearings. Topline trolleys = Especially robust and easy to use. Top quality materials and first class workmanship guarantee the best possible handling and durability.
|
|
| ... products without technical information |
| |
MODEL: ECO I-25
Load Capacity: Kg 2500
Overall Length: mm 1508 / 1538 / 1608
Fork Length : mm 1120 / 1150 / 1220
Width over Fork: mm 520 / 685
Lowered Height: mm 85
Raised Height: mm 200
Wheel Type(s): Poly (std) / Nylon / Steel / Rubber
Weight: Kg 82
OPTIONS: Tandem Rollers
Automotive brake attachment
Low Profile Trucks
4-Way,
Corrosion Resistent trucks
Spark Resistent trucks
Weigh-Scale trucks ,
Straddle & Roll trucks,
Stainless Steel trucks
Galvanised trucks
Quick-Lift Version
KEY FEATURES:
Heavy duty reinforced frame
3-position control handle
Hand & foot lowering controls
Adjustable push rods
Exit / Entry helper rollers
Articulating Axle
|
|
MODEL: ESET10 (Self-Propelled / Manual Pump Operation)
Capacity: 1000 kg
Max. Fork Height: 205mm
Fork Length: 1100 / 1150 / 1220
Fork Width: 520 / 550 / 685
Battery: 24 Volt (4 Batteries)
Charger: 12V / 10A
Turning Radius: 1574 / 1624 / 1694mm
Travel Speed (with Load): 2.6 - 3.8 km/h
Net Weight: 143 - 156 kg
|
|
MODEL: EMSL10
MANUAL PUSH - MANUAL LIFT SCISSOR LIFT
Capacity: Kg 1000
Raised Height: mm 800
Lowered Height: mm 85
Fork Length : mm 1150
Fork Width: mm 550 / 685
Ind. Fork Width: mm 160
Steer Wheels : mm 180 dia. Polyurethane
Load Rollers: mm 74mm dia. Polyurethane
3-Position Control Handle (Raise-Neutral-Lower)
Weight: kg 100 kg
|
|
Type: PM20G
Special: Galvanized
capacity: 2000 kg
Forks: 1150 x 540 mm
Steering wheels: Nylon
Single/Tandem: Tandem
Fork wheels: Nylon
|
|
Type: PM20S
Special: Stainless steel
Capacity: 2000 kg
Forks: 1150 x 540 mm
Steering wheels: Nylon
Single/Tandem: Tandem
Fork wheels: Nylon
|
|
Toyota's Rugged Yet Lightweight Hand Pallet Truck, Designed to Meet and Exceed the Demands of your Toughest Workplace Environments.
- 5,000 lbs.
|
|
Pallet trucks, 2500 kg
Frames and forks of steel construction, finished powder coated distinct Yellow. Hand hydraulic pump with service-free bearing. Low maintenance. Strong steel handle with counter bearing for pushing operation. Powder coated black operating lever for lifting, moving, lowering. Steering wheels 200 x 50 mm. Fork rollers 80 x 70 mm. Locating wheels at fork tips. Wheels 2115: Steering nylon, fork rollers tandem nylon. Very little rolling resistance.
Capacity: 2500 kg
Fork length: 1150 mm
Carrying width: 530 mm
Total length: 1540 mm
Steering lock: 2 x 100 °
Fork width: 160 mm
Lifting range: 85-200 mm
Guarantee: 2 years
|
|
MODEL: ECO I-25-SS
Capacity: 2000 kg
Overall Fork Width: 520 / 540 mm
Fork Length: 1150mm
Individual Fork Width: 165mm
Raised Height: 190mm
Lowered Height: 75mm
Steer Wheel: 180 dia. NYLON
Load Roller: 74mm dia. NYLON
Weight: 80 kg
FEATURES:
All Parts stainless Steel including hydraulic Pump, forks, frame, handle, push rods, Bearings, Pins, Bolts.
Fully sealed hydraulic coated pump
Three position handle-Lift-Neutral-Lower
Tandem Nylon Load Rollers & steer wheels
|
|
Electric and Manual Walkies
5.000lb Capacity Hand pallet Truck
Model Multiple
Type Hand Pallet Truck
Power voltage N/A
Capacity (lb) 5000
Top speed (mph) N/Q
|
|
Hand Pallet Trucks Quality, strength and reliability for a long, economical service life. BT hand trucks have set the industry standard for over 60 years, and remain the benchmark for the industry. Since developing the first lightweight hand pallet truck in 1947, BT has built over two and a half million of them.
The BT Lifter has been proven worldwide as the universal hand pallet truck, suitable for moving loads in all types of application. A highly automated production system maintains consistently high quality levels, and a powder paint finishing process ensures a superb, durable finish. A long life is assured through built-in serviceability. At least ten grease nipples are fitted to every truck to allow easy lubrication of moving parts.
The innovative Pro Lifter models offer the most significant technical innovations in hand pallet truck design. Ease-of-use reaches new levels with up to 67% less effort required to move the load in the manual version, which features BT Pro Start Technology; or totally effort-free travel with the electric Pro Lifter M model. The standard BT Lifter has a lift capacity of 2300 kilograms The BT Quick Lifter can lift loads under 1500 kilograms in just two strokes of the handle.
The BT Heavy Lifter, with its lift capacity of three tonnes, can handle the heaviest loads The BT Stainless Lifter is intended for corrosive environments and applications that demand a high standard of hygiene. Its structure is high-grade stainless steel – long lasting and easy to clean High Lifter models offer hand-truck versatility with the extra feature of a lift height of over 800 millimetres. The electric lift model is the ideal ergonomic workstation. BT hand pallet trucks;build to last under the heavy conditions in warehousing and logistics. Check our Life Time Garantee offer.
|
|
For a durable, economical hand pallet truck, nobody beats Presto. Our HPT Trucks are loaded with features that most more expensive models can't claim.
Features:
- 5500 lb capacity
- Powder coated paint finish
- Solid steel formed forks and chassis with reinforced frame and gusset
- Highest quality pump with special lowering valves and an overload by-pass
- Steer wheels 7" x 2", load wheels 2 7/8" x 3 1/2"
- Nylon steer wheels and load wheels
- All pivot points come with sealed bearings
- 9 strokes to full raised height
- Fork tip roller system for smooth transition in and out of pallets
- Articulating steer axle
- Ergonomic cushioned handle with 3 function trigger for raise, lower and neutral operation
- Polyurethane wheels available
|
|
Over 75 years ago, Raymond invented the industry's first hydraulic hand truck. That same spirit of innovation can be seen today. Raymond hand pallet trucks are designed to meet the demands of a fast-paced material handling industry.
Simplicity; rugged construction, smooth handling and exceptional maneuverability are hallmarks of our hand pallet trucks.
The logical choice for use every day, throughout your operation
Raymond hand pallet trucks include low-profile configurations, for pallet clearances as low as 2.9”. A host of options and accessories enable you to customize your truck's capabilities to meet your specific needs.
Heavy-duty construction stands up to the toughest applications, year after year
Simple, easy-to-access design and fewer parts allow quick, easy servicing. Ergonomic features, including convenient fingertip controls, enhance operator comfort and productivity
A full 180-degree turning radius makes navigation easy, even in tight quarters
5,000 Capacity
|
|
|
Pallet trucks are as diverse as the tasks they are required to fulfill, as compact as requirements dictate and as efficient and long-lasting as you could possibly desire. Moreover, they are ideally suitable for heavy loads of up to 5 tons. All of the pallet truck models are available in customized versions as well so that they can be perfectly tailored to your specific operating environment and amount of use.
|
|
Robust and especially designed for the transport of various loads the Linde hand pallet truck performs its task as an all-round reliable helper in innumerable warehouses and production places.
|
|
* HP Series :
- 3 years warranyty pump: a built in overload valve and totally sealed hydraulic pump.
- German seal kit offers long span life of pump for 3 years warranty .
- Heavy duty and reinforced forks for greatest strength and durability.
- 2 nylon entry and exit rollers prevent physical exertion of the operator and protect load rollers and pallet.
- Oiless bushings at key points offer you less operating force and longer span life of pallet truck.
* SP Series :
Durable Hydraulic pump
- With latest European Technology, SWELIFT self- contained unit provides premium-qualifty hydraulic ,seal kits are made in Germany.
Centeral Fingertip Controls
- Three-position control lever provides fingertip control of all hydraulic system functions with the handle in any position.
- Neutral position frees handle of hydraulic functions.
Fork Frame
- Rugged construction with heavy gauge steel and sturdy continuous welds throughout, SWELIFT fork frame can load 3000kg.
|
|
5,000 lb Capacity Hand Pallet Truck
Every-day-doers. Hand pallet trucks are especially handy for miscellaneous material handling requests. These manual walkies have a capacity of up to 5,500 lbs and are often used to move palletized loads over short distances (less than 100 feet). The hydraulic trucks are equipped with a reinforced, ergonomic handle, making it an easy task to move heavy loads.
|
|
The hand pallet trucks AM 3000 is the ideal solution for all manual transport tasks over short distances. It is a universally suitable truck with its extraordinarily high capacity - for very heavy loads as well as for loads that exceed the usual dimensions. Its advantages are detailed here:
* Comfortable and easy to handle operating element for both left-handed and right-handed operators. Manoeuvring with one hand on the tiller head is possible and both comfortable and safe.
* Fast lift (up to 120 kg) with supplied as standard for off the floor lifting and lowering of pallets in only three pump strokes.
* Excellent manoeuvrability even in most confined spaces through slim front length.
|
|
Lifter GS 25S4 950x525
Main features
Nominal load capacity : 2500 kg
Frame material : Painted steel
Fork length : 950 mm
Fork width : 150 mm
Stowage passage : 1632 mm
Turning radius : 1167 mm
GS PRO Series
The GS Pro Series, is an excellent tool for lifting and carrying loads on pallets or size-standardised containers. Thanks to its light weight, smooth movement and manoeuvrability, all the GS Series models are an ideal working tool for use on smooth floors and other kinds of surfaces.
|
|
