For highly varied applications JOVYATLAS offers the following load banks:
1. SMART LOAD: This type series, with a power spectrum of 5 to 15 kW, has been specially developed for mobile use.
2. Mobile Loadbank ML 500: This mobile load bank was conceived as a result of continuous dialogue with our customers about their wishes. The ML 500 allows load tests and examinations wherever they are required. The built-in three-phase load system for power up to 500kW consists of steel-grid resistors.
3. Load banks up to 1 MW: JOVYATLAS has designed a range of load banks with a power spectrum 100-1000 kW. The PLM-series load resistor is adjustable to a resolution of 1kW by utilising a control box. Thanks to the use of special high-grade steels the load steps have a very low temperature coefficient, so that the adjusted load stays almost constant even if the resistor elements increase in temperature.
4. Load container CONPower up to 7.2 MW: Particularly for diesel engine and generator testing, the demand for high-performance load banks has risen sharply. Therefore JOVYATLAS has adapted developed the "CONPower" load range bank. This product line consists of standard commercial steel sea containers in which the load unit and the whole control unit are configured for controlling the load bank.
|
|
|
|
|
|
Resistor Load Bank support power range : 1KW - 500KW
- Support both single and 3 phase resistors circuitry or any workable resistors circuitry that customer need for their application
- can handle very large current up to 1500A and high voltage requirement
- for Low Ohmic Resistance is needed, please tell the working Voltage and Duty Cycle. Different Voltage can cause different electrical current. And in turn different materials are needed to withstand the current and heat generated.
- Resistance, Current and Power Wattage can be adjusted according to application need
- low Inductive type is available
Our Load Bank can be customized according to your application need.
Options :
- Voltmeter, Ammeter and Wattage meter : digital / analog
- thermal protective device
- Cooling System - Cooling Fans and Water Cooling
- Power Switches / Contactor - with lamp indicator for the Load Bank control and Cooling Fan switching
- plastic wheels ( so that Cabinet can be moved around )
Prompt Delivery within 2-3 weeks worldwide delivery with Attractive Price!
There are more Resistance Load Bank photos in our website : http://www.mf-powerresistor.com
or e-mail to sales@mf-powerresistor.com
|
|
A variable resistor load-bank with fixed stages connected in parallel and switched in, as required, with an adjustable stage for fine trimming. Designed for testing equipment under load.
|
|
|
|
|
|
Welcome to Spohn Burkhardt
Our Products
Our production program includes a diverse range of controllers, control stations, resistors, starters, in addition to a broad spectrum of controls for all types of transport machinery, construction and shipping cranes.
Our comprehensive series production is customisable in many different ways according to specific needs.
Our Company
The firm was founded in 1920 by Karl Spohn and David Burkhardt and remains in family ownership.
Our highly motivated team strives to achieve maximum customer satisfaction starting with the first contact through to after-sales service.
Our recipe for success has remained consistent over the years – and effective:
flexibility in product development and reliability in production.
Quality standards
A high quality standard – and therefore the complete satisfaction of our clients is one of our most important aims.
This is confirmed by various certifications, e.g. DIN EN ISO 9001-2000, CCC as well as by national and international standards, IEC 947, EN 60947, CSA and UL
|
|
The Load Resistors (load banks) are the most technically advanced, most reliable and cheapest way to perform load tests on electrical power sources and are used in a variety of applications such as:
- factory testing of engine diesel generator sets
- periodic tests of stand-by generator sets
- UPS testing
- Battery testing
- Factory testing of turbines
The Telema load banks are designed and tailored to the customer’s requirements to optimize, technically and economically, the performances.
Specifically, the resistors can have the following characteristics:
- Fixed / portable / containerized / silenced installation
- Voltage up to 36 KV
- Use of resistive materials with low temperature coefficient to guarantee a stable load during the tests
- Incremental load steps of variable sizes
- Load steps adjustable through local and remote control systems
- Forced cooling ventilation
- Overtemperatures protection systems
|
|
|
|
