MICROS RAZOR
Manual Microtome
Made in Germany for MICROS!
The manual Microtome ensures day for day comfortable functionality. Highest precision allows a joyful using with greatest possible safety standard according class 4/MedGV.
Guaranteed reliability through over-extension protection and sliding-clutch anti locking system in the coarse advance. Over the total advance range highest precision of sections from paraffin or plastic blocks. Specimen changes are very easy to handle through advanced accessory design. Microtome lock conveniently integrated in the hand wheel.
The compact ergonomically design integrates a comfortable storage area for different handling tools.
TECHNICAL FEATURES
Micro and coarse advance movements are enclosed in housing. Section thickness adjustment possible from 0.5 µm to 60 µm in defined steps. Precise guide way and clamping device for knifeholder with optimum sliding capability and prism guide. Vertical stroke: 70 mm; Max. horizontal stroke: 40 mm. With object orientation unit, adjustable in X/Y axis as option, and object clamp with fixed upper jaw for max. specimen size of 55 x 55 mm. Knife holder base for different knife holders. Many accessories for different applications available. Length: 460 x width 460 mm x height 280. Weight: 35 kg without accessories.
|
|
|
|
|
|
