Intellium™ Z100 Fizeau Interferometer
* The Most Compact 100mm Fizeau Interferometer with a 190mm by 338mm footprint
Applications
- Transmission and surface testing of optics.
- Optical components and assembly alignment
- OEM metrology integrated systems
Main Features & Benefits
- Provides precision and accuracy in a small package.
- 1x to 6x zoom (standard feature).
- Vibration-insensitivity can be accomplished with the IntelliPhase™ Spatial Carrier Method.
- Rugged design.
- Compatible with all industry standard reference optics and 100mm (4”) interferometer accessories.
- Premium-quality measurements at an affordable price.
- Configurations include horizontal, vertical look up, and vertical look down.
- Optional horizontal professional workstation allows radius of curvature measurements.
The Intellium™ Z100 interferometer provides non-contact measurement of flat or spherical surfaces and transmitted wavefronts of optical components and assemblies. Measurements can be made using simple basic visual fringe inspection, static fringe analysis, or phase-modulated interferogram analysis.
The Intellium™ Z100 uses IntelliWave™, the de-facto standard interferometry software for device independent interferogram analysis. Vibration-insensitive acquisition is supported by IntelliPhase™, one of the many versatile features of IntelliWave.The Intellium™ Z100 provides flexibility to handle today’s industrial applications at a significantly reduced cost as compared to other instruments. |
|
The Intellium™ H2000 Simultaneous Phase-Shifting Fizeau Interferometer
* Vibration-insensitive that captures events as fast as 10 microseconds!
* Ideally suited for production and other vibration-prone environments.
Applications
- Measuring high speed events such as fluid flow and thermodynamics
- High accuracy measurements using large beam expanders
- In-situ measurements of machined parts, disks, semiconductor wafers
- Measurements on production floors in vibration-prone environments
- Long path measurements across multiple optical elements
Main Features & Benefits
- Vibration Insensitive
- Capture events down to 10ìs
- 1024x768 true resolution
- Compact 190mm (7.5”) x 370mm (14.6”) footprint
- Standard 100mm (4”) reference optics
- Lifetime module alignment guarantee
A variety of different wavelengths are available. The H2000 uses industry standard 100mm reference optics.
How it Works
Reference and test beams travel the common path through the optical system of the interferometer. Our simultaneous phase-shifting common-path Fizeau interferometer is accomplished using ESDI’s revolutionary HyperPhase™ Module (patents pending). The module uses three sub-pixel aligned industrial cameras, which are monolithically bonded together with the beam splitting and polarization optics into a rugged package smaller than two stacked deck of cards. The result is a rigid camera system similar to high-end 3-Chip color cameras with lifetime alignment. The advantage of using three cameras is that each of the interferograms retains the true resolution of the camera. |
|
Intellium™ Asphere Fizeau Interferometer
* The World's Fastest Interferometer for Aspheric Metrology
Aspheric Optics Measured in Seconds
Applications
- Transmission and surface characterization of aspherical, spherical & flat optics
- Optical component and assembly alignment
- Integration into OEM manufacturing & metrology systems
Main Features & Benefits
- Manufacturer of data acquisition, processing and retrace error compensation in one single step
- No special tools or long scanning process required for measurements
- Provides precision and accuracy of aspheric measurements in a small package
- 1x to 6x professional zoom (standard feature)
- Rugged design
- Premium-quality measurements at an affordable price
- Configurations include horizontal, vertical look up and vertical look down
- Optional horizontal industrial workstation allows radius of curvature measurements
The Intellium™ Asphere Fizeau interferometer provides fast, non-contact and high-resolution measurement of aspheric surfaces. Native sub-Nyquist sampling technology provides transmitted wavefront measurements of aspherical optical components and assemblies, such as optical pick-up professional lenses and micro optics used in micro-cameras. The Intellium™ Asphere uses IntelliWave™, the de-facto standard interferometry professional software for device-independent interferogram analysis.
The Intellium™ Asphere provides ease, efficiency, and flexibility to handle today’s aspheric optics metrology at a significantly reduced cost compared to other instruments. |
|
Nano level 3D profile quickly presents
Carmar’s SWIM-1510MS designs with the latest scanning white-light interferometry technology. Outstanding performance with simple operation, customer design flexibility, high-precision scanning and graphic obtaining. 3D profile and surface texture analysis can can be done by Non contact, none constructive and general Atmospheric Environment. Moreover, Nano level surface roughness of ball and step height analysis tracing the ISO International standardization.
Powerful SWIM series Whitelight Interferometer can acquire the scanning data of FOV in a few seconds. 3D profile and height inspection results obtaining is better than point to point con-focal microscope manufacturer. 3D graphic measuring ability is better than stereo 2D scanning microscope.
No matter the polishing, rough layer, or even the transparent material can be inspected by SWIM as long as the reflection rate of measuring object is over 1%. SWIM is suitable for the inspections of surface profiles and micro all kinds of materials, MEMS components. The applications are as below:
Glass lens
Coating surface
Semiconductor Wafers
Data Storage Surface (HDD, DVD, CD)
MEMS Components
LCD
high-density interconnect PCB
IC Package
Micro Mechanical Parts
and analysis and surface research of other materials and Precision Machined Surface. |
|
Intellium™ SBSI Shearing Interferometer
* Visualize collimation and wavefronts of 1 to 8mm diameter beams in real-time
Applications
- Wavefront and collimation testing
- Test manufacturers of laser diodes at wavelengths from below 200nm to 1700nm.
- Test beams from 1-8mm diameter, or smaller with beam expander
- Alignment and collimation of fiber optic systems
- Optical alignment of holographic storage & disk mastering systems
- OEM integration for real-time monitoring of professional laser collimation
Main Features & Benefits
- Measure collimation to better than 100-200 micro radians (wavelength dependent)
- Wavelengths from 180-1700nm
- Small beam probe allows measurement between optical components.
- Simple operation reduces alignment time to minutes
- Three models to choose from including fluorescent screen, professional camera, and 8x zoom systems
The patented SBSI is a small beam lateral shear interferometer that uses an air gap between glass plates to shear the beam and then projects a magnified interference fringe pattern on a camera or fluorescent viewing screen. Optical aberrations can be identified and corrected while viewing the SBSI fringe pattern in real-time. For example, coma can be corrected by changing the tilt of a collimating lens in an optical system so the fringes on the SBSI change from curved to straight. A reference line on the SBSI screen indicates the best focus (collimation) angle for the fringes. When the fringes are parallel to the SBSI reference line, all optical aberrations are minimized. Beams can be checked directly or in reflection using a rotating beam-splitter cube mounted on the front of the SBSI. |
|
Intellium™ PDI (Point Diffraction Interferometer) with HyperPhase™
* Vibration-insensitive, self-referencing Interferometer
Applications
- Wavefront and collimation testing of telescopes and periscopes
- Test supplier of laser diodes at wavelengths from 480 to 1800nm
- Test beams from 5-25mm diameter
- Alignment and collimation of fiber optic systems
- Optical alignment of holographic storage & disk mastering systems
- OEM integration for real-time monitoring of professional laser collimation
- Atmospheric testing
- Adaptive Optic Measurements/Applications
Main Features & Benefits
- Measure collimation to better than 100-200 micro radians (wavelength dependent)
- Wavelengths from 480-1800nm
- Small beam probe allows measurement between optical components.
- Simple operation reduces alignment time to minutes
- Using the HyperPhase™ module for simultaneous phase-shifting
- IntelliWave™ Interferometric Analyse software
Intellium™ PDI is a state-of-the-art point diffraction interferometer that generates its own reference spherical wavefront using a pinhole in a retarder. The result are highly stable interferograms simultaneously phase-shifted using ESDI's HyperPhase™ module. The instrument measures real-time interferometric laser beam wavefronts at resolutions up to 1024 x 768. |
|
The ESPI system from Steinbichler Optotechnik is an extremely flexible instrument for deformation and vibration analysis. One of its most important features is that the system can be adapted to the customer´s specific demands and applications.
By using the wave character of laserlight, even small deformations can be detected with an accuracy of 0.05 µm. The deformation is measured either one-dimensionally (typ. out-of-plane) or spatially (in- and out-of-plane) with a 3D-unit which is optionally available.
In the vibration analysis, e.g., resonance frequencies and vibration modes of excited parts can be determined fast and precisely. Innovative developments such as the "Free Boundary" and the "Sine Stepping/Universal File" functions significantly improve the handling of the measurement system. |
|
ZYGO's GPI family™ of interferometers are the industry standard for noncontact measurement of flat or spherical surfaces, and transmitted wavefront measurement of optical components and assemblies. When combined with ZYGO's proprietary MetroPro™ software, the GPI systems offer a wide range of operational features and data analysis tools for unmatched measurement capability.
The GPI family provides a solution for most metrology applications from the basic visual fringe inspection configuration, to a phase-modulated high-resolution measurement system, or a vibration-insensitive acquisition technique featuring ZYGO's FlashPhase™ software. Custom GPI solutions, for operation at a specific wavelength, or with special metrology features, are also available as part of the total metrology solution from ZYGO. |
|
