Micromag Magnetic Filter
Removes ferrous and para-magnetic contamination from coolants, lubricants, cleaners, hydraulic fluid and other industrial-use fluids.
CUTS COSTS
No consumables required, ever. No power required. Operating costs are minimal
No loss of fluid - no oil sodden cartridges to dispose of
Specialist disposal not required – contamination is removed as semi-dry cake which can be sold as scrap
No maintenance required - only operator intervention to clean
Reduce machine downtime, increased productivity
HIGHLY EFFICIENT
Sub-micron filtration efficiency: if the particle is magnetic Micromag will remove it
No pressure drop even when fully loaded with contamination
Capable of removing abrasives and non-magnetic material by means of heterocoagulation
REDUCED ENVIRONMENTAL IMPACT
Removed contamination can be recycled
Extends fluid life
Less fluid thrown away
Before you consider spending thousands of pounds on your next filtration system, consider Micromag.
|
|
|
|
|
|
Micromag HP Magnetic Filter
All the benefits of the Micromag magnetic filter but for high pressure applications, up to 80 Bar g.
Full stainless steel construction.
High-power neodymium magnet material.
Removes ferrous and para-magnetic contamination from coolants, lubricants, cleaners, hydraulic fluid and other industrial-use fluids.
CUTS COSTS
No consumables required, ever. No power required. Operating costs are minimal
No loss of fluid - no oil sodden cartridges to dispose of
Specialist disposal not required – contamination is removed as semi-dry cake which can be sold as scrap
No maintenance required - only operator intervention to clean
Reduce machine downtime, increased productivity
HIGHLY EFFICIENT
Sub-micron filtration efficiency: if the particle is magnetic Micromag will remove it
No pressure drop even when fully loaded with contamination
Capable of removing abrasives and non-magnetic material by means of heterocoagulation
REDUCED ENVIRONMENTAL IMPACT
Removed contamination can be recycled
Extends fluid life
Less fluid thrown away
Before you consider spending thousands of pounds on your next filtration system, consider Micromag.
|
|
Using high performance rare earth magnetic material and proven pole-concentrator technology the Filtramag offers an incredible 11,000 Gauss magnetic performance.
Filtramag is capable of attracting sub-micron magnetic particles and can be utilised on inline pressure feed lines as well as gravity fed systems.
Grinding, honing, lapping, boring & fine detail machining operations will all benefit from the use of this technology.
The unit requires no consumables, unlike the more conventional forms of filtration, and has no running costs. Simply install and the Filtramag starts payback straight away.
Units are available with port connection sizes of 3/4", 1", 1 1/2" , 2" & 2 1/2"
|
|
The AutoMag filtration system can be utilised on any machine tool to remove ferrous and para-magnetic particles that cannot be removed by conventional cartridge and membrane media.
The main benefits of using Automag compared to cartridge type filters are:
Low running costs
No maintenance costs
No downtime associated with changing filter media
No loss of fluid due to replacing sodden cartridges
No back pressure, even when the magnetic cores are totally saturated with contamination
No mess!
Because Automag attracts even sub-micron sized particles extending the useful life of the fluid.
Incorporating high intensity rare earth magnetic material, pole concentrators and proven magnetic circuit geometry, the rods generate controlled, deep reaching magnetic flux fields which produce a staggering 9,000 Gauss. These flux fields attract and retain any magnetic particles that are suspended in the fluid.
|
|
Fully automated stand-alone magnetic filtration system
PLC driven and hydraulically actuated to deliver dry ferrous contamination from fluids and coolants.
Use with neat and soluble oils in fine finishing processes e.g. grinding, honing and EDM, cleaning and spray processes.
Can be installed anywhere in the fluid delivery system between the dirty and clean tanks or fluid system, either on-line or off-line.
Large capacity, free-standing magnetic filtration system. 24 / 7 operation.
Modular system:
AF4 up to 350 litres / minute
AF8 up to 700 litres / minute
AF12 up to 150 litres / minute.
|
|
High gradient magnetic separators for capturing fine ferrous and paramagnetic particles in liquids and slurries
Main applications include ceramics and minerals processing industries to purify raw materials, such as ceramic bodies, silica and feldspathic sands and to upgrade quality of final product (purer, cleaner and whiter product)
Proven in practice to offer 30% greater separation performance than traditional WHIMS systems.
|
|
TYPICAL APPLICATIONS
EFS
Standard size housings available with 30 (590), 60 (250), 100 (149), and 150 (99) mesh (micron) reusable, stainless steel filter cartridges. Units measure 11.25" long and feature a 1" NPT intake and dual 1" NPT discharge ports (3/4" reducers provided).
FEATURES
Graymills Superflo filters are designed to overcome the typical pressure drop and reduced flow due to clogging that occurs with ordinary filters. A permanent magnet suspended over the intake port traps ferrous particles which find their way into the fluid, and diffuses the flow outward into the filter screen flutes. Filtered material is trapped on the inside of the removable/reusable stainless steel filter cartridge. To clean, just remove the cartridge. All the contaminants come out with it. Self draining. No wasted fluid or messy leftovers to deal with. Stainless steel filter cartridges are available in four different mesh screens.
|
|
|
Magnetic Filter for liquids. These are purifiers suitable for elimination of magnetic particles contained in any type of more or less fluid liquid. They allow removing obstructions in burners, gums, valves and further parts of the installation.
|
|
- Magnetic filter
- Easy maintenace an cleaning
- Housing in brass or bronze material
- Connection from 1/2" to 3" Gas-F
- Magnetic separator in Barium-Ferrite
- Basket filter AISI-304
|
|
|
Drop-in magnetic separator filters, designed for fluid tanks and reservoirs, pull fine particles out of fluids and hold them until the unit can be cleaned and dropped back in. Used in tanks or other containers having low to moderate flows. Direct blast of fluids over unit is not recommended.
|
|
|
|
|
|
These magnet filters are used to filter ferrous particles from liquids and they are frequently used in hydraulic circuits and cooling systems. The magnet system is constructed from ceramic magnets and the unit is built into a stainless steel (AISI 304) casing. For cleaning, the magnet system is simple to remove by undoing several quick-release fasteners. A special double-walled version is available for use in heated pipeline systems (for example, separating ferrous particles from molten chocolate and cheese). Bakker Magnetics magnet filters are available in a number of versions for special applications. For situations where extremely stringent requirements for ferrous separation have to be met and/or tiny ferrous particles (m region) have to be extracted, a system can
be fitted with Neodymium magnets (add "/01" to the article number). A special version is available for use in systems with high pressures. Sanitary models are also available for applications in, for example, the food industry. For processing large quantities of raw materials, heavy-duty versions can be supplied. These versions have a processing capacity from 1000 to 8500 l/min.
|
|
As pre-cleaners or main cleaners for subordinate applications and magnetisable chips, magnetic filters offer a good and reasonably priced filtration method.
Turbo Separator AG produces magnetic filters with flow rates of 100 - 400l/min.
Depending on the application area, these magnetic filters can also be built up in cascades.
Magnetic filters from Turbo-Separator can be installed as integrated components of a system or built on as accessory products.
Special requirements call for special solutions - we shall implement your wishes, with unconventional solutions if need be! (SE magnets)
|
|
Bunting General-Purpose Grate Magnets provide a properly configured, high-density magnetic field to trap and hold ferrous fines, fragments, and small metal objects. Stainless steel tubing and frames are welded into strong, integral units. They can be installed - or simply laid - inside hoppers, housings, and bins - and easily removed for cleaning. Grates are built for low-abrasion applications and should measure at least twice the size of your outlet opening, so as not to restrict product flow.
General-Purpose Grate Magnets consist of multi-polarity 1-inch diameter cartridges arranged on 2-inch centers. They're available in round, square, and rectangular configurations from 4" through 36" in size. They can be ordered without baffles for freer flowing materials, and with angular baffles for maximum magnetic protection.
|
|
| ... products without technical information |
| |
TYPICAL APPLICATIONS
EFS
Standard size housings available with 30 (590), 60 (250), 100 (149), and 150 (99) mesh (micron) reusable, stainless steel filter cartridges. Units measure 11.25" long and feature a 1" NPT intake and dual 1" NPT discharge ports (3/4" reducers provided).
FEATURES
Graymills Superflo filters are designed to overcome the typical pressure drop and reduced flow due to clogging that occurs with ordinary filters. A permanent magnet suspended over the intake port traps ferrous particles which find their way into the fluid, and diffuses the flow outward into the filter screen flutes. Filtered material is trapped on the inside of the removable/reusable stainless steel filter cartridge. To clean, just remove the cartridge. All the contaminants come out with it. Self draining. No wasted fluid or messy leftovers to deal with. Stainless steel filter cartridges are available in four different mesh screens.
|
|
|
Magnetic Filter for liquids. These are purifiers suitable for elimination of magnetic particles contained in any type of more or less fluid liquid. They allow removing obstructions in burners, gums, valves and further parts of the installation.
|
|
- Magnetic filter
- Easy maintenace an cleaning
- Housing in brass or bronze material
- Connection from 1/2" to 3" Gas-F
- Magnetic separator in Barium-Ferrite
- Basket filter AISI-304
|
|
|
Drop-in magnetic separator filters, designed for fluid tanks and reservoirs, pull fine particles out of fluids and hold them until the unit can be cleaned and dropped back in. Used in tanks or other containers having low to moderate flows. Direct blast of fluids over unit is not recommended.
|
|
|
|
|
|
These magnet filters are used to filter ferrous particles from liquids and they are frequently used in hydraulic circuits and cooling systems. The magnet system is constructed from ceramic magnets and the unit is built into a stainless steel (AISI 304) casing. For cleaning, the magnet system is simple to remove by undoing several quick-release fasteners. A special double-walled version is available for use in heated pipeline systems (for example, separating ferrous particles from molten chocolate and cheese). Bakker Magnetics magnet filters are available in a number of versions for special applications. For situations where extremely stringent requirements for ferrous separation have to be met and/or tiny ferrous particles (m region) have to be extracted, a system can
be fitted with Neodymium magnets (add "/01" to the article number). A special version is available for use in systems with high pressures. Sanitary models are also available for applications in, for example, the food industry. For processing large quantities of raw materials, heavy-duty versions can be supplied. These versions have a processing capacity from 1000 to 8500 l/min.
|
|
As pre-cleaners or main cleaners for subordinate applications and magnetisable chips, magnetic filters offer a good and reasonably priced filtration method.
Turbo Separator AG produces magnetic filters with flow rates of 100 - 400l/min.
Depending on the application area, these magnetic filters can also be built up in cascades.
Magnetic filters from Turbo-Separator can be installed as integrated components of a system or built on as accessory products.
Special requirements call for special solutions - we shall implement your wishes, with unconventional solutions if need be! (SE magnets)
|
|
Bunting General-Purpose Grate Magnets provide a properly configured, high-density magnetic field to trap and hold ferrous fines, fragments, and small metal objects. Stainless steel tubing and frames are welded into strong, integral units. They can be installed - or simply laid - inside hoppers, housings, and bins - and easily removed for cleaning. Grates are built for low-abrasion applications and should measure at least twice the size of your outlet opening, so as not to restrict product flow.
General-Purpose Grate Magnets consist of multi-polarity 1-inch diameter cartridges arranged on 2-inch centers. They're available in round, square, and rectangular configurations from 4" through 36" in size. They can be ordered without baffles for freer flowing materials, and with angular baffles for maximum magnetic protection.
|
|
| ... products without technical information |
| |
|
|
