ODU MAC:
- Modular Attachable Connector System
- extreme high number of mating cycles (>100.000)
- Signal, Power, high frequence, fiber optic, pneumatic fluid,
BUS modules can be mounted into the ODU MAC connector
- Alu-Frame and DIN-housing
- Locking with lever or spindle
- High contact density
- Versatility
- Easy handling with the locking spindle
- Modification of the catalogue version possible
ODU MAC LC (Low cycle) - the economic solution:
- Up to 5,000 mating cycles
- 4 frame sizes (12/18/26/37 units)
- Diverse contact inserts (modules) for signals, power and high
frequency are available
- Centering and keying using the proven ODU guide system
- Easy assembly and removal of the contacts using clip technology
- Simple, quick packaging and module assembly in the frame
- Frame can be mounted in standard DIN housing
with spindle- and lever locking
- Economical and proven ODU contact technology -
turned/slit contacts
|
|
The Han-Modular® series is designed for combining different transmission media and different contact types in a single connector.
It permits any combination of power contacts, signal contacts, fibre optic contacts, coax contacts, D-Sub contacts and pneumatic contacts.
The individual modules are mounted in Han A® (for one module) or Han® B housings using hinged frames. Depending on module size, up to 6 modules can be combined in a single hinged frame.
|
|
|
Mixing several functionalities into the same connector body, the Hybrid line offers highly appreciated versatility in solving today’s complex interconnection requirements and contributes to the design of compact equipments.
|
|
EPIC® MC Module: High Current 1+PE
Mixed assembly guarantees a high flexibility.
Application range
Plant engineering and construction
Control technology
Technical Data
Rated voltage in V
1000 V
Rated current in A
82 A
Contact resistance
< 2 mΩ
Contacts
Copper alloy, hard silver plated
Number of contacts
1 + PE
Termination methods
Screw connection: 10.0 - 25.0 mm²
Cycle of mechanical operation
100
Range of temperature
-40°C - +100°C, temporary up to +125°C
VDE tested
VDE-REG.-No. 870
Pollution degree
3
|
|
|
|
