Simplex Type S
The general purpose standard, single basket filter with a quick-release cover for easy maintenance.
The design does not require specialised tools or knowledge, and results in a minimum of downtime.
Suitable for both liquid and gas applications.
Sizes: 1" to 12" bore, flanged to ANSI 125/250FF and 150/300 RF.
Can be drilled to BS tables and DIN standards.
Also available with screwed connections 1" and 1½" sizes.
Materials: Cast iron, cast steel and stainless steel, all fitted with cleanable baskets and inserts or disposable gas cartridges as required.
|
|
The 5000 series spin-on filter is commonly used to remove contaminates ingested or generated in hydraulic or lube oil applications.
Elements
- Microglass beta 75 in 1, 3, 6, 12 and 25 micron absolute
- Stainless woven wire 141 micron
- Cellulose 3, 10, 25 micron
- Water absorbing 3 and 10 micron
Features
- Housing material: Cast aluminum.
- Flow rates: 0-125 gpm
- Pressure: 250 psig.
- Temperatures: -65º to 250º F
- Port sizes: 1/2" to 1-1/2" NPT or SAE
- Bypass settings: 3, 5 ,15 and 25.
- Element cleanliness indicators: visual, electrical and gauge ports.
- Easy to install spin-on elements.
|
|
|
The designs offered in this filter series accommodate the need for a full range of port types and configurations. Working pressures range from 500 psi to 800 psi and are available with BetaPore or Coreless media.
|
|
Five separate port options provide for maximum design flexibility in the W080 filter series. Quick filter change outs are accomplished with the use of our
serviceable bowl ring assembly. The size and material configuration are will suited for todays demanding proportional and servo applications. Our standard
bowl drain plug helps relieve system pressure during filter change outs. Western Filter’s proprietary BetaPoreTM 5 layer media is offered in a variety of
PakTM and meets the HF3 automotive standard. Three different media grades are offered down to 5.1μ(c). WF elements core collapse options range from 150 to 3000 PSI. The differential pressure indicator line is designed to work with the wide assortment of bypass valves. Thermal lockout and surge control are two
key features incorporated in many of the valves.
|
|
|
BGTS return in-tank filters feature Parker's exclusive magnetic prefiltration core which collects ferromagnetic particles from fluid upstream of the filter element. This feature alone could save hundreds of dollars a year by protecting costly equipment from increased wear and malfunction by assuring that the fluid is as pure as possible when it leaves the filter. Even during bypass due to cold start up, contaminant is collected by the magnetic core, a feature of importance on any fluid power system.
|
|
