The junction between standards, legers, transoms and braces is the core of ALTRAD plettac assco multidirectional system scaffolds. The junction enables quick and easy connection of load bearing items as well as reinforcing parts to each other with an enormous rigidity.
Flat disks are welded to the standards in equal distances of 50 cm. Ledgers/transoms and braces are connected to these disks by a system of casted heads and wedges.
Modular system scaffolds are suitable for industrial scaffold purposes where a bigger variety and larger capacities are required for birdcage scaffolds or special constructions.
ALTRAD plettac assco is supplying two different modular scaffolding systems:
Modular scaffold plettac contur
Modular scaffold assco futuro
Both systems are fully approved in Europe as well as in Germany.
|
|
|
|
|
|
The KT-Module scaffolding system
... is economical optimized through reduction of investment expenses, working hours, logistics, material, warehousing and transport.
... complies exceptionless to the requirements of the BetrSichV, DIN EN 12810 and DIN EN 12811.
... owns the unique german approval for façade scaffolds of class 4 with 3m fieldwidth.
... enables the practicable use of leading railing without additional parts.
... has no restrictions in choosing a point to fix the protective equipment against fall
Advantages and use:
The KT - Module "ONE FOR ALL" scaffolding system is suitable for every application.
No more investment in different scaffolding systems (for instance support and frame scaffolding).
Fewer parts and higher material durability signifies increased productivity.
Low start up investment costs with the possibility of system free plank use.
Decreased weight and assembly costs with fewer components.
The performance data of the KT-Module translates into higher load capacity, giving in addition potential material savings.
In façade scaffolding on the basis of higher knot rigidity a notable increase in load capacity on diagonal braces.
Feasible replacement of diagonal brace in facade scaffolding.
There are no "loose parts" on robust ledger, meaning less repairs.
Simple compulsion adjustments of the standard with one wedge strike.
Optional placement of inexpensive translucent PVC roof protection sheets and holders.
Technical safety optimized: "through placement of pure pipe ledgers" in conjunction with "self-securing plank system", "leading railing", and "dissolved frame construction".
|
|
MODEX
To be honest, there’s hardly anything that cannot be quickly and safely scaffolded with MODEX – large tanks as well as tall spires, mighty vaulted ceilings and intricate façades. Thanks to its versatile junction, MODEX adapts effortlessly to any shape, any ground plan and any height – and not only where façade scaffolds are required. For the construction of support structures, room scaffolds, grandstands, stages and stairways as well, MODEX has all the prerequisites.
|
|
|
|
|
|
PERI Modular Scaffolding – The system for difficult building structures
Scaffolding with standard components replaces tubes and couplers. The PERI UP Rosett node at a distance of 50 cm offers connection possibilities in all directions. Thus complex geometrical structures such as on historic buildings with bays and cantilevers, or towers and spire roofs, scaffolds can be erected economically.
The following versions are available:
PERI UP Rosett 70
PERI UP Rosett 100
PERI UP Rosett 150
Identical system and component dimensions make sure that you can combine T-frames and Rosett components in one structure. Because of the high load capacities of both versions, a simple rule for combining was enough to gain the approval from the site supervisors: Each part system is to be erected and anchored to the instructions on erection and use, no matter how they are combined.
Our customers are provided with a scaffold system whose supporting documents fully conform to structural stability and safe working regulations. In our instructions for assembly and use, which have been translated into numerous languages, the information is cleary presented.
PERI UP is a modular scaffold system which conforms to the European Standards EN 12810 and EN 12811.
|
|
