Measuring Mixers type 30/50/350
Simulate production realistically on a laboratory scale
Brabender® measuring mixers are interchangeable measuring heads which, in connection with a Plasti-Corder® Lab-Station or Plastograph®, serve for testing the processibility of thermoplastics, thermosets, elastomers, ceramic molding materials, fillers, pigments, and many other plastic and plastifiable materials under practice-oriented conditions, cost-effectively, reliably, with little expenditure of time and material.
The measuring mixers consist of a mixer backstand with gear unit and a detachable mixer bowl. In addition to the electronic safety systems, they are connected to the drive unit through a shear pin coupling protecting both mixer and drive unit from damage due to overload.
|
|
The GBM is conceived as universal mixer for powders, fibres granules, liquid injection and reaction.
The GBM mixer includes a single mixing rotor. The mixing paddles are designed for high homogeneity and mixing efficiency. With a comprehensive choice of options, the GBM can be configured for many different processes including reaction mixing.
The mixing paddles rotate with variable speed. Froude numbers between 0.7 and 3.0 are reached. This mixer can therefore work in many different processes and working conditions.
The applications are the following:
Chemicals, Agro-Chemicals, Detergents, Plastics, Dyestuffs, Pigments, Plaster, Rubber, Glue, Food, Construction Chemicals, Industrial and Sewage Sludge.
|
|
|
|
|
|
Starting from the principles ‘faster and more compact’ and on the basis of the existing Vrieco-Nauta mixers, Hosokawa Micron has developed a new variant of the batch mixer under the name Vitomix.
Faster and more compact
The first striking aspect of the Vitomix is its extremely compact design. Thanks to a partly cylindrical form (instead of the completely conical shape of the Vrieco-Nauta mixer), the same volume is achieved with a considerably reduced structural height. A second important distinction of the Vitomix is the double ribbon screw used in the design of this mixer. In combination with the larger diameter of the screws, and therefore also a higher transport capacity per unit of time.
High transport capacity
The double screws, the higher rotational speed and larger diameter results in a transport capacity which is up to eight times higher and a substantial improvement in mixing efficiency. Even at lower linear speeds a much more efficient and therefore faster mixing process is achieved.
Two lump breakers achieve much higher efficiency
The two lump breakers (2 x 7.5 kW) are incorporated into the sidewall of the Vitomix mixer. Thanks to this double feature, more fluid can be injected without lump formation than is the case with a single lump breaker at the top. In addition, the design is adapted, achieving a much higher efficiency.
|
|
Cut your mixing time by up to 90%
A Silverson high shear batch mixer doesn't simply mix, it emulsifies, homogenises, solubilises, suspends, disperses, disintegrates solids and accelerates reactions. Each mixer, with its precision engineered Silverson rotor/stator workhead, far outperforms conventional mixers, cutting processing times by up to 90%, improving quality, product consistency and process efficiency.
Features include:
• Interchangeable workheads for maximum versatility
• Capacities from 4 to 30,000 litres
• Minimum aeration
• Models for open or sealed pressure/vacuum vessels
• Mobile floor stands
|
|
|
|
|
|
The Silverson AX range of High Shear Rotor/Stator mixers is designed to bridge the gap between laboratory scale mixing operations and larger production units. Ideal for pilot plants, research institutes and hospital pharmacies etc., AX models have a capacity of up to 50 litres, depending on product viscosity. A complete range of interchangeable workheads is available, allowing the user to match the unit’s mixing action to their process requirements. All AX range models can be supplied with a spring assisted adjustable bench stand.
The standard Model AXR is powered by a single phase motor, offering variable speed up to a maximum of 3500 rpm. All wetted parts are constructed in grade 316 stainless steel. The unit is finished in a tough, easy to clean, non-chip white nylon coating.
Increased power is offered by the AX3, which can be supplied with a range of 3 phase hoseproof, TEFV or ATEX approved Flameproof motors. With a maximum speed of up to 6000 rpm with an inverter, the higher rotor tip speed makes the AX3 suitable for more heavy-duty applications including particle size reduction.
The AX/AIR is powered by an intrinsically safe air motor, designed for use in flameproof areas. This 0.33 kW unit also offers variable speed up to a maximum of 3000 rpm.
The AXV has an inverted workhead, which draws materials downwards into the workhead from the surface of the mix. This was developed to overcome the problems traditionally experienced with light powders which tend to float or “raft”. The increased surface movement also makes the AXV suitable for some higher viscosity products.
|
|
The Vrieco-Nauta conical mixer is a convective mixer with a high mixing efficiency that treats your product gently and guarantees the highest level of mixing accuracy without any product distortion.
The Vrieco-Nauta conical mixer was developed more than sixty years ago. Since then, many product innovations have followed. The reliability of the design and performance that is known the world over is exhibited in countless installations in a wide variety of applications.
|
|
YTRON-Y ByPass system - Incorporation of free flowing powders without a tendency to stick of form lumps such as Silica, Active Carbon, HPMC, Cocoa, Flour, Carbon Black, can be drawn in below liquid level by the negative pressure created by the rotor/stator system. The venturi shaped stator and the negative pressure created by the flow it affects, draws the powder in, dispersing it instantly and homogeneously into the liquid. The formation of lumps is eliminated.
Certain powders with a low bulk density can be sucked directly and dust-free from a bag or other container.
Liquids such as S.L.E.S., concentrates, additives, and pastes can as well be pumped in via the YTRON-Y ByPass tube, directly into the turbulent zone in the YTRON-Y mixing head. They are then quickly and instantly diluted or dispersed into the batch. The mixing efficiency of YTRON-Y remains unchanged.
|
|
Disintegrator 2500
If you thought it couldn’t be done think again. Silverson’s mighty Disintegrator 2500 mixing system will disintegrate, solubilise or disperse the largest of solids - up to 40’ (1000mm) across – in a single operation and in times you wouldn’t believe!
The D2500 incorporates a powerful and unique Silverson mixer located in the bottom of a custom-built vessel. The mixer exerts a massive suction downwards from the surface of the liquid, pulling down even the most buoyant of solids, no matter what the size. These solids are literally ripped apart and dispersed throughout the mix, and with the refinement of a Silverson In-Line Mixer, included in the system, are totally solublised or suspended.
|
|
Sifter G 308
The smallest centrifugal sifter.
Capacity up to 500 kg/h at screen size 900 µ.
G 308 sifter is a compact designed and light weighted Centrifugal Sifter for a capacity range up to 500 kg/h with a 900 µ screen.
The G 308 sifter has been especially designed for applications where space is limited. Used prior to packing head, paint spraying and for particle classification.
|
|
|
|
|
|
The Duplex is an immersion mixer which consists of two rotor/stator workheads mounted on a single shaft. The upper workhead is inverted so that it draws materials down from the surface of the mix and subjects them to an initial coarse disintegration. The lower workhead then draws this liquid and solid material upwards from the base of the vessel and provides further high shear processing. This system can rapidly reduce solids to a fine particle size, resulting in considerably faster disintegration and solubilisation. The improved product movement produced by the two workheads also makes the Duplex ideal for use on high viscosity materials and for incorporation of powders which tend to float and are difficult to wet out.
The Duplex was originally designed for rapid disintegration and solubilisation of solid rubbers and polymers for the luboil and adhesive industries. However, the considerable advantages offered by the system has led to its introduction into other applications, including in the food, chemical, cosmetic, pharmaceutical and petrochemical industries. Duplex machines are available in a range of sizes from laboratory scale units up to the KDD, one of the largest immersion mixers in the Silverson range.
Typical applications include:
Rapid solution of rubbers and polymers into lubricating oils, solvents and bitumen
Disintegration and dissolving of solid resins into varnishes, inks and other coatings
Dispersion and blending of press cakes or filter cakes
Rapid incorporation of pigments and fillers
Recovery of waste sugar confectionery
Preparation of plant extracts
Disintegration of frozen meats, bone slurries, meat pastes/purées
|
|
|
The concept of the DISA Turbine Sand Mixer SAM is based on extensive experience and systematic trials. It considers all the aspects of modern sand preparation techniques and it creates the conditions for a perfect mix with uniform properties: by full homogenization of the sand and effective integration of water, bonding clay and additives.
|
|
|
|
|
|
Mixing highly abrasive materials such as ceramics, silica, mica, clays, chalk, graphites etc. can cause severe wear to mixing equipment, particularly on the bush and mixer shaft, reducing efficiency and leading to high maintenance costs and downtime.
Silverson offers a high shear mixer specifically for applications of this nature – the Abramix RBX series.
Silverson High Shear mixers are supremely efficient and can cut mixing times by up to 90% when compared to conventional agitators. The shortened mixing times obtained from using a Silverson mixer dramatically reduces the impact of abrasive materials. To enhance this advantage, the Abramix features a heavy-duty shaft which is firmly supported by two precision roller bearings, situated above the level of the product being mixed. The stability and vibration-free running which results from this arrangement removes the need for an immersed bush and reduces the wear to the mixer shaft. Rotor tips are specially hard tipped, further reducing the effect on wetted parts and the associated downtime and maintenance costs - minimum maintenance is a key feature of the design.
Another benefit of the Abramix model is dry running. Mixing of non-flammable products can continue uninterrupted while the vessel is being emptied, especially useful where suspensions need to be maintained or where thixotropic products are being processed.
Typical Applications
• Liquid Glazes - Preparation and Re-dispersion including Incorporation of Pigments, Wetting Agents, Hardeners, etc.
• Ceramic slips
• Clays and Silicas
• Texture Paints
• Foundry Compounds.
|
|
Inline Mixers Cut your processing time by up to 90%
A Silverson high shear In-Line static mixer doesn't simply mix. It emulsifies, homogenises, solubilises, suspends, disperses and disintegrates solids. Each mixer, with its precision engineered Silverson rotor/stator workhead, far outperforms conventional mixers, cutting processing times by up to 90%, improving quality, product consistency and process efficiency.
Features include:
Interchangeable workheads for maximum versatility
Self-pumping throughputs from 19 to 189,500 liters/hour
Aeration-free
Product cannot bypass the precision rotor/stator workhead
Single and multi-stage units available
Easy to install. Easy to operate. Easy to clean
|
|
|
|
|
|
YTRON-Z is a powerful unit for dispersing, desagglomerating, emulsifying, wet grinding and homogenising in a single pass. The reactor head of YTRON-Z houses up to three rotor/stator sets, carrying each 3 slotted rows of teeth with different slot widths to allow for adaptation to the specific application. Even shear sensitive products such as Yoghurt and sour cream are treated gently. This has lead to the development of the yoghurt STRETCHING ® process which revolutionised the process of yoghurt production.
The use of YTRON-Z for YTRONising of liquid products lead to results fully comparable to the products formerly processed via high pressure homogenisers, in some cases the results got even better at a significantly reduced production cost.
The use of special, shear intense tooling in continuous processing allows for production of emulsions (O/W und W/O) with a very fine particle size distribution or, in suspensions, an efficient wet milling or desagglomeration process. YTRON-Z is used in Food Processing, Chemical Production, Cosmetic Industry and Pharmaceutical Industry.
|
|
|
|
|
|
Silverson offers a range of High Shear In-Line mixers developed for the disintegration & solubilisation of polymers into bitumen for the production of modified bitumens. The cylindrical body walls are jacketed for oil heating, ensuring that the product cannot cool & solidify inside machines.
Because processing products that solidify when cold requires thorough heat saturation before start-up, the machines ensure heat reaches all areas where residue accumulates.
Sealing is by means of a graphite/carbon fibre gland packing, designed for operation on bitumens. Standard mechanical shaft seals are available according to the application. Like all Silverson units, interchangeable stators can adapt the machine for varying processes.
Modified bitumen production Polymers & rubbers such as SBS, APP, PVC, EVA & Butyl are blended with bitumen primarily used in the production of road surfaces & roofing felts. The polymers modify bitumen to improve its physical stability, flexibility & resistance to extreme temperatures.
Some polymers such as SBS are more difficult to dissolve/disperse & require high shear to achieve a satisfactory mixing time. Silverson Jacketed In-Line mixers attain this. The bitumen/polymer mix is recycled through the Silverson In-Line mixer where the high shear rotor/stator workhead rapidly disintegrates the polymer pieces. This high shear action exposes constantly increasing areas of fresh polymer to the surrounding bitumen, reducing the process time.
Typical applications: Polymer modified bitumen (production of modified road bitumen & roofing felts), Bitumen emulsions, Underseals & waterproofing compounds, Bitumen cable insulation
|
|
YTRON-XC powder dispersing unit. It is used for dissolving / dispersing of large quantities of solids such as Sodium- and Potassium-Caseinates, Milk Powder, Starch, Sugar, Silicates, Pigments and actives. YTRON-XC is used widely for the production of base mixes and concentrates before spray drying, in three shift productions.
Powders and compounds with a tendency to form lumps are continously incorporated from a BigBag or silo and efficiently dispersed inLine. The motor power used for standard applications typically ranges between 5,5 kW and 15,00 kW . This indicates the efficiency of the YTRON. The quantity of powders incorporated is up to approx. 12.000 kg/h, depending on the powders used.
|
|
|
|
|
|
APV Flex-Mix Liquiverter
The new mixing system for liquid applications.
With over 1,000 machines operating world-wide, APV’s highly acclaimed Liquiverter has been upgraded so that it is even better than before. It incorporates the following new and impressive features, and can now fulfil a wide range of mixing and dispersion applications with even greater efficiency:
* Highly efficient dispersion head for fast operation and improved end product quality
* Re-circulation pump as option
* Fully drainable for improved hygiene and minimum waste
* Direct drive reduces spare parts wear
* Flushed double mechanical shaft seal available in material of customers choice, depending on specific application
* Easy to maintain
Industry applications:
It can be used in an extensive range of applications within the processed food, dairy, beverage, healthcare, and other related hygienic industries.
Typical applications:
Newtonian/non Newtonian fluids
Solids / liquid dispersion (dry floating/settling solids)
Liquid / liquid dispersion (Miscible/immiscible liquids)
Typical operations include blending, mixing and dispersion of various ingredients. Such as mix preparation, incorporation of oils/fats, preparation of starch slurries, rehydration of powders, pigment dispersion, beverages and concentrate blending, and dissolution of dry material.
|
|
Compact and amazingly versatile, benchtop MixMate can be used for virtually any mixing application. It accommodates micro test tubes, PCR plates, deepwell plates and MTPs. It features an integrated vortexing function and an operating concept that is as simple as it is intelligent.
2DMix-Control: uniquely fast and controlled mixing movement
Current findings show that rpm speed is not the only determining factor in efficiently mixing small volumes. More often, the perfect mixing process occurs when parameters such as speed, type of mixing movement (e.g., orbital) and the mixing radius are optimized to smoothly run together. Eppendorf has perfected how these parameters interact in MixMate, and we have named this feature 2DMix-Control.
|
|
|
Silverson's line of laboratory mixers are suitable for the widest variety of applications - mixing, emulsifying, homogenising, disintegrating, dissolving - and will process volumes from as little as 1 ml up to 12 litres with an efficiency and flexibility unmatched by other machines.
|
|
Mixing is a remarkable net product!
When defining a production process, you will eithter choose a continuous or batch mixing process.
Being among the leading manufacturers of mixers for both kind of process, Gericke offers a range of reliable and scientifically proofed mixers.
Very often, we are working together with our customers to find the most satisfying solution. We invite you to visit our test lab for test running with your product to be used in a mixing process. Based on our experience in the fields of feeding and pneumatic conveying but also transport, recipe preparation and further transport of the final mixture, we are the right partner for a competent advice and consultance.
|
|
The Ψ-Mix® inline disperser combines a new dispersion method, in which the solid components are wetted on a large liquid surface, with emission- free, dust-free inline operation. The combination of vacuum dispersion, shearing and pressure wetting results in homogeneous, fine dispersions with very reproducible quality – all at high efficiency levels in a controlled process.
Because the machine is suitable for processing both low- and high-viscosity suspensions, it covers the complete spectrum of applications for dispersion technology. In addition, the design of the mixing zone makes it possible to process temperature-sensitive or dilatant materials.
Compared to conventional rotor-stator systems, this machine uses considerably less energy to disperse your products. The Ψ-Mix® is also easy to integrate into fully-automatic production lines for the manufacture of large batches and is particularly well suited and specially adapted for emission-free and explosion-proof operation.
|
|
Motor-driven mixers for the most exacting liquid mixing requirements.
PENTAX mixers are used where two mutually insoluble liquids must be continuously mixed into a stable emulsion, or where solids in suspension mst be dispersed as finely as possible in a viscous liquid.
Advantages
- Extremely fine droplet size and material distribution
- Low space requirement
- High shearing action and phase boundary area
- Rapid reaction rate for neutralization and other reactions
- Effective material exchange for reactions involving gases
|
|
PML (Planetary Mixer, low speed) and PMH (Planetary Mixer, high speed) planetary mixing and kneading machines operate according to the planetary system. They are used for thixotropic and high-viscosity products.
Temperature-sensitive products can be mixed gently with this system. Even powdered and very light components can be dispersed quickly in liquids, achieving an optimum fineness and distribution. To empty the mixing vessels NETZSCH supplies Container Press Outs.
|
|
Feature
1) This machine can mix all powder of powder is uniform.
2) The machine adopt outer-inner rotation and grain of powder is uniform.
3) The mixing barrel can be tilted freely at the angle of degrees for discharging and cleaning purpose.
4) The automatic stopping device can be set within the range of 0-60 minutes for automatic stopping.
5) Easy to operate, easy to wash, clean and move. It is very suitable for GMP food and pharmaceutical factories.
|
|
|
|
|
|
The water and powder mixer is composed of main machine boby and centrifgal pump water wheel,which are vertically installed.Through a double-layer wall pipe,the liquid materials and solid materials are separately pumped in,which can prevent them from agglomeraling before entering into the main body. When the liquid enters into the main machine body of mixer at high speed,vacuum will produce in the center of water wheel to suck the solid materials. The soild materials will be evenly sucked in through the regulation of valve under the doukou tank.It has brief design and multiple functions.lt can rapidly and evenly mix multiple solid materials without contacting the air.The mixing is enough and the product can be recycled. Under some conditions,use"online" and there is no need for recycling.Sanitary design and clamp connection with convenient assembly and disassembly.No need to dismantle any device during the cleaning and disinfecting.Mechanically close the valve to keep the inside sanitation.40°standard doukou tank.Specialty designed for manufacturers of dairy products and beverages,the equipment can be used to mix solid
materials and liquid materials in the production of syrup,Sorbitol,glucose,lactose and its side products,in the reduction of milk powder,in the solving into milk with cocoa powder or white sugar.in the solving of whey powder,in the solving into water wtih flour and starch,in the production of salt water and in the preliminary mixing of yoghurt and other dairy products.Wilh advanced design.fine manufacturing，high production efficiency and durable use,it has obtained stale patent.
|
|
|
YTRON-ZC powder disperser. Instantly wetting and thorough dispersing of extremely difficult to wet powders and concentrations of 50% and more, leading to highest yields in viscosity. Only a single pass is required to achieve a perfecly wetted product. Typical products to be processed are difficult to wet thickeners and binders such as CMC, Guar, Locust Bean Gum, Alginates, Carrageenan, Pectin, Xanthan Gum as well as other polymers with a tendency to form lumps such as Polyacrylic Acids, Carbopol ® etc. The wide range of YTRON-ZC types ensures that specific requirements from lab size up to production size for incorporating of more than 5.000 kg/h of powders is possible using the standard production range.
|
|
|
YTRON-PID (Powder-Inject-Disperse). The thickener or gelling agents is drawn out of a hopper, BigBag or a silo into an injection chamber where it is pre-wetted by the liquid phase. This pre-wetting process is designed to occur without product hold-up. The forced passage through the rotor/stator system ensures a perfectly wetted out product. A pump installed downstream achieves a controlled discharge of the product. The tendency of powders to stick or form lumps on the contact surfaces of the powder/liquid injection chamber is totally eliminated during either continuous or short process intervals. Typical applications are: Alginate, Blanose ® Carbopol ®, all powdery MC or CMC types, Guar, Xanthan, Neutragel ®, Polyelectrolytes, etc.
|
|
Silverson's new hygienic series of High Shear Bottom Entry Mixers are designed to fit into the bottom or side of a mixing vessel. These high shear mixers are typically used in conjunction with a slow speed anchor stirrer or scraper unit for high viscosity products. The Silverson Bottom Entry mixer gives high shear homogenisation while the stirrer/scraper distributes the homogenised output uniformly through the vessel. This is ideal for high viscosity cosmetic, pharmaceutical and food products.
Bottom Entry mixers can also be used by themselves on low viscosity products and to wet out powders.
Silverson Bottom Entry Mixers offer full compliance with 3A, USDA and GMP requirements.
|
|
|
|
|
|
YTRON-Y rapidly and homogeneously mixes, without aeration, liquids and moderately viscous products. The standard production range includes five different group sizes, with power ranging from 0,25 kW to 55 kW. This corresponds to vessel sizes of up to several million liters volume.
By selection of the suitable mixing rotor, either gentle mixing or intensive shear is applied to the product, but in all cases the mixing action will be very efficient.
The robust construction means that it does not require bearings or seals in the immersed part and therefore involves no hygienic risc. Hygienic execution with surfaces up to mirror polish are available. The use under ATEX conditions is no problem, providing is has been respected in the engineering phase of the project.
Typical use is in the Food, the Chemical , Pharmaceutical and Construction Industries.
Additional services are the supply of hoists (wall mounted, floor mounted or mobile) with manual, electrical or pneumatic drive.
Optional: Support for fork lift or tackle block.
|
|
Batch Sand Mixers
Batch sand mixers are ideal for mixing core sand. All components are mounted onto a heavy-duty steel base that reduces noise and vibration. The mixing tub is fully lined to extend the life of the unit. The durable, yet simple, design provides extremely accurate and efficient sand mixing. Batch sand mixers are designed for easy installation, low maintenance and consistent results.
Vulcan Engineering Co. can supply a standard model batch sand mixer or can manufacture a mixer for your specific needs. Please contact us for more details and information.
Features
- High speed, zero retention mixer head
- Fixed position direct drive mixing chamber
- Three part pumping system
- Recirculating pumps
- Dual resin levels
- Powder feeder for black iron oxide with 5 cubic foot hopper
|
|
|
|
