3-jaw turning chuck / for lathes / quick-change / high-precision
3-jaw turning chuck
ROTA-S plus 2.0

... optimize ROTA-S plus 2.0 and adapt it to the task at hand with closed protection sleeve or depth stop. High precision delivery is ensured with the manual arbor, driven by chuck jaws. ...

3-jaw turning chuck / quick-change
3-jaw turning chuck
ROTA-S flex

... -jaw manual chuck with quick jaw adjustment and an extremely wide clamping range on mill/turn machines - Convenient jaw quick-change system. Minimizing set-up times and costs. - High ...

power chuck / manual tightening / 6-jaw / quick-change
power chuck
FG56Q

Rotational speed: 0 rpm - 2,500 rpm
Gripping force: 0 N - 9,500 N

The FG56Q is a quick change finger chuck manufactured by Kitagawa Europe. Specifically suitable for aluminium wheels with a diameter ranging between 13in to 20in, it features a jaw stroke diameter of 35mm and a maximum ...

See the other products
Kitagawa Europe Limited
lathe turning chuck / clamp / machining
lathe turning chuck
CRS 36

Rotational speed: 0 rpm - 7,100 rpm
Gripping force: 0 N - 36,000 N

The KIATAGAWA Europe CRS 36 is a short series collect chuck that is ideally suited for barfeed applications. This device is equipped with a quick change cap with safety lock that has a net weight of 8 kg. The CRS 36 can ...

See the other products
Kitagawa Europe Limited
lathe turning chuck / quick-change / clamp / machining
lathe turning chuck
CRS 60A5

Rotational speed: 0 rpm - 6,300 rpm
Gripping force: 0 N - 60,000 N

The ultra compact chuck CRS 60A5 designed for first operations is perfect for barfeeders' applications. It is capable of maximizing lathe work envelope because it has short length. Although it has a small ...

See the other products
Kitagawa Europe Limited
dead length collet turning chuck / machining
dead length collet turning chuck
DHF65-A5

Rotational speed: 0 rpm - 6,000 rpm
Gripping force: 0 N - 105,000 N

Kitagawa's DHF65-A5 or the Fixed Length series is specifically designed for an accurate and precise clamping. It has several features which includes a 4-65mm capacity, 0.5mm collet increment and a 4.5mm sleeve stroke. The DHF65-A5 has ...

See the other products
Kitagawa Europe Limited
3-jaw turning chuck / gripper / machining
3-jaw turning chuck
AS04M2C

The AS04M2C Multiplates allow multiple machining functions simultaneously with up to 6 grippers in a single plate. These tools are designed with an optional lock valve that can be detached and reattached in a particular ...

See the other products
Kitagawa Europe Limited
3-jaw turning chuck / through-hole / self-centering
3-jaw turning chuck
MC-SM

Outer diameter: 890 mm

Manual chuck OD.1600mm with 3 self-centering base jaws manually actuated thru-bore diameter 890mm;

See the other products
ROTOMORS
3-jaw turning chuck / large-diameter
3-jaw turning chuck
GD-M-3A

The GD-M-3A is a self-centering lathe manual chuck developed by Romotors Torino. It is supplied with 3 self-centering jaws though the manual actuator with independent ...

See the other products
ROTOMORS
4-jaw turning chuck / lathe / large-diameter
4-jaw turning chuck
G D-M-4I

Outer diameter: 800, 2,500, 1,200 mm

This 4-jaw hand-tightening chuck from Rotomors is designed with a manual platform that has 4 indepedent jaws. This tool operates using a manual actuator with single ...

See the other products
ROTOMORS
4-jaw turning chuck / large-diameter / high clamping force
4-jaw turning chuck
GD-M-4I-MT

Manual platform with 4 independent jaws by manual actuator with single screw, dead center and operating key Sizes: from dia. 800 up to 7000 mm- FORGED MATERIAL FOR LARGE DIAMETERS-GREAT ...

See the other products
ROTOMORS
4-jaw turning chuck / large-diameter
4-jaw turning chuck

Outer diameter: 2,500 mm

Strong clamping 4 manual independent jaws chuck For clamping of large round, square, rectangular or irregular parts HYDROSTATIC SUSTAIN for micrometric centering

See the other products
ROTOMORS
manual tightening turning chuck / 3-jaw / precision / high clamping force
manual tightening turning chuck
DURO-T series

Rotational speed: 1,100 rpm - 6,000 rpm
Gripping force: 23 kN - 320 kN
Outer diameter: 128 mm - 630 mm

... with the jaws retaining their accuracy if used on the same chuck always or when base jaws and top jaws are kept screwed together for recurring work. TECHNISCHE MERKMALE with jaw safeguard stiff chuck ...

See the other products
RÖHM
manual tightening turning chuck / 3-jaw / lathe / closed-center
manual tightening turning chuck
DURO-TA series

Rotational speed: 4,200, 5,400, 4,600 rpm
Gripping force: 185, 114, 73 kN
Outer diameter: 160, 255, 206 mm

The DURO-TA is a manual chuck developed by RÖHM. It is built suitable for applications that requires high tension forces, high concentric accuracy and reliable continuous repeatability. The unit features ...

See the other products
RÖHM
manual tightening turning chuck / 3-jaw / lathe / closed-center
manual tightening turning chuck
DURO TA-XT series

Rotational speed: 800, 570 rpm
Gripping force: 190, 185, 290 kN

... other large chucks, the DURO-TA XT is up to 75 % lighter and that way makes maximum utilisation of the machines potential possible and clamping of higher workpiece weights. Through the extended and easy ...

See the other products
RÖHM
manual tightening turning chuck / 3-jaw / 4-jaw / lathe
manual tightening turning chuck
ZS-ZSU series

Rotational speed: 850 rpm - 5,500 rpm
Gripping force: 27 kN - 105 kN
Outer diameter: 74 mm - 630 mm

... whole clamping range. With this ability, work-pieces with different diameters can be used for clamping without the need for shifting or changing jaws. The scroll is drop-forged and hardened. In order ...

See the other products
RÖHM
manual tightening turning chuck / 3-jaw / 4-jaw / lathe
manual tightening turning chuck
ZG Orange Line series

Rotational speed: 2,000 rpm - 4,500 rpm
Gripping force: 27 kN - 69 kN
Outer diameter: 74 mm - 1,250 mm

... mounting. - The jaws can be adjusted over the entire clamping range by turning the key. This allows workpieces with different clamping diameters to be quickly clamped - ...

See the other products
RÖHM
4-jaw turning chuck / stationary / through-hole / self-centering
4-jaw turning chuck
MPAF/4 series

Gripping force: 13,500 N - 206,000 N

Stationary 4-jaws-Clamping-Chuck, pneumatic-hydraulic - operating pressure: 12 bar pneumatic / 50 bar hydraulic - repeatability accuracuy: from 0.02-0.05 absolute - operating temperature: from 5°C to 60°C - operating ...

manual tightening turning chuck / clamp
manual tightening turning chuck
System SZ

Gripping force: 20 kN

... production. All involved components must fulfill a high degree of precision. One of the co-decisive link in this chain is the clamping device.

See the other products
EMUGE-FRANKEN
3-jaw turning chuck / heavy-duty / clamp
3-jaw turning chuck
System SM

Gripping force: 30 kN

... production. All involved components must fulfill a high degree of precision. One of the co-decisive link in this chain is the clamping device.

See the other products
EMUGE-FRANKEN
clamp turning chuck
clamp turning chuck
System SG

Gripping force: 10 kN

... production. All involved components must fulfill a high degree of precision. One of the co-decisive link in this chain is the clamping device.

See the other products
EMUGE-FRANKEN
3-jaw turning chuck / clamp / hydraulic
3-jaw turning chuck
System SM

Gripping force: 12 kN

... production. All involved components must fulfill a high degree of precision. One of the co-decisive link in this chain is the clamping device.

See the other products
EMUGE-FRANKEN
precision turning chuck / machining
precision turning chuck
System SG

The power train a complex system in the change of time If in the past a Maltese cross joint has been fully sufficient as typical transmission element, this has changed completely. The power transmission of a vehicle includes all components ...

See the other products
EMUGE-FRANKEN
hydraulic turning chuck
hydraulic turning chuck
HYDRO-FIX® series

ETP presents HYDRO-FIX NBC hydraulic clamping system. HYDRO-FIX® has been a proven performer for more than 15 years. HYDRO-FIX® is optimum for boring bars for driven toolholders, internal and external turning, ...

turning chuck
turning chuck
LBDF series

Outer diameter: 18 mm - 140 mm

The LBDF model is a clamping chuck developed by Siam Ringspann. It is specifically designed to cater applications with clamping diameters that range from 18 mm to 140 mm. This chuck ...

manual tightening turning chuck / 4-jaw / EDM
manual tightening turning chuck
FT 02110

Gripping force: 4,000 N

The FT 02110 is a hand tightening chuck, manufactured bu Ftool®. Its chuck system features a size of 50 mm, and a corrosion-resistant design. The unit can be used ...

4-jaw turning chuck / EDM / gripper
4-jaw turning chuck
FT 01334

The ER chuck 80P (FT 01043) is manufactured on a WEDM angle (FT 01338). It is developed based from the standards set for the fast clamping with set of F-tool stop beads. This device has an average height of 40 mm.

manual tightening turning chuck / 4-jaw / EDM / gripper
manual tightening turning chuck
FT 01043

The FT 01043 is a hand tightening chuck that is characterized by its susceptibility to corrosive substances. This manual chuck is engineered for systems ...

4-jaw turning chuck / EDM / gripper
4-jaw turning chuck
FT 01792

The FT 01792 pin center chuck is a reference system for the collet of electrodes and workpieces. It weighs a total of 1.54 kg. The tool is also used as the base of the F-Tool Pin ZeroPoint centering system. The centering ...

3-jaw turning chuck
3-jaw turning chuck

self-centering turning chuck / manual tightening / 3-jaw / machining
self-centering turning chuck

Manual self-centring chuck: It is possible to mount manual self-centring chuck.

3-jaw turning chuck / pneumatic / stationary
3-jaw turning chuck
STP

Outer diameter: 125 mm - 280 mm

Pneumatic chuck fixtures with built-in cylinder - Ø 125 - 280 mm - with THROUGH-HOLE Application/customers benefit Self centering chuck fixtures used on milling machines, machining centers or special ...

3-jaw turning chuck / clamp / machining
3-jaw turning chuck
ROTA TB2

Rotational speed: 500 rpm - 1,700 rpm
Gripping force: 115,000 N - 280,000 N

... reducing maintenance costs. In addition, an advanced lubrication system ensures constant clamping forces and particularly high process stability. Faster clamping processes To increase the processing ...

See the other products
SCHUNK
3-jaw turning chuck / quick-change / lathe / clamp
3-jaw turning chuck
ROTA FSW

Rotational speed: 3,500 rpm - 6,000 rpm

Rota FSW has got many features that can offer optimal function for precise and fast chuck changing on the machines that are turning. It has got many optimal features in it that makes it function in a ...

See the other products
SCHUNK
manual tightening turning chuck / 3-jaw / lathe / flange-mounted
manual tightening turning chuck

Rotational speed: 0 rpm - 4,000 rpm

... DIN 800. The chuck is fitted to a flange from the rear by means of screws and the flange is then mounted on the lathe spindle. Flange blanks must always be fitted first to the machine and then to the ...

riser turning chuck / clamp / machining
riser turning chuck
Unilock

Outer diameter: 80 mm

... also have clamping knobs attached for use in other Unilock chucks or the stacking version can be used for elevation and clearance. All chucks open and close quickly with a single ...

3-jaw turning chuck
3-jaw turning chuck

Outer diameter: 1,500 mm

Pratt Burnerd International have a worldwide reputation for the design and manufacture of manual and power chucking systems. The vastly experienced UK based team are equally at home with both standard and highly specialised ...

manual tightening turning chuck / 3-jaw / 6-jaw / 4-jaw
manual tightening turning chuck

Rotational speed: 2,700 rpm - 5,000 rpm

Pratt Burnerd has an extensive range of multijaw manual chucks manufactured from the highest quality materials. Products include: Standard accuracy chucks have bodies manufactured from ...

manual tightening turning chuck / 3-jaw / machining / precision
manual tightening turning chuck
MANOK

Gripping force: 80 kN - 150 kN

... already surprised many users who never would have imagined that this kind of quality could be found in a manual clamping device. The all-rounder of the manual vises In addition, you ...

manual tightening turning chuck / 6-jaw / lathe / clamp
manual tightening turning chuck
Alufix series

In addition to the proven 3- and 6-jaw manual chucks Witte now offers a new chuck, which offers additional advantages. It enables rearrangement of the jaws any way the user requires. ...

3-jaw turning chuck / EDM
3-jaw turning chuck
MacroJunior

Gripping force: 5,000 N

... 0.002 mm - Recommended tightening torque, manual chucks: 4 Nm. - Permitted torque for 25 mm holder: 10 Nm - Permitted torque for 30 mm holder: 25 Nm - Maximum flushing pressure: 15 bar* - ...

See the other products
SYSTEM 3R
6-jaw turning chuck / EDM
6-jaw turning chuck
Macro Standard

Gripping force: 6,000 N

... New, larger Z-references on the manual chucks - Compatible with oter Macro systems Facts - Repetition accuracy: 0.002 mm - Recommended tightening torque, manual chucks: ...

See the other products
SYSTEM 3R

How to choose this product

manual-tightening-turning-chuck

Manual chucks are mounted on a lathe spindle to hold workpieces for turning operations. It is actuated by a T-handle wrench inserted into the outside of the chuck body.

Applications

Manual chucks are found on all types of lathes. They also are used on rotary tables for measuring purposes or to hold metal pieces in place for welding.

Technologies

There are three different types of manual chuck:
- The scroll type is self-centering, using an internal scroll to move the jaws in and out.
- The independent type is usually has four independently adjustable jaws for holding irregularly shaped workpieces.
- The combination chuck combines the features of scroll independent types, giving the user more options for mounting workpieces.

How to choose

The nature of the lathe spindle mount must be considered when selecting a manual chuck. It is also necessary to choose between closed-center and through-hole models.
