The ceiling mount group of detectors are applied in presence detection and energy saving applications. Again the motion detection principle is applied, here very small movements will be detected. PerkinElmer offers suited detectors with special
|
|
An presence detector is always comprised of one transmitter and at least two receiver chips with high quality optical systems. These are mounted on the sensor's PCB (modular system) or integrated into a pre-assembled housing (individual sensors). The scanning range is set by means of a mechanical micro-speed unit by changing the angle between the transmitter and receiver. This optical procedure is called triangulation or optical differential measurement. Several beams can be combined in the modular system to form lines.
Presence detectors are ideal for edge and pinch protection on revolving and sliding doors and as ride-along anti-collision protection on swing doors. They can also be used for small areas such as kitchen and service areas of restaurants and hotels or as a person counter in shopping centers.
|
|
|
The SX-360 Series ceiling-mount detector, with its unique zoom function and highly dense, triple-element detection pattern, provides unsurpassed detection performance at any ceiling height up to 5 metres. By simply twisting the units domed lens, the detection pattern can be easily adjusted at any installation height, making it one of the most flexible ceiling detectors on the market. This, combined with its compact design, makes the SX-360 suitable for a variety of applications - large or small, residential or commercial.
|
|
Sensors using socalled "combined technology" have two or more different technologies combined in one unit. With this combination the disadvantages of each individual technology can be compensated and at the same time their strengths are conjoined for the applications' ideal performance.
Combined technologies are used for the combined activation and safety at automatic doors. Besides, these sensors offer plenty of auxiliary functions which contribute to a substantial enhancement of the comfort around the door.
|
|
CX-502AM is the world's first Multi Anti-Masking Technology to prevent any kind of detecting disturbances by applying and developing various forms of anti-masking optical technology.
Other models:
CX-502: standard model with no anti-masking function
CX-502V: CX-502 with alarm memory
|
|
With long, narrow detection areas that extend from both its sides the BX-80N is specifically designed to be wall-mounted centrally on a building, covering the building perimeter with a multi-layered, horizontal barrier that detects intruders before they break in. To help reduce false activations, the range can be adjusted so that detection extends only to the end of the building. The unit also has a size-judging function, which helps it discriminate between large and small objects within the detection area.
The BX-80N is stylishly designed to blend in with any architecture and is simple to install and set up - there being no need to align transmitters and receivers.
|
|
The DM25IR passive infra-red movement detector has been designed to control the opening of pedestrian automatic doors. It detects the movement on surfaces of 1 to 4 m2 with the possibility of adjusting the vertical position of the detector and the sensitivity with a trimmer. The angle of the detector can be adjusted and the lens can be masked
internal use
detection area from 1 to 4 m2
max height of installation 2.5 m
|
|
LONG RANGE PIR DETECTOR WITH SELECTABLE DETECTION PATTERN
The CX-702 is designed to give extremely stable long-range detection performance in a variety of internal commercial and industrial applications. With patented Multi-Focus Technology, sensitivity is maintained through the entire coverage area, even in high temperature areas or in applications with low temperature contrast. Combined with Double Conductive Shielding and Temperature Compensation, a high level of false alarm protection is guaranteed.
- Selectable detection pattern with dual purpose optics
wide-angle: 21m x 21m 85°wide coverage
long-range: 45m x 2.4m
- Mounting height from 1.5 m to 3.6m
- Patented multi-focus optics & double conductive shielding
- Temperature compensation
- Sealed optics
|
|
HIGH MOUNT OUTDOOR PIR DETECTOR
• 12m 85°wide coverage
• Mounting height 2.5m - 3m
• Multiple pattern detection area technology with “Brand-New” pyro-element
• Intelligent AND logic
• Dual signal processing circuit
– Summer night compensation logic
– Advanced temperature compensation logic
• Vegetation sway analysis logic
• Patented double conductive shielding
• Ideal detection area setting
– adjustable detection length
– spot area flexible masking
• 180° angle adjustable bracket / hood
|
|
OUTDOOR PIR DETECTOR
The VX-402 provides an innovative solution to external area detection. It employs a highly reliable dual detection technique, which prevents false activations caused by small animals and birds. Two discrete detection areas are created and only when an intruder is detected inside both areas is an alarm output triggered. Double Conductive Shielding ensures that the sensor is resistant to interference from foreign light sources such as the sun and car headlights.
- 12m 90°wide coverage
- Mounting height from 0.8 m to 1.2m
- Limited detection range function with size judging function
- Patented double conductive shielding
- Sensitivity selection switch
- Temperature compensation
|
|
Optex improves its patented “Multifocus Optics” technology to create “Quad Zone Logic” for accurate detection of humans. Using this logic the RX-40Qzhas been designed to give extremely high false alarm protection with tolerance to spot temperature changes from curtains or small animals.
Optex’s Optical Quad Technology uses taller detection zones divided into upper and Lower areas. It detects IR energy changes in both areas and then couples them for extremely accurate detection, offering very high reliability in hostile areas.
|
|
VX-402REC provides great flexibility in detector-activated voice applications. As well as the ability to record any mesage in any language, with its superior playback settings, it allows the right message to be played in every situation.
Other models :
VX-402 : standared model with no voice recording & warning function
VX-402R : battery operated model with no voice recording & warning function
|
|
|
|
|
|
|
SPIDER is the new series of outdoor infrared detectors created from AVS Electronics, in order to realize the protection of external areas in a flexible and effective way. SPIDER range becomes the ideal partner for the protection of areas as industrial sites, parking places, terraces, garden, portico, scaffolds, doors and other outdoor or indoor areas. SPIDER is microprocessor based. Electronic circuits are protected with a drip-proof resin and housed in a special plastic box, to ensure good resistance to environmental conditions. The optical section is based on a professional mirror technology, to guarantee high quality and detection stability. Trough a mechanical solution it is possible an easy and practical adjustment of the pattern on 180 °. A particular circuit controlled by the microprocessor is stabilizing the temperature changing, giving always the best detection sensitivity and a consequent optimal and constant protection. SPIDER can be installed on wall surfaces or on pole (additional brackets KIT SP). Walk test and alignment (only for Spider Active) is easy with the Buzzer and LED help function.
|
|
|
|
|
|
A perfect alarm system installation must be able to rely on the precision and reliability of the detectors that have been installed to protect the zones. For this reason, Tecnoalarm has developped a complete range of detectors permitting a more efficient and customized coverage of every zone in every environmental condition.
Infact, there are infrared, microwave and dual technology detectors, both wired and wireless, with or without antimasking control and with different lenses.
The detectors equipped with the technology of Remote Digital Verification (RDV®), an exclusive technology by Tecnoalarm, stand out against the others as they permit the remote verification of the presence of intruders in the protected area.
For the protection of outdoor spaces, Tecnoalarm has developped the infrared barriers DOORBEAM/S and WINBEAM/S, mounted next to the doors or windows and available in several colours and lengths, as well as the microwave barriers EXPLORER II and MINIEXPLORER, apt to cover perimeters and large open spaces such as gardens, parks or courtyards.
|
|
|
This infrared barrier is ideal for all situations being protected against and immune to all envoirmental conditions; it is also equiped with thermostatically controlled heaters so that it can be used in extreem weather conditions. Sandor model, thanks to its unique system whereby each transmitter is "seen" by each receiver produces a intricate web giving a high security beam with an extremely high level of detection and efficiency. Specifically designed to reduce false alarms, the beam towers give diffentiated alarm responses; one broken beam will give a delayed alarm whereas two or more beams interrupted at the same time will give an immediate alarm.
|
|
|
|
|
|
The FSLIMPRO active infra-red barrier has been designed and built to guarantee a fast and easy installation. The electronics incorporated in the profi le with optic synchronism, reduce the amount of connection cable laying to the minimum: power supply and alarm contact.
The available in profi les from 0.5m to 3m the FSLIMPRO may be adapted to suit specifi c applications. The type of the profi le and the special shape of the caps ensure a sealed fi xing for external use. The beams can be positioned at the desired height inside the FSLIMPRO to personalise the protection level.
FSLIMRF is a battery powered active infra-red barrier for the protection of balconies, doors, and windows which will transmit alarm transmission via radio for a completely wireless installation. The barrier is made up of two aluminium the infra-red transmitter and receiver, within the dark polycarbonate covers. The basic unit consists of a master card to make up a two-beam barrier to which may be expanded to include additional FSLIMPLUS expansion beams can be added up to a maximum of 8.
The additional beams can be freely positioned inside the profi le, allowing the installer to adjust the beams to suit any installation or application. Profi les are available in variuos sizes from 0.5m to 3m, to allow adapted to suit specifi c needs. The type of the profi le and the special shape of the caps ensure a sealed fi xing and allow it to be mounted wall-fl ush externally
|
|
|
|
|
|
SORHEA uses its technological expertise in the field of infrared barriers and microwaves to develop some costumized products:
For external climatic conditions such as high humidity, low or high temperatures, etc.
For special applications: intrinsically-safe housings can be adapted upon specific request (alarm managment, alarm location and number of beams, column size, attachment systems, etc.)
SORHEA Research and Development department analyzes the special needs in compliance with version 2000 of the ISO9001 standards.
MAXIRIS 2000 double stack: MAXIRIS 2000 infrared barriers can be mounted in double width housings so that a column can contain twice as many IR cells.
Tropicalized MAXIRIS 2000 Desert type or Seaside versions: This barrier was specially conceived for tropical countries. It housing double stack adapted to the warm countries.
They are equipped with dust filters and with an additional thermostat-controlled heater integrated for protection angainst humidity and low temperatures (night). MAXIRIS 2000 Desert type integrates a thermostat-controlled ventillation for protection against high temperatures (day) and sand filters.
|
|
|
|
|
|
MAXIRIS III, 3rd GENERATION INFRARED BARRIER
Expert experience and Technology at your service. SORHEA has developed a new aesthetically pleasing and robust design for the MAXIRIS III Columns.
With a self-supporting column that is fixed to a floor socket it is possible to have a single or double-faced column. This unique system inceases the number of possible configurations in direction and in number of beams (up to 18).
The MAXIRIS III design is especially pleasing thanks to a complete top to bottom Housing to cover all screws and cables.
Identification card:
- Zoning option (according to the configuration): up to 3 zones per barrier, size of the zones is configurable.
- Celles more performing in poor visibility conditions.
- Beams multiplexed and synchronised.
- Integrated alignment assistance.
- Memory storage: 200 events.
- Alarm configurable for the cutting of 1, 2 ou 3 beams.
- Configuration of the columns: local or at distance.
- Relay contacts on ervery column.
The modularity and flexibility in the use of the MAXIRIS III infrared columns allows them to be installed on the majority of sites:
- Military facilities
- Nuclear power plants
- Prisons
- Logistic sites
- Public places (underground, airports...)
- etc.
|
|
|
|
|
|
With D.I.S. technology(*) 100Hz (Double Interlaced Scanning 100Hz), each cell integrates the dual functions of transmitter and receiver. The infrared beams that are created are multiplexed and synchronized at a frequency of 100Hz.
Thanks to this technology, all columns are identical. The idea of separate transmission and reception modules has been surpassed.
The D.I.S.(*) TECHNOLOGY 100HZ IS INNOVATION THAT SORHEA HAS DEVELOPED IN THE QUEST FOR RELIABILITY ! * Patent pending - No. 06 02310
Dual digital AGC enables compensation for variations in the incoming signal to ensure uninterrupted operation of the barrier. This digital processing of the signal is performed based on a time curve that differentiates exterior phenomena (meteorological or others) from intrusion attempts and thereby significantly reduces the number of false alarms.
COLIRIS II has output switches for each column.
This feature permits maximum limitation of wiring constraints.
You choose, with respect to your needs and constraints, where to wire alarm switches, at one end or the other of the infrared barrier.
There are multiple possibilities for wiring and output switches !
|
|
|
|
|
|
A perfect alarm system installation must be able to rely on the precision and reliability of the detectors that have been installed to protect the zones. For this reason, Tecnoalarm has developped a complete range of detectors permitting a more efficient and customized coverage of every zone in every environmental condition.
Infact, there are infrared, microwave and dual technology detectors, both wired and wireless, with or without antimasking control and with different lenses.
The detectors equipped with the technology of Remote Digital Verification (RDV®), an exclusive technology by Tecnoalarm, stand out against the others as they permit the remote verification of the presence of intruders in the protected area.
For the protection of outdoor spaces, Tecnoalarm has developped the infrared barriers DOORBEAM/S and WINBEAM/S, mounted next to the doors or windows and available in several colours and lengths, as well as the microwave barriers EXPLORER II and MINIEXPLORER, apt to cover perimeters and large open spaces such as gardens, parks or courtyards.
|
|
| ... products without technical information |
| |
|
|
|
|
With D.I.S. technology(*) 100Hz (Double Interlaced Scanning 100Hz), each cell integrates the dual functions of transmitter and receiver. The infrared beams that are created are multiplexed and synchronized at a frequency of 100Hz.
Thanks to this technology, all columns are identical. The idea of separate transmission and reception modules has been surpassed.
The D.I.S.(*) TECHNOLOGY 100HZ IS INNOVATION THAT SORHEA HAS DEVELOPED IN THE QUEST FOR RELIABILITY ! * Patent pending - No. 06 02310
Dual digital AGC enables compensation for variations in the incoming signal to ensure uninterrupted operation of the barrier. This digital processing of the signal is performed based on a time curve that differentiates exterior phenomena (meteorological or others) from intrusion attempts and thereby significantly reduces the number of false alarms.
COLIRIS II has output switches for each column.
This feature permits maximum limitation of wiring constraints.
You choose, with respect to your needs and constraints, where to wire alarm switches, at one end or the other of the infrared barrier.
There are multiple possibilities for wiring and output switches !
|
|
APIRIS is the only triple-technology barrier to combine an infrared barrier with synchronized and multiplexed beams, a microwave barrier and a microwave doppler sensor.
The alarm is triggered when an intrusion is detected by the infrared and by one of the two microwave technologies
APIRIS is an outdoor anti-intrusion system designed for the protection of sensitive sites such as prisons or military sites.
Main APIRIS features:
- 4 to 7 infrared beams spread over the whole column’s height
- Double direction column
- In case of a low visibility, one or more IR beams can be disqualified
- Barrier connection with RS485 Network
- History of the last 100 events
|
|
|
|
|
|
MAXIRIS 2000 is the highest performing product on the market, creating a veritable invisible and impassable wall. Indeed, it is possible to raise the barrier up to a height of 5 meters and to choose up to 16 beams (depending on the model).
Each column can be configured with respect to the location of the site and configured in order to carry out maintenance.
Networking MAXIRIS 2000 columns opens the way to tele-maintenance and video confirmation using the MAXIMAJ system.
SORHEA also offers the WINMAXI application, which allows real-time visualization of the status of each unit, including the cells and the level of the infrared signal. It also allows review of the event log. It is the indispensable tool for installation and maintenance of MAXIRIS 2000 barriers.
SORHEA's technology goes even further with network installations for MAXIRIS 2000 barriers thanks to the MAXIBUS hub. In particular, the hub allows simplification of the wiring but also simplifies maintenance for the entire network of MAXIRIS 2000 barriers.
|
|
MAXIRIS III, 3rd GENERATION INFRARED BARRIER
MAXIRIS III is the only one infrared barrier on the market to feature up to three detection zones per barrier!
In adition, the dimension of each zone is ajustable according to your needs to optimize the protection of your sites.
The alarm information is specific for each zone created, that allows a better camera video piloting.
Expert experience and Technology at your service. SORHEA has developed a new aesthetically pleasing and robust design for the MAXIRIS III Columns.
The modularity and flexibility in the use of the MAXIRIS III infrared columns allows them to be installed on the majority of sites:
- Military facilities
- Nuclear power plants
- Prisons
- Logistic sites
- Public places (underground, airports...)
- etc.
|
|
|
|
