MINIDUMPER HS400 BATTERY
No smoke, no fuel, no noise, no pollution, environmentally friendly,
easy to operate.
|
|
|
|
|
|
MINI DUMPER HS1100 SILENCED VERSION ACCORDING REGULATIONS CE 2000/14
This is the ideal mini dumper for heavy-duty applications: it can be supplied in many versions and with many accessories that makes this machine unique.
Also this machine is silenced according to European regulations CE 2000/14
Main characteristics:
Loading capacity 1100 kg.
Triangle shaped with counterrotation tracks
Double travel speed
Hydraulic track tensioner
Operator’s footboard with shock absorber
Heat exchanger for the hydraulic oil
Auxiliary hydraulic power sockets
Document box
Honda petrol engine 13HP
Yanmar diesel engine 10 HP
Optional:
- Electric start
- Hydraulic widening of the undercarriage
- Hour meter
Interchangeable accessories:
• Construction bed with hydraulic tipping for building sites
• Self-loading construction bed with hydraulic tipping
• Self-loading dumper bed with hi-tip device for building sites
patented by HINOWA
• Self-loading concrete mixer
• Mini excavator
• Front blade
• Rhinetta standard with front bucket
• Rhinetta standard with agricultural shears
• Rhinetta standard with pallet forks
• Farm bed with hydraulic tipping for agricultural use
• Spray kit
• Log splitter
• Winch
|
|
|
|
|
|
|
The way chosen these last years by our company is that to be a partner technical and specialized in the solutions with the service of the building sites; since always we pay attention to the particular requirements of our customers in their offering the expertise of our technicians and the reliability of a mark which can be praised to have more than 60 years of experiment in its field. It is indeed accordingly of specialization and new achievements that we began, in 1991, the production of the first microexcavateurs, minichargeurs, and minidumpers. Compactness, power, mobility and robustness, here are the characteristics on which we based all our research with an aim of developing and to build these small but important syst¨me allowing to transport, dig and charge. Perfect for any type of work. Useful to save tiredness. Handy in exiguous spaces. Rapids and sharp moving. Forts, robust and compact, but especially available and adaptable to your requirements according to the multitude of sectors in which they can be used. It is also completely possible to transport our machines on any truck thanks to their reduced dimensions and with their lightness.
|
|
DUMPER D6
Loading capacity: Struck: 4500 l. Heaped: 6000 l
Payload: Kg 10.000
Transmission: Fully hydrostatic Bosch Rexroth with electric inverter
Engine: Diesel Perkins 1104C-44TA Turbo water-cooled, 107 HP
ROPS-FOPS cab closed on 3 sides
|
|
HYDRAULIC FRONTAL UNLOAD AND AUTOCARGABLE LOADS MAX.: 2.500 kg. ENGINE: 50 C.V. TRANSMISSION: HYDROSTATICS 4x4.
DUMPER autocargable. Hydrostatic transmission. Traction to four wheels. Engine Perkins, diesel, I shape 404-C, four cylinders, refreshed by water, power 50 CV. Hydraulic frontal unload. Hydraulic brakes. Electrical take-off and stop. Capacity of load 2.500 kg. Bulón of dragging. Plate hooks for installation of accessories (Retro, Mast). Protective roof of the driver. Intermittent top light. It counts hours. Acoustic adviser of reverse. Safety belt.
|
|
|
|
|
|
MUCK-TRUCK®
Muck-truck® the world's leader in mini pedestrian dumpers.
The mini dumper has been in production for over 16 years
The Honda engine comes with a 24 month warranty
Interchangeable accessories transforms dumper in seconds
Will climb up to 30° fully loaded.
Transports easily, no ramp required for loading the mini dumper into a van
The muck-truck® is easy to steer
Works well with a number of other appliances, such as mini diggers and cement mixers
Spare Parts readily available, can be delivered next day provided they are ordered by noon
Model: Muck-truck® - 4 Wheel Drive
Engine: Honda GXV 160, 4 stroke
Transmission: Tecumseh Peerless transaxle 3 forward / 1 reverse speed
Fuel: Unleaded petrol
Capacity: 6 cu ft. or ¼ tonne (250kg) carrying capacity
Noise Rating: 79db
Parking Brake: Disc
Wheels: Front 400 x 10, 4 ply tractive. Rear 400 x 8
Dimensions: Length - 155cm/61", Width - less than 70cm/28", Height - 85cm/34"
Weight: 110kg unlaiden
The muck-truck® power barrow is easy to transport and shifts loads quickly, it's ideal for:
Builders / Local Authorities - fast skip filling, easy to move paving slabs, bricks, rubble and waste
Landscapers / Gardeners - carry rolls of turf, soil, gravel, mulch and waste material, easily to the tip
Garden Centres / Nurseries - transport plants, rocks, trees, compost and bulky garden stock quickly
Farmers / Small Holdings / Stables - move straw and hay bales, feed, muck and rubbish without the back-ache
Plant Hire Shops - easy to use and easy to hire, a good return on your investment
All mucktrucks are CE marked and comply with European Health and Safety regulations.
|
|
MAX DUMPER
Model: MAX DumperTM - 4 Wheel Drive
Engine: Honda GXV 160cc commercial grade, 4 stroke, 5.5hp
Turned 180o, exhaust points to the rear. 24 Month warranty.
Transmission: Peerless transaxle 3 forward / 1 reverse speed
Fuel: Unleaded Petrol
Capacity: 8 cu ft. or 365kg/800lbs carrying capacity
Noise Rating: 79db
Tires: Four 10 inch tires and rear wheel hubs
Parking Brake: Disc
Wheels: Front 400 x 10, 4 ply tractive. Rear 400 x 10 pneumatic tires
Dimensions: Length - 64", Width - less than 28", Height - 36"
Weight: 130kgs unlaiden
ACCESSORIES
Flatbed
Tow Hitch
Snow Plow
Powerlift
|
|
|
Because of its compact dimensions and high agility the Bergmann Dumper 1160 as front tip is specially designed for the area of gardening and landscape design as well as the areas of cemetery technique and inside demolition. The hydrostatic drive unit and the payload of 1,600 kg provide effective earth movement in spatially limited working areas.
|
|
The Stanley MHP1 TracHorse is a carryall with hydraulic driven tracks, powered dump bed, and hydraulic tool circuits.
The Stanley MD10 Mini Dumper is a carryall with powered tracks.
|
|
850-1500 kg Articulated chassis
Articulated chassis dumpers with hydrostatic transmission.
1500 - 1750 kg Rigid Chassis
Robust and compact rigid chassis dumpers with frontal and hi-tipping or with rotating skip.
2000 - 3000 kg Rigid Chassis
Rough-terraing rigid chassis dumpers with an optional self loading shovel.
3000-4000 kg Articulated chassis
Articulated chassis dumpers with mechanical or hidrostatic transmission.
6000-10000 kg Articulated chassis
Articulated chassis dumpers with hydrodynamic transmission by torque converter.
|
|
|
The Bergmann compact dumper range offers the complete program for payloads from 700 kg to 8.5 tons. Nearly all applications like gardening and landscape design, cemetry care, inside demolition as well as the classical building construction and civil engineering are covered. Smaller and middle-sized earth moving sites in route transport and off highway are thus rationalised most effectively.
|
|
|
Capacity 2.500 kg Dump body capacity (level) 1 m3 Dump body capacity (heaped) 1,2 m3 Total weight empty (frontal) 1200 kg Total weight empty (with self-loading shovel) 1550 kg
|
|
|
The Bergmann compact dumper range offers the complete program for payloads from 700 kg to 8.5 tons. Nearly all applications like gardening and landscape design, cemetry care, inside demolition as well as the classical building construction and civil engineering are covered. Smaller and middle-sized earth moving sites in route transport and off highway are thus rationalised most effectively.
|
|
|
Capacity 2.500 kg Dump body capacity (level) 1 m3 Dump body capacity (heaped) 1,2 m3 Total weight empty 1300 kg
|
|
Compact enough to get round to the rear of houses/buildings. Low ground bearing pressure – can work in wet ground where wheeled machines would normally be immobilised.
|
|
