AC and DC LVDT transducers to meet requirements of most single- and multiple-point industrial gauging applications as well as micro-displacement. Available with free unguided, captive spring return, and captive guided armatures. Features include rugged stainless steel construction, ranges from ±0.1” to ± 18.5”, and operating temperature from -58° to 257°F. Submersible underwater connectors are also offered.
|
|
LVDT instrumentation and OEM linear position transducers. The world’s first manufacturer of LVDTs, Schaevitz® has been designing LVDTs since the 1940's.
Originally known as Schaevitz® Engineering, the company was purchased by Measurement Specialties in 2000. Combining 60 years of design expertise and Measurement Specialties world wide low cost manufacturing facilities allows Schaevitz® to offer its customers the highest quality products for the most competitive prices.
The largest industrial LVDT sensor supplier in the world, Schaevitz® LVDTs are used to monitor and provide positional feedback for steam and gas turbine valve position, control roller gap and dimensional gaging. Its wide variety of catalogue AC & DC LVDTs and gaging heads are available for purchase online using our Sensor Select Program and will ship from stock.
In addition to supplying sensors for industrial applications, Schaevitz® has vast experience designing LVDTs for the aerospace industry supplying products for missiles, military and commercial aircraft, and even space rated LVDTs used in satellites.
|
|
|
The AF111 and AF145 ranges of high accuracy LVDT displacement transducers have been designed primarily for use in the ratiometric configuration (difference over sum), and have a very compact size, with stroke lengths from 5mm to 150mm.
|
|
|
Our wide range includes LVDT Displacement Transducers, Magnetostrictive Transducers, Non-contact Displacement Transducers, Draw Wire Transducers and Intrinsically Safe Systems.
|
|
• LVDT technology
• Measuring stroke from ±1mm to ±300mm
• Miniature transducers
• DC output (with external or internal electronics)
• Low cost version
• High temperature (200°C) version
• Submersible (100 Bar) version
• Custom design transducers
From checking the notes issued by an automatic cash dispenser to controlling the active suspension on the Thrust SSC, Solartron's wide range of LVDT displacement transducers measure to laboratory standards in the real world conditions of vibration, shock and temperature.
|
|
PENCIL PROBES WITH HIGH PRECISION POSITION TRANSDUCERS
The Red Crown pencil probes line developed by TESTAR, a MARPOSS division, to fulfil quality control requirements in the workshop is available in four variants:
Basic line:
A family of 52 standard models covering a measuring range from ± 0,5 mm to ± 5 mm. The pencil probes are supplied with full-bridge (LVDT) or half-bridge (HBT) transducer already calibrated for connection to any TESTAR electronic display units.
Compatible line:
A comprehensive list of probes covering the TESTAR standard measuring ranges with appropriate electrical connector and calibrated to comply with your existing electronic display unit.
Unplugged line:
The 52 standard models of the basic line can also be provided without connector. The user can add the necessary connector and perform the appropriate calibration to the electronics in use.
Soft touch line:
Pencil probes especially designed with very low measuring force to directly gauge delicate parts such as glass, TV tubes, car windshields and plastic material.
|
|
|
Small and compact sensors allow minute movements to be measured in situations where space may be limited.
|
|
Rugged environment applications
Watertight, submersible up to 600 bars, transducer for hydraulic actuators.
Rugged environment, sensors with guide and ball joint
Application : radioactive, offshore (ex ATEX), sensors for servo-actuators
|
|
Precise Position Sensing in Critical Defense Systems
ADS/Transicoil is a reliable and experienced supplier of aerospace and defense position-sensing feedback devices. ADS/Transicoil LVDTs have been proven in some of the most demanding systems and environments, including programs such as F-15, F-16, F-18, B-2, ATA/ATF, and Chinook helicopter, as well as tanks, spacecraft, nuclear-powered naval vessels and more. Similarly, ADS/Transicoil RVTs and RVDTs have been specified for airborne and ground-based fire-control systems, for aircraft flight-surface controls and as feedback components on electromechanical actuators and in fuel- and throttle-control systems.
As shown by this extensive program experience, ADS/Transicoil designs and manufactures to meet the most stringent requirements. Our facility is approved to MIL-Q-9858A and Boeing D1-9000. We are equipped and have the experience to undertake servo component, subassembly and system projects at any level, either as a prime contractor or subcontractor.
ADS/Transicoil position-sensing components and controls include the following:
• Linear Variable Displacement Transducers (LVDTs)
• Long-stroke LVDTs up to 36 inches
• Rotary Variable Transformers (RVTs)
• Rotary Variable Displacement Transformers (RVDTs)
• Synchros and resolvers
|
|
SX20M DIGITAL
Numerical sensor LVDT - High Performances
Integrated numerical electronics
Analogical and Numerical exit on M12 connector
Numerical compensation of the errors (drifts, not linearity)
Not linearity < 0,05% EP
|
|
DX20EL - Linear sensor LVDT
* Extended from measurement from 20 to 300 mm
* Technology LVDT
* Integrated electronics
* Analogical exit 0-10 V and 4-20 my
* External diameter 20mm
* Many options of assembly
|
|
|
Trans-Tek offers a wide variety of LVDTs for precision linear feedback. Both AC-AC and DC-DC styles are available with total strokes ranging from 0.010" to 60.0" and non-linearity’s of +/-0.10% to +/-0.50%. Free-floating core and spring-loaded versions are found throughout our product lines. You will also see special features such as vented housings for high-pressure applications and units that can be exposed to temperatures of 400°F. Please click the link below to visit our web site (www.transtekinc.com) and view full specs in PDF form.
|
|
Stainless steel construction
Extended from measurement of +-0,5mm until +-600mm
Exits in tension AC/DC or running 4-20 my
Sealing until IP68
Temperature of use: -30°C with +150°C
Various mechanical and many configurations model
|
|
| ... products without technical information |
| |
We offer a variety of displays from simple single-channel devices
to networked multi-channel MODULAR 600 systems.
|
|
Chart SX9130 (format Europe) makes it possible to condition all the types of sensors LVDT and RVDT: Half bridge 3 wire, differential 4,5 or 6 wire, ratiometric 5 and 6 wire
It is entirely personnalisable according to your application:
- Tension excitation (until 7,5V rms)
- Frequency of excitation (between 900Hz and 15.000Hz)
- Correction of dephasing
|
|
SERIES 1000 Oscillator/Demodulator
The Series 1000 Oscillator/Demodulators are designed and built to provide DC-in/DC-out operation for AC LVDTs. For additional stability of the output signal, these units are internally regulated. Two versions are available for AC transducers that are optimized for either 3 or 7 kHz performance. VDC or 4-20 mA output versions also available.
SERIES P010 PC Board Oscillator/Demodulator
The Series P010 OEM PC Board Oscillator/Demodulators are designed and built to provide economical DC-in/DC-out operation for AC LVDTs. For additional stability of the output signal, these units are internally regulated. Two versions are available for AC transducers that are optimized for either 3 or 7 kHz performance. The small size of this board makes it ideal for applications where space is limited. End-users will also enjoy a significant cost savings over our Series 1000 O/Ds.
|
|
| ... products without technical information |
| |
As well as the standard functions - preset, alarms, RS232 output, Max, Min, Difference, etc - Solartron digital readouts and dual digital displays boast a number of new functions.
For example, the new "Scaling Factor" function can be used to compensate for angled or lever operated probes, or diameter when measured in a V block. It also enables measurement of angles or squares.
Other new functions include the "Gauging Mode" - allowing global pass/fail evaluation of up to 30 scan channels -and "Max A +Max B".
Ergonomically designed for the operator, the DR700 can be used with multiple probe fixtures using either Linear Encoders, Digital Probes or a combination of both - making it a truly versatile addition to the Solartron "Orbit" range.
|
|
The new SI 3000 range of Controllers are specifically designed to operate with Solartron's extensive range measurement transducers, and/or third party transducers, such as pressure and temperature.
One of the main features is an intuitive menu-driven display, which can be programmed to display readings, set Limits/Alarms, Peak Hold, Track, or act as a Data Logger for inputs from one or two transducers
The SI 7500 is a multi axis metrology display that connects to a Solartron Metrology Orbit Network and accepts up to 16 Orbit Module inputs; such as Digital Probes, Linear Encoders and Analogue Input Modules. It features intuitive displays, helpful audio cues and user defined formulas. The SI 7500
also reports dynamic Min/Max measurements, provides SPC analysis from an integrated database and offers connectivity to PC's and other peripherals.
|
|
|
The Model 1003 Transducer Indicator has been specially designed to operate with both DC and AC style LVDTs. It can also be configured to work with our Series 600 & 605 ADTs. This meter features a 5-digit display, high speed analog output, and optional RS232 & relays.
|
|
| ... products without technical information |
| |
|
The Series D100 DC Dual Output Power Supply is designed to deliver a highly regulated voltage. This supply is ideal for transducers that require a regulated DC voltage for operation, and can also be used where a dual supply is required, such as with the Series 1000 O/D or Model 605 ADT.
|
|
|
|
