PreDyne specializes in giving each and every OEM the personal attention and company wide support that delivers the right, made-to-order fluidic system through the integration of pneumatic solenoid valves, miniature solenoid valves and manifold assemblies.
Each system and direct acting valve can be individually designed for your specific application. Whether pneumatic or liquid, cryogenic or high temperature, vacuum or high-pressure, we partner with customers to identify, create, and produce the best possible fluidic solution.
|
|
Whether you are performing blood chemistry analysis, drug discovery, DNA sequencing, liquid chromatography or precision fluid handling, there is a Kloehn Ltd. solenoid valve to meet your application needs. These valves are available with various body and diaphragm materials and feature high reliability, low power consumption, and complete chemical inertness. They are available
in 2-way, 3-way, manifold and other multi-port configurations.
80 Series 2-Way Miniature Inert Isolation valves
- 1/16" Barb
- Zero dead volume
- Very low internal volume
- Low power consumption
- Vacuum thru pressure service
- EPDM & CHEM-RAZ diaphragms
- Small size (1/2" diameter)
|
|
|
The Lee Miniature Piloting Solenoid Valve was designed and developed for use in aerospace hydraulic and fuel systems, oil tool applications, and other challenging high pressure applications. Incorporating innovative design and advanced technology it has set a new bench mark in space and weight savings and power consumption. The lightest version weighs under 0.14 lbs. (2.3 oz.) and uses only 7.8 watts at 28 Vdc. Each subcomponent and manufacturing process has been optimized to ensure a design with the highest performance, longest life, and highest reliability - all within the smallest envelope possible.
|
|
|
When medical device manufacturers require miniature, high speed miniature solenoid valves with extremely low leak rates for their FDA-approved instruments, they turn to Parker Pneutronics. Proven technical expertise and lean operations ensure that you will keep your technical risks low and your business results high.
|
|
|
|
|
|
KOFLOC PV 2900, 2910, 2920, 2930, 2940
The KOFLOC Small Proportional Solenoid Valve MODEL 2900 SERIES (U.S. P.A.F.) allows high-precision control of minute amount of fluids. It also has the lowest hysteresis in the industry, within 15% of full-scale current, making it ideal for automatic gas flow control in analyzers such as gas chromatographs, biomedical and other industrial applications. The annealed magnetic materials together with the specially designed flat spring (P.A.F.) completely eliminate flow fluctuations caused by vibrations due to wobbling plunger core or its frictions. The magnetic yoke of MODEL 2900 SERIES is annealed after machining, not bending, for improved magnetic flux permeability, resulting in greater magnetic force.
FEATURES
- Lowest hysteresis in the industry
- Low power consumption
- Special flat spring (P.A.F.)
- Superior resolution
- PWC (Pulse Width Coding) control possible
APPLICATIONS
- Analytical equipment
- Gas chromatography
- Industrial application requiring precision pressure control
|
|
|
Alcon 2-way General Purpose Small Solenoid Valves feature a compact design with a wide range of pipe sizes and available orifices. These valves are zero pressure rated. The U21 and U22 Series offer standard and optional valve materials for both the body and seals. Valves are offered with wire or DIN electrical connection. The class H coil insulation is suitable for continuous duty.
|
|
SIRAI® micro solenoid valves constitute a specific response to the growing demand for small size low power control components, created by the constantly increasing integration of electronics and industry. A natural development of general purpose solenoid valves, micro solenoid valves can control a variety of non-aggressive liquid and gaseous fluids.
In addition to maintaining an excellent balance between miniaturisation and reliability, the construction solutions adopted provide the possibility of disassembly for cleaning and maintenance.
Produced in 2/2 or 3/2 normally closed, open or universal service versions plus proportional control and latching versions.
The enormous range of models makes these valves suitable for several applications; the solenoid valves can be produced according to customized drawings and with materials and performances different from the standard models in the catalogue to meet specific or particularly complex requirements.
|
|
Size 15 and 30 miniature CNOMO solenoid valves
Features:
* Low power consumption 0,5W
* IP65 or IP67 protection
* Multiple electrical connections ( M12, DIN…)
* Possibility for gang mounting on joinable subbases
|
|
Size 15 and 30 miniature CNOMO solenoid valves
Features:
* Low power consumption 0,5W
* IP65 or IP67 protection
* Multiple electrical connections ( M12, DIN…)
* Possibility for gang mounting on joinable subbases
|
|
6 mm-slim diaphragm-isolated solenoid valve
KV Series
6mm Slim Design
This small valve enables you to reduce not only the installation space but also internal pipe length of your manifold by making it possible to mount at 6mm intervals.
- Capacity for Bilateral Connection
Easy to make manifolds
- Small Internal Volume
Only 10 micro liters (each port)
- Excellent Chemical Resistance
PEEK molded body and Perfluoroelastomer diaphragm
|
|
Model number JTV-2
Dimensions (mm) Dia.14.5 x H34.1
Type 2way-NC
Orifice Diameter (mm) 1.2
Port Connection Barb Type
Inlet Pressure (kPa) 0 - 80
Outlet Pressure (kPa) 0 - 10
Fluid Temp. Range 0 - 40
Voltage (V) 12DC
Power Consumption (W) 1
Operating Duration Continuous Duty
Coil Temperature Increase 50
Insulation Class E
Body Material U-Polymer
Seal Material FPM
|
|
|
Series mini-distributor LS04 M8 Connector industry, Ø4 connection, Ø6 XS 30 gr. 200 Nl/min AF 51 gr. 330 Nl/min Systems compact carry-distributor VTS LS04 330 Nl/min
|
|
|
|
|
|
2002 Series Valve
Modular reality, plug together flexibility in design! Sub-miniature 3-way and 4-way solenoid air pilot actuated valves. Available in manifold & base mount. Electronic interface options include DeviceNet, Profibus-DP, 1771 Remote I/O, and DeviceLogix.
Standard Specifications:
Cv: 0.20 to 0.25
Port Sizes: 1/8 NPTF, 4mm, 6mm
5 ported, 2 & 3 position, 4 way
Flow Capacity: 11.5 SCFM @ 80 PSIG / 246 NI/m @ 6 bar
Operating Pressure Range: 28" Hg. Vacuum to 150 PSIG / Vacuum to 10 bar
Pilot Pressure Range: 35 to 115 PSIG / 2.5 to 8 bar
Temperature Range (Ambient): -10°F to 115°F / -23°C to 46°C
2004 Series Valve
Modular reality, plug together flexibility in design! Miniature direct solenoid and solenoid air pilot actuated valves. Manifold mounting with DIN rail option. Electronic interface options include DeviceNet, Profibus-DP, 1771 Remote I/O, and DeviceLogix.
Standard Specifications:
Cv: 0.35 to 0.40
Port Sizes: 1/8 & 1/4 NPTF, 4mm
Flow Capacity: 16 to 18 SCFM @ 80 PSIG / 345 to 394 NI/m @ 6 bar
Operating Pressure Range: 28" Hg. Vacuum to 150 PSIG / Vacuum to 10 bar
Pilot Pressure Range: 20 to 115 PSIG / 1.5 to 8 bar
Temperature Range (Ambient): -10°F to +115°F / -23°C to +46°C
|
|
|
|
