The flexible high performance heavy duty electric grease pump solution.
DUAL PUMPING MODULE
400cm3 (2x200cm3) pump modules installed in tandem configuration provide 400bar (5880 psi) and redundancy .
This allows the system to continue working even if one pump module becomes ineffective.
Sumo pump is suitable for large single line or dual line systems.
INSTRUMENTATION MODULES
Sophisticated add on instrumentation modules and options means even complex requirements can be met with off-the-shelf standard product.
QUICK SWAP SYSTEM
Both pumping modules can be quickly replaced from the front mounting of the pump. No pipe work needs to be disrupted meaning near-zero downtime during maintenance.
DUAL LINE OR SINGLE LINE IS EASY
The outlet plate fixing system has both Pressure and Return ports.
The outlets are directly compatible with Dropsa's electrical or pneumatic line inverters (including Modular version).
|
|
The Lubeplus GX is ideally suited to mechanical applications and plant used in the food processing, packaging and printing industries. Can accommodate systems with up to 200 lubrication points.
Lubeplus GX is designed to operate with Positive Dsplacement Units (PDU) or with Metering Flow units . The lubricator is available with a wide combination of condition monitoring features and a choice of 'with' or 'without' microprocessor control.
Gear Pump operation
Max. operating pressure 25 bar
Can pump Oil or fluid grease
Available in 3 or 6 litre reservoirs.
Supply voltages 110v or 240
|
|
|
The High-Speed Compact internal gear pumps offer heavy-duty design and small footprint for rotating equipment lubrication such as compressors and turbines. They are just one of many options that Viking offers for lubrication pumps. Others include gearbox lube pumps that pump in one direction regardless of shaft rotation, pump kits for OEM lubrication applications, and a variety of internal gear, external gear and gerotor pumps suitable for lube oil and grease applications,
|
|
|
|
|
|
BRAVO: THE SMALL PUMP PACKAGE WITH BIG FEATURES
This small pump package contains many innovative features exclusive to DropsA allowing fresh possibilities in lubrication systems engineering.
It is suited for not only for indoor industrial applications but also mobile plant and vehicle lubrication systems.
VARIO-DRIVE: THE INNOVATIVE SYSTEM
VARIO-Drive is a new power management system for the pump motor that protects and adjusts the pumping system electronically. That means increased reliability and greater lifespan of the pump motor as well as the ability to electronically adjust the pump output from 50% to 100% of its nominal value.
You will find that you are able to precisely control and engineer systems like never before.
NEW GENERATION CONTROLLER
The integrated next generation control system is a central to delivering these new solutions to the customer.
It allows five different ways to trigger and control the lubrication event in a system:
1. Time based interval: 0 min - 99 hours
2. Impulse Counter: 1 - 9999 cycles
3. Combined Trigger: both Timer and impulse counter
4. Impulse Driven: uses impulse input to determine both standby and operation mode (0-9999 impulses)
5. Remote Only: Acts as Slave to host machine.
|
|
The Electric barrel pump ready to be used on Progressive and Dual Line Lubrication systems.
The CannonPump has been designed to meet the requirement of designers that require a traditional barrel pump approach to system design when no compressed air is available.
|
|
Professional Two Speed 14.4-Volt Cordless Grease Gun
Lincoln’s new, heavy-duty 14.4-Volt PowerLuber gives you the power to lubricate just about anything, anytime, anywhere. It features a two-speed switch for high-pressure or high-volume delivery and a cycle indicator pin to monitor grease output. A “Smart” charging system delivers reliable power while its ergonomic grip and balanced design provide optimal user control and comfort. Other features include a hook for a shoulder strap, a built-in hose and coupler holder, and a slim, compact carrying case.
|
|
G Series Gear Pumps
G-series is designed for metering, booster, vacuum extraction, lubrication and transfer of a great variety of fluids in any industrial application. Continually updated, more than forty years of experience and development are invested in this series, making it the meeting point for quality and practicality.
Materials
Housing: Cast Iron G25
Rotors: Steel 39NiCrMo3
Bearings: PTFE on Stainless Steel
Sealing Elements: Various
Application
Viscosity: from 1CST to 1'000'000CST
Pressure: from 0BAR to 30BAR
Size: from 1.5cc/rev to 300cc/rev
Temperature: from -10°C to +240°C
|
|
Tuthill lubrication and circulation pumps handle many viscosities and sustain a constant flow at any pressure. With only two moving parts the internal gear design allows the pump to handle more viscosities than it's competitors.
Simple, Compact Design offers high efficiency and longer life.
Positive Reversing Action - The unique reversing feature allows the lubrication and circulation pumps the ability to reverse flow without the use of valves.
1000 Series
- Internal gear pump design
- Flow rates to 13.7 usgpm (3M3/hr)
- Pressures to 300 psi (20.7 bar)
- Multiple porting options with side ports as standard
- Cast iron construction
|
|
Tuthill lubrication and circulation pumps handle many viscosities and sustain a constant flow at any pressure. With only two moving parts the internal gear design allows the pump to handle more viscosities than it's competitors.
Simple, Compact Design offers high efficiency and longer life.
Positive Reversing Action - The unique reversing feature allows the lubrication and circulation pumps the ability to reverse flow without the use of valves.
L Series
- Internal gear pump design
- Compact and flexible drive options
- Available with positive reversing feature
- Flow rates to 13.7 usgmp (3m3/hr)
- Pressures to 500 psi (34.5 bar)
- Standard with single mechanical seal
- Cast Iron Construction
|
|
|
|
|
|
Battery Driven Grease gun LAGG 400B
Quick and easy grease filling
The SKF Battery driven grease gun LAGG 400B is a high quality grease gun suitable for lubricating bearings, machines, vehicles and other applications. Ergonomically designed and user friendly, the grease gun can be used with standard SKF grease cartridges (420 ml) or filled with approximately 500 cm3 (17 US.fl.oz) of loose grease.
Compared to hand operated grease guns, a 420 ml cartridge can be emptied in approx 10 minutes with minimum effort, resulting in significant cost and time saving
-Electrical operation and the ergonomic design of hand grip helps reduce operator fatigue compared to manual methods
-Easy-to-use one hand operation makes the grease gun user friendly
-Supplied with various electrical plugs and two power supply versions (230 and 110 V charger) makes it operational worldwide
-Battery operation allows use in almost all environments without use of a mains supply
-Long battery life of 1000 charging cycles helps reduce product life costs
-Refillable: grease filling nipple and de-airing valve allow filling up by filler or grease pump
-Safety valve setting set to 40 MPa (5 800 psi) helps increase operator safety
-Supplied with M10x1 nozzle, interchangeable with SKF hoses, SKF grease meter LAGM 1000E and other accessories
|
|
These hydraulic pump units are for the closed circuit lubrication of special machines.
They are tailor-made to designs developed with the design offices of our industrial clients.
The CMtec positive-displacement pump carries the lubricant in a closed circuit between the machine to be lubricated and the oil sump of the lubrication unit. The assembly forms a self-contained unit that may be mobile.
These units are fitted with :
· Closed oil sump
· Filler breather
· Suction tube with oil strainer
· Visual level indicator with thermometer
· Motor-pump unit
OPTIONAL EXTRAS
· Air cooler
· Filtration system
· Heated tube
· Pressure control gauge
· Other tailor-made options available on request
|
|
The New HDI Product Range - suitable for medium to large machine tools, fixed plant in quarries, steel works, coal mines, cement works and large cranes where a choice of lubricant from SAE 90 oil to NLGI grade 2 grease is required.
The Progressive Grease pump is an electrically operated pump, supplied with a 12/24v DC Internal controller with external digital display, which can be fitted with up to three pumping units. Available with 3, 6 ,9 and 15 KG reservoirs, delivering precise amounts of lubricant through progressive distribution blocks, providing the user with lubrication point versatility and reliability.
Progressive HDI Pump
Pumps Lubricants including and up to Heavy Grade 2 greases
Delivery pressure: 350Bar Maximum
Output: 4.2cc per minute per outlet.
|
|
| ... products without technical information |
| |
|
The High-Speed Compact internal gear pumps offer heavy-duty design and small footprint for rotating equipment lubrication such as compressors and turbines. They are just one of many options that Viking offers for lubrication pumps. Others include gearbox lube pumps that pump in one direction regardless of shaft rotation, pump kits for OEM lubrication applications, and a variety of internal gear, external gear and gerotor pumps suitable for lube oil and grease applications,
|
|
G Series Gear Pumps
G-series is designed for metering, booster, vacuum extraction, lubrication and transfer of a great variety of fluids in any industrial application. Continually updated, more than forty years of experience and development are invested in this series, making it the meeting point for quality and practicality.
Materials
Housing: Cast Iron G25
Rotors: Steel 39NiCrMo3
Bearings: PTFE on Stainless Steel
Sealing Elements: Various
Application
Viscosity: from 1CST to 1'000'000CST
Pressure: from 0BAR to 30BAR
Size: from 1.5cc/rev to 300cc/rev
Temperature: from -10°C to +240°C
|
|
Tuthill lubrication and circulation pumps handle many viscosities and sustain a constant flow at any pressure. With only two moving parts the internal gear design allows the pump to handle more viscosities than it's competitors.
Simple, Compact Design offers high efficiency and longer life.
Positive Reversing Action - The unique reversing feature allows the lubrication and circulation pumps the ability to reverse flow without the use of valves.
1000 Series
- Internal gear pump design
- Flow rates to 13.7 usgpm (3M3/hr)
- Pressures to 300 psi (20.7 bar)
- Multiple porting options with side ports as standard
- Cast iron construction
|
|
Tuthill lubrication and circulation pumps handle many viscosities and sustain a constant flow at any pressure. With only two moving parts the internal gear design allows the pump to handle more viscosities than it's competitors.
Simple, Compact Design offers high efficiency and longer life.
Positive Reversing Action - The unique reversing feature allows the lubrication and circulation pumps the ability to reverse flow without the use of valves.
L Series
- Internal gear pump design
- Compact and flexible drive options
- Available with positive reversing feature
- Flow rates to 13.7 usgmp (3m3/hr)
- Pressures to 500 psi (34.5 bar)
- Standard with single mechanical seal
- Cast Iron Construction
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
| ... products without technical information |
| |
... see all the products in the category
