-3*1W High Power LEDs as the Light Source;
-Aluminium Alloy Extruded Shape;
-Excellent Heat Sinking Design;
-Long Term Lumen Maintainance & Long Lifespan;
SPECIFICATION:
- Color: Cool White / Warm White
- Luminescence Angle: 30 Degree
- Lumens: 180 LM
- Power Consumption: 3W
- LED pieces: 3
- Working Voltage 90-260VAC
- Lamp Base: E27
- CRI: Ra > 85
- Design Life: > 50,000 hours
- Warranty: 2 years
- Light Degradation: < 5% in 30,000 hours
PACKING DETAIL:
-E27 (Carton Size:320*320*350 mm )
-40 Pcs / NW 5.5 Kg / GW 6.5 Kg
|
|
Model No. RP-BU-E04-5WXXE27
Key Specifications:
Wattage:5W
Socket: E27
Lumen: 240
Voltage: VAC85-260
Color Temperature: WW/CW
Beam Angle: 180
|
|
SPECIFICATION:
- Color: Cool White / Warm White
- Luminescence Angle: 180 Degree
- Lumens: 180 LM
- Power Consumption: 3W
- LED pieces: 3
- Working Voltage: 110 / 220 VAC
- Lamp Base: E14 (E27 available)
- CRI: Ra > 85
- Design Life: > 50,000 hours
- Warranty: 2 years
- Light Degradation < 5% in 30,000 hours
PACKING DETAIL:
- E14-03 (Carton Size:320*320*350 mm )
- 75 Pcs / NW 6.5 Kg / GW 7.5 Kg
|
|
SPECIFICATION:
- Color: Cool White / Warm White
- Luminescence Angle: 180 Degree
- Lumens: 180 LM
- Power Consumption: 3W
- LED pieces: 3
- Working Voltage: 110 / 220 VAC
- Lamp Base: E14 (E27 available)
- CRI: Ra > 85
- Design Life: > 50,000 hours
- Warranty: 2 years
- Light Degradation: < 5% in 30,000 hours
PACKING DETAIL:
- E14-01 (Carton Size:320*320*350 mm )
- 75 Pcs / NW 6.5 Kg / GW 7.5 Kg
|
|
SPECIFICATION:
- Color: Cool White / Warm White / Red / Green / Blue / Yellow
- Luminescence Angle: 60 Degree
- Lumens: 450 LM
- Power Consumption: 7W
- LED pieces: 7
- Working Voltage: 90-260VAC
- Lamp Base: E27
- CRI: Ra >85
- Design Life: > 50,000 hours
- Warranty: 2 years
- Light Degradation: < 5% in 30,000 hours
PCKING DETAIL:
- E27-7W (Carton Size: 320*320*350 mm)
- 27 Pcs / NW 8.5 Kg / GW 9.5 Kg
|
|
- 1*3W High Power LEDs as the Light Source;
- Aluminium Alloy Extruded Shape;
- Excellent Heat Sinking Design;
- Long Term Lumen Maintainance & Long Lifespan.
SPECIFICATION:
Color: Cool White / Warm White / Red / Green / Blue / Yellow
Luminescence Angle: 30 / 60 Degree
Lumens: 120 LM
Power Consumption: 3W
LED pieces: 1
Working Voltage: 90-260VAC
Lamp Base: GU10,
CRI: Ra > 85
Design Life: > 50,000 hours
Warranty: 2 years
Light Degradation: < 5% in 30,000 hours
Packing Details:
- GU10 (Carton Size: 320*320*350 mm )
- 100 Pcs / NW 7.0 Kg / GW 8.0 Kg
|
|
-1*5W High Power LEDs as the Light Source;
-Aluminium Alloy Sinking Design;
-Excellent Heat Sinking Design;
-Long Term Lumen Maintainance & Long Lifespan.
-Color: Cool White / Warm White
-Luminescence Angle: 10 / 38 / 60 Degree
-Lumens: 240LM
-Power Consumption: 5W
-LED pieces: 1
-Working Voltage: 12VAC/DC
-Lamp Base: MR16(GU5.3)
-CRI: Ra > 85
-Design Life: > 50,000 hours
-Warranty: 2 years
-Light Degradation: < 5% in 20,000 hours
Packing Details:
-MR16 (Carton Size: 320*320*350 mm)
-100 Pcs / NW 7.5 Kg / GW 8.5 Kg
|
|
Key Properties
Model No. RP-BU-H01-6WXXE2
Wattage:6W
Beam Angle:180
Socket: E27
Voltage:110V/230V
Lumen: 400lm
Color Temperature: 6000K/3000K
|
|
Wattage: 6W
100 to 240V AC
Base: E27, E26, E17, E14, B22
250LMA30LUX
CE, RoHs certificate
|
|
1W, 2W, 3W, 5W choices
Cold white and warm white
Base: E27, E26, JDR+E14
AC12, AC220V, AC110V
Maximum brightness: 150LM, 600Lux
Beam angle: 38 degrees
CE, RoHS
|
|
The LED Lighting Strips for single or multi-colour illumination use XLamp LEDs from pioneering American LED manufacturer Cree Lighting to give industry-leading brightness and efficiency. Applications include AWP glass illumination, compact fluorescent replacement, RGB colour backlights, top box illumination, coin mechanism illumination... The list is endless!.
The range is extensive from simple chains of single LEDs mounted on metal or FR4 circuit boards to complex multi-LED arrays complete with drive electronics.
|
|
APPLICATIONS:
- Direct replacement of traditional halogen bulbs
- Illumination and decoration at home and public areas
- Suitable for hotel, bar,meeting room,groggery, shop,telephone booth etc
FEATURES:
1) 1*5W High power LEDs as the light source;
2High quality aluminium alloy heat dissipation design to enlarge the heat dissipation area to the maximum;
3) Using the wide pressure constant-current power supply design for the driven power supply, adaptable to 100-240/AC;
4) Unique bulb appearance with modern streamline design;
5) E27, MR16, GU10 choice;
6) Control Mode :IR Remote control(power on and of control);
7) Feature: many pcs synchronous change-color;
8) Long Term Lumen Maintainance & Long Lifespan.
|
|
Character
1. Socket:E27/MR16/GU10
2. Multi-color(16 colors)
3. IR Remote control/ Master Slave configuration
4. Input voltage:100~240VAC 10~15VAC/DC
5. Total power:4.5W
6. Lifetime:50,000hours
|
|
Product: Round Recessed-Mounted 7W
Item Number: BB-C11-07
Size: 105 mm ( Dia. ) * 70mm ( H )
Inner Dia. : Φ90 mm
Voltage: AC 100 265 V / 50/60HZ
Beam Angle: 30Lens
Connection: 30cm cable with tip
LED: Edison / BridgeLux / SSC / Cree
Luminous Flux: 315-595LM, depends on LEDs and Color Temperature
LED Drive: 350mA
LED (Qty * Wattage): 7 * 1W
Power Consumption: 7W
|
|
Model No. RP-PAR-A07-12WXXE27
Key Specifications:
Wattage:12W
Socket: E27
Lumen: 450lm
Voltage: AC85-260V
Color Temperature: R/G/B/Y/Warm White/Cool White
Beam Angle: 30
Package: 100pcs/ctn
LED pieces: 12
List in CE,RoHS.
|
|
Item Number: BB-S09-7
Product: LED Lighting, LED High Power Lamp
Description: PAR30
Size: Dia93*79mm
Color : White / Warm White / Red / Green / Blue
Luminance : against the LED brand
LED Brand: Cree / SSC / Bridgelux / Edison or on your request
Qty * Wattage: 7 * 1W
Power Consumption: 7 W
Dimmable: Optional
Base: E27
Voltage: AC110V, AC220V, AC230V, AC240V
|
|
Item Number: BB-S09-5
Product: LED Lighting, LED High Power Lamp
Description: PAR30
Size: Dia93*79mm
Color : White / Warm White / Red / Green / Blue
Luminance : against the LED brand
LED Brand: Cree / SSC / Bridgelux / Edison or on your request
Qty * Wattage: 5 * 1W
Power Consumption: 5 W
Base: E27
Voltage: AC110V, AC220V, AC230V, AC240V
|
|
Item Number : BB- B01-03
Base : E27, which can replace ordinary incandescent directly.
Size: 110mm*60
LED (Qty * Wattage) : 3 x 1W
Power Consumption: 3W
Voltage: AC100 C 240V
LED Brand: SSC / BridgeLux / Cree, or on Request
Full Range of Colors: warm white / white / cool white / red / yellow / blue /green
Luminous Flux: 150-180LM
Dimmable : on request, different price
Material: Aluminum and PC Cover
Heat Spreading: Excellent thermal cooling design with internal copper heat conductor and external aluminum housing
Brightness Attenuation: only 3% - 5% after 1,000 hours
Life Time: 50,000 hrs
No UV or IR radiation
Body temperature: 48
Working Temperature: -40 ~ 70
|
|
|
|
|
|
Features
. Fixed or Adjustable Intensity
Built-in Current Limiting Resistor for Direct 120VAC Applications (Other Voltages Optional)
Choice of Narrow (12), Standard (30), Medium (50) or Wide Angle (120) Illumination
Stability of LED Wavelength Eliminates Costly Filters
LED Operating Life: 100,000+ Hours (10+ Years)
Monochromatic, Narrow Bandwidth Light Gives More Open Time Before Fogging Film
Very Low Power Consumption
Solid-State, High Shock / Vibration Resistant
Direct Mount in Industry Standard Sockets Without Modification
3-Year Lamp Warranty
Applications
Light-Sensitive Film or Paper Manufacturing Plants
Darkroom Illumination
Control Panel Lighting in Darkrooms
Photo Processing Labs
Darkroom Safelight Spotlights & Task lights
Safelight Hallway Path lights
All specifications subject to change without notice.
Options: For qualified applications and large quantity orders
- Not all possible combinations of voltage, intensity, and angle are available.
- Intensity shown is for narrow angle. Intensity is reduced 12 to 15 times when using extra-wide angles.
- Designed to work in negative ground vehicles.
|
|
Item Number: BB-B06-03
Base : E27, which can replace ordinary incandescent directly.
Size: 55mm (H) * 50mm (Dia.)
LED (Qty * Wattage) : 1 * 3 W
Power Consumption: 3W
Voltage: AC100 C 240V
LED Brand: SSC / BridgeLux / Cree, or on Request
Full Range of Colors: warm white / white / cool white / red / yellow / blue /green
Luminous Flux: 90-120LM
Dimmable : on request, different price
Beam Angle: 30 / 40(glass lens, optical grade)
Material: Aluminum
Heat Spreading: Excellent thermal cooling design with internal copper heat conductor and external aluminum housing
Brightness Attenuation: only 3% - 5% after 1,000 hours
Life Time: 50,000 hrs
No UV or IR radiation
Body temperature: 48
Working Temperature: -40 ~ 70
|
|
Features
- Puts out over 1200 Foot-Candles of light in a Focus-beamed flashlight
- LED bulb will light for 92 hours on 2 fully charged D Batteries , that's 74 hours of more light than incandescent bulbs
- LED bulbs last 6 times longer on a set of batteries than incandescent bulb
- White LED bulbs last up to 5 years, that's over 30 times longer than incandescent bulbs
- You save 12 batteries by using a LED bulb per usage of battery life
- LEDs are Solid-State, High Shock / Vibration Resistant, virtually Unbreakable
- Easily replaces standard PR bulbs, no extra parts needed
- 8000 Kelvin pure white light
- One year warranty
|
|
MAIN FEATURES
- High Luminous Output: > 35 lumens
(Most competitions: 20 to 25 lumens)
- High Efficiency: 96% (max)
(Most competitions: 60 to 70%)
- Deep Battery Usage: 2 > similar products
- Long Lasting: > 10 years
- Low Cost
APPLICATION
- Drop-in replacement for incandescent bulbs in
- 3 cell and lantern flash lights
|
|
LD SERIES (Lighting: led light)
Description:
* Easy to wire and install
* Direct interchangeability with MR16 sized and GU5,3 jointed halogen lamps
* Low absorption and consequent energy saving (approximatively 80% in comparison to halogen lighting)
* Low heat output in the cabin
* Aluminium fiffed body: effective cooling to guarantee a long life (estimated 50.000 hours)
* Low maintenance cost in comparison with a similar halogen lamp.
* Excellent luminous flux
|
|
