EAO, the Expert for Human Machine Interfaces, is now offering a switch with multicoloured “Halo” illumination for creating highly flexible displays. Designed for use with SMD LEDs, up to 10 different colours can be combined
in one switch: eight within the outer ring and an additional bi-colour LED in the centre. For designers and developers, this opens up new and previously unimagined possibilities.
Key characteristics:
Segmented illumination of the outer halo ring (actuator)
Up to 8 SMD LEDs can be positioned on the PCB
Additional bi-colour LED can be used with the switch element
Flat or raised plastic or aluminum lenses
Assembly:
The transparent actuator is mounted on the PCB by means of a newly developed flange with snap-on connector. The switch mounts into a 22.5 mm dia. mounting hole.
Typical applications:
The Series 84 can be utilised for a variety of applications:
Ticket machines
Instruments and medical devices
Machine and process controls
Audio, video, general lighting and stagecraft
|
|
Pushbuttons are switching devices which close and open electrical circuits. Actuators and contact chambers of pushbuttons are always integrated into one product (as opposed to control units). The "LUMOTAST" product families also include signal lamps, keylock and selector switches which are compatible with the pushbuttons in design and technology.
Illuminated pushbuttons, 8 mm range, mounting hole diameter 8 mm
LUMOTAST illuminated pushbutton range, mounting hole diameter 16,2 mm
LUMOTAST FK, with flat-ribbon cable connector
LUMOTAST 25, actuating area 25 x 25 mm
LUMOTAST 75, for up to 250V /4 A
Keylock switch, mounting hole diameter 16,2 mm
Other pushbuttons, mounting hole diameter 9,1 mm - 20,3 mm
|
|
|
Piezo switch with ring illumination in various colors, IP68 waterproof rated, metal aluminum housing or STS, 50 million cycles. These push buttons are ideally for outdoor use and heavy traffic areas.
|
|
General Purpose Illuminated Pushbutton Switches
Eaton offers a wide range of pushbutton switches for standard industry applications such as appliances, electronics, medical and test instrumentation, office equipment and many other commercial applications. A variety of options are available such as illuminated and non-illuminated versions, colored lens caps, lamp styles, and mounting styles.
Each pushbutton series offers a matching indicator for a consistent look. See the reference table below to quickly identify the required product. Then, refer to the selection table to determine the catalog number.
095 Series
Options:
T-1 lamps.
Special dead front and sunlight readable lenses legends.
Split legend lenses.
Military Snap-Switch, MS 8805.
|
|
The GE Push Button offering includes a complete line of pilot devices and stations for industrial and commecrial applications. They are available in 30mm and in 22mm sizes.
They are available in 30mm and in 22mm sizes.
The C-2000TM 22mm push button line has interchangeable components that snap together, simplifying assembly, reducing inventory requirements, and increasing flexibility.
Features and Benefits
Ultrasonically welded contact block - provide superior environmental protection.
Double bridge contacts - provide excellent performance even in low-voltage applications.
Permanently bonded front gasket-provide superior sealing against contaminants and makes installation foolproof.
|
|
FP01 (Contactless)
Illuminated Pushbutton Switches
GB (ultra-mini)
Fully Illuminated Plunger
HB (sub-mini)
Illuminated Pushbutton Switches
HB2 (sub-mini)
Illuminated Pushbutton Switches
KB (miniature)
Illuminated Pushbutton Switches
KP (miniature)
Silent Pushbutton Switches
LB (standard)
Illuminated Standard Size Pushbutton Switches
LP01 (miniature)
Illuminated Short Body Pushbutton Switches
UB (miniature)
Illuminated Single Element Pushbutton Switches
UB2 (miniature)
Illuminated Multi-Element Pushbutton Switches
YB (miniature)
Illuminated Bushing & Snap-in Switches
|
|
