Introduction
The MB3170 and MB3270 are advanced Modbus gateways that provide maximum flexibility for integrating industrial Modbus networks of all types and sizes. They are designed to integrate Modbus TCP, ASCII, and RTU devices in almost any master and slave combination, including serial master to serial slave, or simultaneous serial and Ethernet masters. A special priority control feature allows urgent commands to obtain immediate response. All models are ruggedly constructed, are DIN-rail mountable, and offer built-in optical isolation for serial signals as an option.
Features
• Configuration is exceptionally easy
• Slave mode supports 16 TCP masters and up to 62 serial slaves at the same time
• Master mode supports 32 TCP slaves at the same time
• Emergency request tunnels ensure QoS control
• Serial redirector function provided
• Embedded Modbus protocol analyzer
• Redundant dual DC power inputs
• Built-in Ethernet cascading for easy wiring
|
|
|
|
|
|
MGate™ EIP3000 series products can be used to connect DF1 devices and EtherNet/IP devices to provide Allen Bradley PLCs with remote maintenance capability. By supporting PCCC objects on CIP, the MGate™ EIP3000 can communicate seamlessly with Rockwell Ethernet devices. The EIP3000 protocol gateways come with either 1 or 2 serial ports to allow users to select a suitable gateway depending on the size of the network. The EIP3000 series supports up to 8 Ethernet/IP clients and 8 Ethernet/IP servers simultaneously; each client can send up to 16 requests at one time. Moreover, each MGate EIP3000 gateway supports four virtual serial ports for remote control over an Ethernet connection. OPC servers and SCADA systems can use these virtual COM ports to communicate with EtherNet/IP devices or DF1 devices through the gateway.
Features:
ÿPCCC objects for Rockwell Automation networks supported
ÿProCOM provides a virtual serial port for multiple DF1 and ››EtherNet/IP device communication
ÿ16 simultaneous EtherNet/IP clients/servers with up to 16 ››simultaneous requests per client
ÿSerial redirector function provided
ÿEmbedded EtherNet/IP and DF1 protocol analyzer
ÿRedundant dual DC power inputs
ÿBuilt-in Ethernet cascading for easy wiring
|
|
|
|
|
|
Solve most any Modbus conversion challenge with the MESR Modbus Gateway
MESR Modbus Gateways bridge devices on Modbus serial networks (RS-232, RS-422 or RS-485) with those on Modbus TCP networks, allowing seamless integration of any Modbus device. Each serial port is accessible over a LAN or WAN by up to 16 simultaneous Modbus TCP masters. All Vlinx™ MESR gateways feature auto detecting 10/100Base T copper and fiber optic connections.
Simple Installation and Setup
Removable terminal blocks simplify power and data connections
Slimline IP30 DIN mount enclosure minimizes footprint
Simple configuration through the built-in web server, or Windows configuration software
Built-in traffic monitor for instant verification of successful installation and simple network diagnostics
Optional pass-through Ethernet port eliminates need for additional Ethernet switch port
Optional Fiber Optic Ethernet connections for long-distance and total noise immunity
Features
Slim, Industrial Enclosure
Modbus Master/Slave Flexibility
Web Server Configuration Software
Complete Fiber Options Low Latency
High Throughput
Heartbeat Connection
Benefits
Save DIN rail space while maintaining industrial ratings
Modbus master or slave can be on any serial port or on the Ethernet port. Customizable to your application.
Program through web browser or local port. Same user interface; no training required
Connect to all fiber networks in your plant without converting to copper connections
View status in real time
Detects communication failures and automatically reconnects to keep the system online
|
|
|
|
|
|
FNL – for an optimum connection of fieldbus and Ethernet networks up to 100 Mbit/s.
FNL allows the connection to all PROFIBUS DP networks based on RS485 (up to 12 Mbit/s) and supports DP Master class 1/2 on the basis of DP and DPV1 services as well as DP Slave.
The access to FNL is carried out through a TCP/IP socket interface. The interface is operating system independent, completely unfolded and because of its quickness convincing.
The Ethernet based operation mode as MODBUS TCP/IP Slave provides easy integration of FNL as PROFIBUS DP Master into a large number of visualisation and control systems. The PROFIBUS DP based diagnostics and IO data are dynamically compiled into the MODBUS TCP/IP structure and do not have to be configured additionally.
OPC Server
The OPC Server directly connects FNL to all OPC-client-capable Windows applications. OPC is supported by all common SCADA, control, visualization, and process control systems.
Programming Interface
The FNL TCP/IP socket interface provides the exchange of the DP Slaves' process and diagnostics data as well as all DP/DPV1 Master class 1/2 and DP Slave services. So FNL can be easily integrated in any operation systems.
FDT 1.2 Communication DTM
FDT allows the standardized configuration of fieldbus devices via different bus systems like HART-Bus, Foundation Fieldbus, PROFIBUS DP/PA or Ethernet.
LabVIEW Driver
The driver can be integrated in a simple manner into every LabVIEW version due to its standard TCP/IP socket interface. Ethernet and PROFIBUS DP configuration are generated via full graphical tools, included in the delivery. The package also includes LabVIEW sample VIs incl. source code.
|
|
|
|
|
|
The Anybus- X-gateway® family consists of over 180 certified and proven industrial gateways connecting almost any two industrial networks. The X-gateway is a simple, easy to use gateway connection real-time Ethernet networks to almost any fieldbus.
Real-time Ethernet protocols supported:
• EtherNet/IP scanner or adapter
• PROFINet IO Device
• Modbus TCP slave
• EtherCAT slave
• HTTP Server
• FTP Server
• Telnet Server
• SMTP Client
Fieldbusses supported:
• Profibus master or slave
• DeviceNet scanner or adapter
• AS-interface master
• CANopen slave
• ControlNet adapter
• CC-Link slave
• Modbus RTU slave
• Modbus Plus slave
• Interbus slave
• FIPIO slave
Slave to Slave Gateway:
Many applications need to take two disparate independent networks with each having its own master control and allow them to exchange data. This happens where two PLCs need to exchange information. The X-gateway helps to accomplish this by acting as an I/O slave device on the fieldbus and Ethernet networks. Each master/client writes to the output table of the X-gateway on its network and then the X-gateway maps this data to the input table of the opposite fieldbus or Ethernet network where it can be easily read by the other master/client.
Master to Slave Gateway:
Many applications needs to interface field I/O devices to a controller that has a different fieldbus or Ethernet protocol from the I/O. In these cases, the X-gateway serves as a fieldbus or Ethernet master on one side while acting as a fieldbus or Ethernet slave on the other. The I/O data is polled from the field devices then mapped into the I/O table of the controller.
|
|
|
|
|
|
Anybus Communicator® is a family of certified and proven gateways, connecting automation devices via their serial interface to all major real-time industrial Ethernet networks. The Communicator enables industrial devices without a network interface to connect to all major real-time Ethernet standards including EtherNet/IP, Profinet, Modbus-TCP and EtherCAT.
The Communicator performs an intelligent conversion between the serial protocol of the automation device and real-time industrial Ethernet network.
The Anybus Communicator supports RS-232, RS-422 and RS-485 serial electrical signals without any change in hardware. This allows for connectivity to a broad range of serial devices. Typical serial applications include variable frequency drives, sensors, actuators, human machine interfaces, barcode readers, RFID readers and industrial scales among others. It is much more than just a standard tunneling gateway and provides full flexibility and extended connectivity options.
The Anybus Communicator is configured using a very simple Windows™ based software package that requires that the user simply fill in the blanks to match the protocol of the serial device it is connected to. Applications that require conversions from serial Modbus to real-time Ethernet protocols are even easier as a built-in software wizard guides the user through each step of the configuration process.
|
|
|
|
|
|
COMETH Range
Instant & direct serial connection over Ethernet TCP/IP network
Available in dongle, din rail & printed circuit format
Ultra small & compact size, COMETH-EMBD "System on a Chip" : 20x63 mm, RJ45 included
RS232, RS422, RS485, TTL interfaces depending to models, up to 250 Kb/s or 350 Kb/s (COMETH-FIELD) sustained data rate
Direct connection to any DTE serial device (e.g. PC computer) without adaptation cable (COMETH dongle only)
Support for TCP Client/Server, DHCP Client, TELNET RFC2217 extension, Telnet Server, COM port re-director (VIP), multipoint or point to point virtual link over UDP modes and MODBUS/TCP Client/Server, MODBUS/RTU & MODBUS/ASCII protocols
Scanning I/O for all PLC's running MODBUS/RTU & MODBUS/ASCII
Virtual COM port redirection software for Windows 2000, NT & XP (VIP)
Easy administration through the serial link or Ethernet (TELNET)
Multiple configuration tool for deployment in volume
Remote firmware download for easy upgrade operations
External power supply or remote-power supply depending to models
15 kV ESD protection (except COMETH-EMBD)
Metallic case (except COMETH-EMBD), CE industrial standards
Ethernet / RS 1500 Veff isolation (except COMETH-EMBD)
This new range of Serial over Ethernet TCP/IP servers is intended to connect to any serial equipments.
The high level of integration and its built-in protection make the COMETH range extremely reliable and the world's smallest module.
COMETH's technical characteristics make it a universal product at a very attractive price.
|
|
|
|
|
|
UP for an industrial strength painkiller?
Enabling communication from factory floor devices to PLC controllers just got a whole lot easier. The DeviceMaster UP industrial Ethernet gateway offers a flashable solution that configures in minutes via the web, allowing you to support the major industrial Ethernet PLC networks – EtherNet/IP, PROFINET, or Modbus/TCP – on a single platform.
Whichever protocol you need, the DeviceMaster UP provides an RS-232/422/485 software-selectable connection to an industrial Ethernet network.
By accommodating multiple protocols, the DeviceMaster UP provides an adaptable and flexible platform device integrators and distributors need to thrive in rapidly changing markets. It's the pain-free Industrial Ethernet solution that simplifies supply chain management and reduces expenses for you and your customers.
It's power over protocol.
DeviceMaster UP Highlights
DualConnectPlus™ Technology – simultaneously connect both serial and Ethernet devices to PLCs and/or applications. String, RFID, and barcode data filtering eliminates redundant data while extracting the RFID and barcode parameters.
Provide PLC connectivity to standard serial devices with flashable protocol support for EtherNet/IP, PROFINET, Modbus/TCP, and TCP/IP
Compact and hardened form-factor — wide -37° to 74°C industrial temperature range
Variable power input eliminates need for power converters
PortVision® enables user to view status, update firmware and resolve issues remotely.
RoHS Directive 2002/95/EC compliant
|
|
|
|
|
|
UP for an industrial strength painkiller?
Enabling communication from factory floor devices to PLC controllers just got a whole lot easier. The DeviceMaster UP offers a flashable solution that configures in minutes via the web, allowing you to support the major industrial Ethernet PLC networks – EtherNet/IP, PROFINET, or Modbus/TCP – on a single platform.
Whichever protocol you need, the DeviceMaster UP provides an RS-232/422/485 software-selectable connection to an industrial Ethernet network.
By accommodating multiple protocols, the DeviceMaster UP provides an adaptable and flexible platform device integrators and distributors need to thrive in rapidly changing markets. It's the pain-free Industrial Ethernet solution that simplifies supply chain management and reduces expenses for you and your customers.
It's power over protocol.
Highlights
DualConnectPlus™ Technology – simultaneously connect both serial and Ethernet devices to PLCs and/or applications. String, RFID, and barcode data filtering eliminates redundant data while extracting the RFID and barcode parameters.
Provide PLC connectivity to standard serial devices with flashable protocol support for EtherNet/IP, PROFINET, Modbus/TCP, and TCP/IP
Compact and hardened form-factor — wide -37° to 74°C industrial temperature range
Variable power input eliminates need for power converters
PortVision® enables user to view status, update firmware and resolve issues remotely.
RoHS Directive 2002/95/EC compliant
|
|
|
AS-Interface networks up to 62 field devices onto a single pair of wires that delivers both signal and power. Actuator Sensor Interface, or AS-Interface, was developed by a group of sensor manufacturers and introduced into the market in 1994. Since that time, it has become the de facto standard for discrete sensors in process industries throughout the world. AS-Interface may be used in hazardous process environments using explosion proof, tray cable, nonincendive and for nonincendive wiring protection concepts.
|
|
