EAO mechanical, metal keypads and rugged keypads for industrial and public use. Keypads are vandal-resistant and protected up to IP 67.
|
|
|
|
|
|
EAO, the expert partner for Human Machine Interfaces, offers the rugged, reliable and vandal-resistant W.Series metal keyboard, designed specifically to operate in harsh internal and external public environments.
The heavy-duty, all metal W.Series keyboard range features a front plate constructed from brushed stainless-steel, together with chromed Zamac (zinc alloy) anti-pull off keys. The W.Series delivers high levels of resistance against shock and vibration.
EAO’s W.Series keyboard range is ideally suited to ‘hostile’ public service environments including point-of-service information terminals and multimedia applications including libraries, shops and internet kiosks. With protection of IP67 from the front against the ingress of dust and water, the range is ideal for outdoor applications.
Whilst incredibly tough the W.Series keyboard retains the smooth key action of a normal PC, with a 1.5 mm travelling feedback. The keys are finished in matt chrome and are laser engraved for high-definition black marking which will not easily corrode or wear off. EAO has the technology to create custom-specific layouts upon request.
EAO’s W.series range is available in:
• A choice of two interface languages : PS2 and USB
• Standard availability in the keyboard layout of 10 different languages
• Internet dedicated shortcut keys like ‘www’, ‘.com’ and ‘@’
• A single integrated unit for faster, easier mounting
|
|
Bergquist's proprietary HeatSeal® membrane switches are custom engineered for use in environments where reliability is critical. The HeatSeal process thermally bonds switch layers together, providing a seal that is impervious to moisture, temperature extremes and cleaning chemicals. Options include screened silver ink or PC board circuitry, tactile graphics, rim or pillow embossing, deadfront or translucent windows and more.
|
|
|
|
|
|
EAO, the expert for Human Machine Interfaces, has in its product range some touch-sensitive keyboards which are extremely tough, versatile and cost effective.
The keyboard operates from under a transparent protective screen that resists cleaning agents and fluids, moisture and dirt ingress, and damage from shocks and impacts , making it suitable for a wide spectrum of applications located in:
• aggressive environments polluted by dust, grease or ink particles suspended in the air, e.g. printing machines.
• sterile environments cleaned using ultrasonic techniques, e.g. medical equipment.
• hygienic environments cleaned using pressure washing, e.g. food packaging equipment.
• explosive atmospheres which must be free of contacts and electro-static discharge.
• public areas susceptible to vandalism, e.g. public-access internet kiosks.
The keyboard is extremely thin, which allows it to be mounted in existing machines. What’s more, the keyboard layout can be designed and configured out-of-box to suit different applications by using the simple-to-use proprietary software. The customer can vary the position of function keys according to their specific needs and alter the sensitivity of the keys according to the material of the protective screen. There is a choice of standard keyboard layouts for 10 different languages, a feature which makes the EAO touch-sensitive keyboard suitable for use across the world.
The keyboard, available with PS2 or USB interface, is compatible with both PC and Apple Macintosh operating systems.
|
|
|
|
|
|
The new edition to this range of mechanical, metal keyboards offers six rows of keys including the standard ‘F’ function keys. The ‘F’ keys perform the same, standard functions as any other office keyboard. Different language layouts are available also.
Even with an extra row, the external dimensions of the MF2 layout are exactly the same as the existing 5-row keyboards, so existing equipment can be upgraded without design changes.
Strength and durability are at the heart of this product. A brushed, stainless steel front plate provides resistance to shock and vandalism up to IK09 (10J) and resistance to liquid and dust penetration to IP67. The anti-pull-off keys are made from Zamak with a chrome finish and offer more than four million operations. Key markings are enhanced by using laser engraving methods to give better resistance to wear.
The keyboard can be supplied with an integrated numeric pad, similar to a standard office keyboard, or with an integral ‘trackball’ pointing device, which is available in three types: stainless steel, phenolic (plastic), and optical.
The optical trackball provide full sealing to IP67.
EAO’s W.series keyboard range is particularly suited to the needs of any public environment applications including kiosks and information terminals, or any harsh industrial environment.
|
|
EAO, the expert in Human Machine Interfaces, is proud to introduce
the M.series keypad range, designed to operate in varied environments
and which can be used in different applications.
The main advantage of this keypad system is its flexibility in terms
of mechanical characteristics. These include for example, choice of
illumination, colour and shape of keys, and tactile feel (membrane
with carbon pills or domes on the PCB for instance), amongst others.
With M.series, the right keypad is available for every need!
|
|
|
|
|
|
The short travel technology cannot be missed in keyboards used for industrial applications. Long lifetime, excellent tactile feeling and resistance against water and dust are just some of the namable features.
Indukey® Keyboard Production produces short travel keyboards in different enclosure or frontpanel versions. Beside MFII-standard layouts there are space saving keyboards and customized keyboards available as well.
One of the highlights of the extensive product range is the industrial radio link keyboard with integrated radio encoder.
To realize implementing access, timestamp and user right management Indukey® offers an industrial keyboard with integrated contactless chip card reader. Double security is guaranteed because of the combination with PIN-entry.
If the customer wants to integrate the keyboard in 19”-racks, he or she will be fascinated of the frontpanel-keyboard family TKS-105a-FP-3HE. These keyboards consisting of a stable aluminium frontplate are optional available with touchpad, trackball, mousebutton or numpad in nearly all language versions and are just 3 HU high.
|
|
|
This unit combines all functions, controls and features for comfortable key input and cursor control under low light conditons as well as under normal daylight. This sealed industrial keyboard integrates a 50mm large industrial grade trackball for accurate and precise cursor control. The key legends, the key edges and the trackball contour are backlighted for ease of recognition under low light conditions. In addition, the intensity of the backlight is digitally dimmable in 8 steps in order to set it to the operators' best comfort. An automatic night/day sensor controls the on/off setting of the backlight. Several internal features warant for a longer life of the backlighting source.
|
|
From the following keyboard technology you can get customized versions:
- short travel keyboards
- flat input keyboards
- membrane foil keyboards
- design foils
- metal plates
- silicone keyboards
- long travel keyboards
- enclosures an devices
- resistive touchscreens
|
|
NSI has all necessary mechanical and electrical design facilities available in order to meet specific customer requirements. Examples of some of our custom made industrial keyboards and pointing devices are shown here.
Custom designs include a large choice in :
Sizes of panels
Front layer colours
Panel and housing materials
Panel colours and finishing
Ball colours
Sealing grades
Switching technology
Key arrangements
Country layout versions
Output protocols
Cabling
Industrial trackballs
Touchpads
Joysticks
TouchStyks
Backlit trackballs
Backlit keyboards
Etc.
|
|
Customised keyboards with keycaps
RAFI short and full-travel keyswitches with keycaps
Good tactile feedback (click)
Fully illuminated/spot-illuminated
Integration of displays and electronic components
|
|
Industrial, sealed keyboards ranging from 26 to 106 keys. They can be provided with an integrated high quality industrial pointing device. Panel mount versions or versions with enclosure. Available in the major European and US layouts. Also customized versions
Membrane keyboards (KBM series) :
- 5-layer membranes
- Relatively long travel of 1,4 mm with distinctive tactile click
- The higher pressure force (typ 4N) limits the data entry speed
(not always a disadvantage for industrial applications)
- Overall sealing up to IP65 static (opto-mechanical trackball)
- Robust, field prooven technology
Short travel keyboards (KST series) :
- Individual short travel switches mounted on a rigid PC board
- Short travel of 0,3 mm with tactile feel
- Lower pressure force (typ 2.5N) allowing a higher speed of data entry
- Overall sealing up to IP67 (panel mount versions)
- Lower set up charges and lead times for new country versions
as only the front foil needs to be changed
|
|
Short-travel standard keyboards
Standard keyboards for industrial data input on a PC. Designed as a short-travel keyboard with a membrane surface.
Features of "type A" versions with membrane surface
* Waterproof IP 54 or IP 65
* Good tactility (click)
* USB or PS/2 port
* In robust metal or plastic housing
* Various mouse devices integrated
* Housing, front panel and 19" versions
|
|
This unit consists of 36 numerical, function and control keys and a compact 25mm industrial grade trackball.
The condensed but well defined key layout together with the use of a separate trackball enables a fast and comfortable access of the most important machine commands and an accurate control of the screens' cursor.
|
|
APEM modular stainless steel keypads and keyboards designed for intensive use or harsh environments
- Professional anti-vandal keyboards, frontally sealed to IP65
- 3 series for semi-protected or harsh environments
- Standard or custom configurations
- Good tactile feedback
- Oblong, round, square or rectangular keys
- LED backlighting
- Custom key marking by chemical etching (colours available)
Applications: vending machines, banking equipment, access control, chemical, food and oil industry…
APEM, the broadest offering in the switch market: miniature switches, industrial switches, LED indicators, professional switch panels and professional joysticks.
|
|
|
|
|
|
InduKey Keyboard Production presents the next generation of vandal-proof stainless steel keyboards, InduSteel and InduSteel². These stainless steel keyboards have been specially developed for the POI market and for semi-supervised or unsupervised applications. The InduSteel range offers the combined benefits of robust construction and quality data input making it the ideal choice for kiosk builders.
Most internet based kiosks such as web payphones come with keyboards. The clients who use these facilities are mostly web surfers and email users and are more familiar with the use of keyboards. In general touchscreens will remain popular for use in the public and retail sectors but keyboards will continue to be used for all kiosk types, especially in the fast growing internet based kiosks segment.
The InduSteel range is ideally suited to ‘hostile’ public service environments such as information and multimedia terminal applications including libraries, shops and internet kiosks. Sealed to IP65 standard, a silicon membrane between the keycaps and the silicon switching elements prevents any ingress of liquid and dust also making the range ideal for outdoor applications.
|
|
InduMedical™
InduKey® introduces first anti-microbial keyboard with Microban protection
The InduMedical™ keyboard represents another milestone in data input systems: the first antimicrobial industrial keyboard with Microban®’s active protection against bacteria, yeast, mold, mildew and fungi that cause stain, odors and product degradation.
InduKey®, the global leader in industrial input solutions, introduces the InduMedical™ keyboard, which features an antimicrobial design foil for data entry with Microban® technology. The specially treated front cover actively protects against most common bacteria, molds, and fungi. The InduMedical™ is intended for use in hygiene sensitive environments for medical, pharmaceutical and food processing applications. Its active protection against microbes makes equipment easier to clean and keeps it cleaner and safer between cleaning as recommended by GMP (Good Manufacturing Practice) and HACCP (Hazard Analysis and Critical Control Point) systems.
|
|
Customised membrane keyboards
Extremely low profile (> 1mm)
With or without tactile feedback/snap-action disc
Integral LEDs/displays
|
|
APEM professional membrane switch panels
- Custom designed front panels
- Sealed, easy to clean
- Tactile feedback by snap dome or embossing
- Many options available: texture varnish, integrated components, prominent shapes, changeable legends, reinforced sealing…
Applications: instrumentation, medical, time management, weighing systems, vending machines, access control…
APEM, the broadest offering in the switch market: miniature switches, industrial switches, LED indicators, professional switch panels and professional joysticks.
|
|
Customised membrane keyboards
- Extremly flat profile (> 1mm)
- With or without tactile feedback/snap-action disc
- Integral LEDs/displays
Customised low profile keyboards with RAFI short-travel keyswitches RACON 8/12 on RF15/19 in front panel under an overlay
- Good tactile feedback (click)
- Fully illuminated/spot illuminated
- Integration of displays and electronic compoments
- Integration of RAFI KN 19 main switches (250V / 4A) under an overlay
|
|
Flexible, Tough and Reliable-
Silicone Keyboard for Modular System Integration
16 keys, a closed surface and a positive tactile feedback are the features of the silicone keyboard TKG 016, which is excellent suited for information terminals. The modular character results from the simple integration in already existing systems and from the separate availability of the keypad and the PCB.
Sealed to IP65 the keyboard is protected against jet water and dust income. 10 numerical keys, 2 instruction keys and 4 keys for the cursor control ensure a complete functionality of the data input. The keypad is equipped with a carbon-contact on gold- coated-PCB, which creates a positive tactile feedback with a high lifetime.
InduKey Keyboard Production offers the silicone keypad and the PCB as single parts or as combination of both. Suitable accessories like controller and cables can be ordered as well. Furthermore the keyboard is adapted for backpanel mounting.
|
|
The high-quality industrial keyboard TKG-105-MB-IP68 of the keyboard specialist InduKey® Keyboard Production from Treuen, Germany was tested in the Institut for medical microbiology & hospital hygiene (clinical center of the Philipps university Marburg) on risks within the hygiene-sensitive fields. These tests have shown that the data input device is best suited for exertion in hygenically critical and sensitive fields regarding the possibility of a spraying and/or a wiping disinfection.
The complete keyboard surface is provided with a complete silicone cover, which causes a high stability against chemicals. The cable connection consists of a non-spiral, smooth and sealed data cable.
The lower surface of the Induproof is closed by a stable, disinfectant persistant metal plate, so it is resistant against solvents and acids.
|
|
|
|
|
|
InduKey®’s comprehensive range of industrial short travel keyboards offers exceptional reliability for the Food & Beverage industry. InduKey® keyboards and input devices have been designed and manufactured to withstand the demands of heavy industrial cleaning, up to IP68 standard, a must in today’s industry.
These short travel keys provide an excellent tactile feedback for the user. All InduKey® short travel keyboards use high quality OMROM mechanical switches on a reinforced PCB which also contains the keyboard controller. A 3mm thick aluminium plate is placed over the top and will protect the keys and PCB from any heavy impact. The 150 µm thick Autotex polyester frontsheet is wear and tear resistant as the legends are printed on the underside and is also resistant to most industrial chemicals. The keyboards are available in desktop, 19 inch rack-mount or panel mount versions. Our short travel keyboards are sealed up to IP65 specification and are available with trackball, IP68 optical trackball, capacitive/resistive touchpad or joystick. The keyboards have USB connectivity as well as PS/2. All InduKey® keyboards can be semi or fully customised. Other language layouts are also available.
|
|
Long-travel standard keyboards
* Waterproof IP 54
* Suitable for input of quantitative data and continuous text
* USB or MF2 port
* Housing, front panel and 19" versions
|
|
|
|
|
|
An exclusive design combined with high-quality technology results in the new high-grade stainless steel space saving keyboard "Industeel" from InduKey®. The data input device with 84 keys distinguishes by its congenial key form: The key tops with finger identation. You will have the best tactile feeling due to carbon contact. Big letters ensure best operation comfort. The Industeel is used within public ranges, which require a vandal proof keyboard, e. g. information terminals and kiosks. Therefore the keyboard is also dust and water-protected (IP65 / Nema6) and possesses non-removable key caps.
The Industeel is available with and without trackball by the keyboard specialist: Under the designation TKV-084-MODUL the customer gets the keyboard without additional mouse device. The TKV-084-TB25V-MODUL includes an integrated 25 mm robust high-grade stainless steel trackball, which can also be replaced by a black plastic ball on customer's request. Both keyboards do have a laser lettering that protects against abrasion.
|
|
|
|
|
|
EAO offers the ultimate keypad for product designers
A rugged keypad which combines strength, versatility and beauty is available from EAO - the expert partner for Human Machine Interfaces.
EAO's S.series keypad is the ultimate product for any application that requires a key-entry control, including access control systems, industrial machinery, banking terminals, public telephones, kiosks and vending machines. It is highly tactile and therefore reassuring to use, yet extremely reliable and hard-wearing enough for the harshest of environments, such as outdoor and unsupervised locations.
The S.series keypad offers great design flexibility from a standard product and can be customised to suit the environment of the application.
The keys on the S.series keypad can be engraved with a range of standard symbols or ones specified by the customer. The keypad and individual keys can be illuminated in white, blue, red, yellow and green, or a combination of these colours; halo illumination around the keys is also a possibility.
The metal-bodied S.series keypad features a front plate and anti-pull-off keys constructed from an ultra-tough material, Zamak, which guarantees a high level of impact-resistance. It is sealed to IP67 against water and dust, and it will resist heat, shock and vibration to a very high level. It is tested for quality to 4 million operations and is certified according to the latest international standards.
The S.series keypad from EAO requires minimal maintenance and delivers long term value in terms of lifecycle cost benefits.
|
|
Elastomer Plastic Key
-Mid-Travel Elastomer plastic key products incorporate a conductive silicone or elastomer keypad over a switch circuit actuated by a plastic key.
Elastomer Metal Key
-Mid-Travel Elastomer metal key products incorporate a conductive silicone or elastomer keypad over a switch circuit actuated by a metal key.
Elastomer Dome
-Mid-Travel Dome technology keyboards incorporate a tactile metal dome on a printed circuit board actuated by a plastic key.
Elastomer Rubber
-Mid-Travel Elastomer rubber products use a conductive elastomer as the keypad over a switch circuit.
High Value-Added Capabilities:
Custom graphics
Custom lighting
Custom electronics
Custom packaging
Custom colors
Custom integration of alternate input technologies
|
|
Custom keyboads at times require two or more switch technologies:
Whether you require an intricate device incorporating multimedia options, cursor control, and touch screen or perhaps just a single-station keypad, Advanced Input Systems is dedicated to providing end-to-end solutions. Rapidly and cost effectively.
Hybrid keyboards use a combination of two or more switch technologies. Hybrids are particularly useful when a high-speed typing array is combined with a large number of special function keys. These keyboards give our customers yet another way to differentiate their products from the competition and to meet the needs of their unique application.
|
|
The KIO7000-BX Series are NEMA 4/4X sealed industrial keyboards with full 101/104 key functionality in a patented, innovative small foot print with full size keys. These illuminated keyboards include 12 function keys, a separate numeric keypad, and are combined with CTI's OrbitalMouse button style mouse pointer.
These backlit keyboards are molded of black silicone rubber, and are available with red or green LED backlighting with ten levels of intensity. This series is designed for continuous use in harsh environments, and in areas with low-level lighting.
The KIO7000-BX Series is available in anodized aluminum or stainless steel enclosures rated at NEMA 4/4X (IP66), or as OEM sub-assemblies.
For more information, please visit www.ctielectronics.com or e-mail sales@ctielectronics.com
|
|
