These devices are entirely built in stainless steel AISI 304 and have been planned to contain at the same time the material which must be sent to the different utilizing points through a pneumatic suction conveying system. They have different geometric shapes in their outlets because of the different types of materials to allow the flow without the use of any mechanical stirrer. At the starting point of the conveying line there are the mixing valves air-product and of pipes cleaning.
|
|
Universal unit for automatic feeding of extruders, processing machines, hoppers and storage silos. Handles powders, pellets or granulated/flaked products with some powder content.
Large filter surface area specifically designed for powdery products.
Use as stand-alone unit or integrate into complete feeding systems.
Design characteristics
- high efficiency hose filter with reverse-jet cleaning
- filter plate/filters removed in one piece for easy product changes
- product-contacted parts of stainless steel/aluminium
- electro-pneumatically operated conical discharge valve
- level indicator installed in discharge flange
- easy access for servicing the filter elements
- pre-piped and pre-wired ready for operation
- electronic control system
- large filter surface area
- large outlet diameter
- temperature range -10 to +80°C
|
|
MANN+HUMMEL®
- Fördergeräte Baureihe FG 400
Modulare und kompakte Bauweise
Fördergutbehälter aus Aluminium-Gußlegierung oder nicht rostendem Stahl
Mit separater Gebläsestation
Abreinigung des Förderluftfilters mit Gebläse-Abluft, vor oder nach dem Fördern
Auf dem Gebläse oder auf der Förderstation angeordnetes Wechselventil
Bedienerfreundliche Mikroprozessor-Steuerung
Programmierbare Steuerungsfunktionen für:
- Fördern
- Abreinigen
- Dosieren
- Leersaugen
- Gebläse-Ausschaltverzögerung
Anzeige des aktuellen Betriebszustandes mittels LEDs
Beendigung des Fördervorganges über Zeit oder Füllstandmelder
Geräuscharmer Betrieb
Optionen:
- Füllstandmelder
- Störungsmelder
- separate Steuerung
- Zentralfilter
|
|
|
|
