ELAP product range includes different types of linear transducers, eg. traditional optical scales, and the innovative digital series named PD/PE.
Optical scales
Thanks to their excellent reading resolution they are traditionally preferred when dealing with machine tools.
- series KD: strokes up to 20 metres, in modular version
- series KP: thanks to its reduced dimensions it represents the best solution on small-sized machine tools or in case of narrow passages.
Great accuracy, easy mounting, high protection degree: PD/PE characteristics make them fit to industrial machines on any field.
- measuring range: 60 to 990 mm
|
|
Valve Position Transducer (LVDT)
Some valve position measurements incorporate a linear, rather than rotary, mechanical linkage. Our AC LVDT is designed for such applications and is available in ranges from 1.0 to 28.0 inches (25 to 703 mm).
measurement of governor valves on the steam turbine. By measuring the
opening of these valves, the amount of steam flowing to the individual valves in the group can be monitored and adjusted to provide highest machine operating efficiency.
|
|
Velocity Transducer Systems - 9200 and 74712
These are 2-wire, moving-coil velocity transducers, designed for general purpose velocity measurements. For most applications, however, we recommend the use of our Velomitor® piezo-velocity sensors.
|
|
Fagor Automation has manufactured linear and rotary encoders with optic technology since 1975. A technology that beats the rest by its excellent quality and performance.
All this time, Fagor has researched and designed encoders and can now offer one of the highest-quality products on the market as confirmed by the numerous demanding tests carried out by our own customers.
|
|
Highly dynamic NOVOSTRICTIVE measuring system. Secure data transfer with 16 kHz update rate.
Also versions for integration in pneumatic and hydraulic cylinders.
|
|
|
|
|
|
Foil sensor
Linear foil sensor - FSL
Small dimensions
IP65
Development and production of linear and rotary position transducers
Established in 1960, Contelec, with headquarters in Biel, Switzerland, is part of the German Siedle Group, and employs more than 100 people. Contelec specialises in the engineering and production of high-quality sensors for angular and path measurement. The company’s offering ranges from low-cost, high-quality standard components to individual custom solutions, which can be supplied in small-run production batches. The range includes contact-free and non-contacting rotary position sensors, as well as potentiometers based on conductive plastic, wire or cermet technologies.
Contelec, as international orientated company, exports 80% of its products. A key part of the company is the Contelec Engineering Division, which provides integral services for the engineering and production of complete subassemblies. Contelec has been ISO9001 certified since 1995 and has made its name in the top-end quality segment. The company invests heavily in research and development to ensure that the high innovation rhythm will be maintained into the future. This makes Contelec a strategic solution partner for a wide range of customers, making a significant contribution to the successful development of new products.
|
|
PL serie position linear transducers are potentiometers for industrial applications.
Their characteristics like precision, linearity, compactness and stoutness are well suited for plastic, wood, marble, metal sheet machinery and every applications with absolute measurements of position or displacement.
Mounting is very easy and they are interchangeable with other manufacturers' models.
|
|
|
Warner Electric has many years of experience in applying sensors and switches in motion control applications. Our broad range of innovative and technologically advanced products offers our customers the exact solution to satisfy their sensing applications needs.
|
|
|
Trans-Tek Linear Velocity Transducers, or LVTs, provide a simple way to detect speed of an object. Just connect to our internal magnet and push/pull it through the center of the transducer. No excitation required! The motion of the magnet induces a VDC output that is proportional to the velocity of the object being measured. Standard strokes range from ½” up to 24”. Please click the link below to visit our web site (www.transtekinc.com) and view full specs in PDF form.
|
|
|
Optimum performance for industrial applications - this is what the Temposonics R-Series offers. As a high-end product, the series is the racehorse of MTS. Powerful electronics and unrivalled immunity against interference are a warranty of high-accuracy measurement results.
|
|
|
The E-Series is the basic sensor in the product range of magnetostrictive position sensors. An excellent price/performance ratio is an unbeatable asset even for traditional users of different position measurement technologies.
|
|
POSICHRON is an absolute, contact-free and wear-free position measuring system. It is extremely sturdy making it suitable even for applications where other measuring principles would fail. The availability of various constructions - quad profile housing, flat profile, stick design, rod profile - means that the system can be adapted to suit all kinds of installation conditions.
Technical advantages:
Absolute measuring principle, totally wear- and maintenance-free, resistant to dirt humidity and dust, protection category to IP68, highly resistant to vibration and shock, resolution is virtually unlimited, linearity of up to 0.01%, no energy feed for positional magnets, measuring lengths of up to 5,750 mm.
The areas of application for POSICHRON positional sensors are wide and varied. They are used in e.g. injection-moulding equipment, dosing and mixing systems, die-casting machines, road vehicle tests, hydraulic cylinders and presses, fill-level measuring equipment etc.
|
|
|
Optimum performance for industrial applications - this is what the Temposonics R-Series offers. As a high-end product, the series is the racehorse of MTS. Powerful electronics and unrivalled immunity against interference are a warranty of high-accuracy measurement results.
|
|
LDT Feedback Transducers The Linear Displacement Transducer (LDT) is a magneto-strictive device which provides analogue or digital information of actuator position through the interaction of two magnetic fields.
Applications for the LDT include closed loop feedback to achieve accurate position, velocity or motion control.
On open loop systems, an LDT may be used as a continuous, infinite resolution position monitoring device. Parker feedback systems are suitable for precision control of a wide variety of applications, including machine tools, flight simulators, injection moulding equipment and marine stabilisation systems.
Max. working pressure: 350 bar
Max. stroke: 3.5m
Standard temperature range: -40°C to 65°C
Fluid suitability: all
Special designs to customer specification.
Click here to view catalogue page
|
|
|
Optimum performance for industrial applications - this is what the Temposonics R-Series offers. As a high-end product, the series is the racehorse of MTS. Powerful electronics and unrivalled immunity against interference are a warranty of high-accuracy measurement results.
|
|
|
Compact construction, a reasonable price for large-series production, complete functionality and modularity: the C-Series sensors provide persuading solutions for all requirements of the OEM-market.
|
|
Magnetostrictive Position Sensors for Mobile Hydraulics: PCST25
Technical advantages:
Protection class IP69K
Compression-proof up to 400 bar
Measurement range 0 ... 100 to 0 ... 5750 mm
Position sensor manufacturer ASM has extended its successful family of magnetostrictive Position Sensors POSICHRON® with a new sensor series PCST25, which has been designed for special requirements in the field of mobile hydraulics.
The PCST25 series with measurement ranges up to 5,750mm and linearity up to 0.02% for high accuracy, can be used in an operation pressure zone up to 400bar and is already available at ASM.
The extremely robust construction of POSICHRON® sensors with up to an IP69K rating guarantees years of trouble-free operation. Due to their high electrical compatibility and extremely high resistance against shock and vibrations, POSICHRON® sensors are best suited for applications in extreme hostile environments, such as with off-road construction equipment.
|
|
|
|
|
|
MTS has developed the Temposonics M series especially for integration into hydraulic cylinders. The sensor is protected against shock, vibration and extreme environmental conditions and offers an unrivalled measurement rate, outstanding repeatability (better than +/- 0.005%) and stable linearity (better than 0.04%). External effects on the measurement signal are virtually excluded by interference suppression for HF electric fields up to 200 V/m, vibration resistance up to 30gav and shock resistance of more than 100g. Changes of the hydraulic oil during operation are without effect on the measurement. The magnetostrictive technology of Temposonics sensors was invented by MTS and widely used and well proven in stationary industrial applications for many years. The magnetostrictive measurement principle is a warranty for wear and maintenance free absolute, contactless position measurement.
Temposonics MH offers continuous measurement of both - position and speed - during the position change. The integrated sensor electronics permits parameter adjustment for evaluation of the cylinder piston speed and end position attenuation can be omitted. Due to the output of a velocity signal, highly dynamic control of the movement profile of several independent hydraulic cylinders is possible for the first time. It enables the power actuators to be developed into complex movement axes and permits realization of high-quality control systems. With electro hydraulic parallel guidance of excavators or loaders, for example, Temposonics offer high signal quality and simple analogue transmission due to screening and a short signal lead.
|
|
|
|
|
|
PCFP24: a magnetostrictive Position Sensor as flat as a ruler
Position sensor manufacturer ASM introduces a new magnetostrictive position sensor with a unique extremely flat housing: the POSICHRON® model PCFP24. With a height of only 12 mm, the “flat pack” is suited for numerous applications in narrow installation environments.
POSICHRON® is an absolute, contact-free and wear-free measuring system designed for almost all industrial applications. The PCFP24 has absolutely no protrusion in form of screws, connectors or probes jutting out of the 12 mm construction. This feature makes PCFP24 best suited for applications in narrow installation environments.
The sensor can be installed easily by means of mounting brackets. With this design the sensor position can be adjusted over its whole mechanical length without any mechanical collision. The system is wear- and maintenance-free and features high shock and vibration resistance.
The PCFP24 is available with analog interfaces for voltage (10V) or current (4-20mA) output as well as with SSI or digital pulse output Start/Stop, which makes it possible to bind the sensor into subsequent electronics for bus systems. The sensors measurement range is up to 5750 mm.
|
|
|
|
|
|
Magnetostriction - A Milestone in Measurement Technology
The heart of MTS sensors is the ferromagnetic measuring element, also known as the waveguide, and a movable position magnet that generates a
direct-axis magnetic field in the waveguide. When a current or interrogation pulse passes through the waveguide, a second magnetic field is created radially around the waveguide. The interaction between the magnetic field in the waveguide and the magnetic field produced by the position magnet generates a strain pulse which travels at a constant ultrasonic speed from its point of generation, the measurement point, to the end of the waveguide where it is transformed into an electric pulse in the sensor element. The resulting signal is processed by the specialized electronics of the Temposonics sensor. With our extensive know-how of ferromagnetic materials, magnetic effects and ultrasonic processes, MTS remains unrivalled in performance standards for non-contacting position measurement of the highest precision.
|
|
The electromagnetic sensors induSENSOR are based on the well-proven inductive principle. They are employed both in single and large-scale applications.
The measurement ranges of the displacement transducers extend from a few tenths of a millimeter to over 600 mm. The actual measurement acquisition takes place without contact and wear free.
|
|
|
|
|
|
With our new Laser-Distance Sensors DLS-B you measure absolute distances up to 500 meters. Thanks to state of the art laser technology the DLS-B device measures with a precision of 1.5 millimeters. It represents a cost efficient solution even at extreme environment temperatures as low as -40° C.
The DLS-B is an optical measuring device. You can measure, maintenance-free, distances on natural and reflective surfaces. You determine positions on objects difficult to access or with very high surface temperatures. Just as well you can measure distances in an aggressive environment in an easy and accurate way.
Serial, analog and digital interfaces are standard features for the complete DLS-B product line. This enables you to easily connect the DLS-B to a control system (SPS, IPC or PC)
The DLS-B device runs in a “Stand-alone-mode” and independently executes all programmed functions. Thanks to the flexible range of functions an external display can be connected directly to the DLS-B device via interface RS232 or RS422. Via a digital input, measurements can also be activated from an external button or switch.
For easy configuration of the DLS-B devices, the necessary software is at your disposal
|
|
|
|
|
|
What is a laser?
Laser light consists of light waves of identical length which have a defined phase relation (coherence).
Laser systems also have a relatively small angle of radiation.
What are the distinctive features of laser systems?
Laser systems are used where detection of small objects or precise positioning is required. Due to the small angle of divergence this can be achieved over long ranges.
How dangerous are laser sensors?
Due to the small angle of divergence laser beams are focussed on a small area. The energy and power density on this area is extremely high. Depending on the technical data of the laser transmitter, this is a risk for human health, specially for the eye. ifm laser sensors conform to the Euro standard EN60825 and the international standard IEC60825. These standards describe the operation of laser systems. In the standard laser systems are divided in 5 classes.
ifm laser sensors are classified in the laser protection class 2. Thus the laser power, also in the setting mode is max. 1 mW. When the laser beam hits the human eye the eyelid is instinctively closed. When hitting the unprotected eye the laser beam must cause no damage within a time of 0.25 s.
|
|
“POTENTIOMETRIC” linear transducers, with resistive element made of conductive plastic, are suitable for applications on hydraulic and pneumatic cylinders, plastic moulding-, packaging, textile machines etc.
The available lengths are from 10 cm to 100 cm (according to the choosen model) with infinite resolution.
|
|
|
A comprehensive range of linear potentiometers covering strokes from 10mm to 1600mm. See information on the models SLS095; SLS130; MLS130; SLS190; SLS220; SLS320
|
|
|
Conductive polymer with 10mm linear effective travel for automotive and industrial applications. Colour coded leads 300mm in length. Standard spindle is 3mm diameter with a length of 29mm from fixing face. Other length are available upon request.
|
|
Hall sensors have proved to be the most reliable technology for revolution measurement. DIS has been using Hall technology for over 10 years in the Quadro-Flux series. There is choice from a range of I/O circuits and housing options to measure revolution up to 25 KHz. For direction indication or fail safe options we offer dual circuits for phase shifted signals.
Measuring range: 0 - 25 KHz max.
Supply voltage: 5Vdc of 10 - 30 Vdc
Output: PNP, NPN or totem pole
Temperature range: -25 tot + 150ºC
Protection class: < IP68 (submersible)
|
|
The UltraSensor has been designed as a next generation replacement of Proximity and Micro switch systems for monitoring spool movement in progressive divider elements.
A single model will work with all standard SMX and SMP divider blocks as a screw-on accessory without requiring special arrangement or modification to the spool.
The patented concept works by monitoring magnetic flux variations through a hall-effect sensor as the spool enters the sensing range. There are no moving parts which means the solid state device is completely wear free.
NPN and PNP connection options are standard within the same sensor.
|
|
Designed specifically for use in hydraulic and pneumatic actuator
applications, where the transducer is fitted inside the pressurised
environment. Can operate at pressures of 670 Bar and temperatures of +200C.
Seperate electronics module operates from 10-60Vdc.
Available in a choice of mounting styles (Internal or External), these
transducers can be supplied to suit actuator strokes up to 2000mm.
|
|
The POSIMAG length measuring system comprises an MR scanning head and a magnetic dimensional scale. The position is determined without contact and thus without wear or tear. This measuring setup supports resolutions in the µm range.
POSIMAG is suitable for linear, angluar and speed measurements.
Technical advantages:
Sturdy construction, contact-free and wear-free, shielded metal housing, protection category up to IP67, signal processing as standard with encoders, distance between the MR sensor head and the magentic strip up to 2 mm, measuring lengths of up to 30,000 mm.
Thanks to its special properties, POSIMAG is ideal for many industrial applications in the production of machinery, plants and precision equipment as well as research. For example: Metal and wood processing, manual tasks in handling systems, positional checks for linear units, quality-control systems for sheet metal, punches and presses.
|
|
|
|
