State of the art video microscope system for Visual Inspection, Digital Image Recording, Non-contact Dimensional Measurement, Documentation & Reporting of any object in any location.
Application:
Visual Inspection and XY-measurement of:
- mechanical parts and assemblies
- wires, coils, filaments and cables
- leads, bores and cuts on printed circuit boards
- gluing and bonding
- cutting edge tools and wear-out in CNC machines
- fibres in paper and textile industry
- plastic parts and injection moulds
- metallurgical and welding examination
- micro cracks in aircraft parts, engines, turbine blades
- identification of pollen, insects, stones etc.
- crime investigation and forensic analysis
|
|
Kestrel is the first non-contact measuring system to combine quality control laboratory accuracy, repeatability and optical quality, with in-line speed and ease of use in one low investment system.
Kestrel utilises Vision Engineering's patented optical projection technology to give a high resolution, high contrast view of parts to be measured. In comparison to profile projectors/shadowgraphs or video-based systems, the Kestrel's high performance pure optical system gives crisp and colour true views of intricate parts of optically difficult colour and texture (metals, plastics, ceramics).
|
|
|
The attoCFM I has been developed to offer highest flexibility in order to enable adaptation of the experimental setup according to the customer‘s needs. This flexibility is realized by the modular beam splitter head which is positioned outside of the cryostat. Furthermore, the free-beam optical design allows to adjust the excitation and the collection port completely independent. Thus, filtering of the excitation and collection signal enables also applications as e.g. raman spectroscopy. The easy handling opens up new possibilities in quantitative surface characterization in the submicron range.
|
|
|
|
|
|
* Conventional Scanner
* True confocal point-scanning - real optical sectioning
* Extra large field of view (21 mm)
* 64 Megapixel images (8k x 8k)
* Beam park data acquisition
* Spot-bleaching FRAP
* Zoom and pan function
* Slow scan mode
* Up to 5 confocal channels simultaneously
* 2-channel SP FLIM (Spectral Fluorescence Lifetime Imaging)
* Resonant Scanner
* True confocal point-scanning - real optical sectioning
* Large field of view (15 mm)
* Zoom and pan function
* 16,000 lines per second
* 250 frames per second
* 25 frames per second 512 x 512
* Up to five confocal channels simultaneously
* Tandem Scanner
* Conventional and resonant Scanner in one system
* Switch by computer controlled super precision mechanical actuator
* Spectral Imaging Detector
* Five confocal channels
* True confocal point-scanning - real optical sectioning
* High dynamic sensors
* Low dark current PMTs
* High efficiency prism spectrometer
* Loss-free band selection
* Free tunable emission bands
* Any dye adaptable
* Five bands simultaneously
* Dye separation: sufficient for five channels simultaneously
|
|
Nikon now has a confocal solution to suit virtually every research need. From the all-new state-of-the art A1R/A1 to the modular and flexible C1 unit, Nikon can configure a confocal system that's ready to take on virtually any advanced research application.
Eclipse C1si Confocal
As research demands continue to grow, the need for greater detection of even more spectral information has become necessary, especially when discerning very similar or closely spaced spectral colors. The innovative C1si Confocal Microscope System gives you a level of flexibility, speed and spectral capability not available in conventional confocal systems, with detectors for both traditional fluorescence and spectral imaging in a wide range of applications.
|
|
Axio CSM 700
True Color Confocal Microscope
Fast. Precise. Contactless.
3D Topographies with High Resolution
Use the True Color Confocal Microscope from Carl Zeiss for materials research, quality inspection and routine applications.
Surfaces are displayed in three dimensions with high resolution and in true color. Topographical measurement at a speed of more than 100 frames per second leaves your sample untouched.
The easy-to-use software provides numerous analysis options, including roughness measurement, layer thickness evaluation and particle analysis. Save the captured images and measurement results as a report.
|
|
FRT MicroSpy Topo -
Winner of the German Industry Prize 2008
Application Versatility
Measurement of rough, reflective and transparent surfaces
High angular acceptance
Stitching mode for measuring field enlargement
The confocal measuring principle which comes to use in this system is an established, contact-free approach for the analysis of roughness, contour and topography in a multitude of lab and production control scenarios.
|
|
The new SurPhase HS® sensor from PhaseView allows very fast 3D measurement for the shop floor or in line production.
Roughness with Ra below 1nm or profiles up to 400 µm height can be measured in less than 1 second for 1M measurement points, with high accuracy and repeatability.
This new 3D optical instrument comes in a smart light weight packaging, and is totally insensitive to vibrations for use in any industrial environment. PhaseView offers both turnkey and OEM version to ease integration in automated inspections systems.
|
|
We offer a wide range of different microscopes for individual purposes.
Biological Microscopes, stereo Microscopes, stereo zoom microscopes, invers microscopes, camera- accessories.
|
|
|
|
|
|
MICROS Biological Microscope - Flower Series MC300
MC300Series breaks new ground in microscopy with excellent optical performance and impressive cost-efficiency. The variety of the MC300 series offers the ideal instrument for every application area and thus is able to meet with the individual requirements of the users.
MC300 ROSE is the standard model in the Flower Series with an excellent cost-performance ratio. Already the basic version is equipped with S-Plan objectives and Koehler illumination.
Available as 20W Halogen or LED version.
MCP300 EDELWEISS model for transmitted Light-Polarization.
MCX300 ORCHID model with ICO Plan Infinitive objectives to obtain high contrast images. ORCHID is particularly suitable for sophisticated scientific analysis and research.
ROSE and ORCHID are equipped with the unique glass stage. This ultra hardened glass plate has a abrasion and scratch resistant surface. Because of the frosted screen, it is possible to make a preselecting of the specimens.
For all models lot of accessories like different heads, photo/video equipment, transport case etc. are available
|
|
BINOCULAR OBSERVATION HEAD
- Binocular siedentopf head rotatable at 360° inclined at 30°.
- Diopter adjustment ring on ocular tube. Interpupillary distance from 55mm to 75mm.
EYEPIECE
- EWF 10X FOV 18mm
OBJECTIVES
- E-Plan Achromatic 4X
- E-Plan Achromatic 10X
- E-Plan Achromatic 40X(S L)
- E-Plan Achromatic 100X Oil(S L)
MECHANICAL BODY
- Co-axial focusing system. Pre-focusing lever & tension adjustment ring.
- The slow motion has 1Div=0.002mm.
- Quadruple nosepiece revolves on ball bearing.
- Mechanical stage size 125mm X 135mm having low positioned co-axial controls on ball bearing.
- Built-in-base illumination system with 6V-20W halogen bulb and power supply.
- Cross movement 55mm X 75mm.
SUB STAGE CONDENSER
- Abbe Condenser N.A.1.25 swing out filter holder, Iris Diaphragm.
BLUE FILTER
- Styro Foam Molded Pack.
|
|
|
|
|
|
Crocus II MCX100LCD
Computerized Real Time Digital Microscope
OPTICS:
Objectives: ICO Plan Infinitive 4x/0.10x, 10x/0.25, 4x/0.65 spring loaded and 100x/1.25 oil, spring loaded; Condenser: Abbé brightfield condenser n.A. 1.25; Eyepieces: EW 10x/20 widefield
MECHANICS
Body: Sturdy base, 300 x 70 mm; Head: Binocular/Trinocular Siedentopf head, 30° inclined, 360° rotatable; Nosepiece: Quadruple, reverse-angle mechanism; Stage: Double layer mechanical stage with innovative glass plate; Illumination: Koehler illumination, 6V 20W, adjustable for 110/220V
OPTIONS
LED illumination, different eyepieces, photo/video, phase contrast, darkfield attachment. Eyepieces securely lockable, aluminium case.
LCD SCREEN
• Real time live camera
• 8.4 inch TFT LCD screen (Touch Screen function)
• Resolution 800 x 600
• 2 Megapixel CMOS camera, real time camera USB 2.0
• SD interface, AV /VGA connection
• Image capture function
• Real time operating system WIN CE 5.0
• W-LAN, LAN function
• Video recording for MPEG-4
• MIC audio input, digital voice recording function
• Support audio output
• Keyboard, mouse input support
• Measuring function
With customary tables after many working hours you have the problem of scratched, blotchy surfaces. From now on this sad fact can be changed easily. As standard for CROCUS II, we provide a stage with an exchangeable, ultra-hardened, flexible glass plate which is resistant against abrasion, scratches and chemical fluids. In addition, the frosted screen makes the specimen visible and gives you the possibility to preselect your samples.
|
|
|
|
|
|
AM413MT - Dino-Lite X
The AM413MT handheld digital microscope comes with two unique features. One is that the housing is made of aluminum alloy. It protects the scope from extreme conditions where the normal Dino-Lite housing may not withstand.
The second unique feature on this metallic model is that it has an amazing yet easy to use MicroTouch trigger. The MicroTouch feature on the Dino-Lite gives users the option of taking a picture right from the scope itself. The MicroTouch was designed to minimize image blur while taking a picture with the microscope. Great for those moments when you need to take a picture, but having a hard time reaching the computer.
The AM413MT handheld digital microscope uses our high quality 1.3 megapixel image sensor that views and takes highly detailed images for professionals.
This unit provides variable mag. depending of distance with the highest mag. at over 200X.
Included with the Dino-Lite handheld digital microscope is a copy of the "DinoCapture" software, enabling you to "capture" either a photograph, video, or time-lapsed video within a few simple clicks. This model comes with the full version of DinoCapture software which includes measurement and calibration for greater precision work. As for all DinoCapture software though, updates with improvements to the software is always free.
Product Features:
Resolution:1.3Mpixels
Adjustable mag.: 10x~50x, 200x
Built-in 8 white-light LED illumination (s/w switchable)
MicroTouch snapshot
Frame rate: up to 30fps
Interface: High speed USB image transmission (PC)
Software: DinoCapture
Support OS: Windows Vista, XP Professional x64 Edition, XP, 2000, or Windows Server 2003
|
|
|
|
|
|
OBSERVATION HEAD WITH LCD SCREEN
Binocular observation head inclined at 30° rotatable at 360°. 8 inch LCD Screen. Built-in-digital camera with RCA, S-Video & USB-2 output with 3.1 Mega Pixel Resolution Internal media card reader/writer.
EYEPIECE
- Wide field eyepiece 10X (Paired) FOV 18mm
OBJECTIVES (INFINITY CORRECTED)
- M Long Working Distance Plan Achromatic 5X
- M Long Working Distance Plan Achromatic 10X
- M Long Working Distance Plan Achromatic 50X ( S L )
- M Long Working Distance Plan Achromatic 80X ( S L ) Dry
MECHANICAL BODY
- Co-axial focusing system with large knobs, PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.
- Reverse Angle quadruple nosepiece on ball bearing.
- Mechanical stage is 242mmX172mm.
- The Mechanical stage has low positioned co-axial controls on ball bearing guide ways.
- Hand rests on both sides.
ILLUMINATOR
- The Epi illuminator has 12V-30W halogen lamp, adjustable brightness.
POLARIZING OUTFIT
- Analyser rotatable 360o. Polarizing & Analyser can be slided in/out of the optical path.
|
|
|
|
|
|
AM413T - Dino-Lite PRO
The AM413T handheld digital microscope is designed with a high quality 1.3 megapixel image sensor that lets you view and capture objects with the greatest of details.
This model also releases all the features in the DinoCapture software. You can now do measurements on pictures taken with the Dino-Lite, and also you now have the ability to calibrate measurements for greater accuracy.
The AM413T handheld digital microscope can view objects at various magnifications depending of distance with a max magnification of up to 200X.
The AM413T handheld digital microscope is featured with the unique MicroTouch snapshot feature. The MicroTouch (touch sensitive static sensor) feature on the handheld digital microscope gives users the option of taking a picture right from the scope itself. The MicroTouch was designed to minimize image blur while taking a picture with the microscope. Great for those moments when you need to take a picture, but having a hard time reaching the computer.
This unit provides high resolution, professional tools, ease of use, and flexibility for the user.
Product Features:
Resolution:1.3Mpixels
Adjustable mag.: 10x~50x, 200x
Built-in 8 white-light LED illumination (software switchable)
MicroTouch snapshot
Frame rate: up to 30fps
Interface: High speed USB image transmission (PC)
Dimension:10cm (Height) *3.2CM (R)
Software: DinoCapture --With measurement & Calibration capabilities
Support Operation System: Windows Vista, XP Professional x64 Edition, XP, 2000, or Windows Server 2003
|
|
Med-Prax
Description:
Brightfield microscope for education and routine
Stand:
with quadruple revolving nosepiece
Method of contrast:
Transmitted light brightfield
Tube:
binocular, 45°
Eyepieces:
Widefield 10x/18
Objectives:
A 4/0,10, A 10/0,25, A 40/0,65 and A 100/1,25 (Oil)
Magnification:
40 - 1000 times
Object stage:
Mechanical stage 130x130mm
Condenser:
Brightfield condenser NA 1,25 with aperture diaphragm
Illumination:
6 V / 20 W halogen, continuous regulation
Accessoires:
Mains cable, 1 spare bulb, 2 spare fuses, immersion oil, instruction for use, dust cover
Order number:
008.0314.0
|
|
|
Benchmark microscope for field inspection of fibre optic connectors for contamination or damage. Available in 200x, 400x and 200-400x zoom versions with adapters for all popular connector types the PriorSpec II offers a high degree of flexibility along with the highest image quality of its class.
|
|
|
|
|
|
AM413TL-Dino-Lite PRO(Long Working Distance)
The AM413TL digital microscopes unique ability is to examine objects at long distances. The model can magnify objects from 20X~90X, yet it gives most users great clearance to work under the scope. Great for situations where you need high mag. and extra room to work under. Such as repair work, antique inspections, machine vision, and much more.
The AM413TL can capture and record images at 1.3 megapixels, giving users the ability to examine objects with great clarity.
This model comes with the unique MicroTouch snapshot feature. The MicroTouch feature on the Dino-Lite gives users the option of taking a picture right from the scope itself. The MicroTouch was designed to minimize image blur while taking a picture with the microscope. Great for those moments when you need to take a picture, but having a hard time reaching the computer.
Included with the Dino-Lite digital microscope is a copy of the “DinoCapture” software, enabling you to “capture” either a photograph, video,or time-lapsed video within a few simple clicks. This model comes with the full version of DinoCapture software which includes measurement and calibration for greater precision work. As for all DinoCapture software though, updates with improvements to the software is always free.
Product Features:
*Resolution: 1.3M pixels (VGA)
*Adjustable mag.: 20x~90x
*Built-in 8 white-light LED illumination (s/w switchable)
*MicroTouch snapshot
*Frame rate: upto 30fps
*Interface: High speed USB image transmission (PC)
*S/W: DinoCapture (with measurement & calibration capabilities)
*Support OS: Windows Vista, XP Professional x64 Edition, XP, 2000, or Windows Server 2003
|
|
POCKET MICROSCOPES
Features:
Distortion free magnification at powers up to 100X
Rugged and pocket size (.5ø x 5"/12.7 x 127mm)
High resolution color corrected glass lens
Comes with a leatherette carrying case
Lightweight 2 oz. (57g)
|
|
The KH-1300 digital microscope is revolutionary in that it achieves both the highest transfer speeds in its class and high-quality images at the same time.
An original CCD camera was developed exclusively to create the highest quality images.
As a result, high-resolution images can be transferred quickly allowing video to be observed on PC screens.
High quality imaging with cost effectiveness in mind.
|
|
Nicolet iN10
The Nicolet iN10 infrared microscope brings new simplicity, efficiency and cost-effectiveness to IR microscopy. The OMNIC™ Picta™ software user interface guides users through simple task-based procedures. Slide-View and the virtual joystick make loading, centering and focusing the sample a breeze. The Nicolet iN10 is fully operational without a separate bench spectrometer, saving money and space in the laboratory.
|
|
|
|
|
|
AM413ZT - Dino-Lite PRO (Polarizer)
The handheld digital microscope AM413ZT is a product extended from
handheld digital microscope AM413T by adding rotatable polarizer filter.
Simply by rotating the polarizer filter, the handheld digital microscope
AM413ZT could amazingly decrease the reflection glare to almost any extent, and could thus help the user see through the surface of fully or partially transparent materials, such as jewerly, skin, glass, and plastic, or see clearly the high reflectivity materials, such as metal or soldering. The handheld digital microscope AM413ZT could be very userful in some application including PCB, printing, machining, textile, jewerly, or skin care etc.
Product Features:
*Resolution: 1.3M pixels
*Adjustable magnification: 10x~50x, 200x
*Built-in 8 white-light LED illumination (software switchable)
*MicroTouch snapshot
*Frame rate: up to 30fps
*Interface: High speed USB image transmission (PC)
*Dimension:10cm (Height) *3.2CM (R)
*Software: DinoCapture
*With measurement & calibration capabilities
Support Operation System: Windows Vista, XP Professional x64 Edition, XP, 2000, or Windows Server 2003
|
|
GOLD MCXI700
Inverted Metallurgical Microscope
Inverted microscopes are used for inspection, analysis and testing of microstructure of materials. The special design is necessary for observing large and heavy objects, e.g. metallurgical or electronic parts which are integrated in a compact body without special and expensive sample preparation.
OPTICS:
Objectives: MET ICO PLAN 5x/0.12, 10x/0.25, 20x/0.40, 50x/0.75; Eyepieces: EWF 10x/22 high eyepoint
MECHANICS
Body: stable, sturdy base, 360 x 280 mm; Head: ERGO head with variable inclination from 5° to 35°; Nosepiece: Quintuple ball-bearing nose-piece; Stage: Plain stage with glass insert plate; Illumination: 6V30W halogen for 100 - 240V / 50 - 60 Hz
OPTIONS
Photo/video port for ERGO head, binocular or trinocular head, objective MET ICO PLAN 100x/0.9, WD 0.7 mm, various eyepieces, attachable mechanical stage, auxiliary stages, photo/video adapters, digital cameras, aluminium carrying case
|
|
Mantis Compact excels in the low magnification range for inspection or manipulation tasks where bench magnifiers have traditionally been used. Mantis Compact has a small footprint and low investment cost giving a superb price / performance ratio.
Patented optical technology allows operators freedom of head movement for superb ergonomics and hand-eye co-ordination, with the ability to wear glasses if required. Operators can increase productivity and improve quality, at an affordable price.
Mantis Compact offers: Superb hand-eye co-ordination for inspection and manipulation tasks; a choice of x4, x6 quick change objectives; Bright white, true colour, LED illumination providing over 10,000 hours of shadow-free viewing.
|
|
The VDM-E/Z™ is available with two interchangeable optics options:
- Patented Extended Depth of Field (EDF) Objective with on-axis lighting
- Zoom Objective with fiber optic ringlight and add-on lenses
The system is complete with fiber optic lighting and is available with a number of options to enhance its versatility. When inspecting small parts from any angle, VDM is the effortless clear choice.
|
|
MicroInspector II with microscope optic and big TFT
Inspection system for optical inspection with rigid endoscopes and microscope optics
The modular design allows all types of inspection using one system. This includes a sophisticated XYZ manipulator with a special object mount system, a MegaPixel camera set-up and an innovative Xenon lamp illumination system. One system provides both overviews and microendoscopic details.
|
|
The MBL3200 is an inverted microscope for identification and analysis of biological substances and cultures.
Plano eyepieces (10X) and infinitve plano achromatic objectives (4X, 10X, 40X) as well as a phase contrast unit (20X) in combination with a photo tube to mount photo or video cameras allow a versatile use in quality assurance, raw material analysis or biological research.
Illumination: 6 V 30 W, with top-quality double-lens condenser. Power supply 90 - 240 V for worldwide use.
|
|
SUNDEW MCXI600
Inverted Biological Microscope for Routine Examinations
SUNDEW is a perfect microscope for routine examinations of cell and tissue cultures, as well as for sediments and different liquids. Easy observation of living cells. The large stage gives enough space for bulky culture flasks. Both transmitted and reflected light observations are possible.
OPTICS
Objectives: ICO PLAN Infinitive for brightfield or phase contrast observations, making the field of view flatter and brighter; Condenser: ELWD brightfield condenser, n.A. 0.3; Eyepieces: EW 10x/22 extra widefield, high-eyepoint
MECHANICS
Body: Sturdy high-tech cast aluminium base, 300 x 295 mm; Head: Binocular ERGO head; Nosepiece: Quintuple ball bearing nosepiece; Stage: Plain stage with glass insert plate and attachable mechanical stage; Illumination: 6V 30W (brightfield), HBO100W (fluorescence), adjustable for 110/220V
OPTIONS
Phase contrast, fluorescence, observation set for up to 3 people, photo/video
|
|
An inverted microscope that meets the demands of routine cell observation
The DX61 offers life science professionals convenience, performance and flexibility combining infinity corrected optics with innovative mechanical design and isparticularly suited to most tissue culture applications.
Outstanding optical performance
Infinity optical system
Ergonomically optimised and compact design
Optional ISIS Expanded-Pupil eyepieces increase eye-relief
Observation modes include brightfield, fluorescence and phase contrast, with a pre-centred phase contrast slider making operation straightforward.
|
|
Wilovert Standard PH 20
Description:
Standard equipment for investigations in transmitted light brightfield and phasecontrast
Stand:
quadruple revolving nosepiece
Method of contrast:
brightfield and phasecontrast
Tube:
binocular, 30°
Eyepieces:
Widefield 10x/18
Objectives:
A 4/0,10; A Ph 10/0,25; SPL Ph2 20/0,35;
Magnification:
40 - 200 times
Object stage:
210x235mm
Condenser:
NA 0,25 (brightfield and phasecontrast)
Illumination:
12V / 30W halogen, continuous regulation
Accessoires:
Spare fuse, filter VG 9, spare lamp 12 V / 30 W, mains cable, instruction for use, dust cover
Order number:
008.0305.0
|
|
|
|
