EE14 Series
Hygrostat for Duct and Wall Mounting
The EE14 hygrostat is based on the well proved E E humidity sensors of the HC series, which guarantee excellent long term stability, low hysteresis and high resistance to pollutants.
The switching threshold is freely adjustable in the range of 10...95% RH with a hysteresis which can be set independently between 3% and 15% RH.
The EE14 hygrostat is available for wall or duct mounting.
EE45 Series
Condensation Monitor for Chilled Ceilings, HVAC, ...
EE45 condensation monitors are used to monitor the formation of condensation on chilled ceilings and to prevent condensation at critical spots of heating-, ventilation- and air conditioning systems. It is also used as a dewpoint monitor for systems operating near the dewpoint.
Because of the temperature coupling between the condensation monitor and the environment, the relative humidity is a measure for the dew-point.
|
|
-Adjustable relative humidity
-Change-over contact
-High switching capacity
-Easily accessible terminals
-Clip fixing
The electromechanical thermostat MRF 012 is designed to control enclosure heaters so that the dew point is raised when a critical relative humidity of 65% is exceeded.
In this way condensation and corrosion is effectively prevented.
Approvals: UL File No. E164102
|
|
-Temperature and humidity adjustable
-Optical operating display (LED)
-High switching capacity
-Clip fixing
The electronic hygrotherm senses the ambient temperature and relative humidity in anenclosure with electric/electronic components, and turns on a heater (or alternatively, a fan) at either set point, helping prevent the formation of condensation in the enclosure.
The LED integrated in the adjustment knob on the active controller is lit when theconnected device is in operation.
Approvals: VDE + UL File No. E164102
|
|
The hygrostats HG with Polyga® measuring element are used as on-off controllers to control and monitor air humidity and related automation components (humidifiers, dehumidifiers etc.). With their robust and long-term stable Polyga® measuring element the HGs of Galltec+Mela are the ideal partners for humidity control, working on and on and on...
Available as duct version HG80, room versions HG120 and HGMini and OEM versions HM80 and HM120.
|
|
-Temperature and humidity adjustable
-Optical operating display (LED)
-High switching capacity
-Clip fixing
The electronic hygrotherm senses the ambient temperature and relative humidity in anenclosure with electric/electronic components, and turns on a heater (or alternatively, a fan) at either set point, helping prevent the formation of condensation in the enclosure.
The LED integrated in the adjustment knob on the active controller is lit when theconnected device is in operation.
Approvals: VDE + UL File No. E164102
|
|
|
|
