Features
Battery operated laser for line, dot or cross projections
Operated by a 1.5 V battery (AA) or 1.2 V accumulator (patented)
Maintenance-free magnetic On/Off switch
Output power / Wavelength: 1 - 5 mW / 635 nm +/- 10 nm
Dimensions: Ø 20 x 108 mm
Electronics: APC
|
|
Features
5-30VDC operation
Powers up to 200mW
Red, infrared, blue laser wave lengths available
Gaussian, uniform and DOE optics available
Simple, external hand focusing mechanism
Up to 20MHz Analogue and TTL modulation together (at the same time)
IP67 rated, fully water proof
LED laser operation and pre-failure indicator
|
|
|
|
|
|
A range of compact and affordable laser modules generating an accurate line or cross at 635nm or 650nm with uniform intensity distribution. The laser modules measure just 29mm in length, with a diameter of only 8mm and are extremely efficient and reliable.
They are ideal for the most demanding industrial and medical applications where space is at a premium, such as handheld instrumentation, targeting, alignment and machine vision.
These laser diode modules generate either a 70 degree full angle cross or a 58 degree or 88 degree full angle line, all factory focused at 1000mm. The focus can be set to other distances on request. The lens system produces an efficiently uniform intensity laser line.
At a visible wavelength of either 650nm or 635nm, these compact laser diode modules offer output powers of 0.9mW or 4mW with power stability of less than 5 per cent. Operating voltage is from 3V to 6V DC at an operating current of 30mA typ, (0.9mW) or 40mA typ, (4mW). Operating temperature range is -10 degrees Centigrade to +40 degrees Centigrade.
The laser modules consist of a brass housing, a laser diode, drive circuit and beam-shaping optics. Electrical connections are made via external flying leads. All modules have static, surge and reverse polarity circuit protection.
|
|
|
|
|
|
The 405nm laser modules are designed for applications such as biomedical instrumentation, imaging, spectroscopy, fluorescence sensing, microscopy and many other emerging technologies.
The compact and efficient 405nm laser modules produce either an elliptical output beam of 4 x 1.5mm with output power of 4mW, or a 2mm circular output beam with output power of 0.9mW. The glass AR coated optical lens may be adjusted to produce either a collimated beam or focused spot. The standard lens may be replaced by other optical systems such as line generators.
The laser is extremely stable and reliable and offers the added advantage of TTL modulation input which will accept signals from DC up to 1 kHz minimum. TTL modulation can be used to enable, inhibit or modulate the laser.
Operating voltage is from 8V to 12V DC at an operating current of 90mA, or 100mA. Beam divergence is <0.6mrad for the circular output beam and <0.6 x 0.3mrad for the elliptical output beam. Operating temperature range is -10°C to +50°C.
The modules are cylindrical with an optional 25mm mounting flange and consist of an aluminium housing, laser diode, drive circuit and collimating lens. Mechanical dimensions are a compact 12 mm diameter x 43mm length. Electrical connections are made via external flying leads.
|
|
|
|
|
|
Thermo-electrically cooled, (TEC), blue/violet laser diode modules which offer exceptional wavelength and power stability, (better than 1%), greatly increased pointing accuracy and significantly extended laser diode lifetime.
Designed for applications demanding consistency and repeatability such as industrial inspection, high-resolution printing, reprographics, biomedical instrumentation, spectroscopy, microscopy and genomics, the modules are compact, versatile and highly cost effective.
They produce elliptical output beams and output powers of 1.5mW in the 375nm ultra-violet, 4mW and 25mW in the 405nm violet and 4mW in the 440nm blue wavelength bands.
The modules incorporate microprocessor based temperature control electronics, thermo electric cooler, heatsink and fan that enable the laser diode temperature to be controlled to a set point temperature between +15 degrees C to +25 degrees C, (user adjustable), and with a stability of +/-0.05 degrees C.
All UV, violet and blue TEC laser diode modules in the range offer low and high temperature automatic shut-off protection, analogue and digital modulation capability and safety interlock, as standard.
|
|
TEC Laser:
The TEC laser is now available in Ultra-Violet, Violet, Blue, Red or Infrared. Our design boasts one of the longest violet/blue diode lifetimes. All the interchangeable pattern projection heads of our SNF Series laser work with the TEC series laser.
The TEC laser's thermoelectric system maintains a constant laser diode temperature, allowing the use of these lasers in applications demanding consistency.
- Excellent wavelength and power stability
- Extended lifetime
- Line generators that have a uniform intensity distribution
- Wide range of wavelengths, fan angles and patterns
- Focusable
- Spatial filters available
- ESD, over-temperature, and reverse-polarity protection
Applications
-Medical applications
-Machine vision
-3D contour mapping
-Alignment
-Positioning
-Industrial inspection
-R&D
-Microscopy
|
|
Green TEC Laser:
StockerYale's Lasiris™ Green TEC structured light laser offers a thermoelectric system and fan that maintains a constant laser diode temperature, resulting in excellent wavelength, power, and pointing stabilities. The new, improved design makes focusing even easier with the focus adjusting screw located directly on the body of the laser. In addition, the Green TEC boasts one of the longest green laser lifetimes, and is offered with a 1-year warranty.
A green beam can provide better contrast on red hot metal or wood. Another advantage is that a green beam is more visible to the human eye than red, thereby making the relative eye response to the green much higher. A 1 mW green beam (532 nm) will be better perceived by the human eye than a 1 mW red beam (635 nm).
Applications
-High-end aligment and targeting
-Fluorescence
-Machine vision
-Positioning
-Industrial inspection
-R&D
|
|
BC4 series diode laser beam combiners can combine up to four laser diodes with similar (at least two different wavelengths with 50 nm spacing) or disimilar wavelengths (at least 50 nm spacing) .
Photo monitor of the combined power output is an optional addition.
The standard package features an SMA receptacle for multimode fiber coupling. The combiners can accept both 5.6 mm and 9.0 mm TO packages.
|
|
VULCAN Runner (Power cross)
- Good visible cross-projektion
- 2 line laser in one housiing
- Wide range input 95 - 265 VAC
- Integrated power supply "Heavy Duty"
- Dimensions: Ø 40 x 221 mm
|
|
| ... products without technical information |
| |
|
|
|
|
Models:
- LCM-T-111-20, LCM-T-111-10, LCM-T-111-1 (with output power of 20, 10, 1 mW CW accordingly);
- - LCS-T-11 (complete laser system with 3 mW CW output at 532 nm, has AC Power Supply).
High reliable product industrially verified during many years
>10,000 hours lifetime
Small in size and easy-to-install T-series laser modules provide gas-laser beam quality and semiconductor laser module size.
LCM-T-series module incorporates driving electronics, therefore no additional driver for laser diode is required. In order to operate the module just 3.3 VDC voltage should be applied to input of the laser.
Each LCM-T-series laser module features an active power stabilization control loop. This control loop monitors output radiation of the laser module and maintains it at constant level within wide temperature range. Spherical-mirror laser cavity provides perfect and stable beam geometry. Two-lens output optics yields well collimated, centered and aligned ray of light.
Fan heat sink accessories are available.
All above allows to consider LCM-T-series modules as the best price-to-quality ratio solution for many applications.
|
|
|
|
|
|
Models:
- laser modules LCM-T-112-100, LCM-T-112-10
(with output power of 100, 10 mW respectively, operating from 3.3 V DC)
- LCS-T-12 (complete laser system with 50 mW CW output at 1064 nm, has AC Power Supply)
High reliable product industrially verified during many years
>10,000 hours lifetime
Small in size and easy-to-install T-series laser modules provide gas-laser beam quality and semiconductor laser module size.
LCM-T-series module incorporates driving electronics, therefore no additional driver for laser diode is required. In order to operate the module just 3.3 VDC voltage should be applied to input of the laser.
Each LCM-T-series laser module features an active power stabilization control loop. This control loop monitors output radiation of the laser module and maintains it at constant level within wide temperature range. Spherical-mirror laser cavity provides perfect and stable beam geometry. Two-lens output optics yields well collimated, centered and aligned ray of light.
Fan heat sink accessories are available.
All above allows to consider LCM-T-series modules as the best quality-to-price ratio decision for many applications.
|
|
The 532nm DPSS green laser module is a compact, self-contained laser module designed for use in industrial alignment, medical and scientific applications where a highly visible beam is required.
It produces a very visible circular output beam of <2.0mm diameter and output powers of 0.9mW and 4mW with a maximum operating current of 250mA.
Power stability is better than 5% over 7 hours. Modulation capability of 0-1kHz is standard.
In addition, the module uses a front facet monitor photodiode to maintain a stable output power, as opposed to using the internal monitor of the laser diode, which is often less responsive.
The green laser module consists of an anodised aluminium housing, laser diode, drive circuit and collimating lens. Electrical connections are made via external flying leads.
Line generator options are available on request - contact our sales department for more information.
|
|
All solid state 593.5nm yellow laser is made features of ultra compact, long lifetime, high stability, low cost and easy operating.Output power,up to 500mW is available, which is widely used in laser medical treatment, scientific experiment, optical instrument,collimation,lighting etc.
up to 500mW, 80-240VAC, RoHS, FDA, CE complied
|
|
The OLGDP-300F series are OEM continuous wave green laser modules with Photo Diode, PD, Feedback. This combination produces a suitable laser for industrial application and scientific research.
The laser module with PD Feedback, offers excellent power stability at a given temperature, and little fluctuation with changing temperature. The 200F Series however, outperforms the 300 Series where wide temperature range is required.
OLGDP-300 Series :
. Compact Package
. High Power Stability
. High Reliability
. Low Cost
. 10mW and 20mW models
|
|
|
Diode-Pumped Solid-state Lasers are ideal lasers that serve various and diverse industrial market segments. Excellent beam quality, rock-solid stability, incredible efficiency and solid-state reliability make these lasers the clear choice for application. It integrates a ND: YAG laser rod which is efficiently pumped by a radial array of long lifetime laser diode bars, and delivers excellent gain uniformity and lensing performance. It is used for medium power multi-mode applications, precise micro-machining and scientific applications.
|
|
