Moisture Measurement on Bulk Materials
The Moisture Meter LB 350 has been designed to measure the moisture content of a variety of different products.
For example:
- in bunkers
- on weighting tanks
- on feeding tanks
The large measuring volume of up to 1 meter in diameter assures a representative measured value.
|
|
|
|
|
|
The Portable Moisture Meter is a micro-controller based instrument that permits instantaneous nondestructive moisture measurement on all types of paper and paperboard.
For immediate, measurement of moisture on moving or stationary rolls, stacks, or reams of paper and paper board. The paper industry has long recognized the need for rapid on-line moisture measurement to assure efficient energy usage and a high yield of quality paper.
The instrument is built a rugged, portable instrument which truly excels in measurement accuracy. It measures the moisture of a variety of materials by determining its dielectric constant, which is related to its moisture content. Eight readings are taken and the average is displayed as one moisture reading. A new average is taken every half (0.5) second.
APPLICATIONS
bleached sulfite board • bonds • corrugating medium • creped wadding • disposable diapers• envelope stock • fiber mat • glassine• hardboard • jute • kraft • liner board • newsprint • nonwovens • paper • paper board • particle board (½” thick) • pulp sheets • roofing paper • sheet plastics (PVC and acrylic) • tissue • tobacco paper • toweling • tube sock ·waxed release
FEATURES
* Field Selection of up to 11 Calibration Curves Pairs
* Measures 0 to 15 percent Moisture Range
* Heavy Gauge Stainless Steel Rollers
* Double Sealed Precision Bearings
* Recessed Digital LED Display calibrated directly in percent moisture
* Internal electrical standard assures calibration accuracy
* Lead Acid Gel Rechargeable Battery
* Aluminum enclosure
* Calibrations programmed in micro-controller
* Complete with Automatic Battery Charger and Carrying Case
|
|
The Moisture Encounter PLUS is the fully upgraded replacement version of the world’s most popular and successful non-destructive moisture meter the Moisture Encounter.
The Moisture Encounter PLUS incorporates all the features and benefits found in the original Moisture Encounter such as:
- Non-destructive moisture measurement of wood, plaster, drywall, block, brick, roofing and most materials found in the building envelope using 3 ranges of sensitivity.
- Deep signal penetration to detect elevated moisture through most
covering materials such as Ceramic tile, Drywall, Carpet, Vinyl Flooring,
VCT, Floor Laminates, Wall Coverings, Roofing Membranes and Coatings without having to damage or puncture the materials being tested.
- Rubber electrode pads in direct contact with material being tested for better sensitivity and depth of signal penetration.
|
|
|
|
|
|
CONCRETE AND WOOD MOISTURE AND HUMIDITY METER
The complete instrument for moisture and humidity testing
of flooring incorporating 3 modes of operation.
• Digital Non-Destructive meter for measuring moisture
content…instantly … in concrete floors and floor screeds.
• Plug in Wood Probe to give accurate moisture readings
in wood from 7 to 40%.
• Plug in Humidity Probe for Relative Humidity,Temperature,
Dew-Point and Mixing Ratio readings.
CONCRETE AND WOOD MOISTURE AND HUMIDITY METER
The complete instrument for moisture and humidity testing
of flooring incorporating 3 modes of operation.
- Digital Non-Destructive meter for measuring moisture
content...instantly ... in concrete floors and floor screeds.
- Plug in Wood Probe to give accurate moisture readings
in wood from 7 to 40%.
- Plug in Humidity Probe for Relative Humidity,Temperature,
Dew-Point and Mixing Ratio readings
WOOD MOISTURE PROBE
The Tramex Wood Probe is a hand-held attachment designed to take precise measurements
of moisture content in wood and wood products when plugged into the CMEXpert. Using built-in
electronic probes, or optional interchangeable electrodes, the Wood Probe is easy to use,
extremely accurate, giving readings in 0.1% increments over the entire measurement range.
RELATIVE HUMIDITY (RH) PROBE
When theTramex RH Probe is plugged into the CMEXpert, it automatically changes to
Hygrometer Mode.The Tramex RH Probe provides the ideal solution for Measurements
of Humidity,Temperature and Dew-point in structural materials such as concrete flooring, walls
etc as well as the environmental conditions within the building or structure.
|
|
for measuring moisture content ...
instantly ... in concrete floors and floor screeds without the need to drill or damage the surface.
SCREEDS AND CONCRETE FLOORS MUST BE DRY BEFORE THE FLOOR COVERING IS INSTALLED
- Regular checking of moisture content during the drying out period of a new concrete floor or floor screed is important to ensure it has reached sufficient dryness to accept the floor covering.
- Excess moisture in the concrete could cause latent problems such as condensation or failure of the adhesive under the floor covering.
-The Concrete Encounter 4 will give you an instant reading of moisture content up to 6% concrete; up to 0 - 10 comparative on gypsum screed enabling you to make an informed decisions on when to install the floor covering.
- To use, simply switch on and hold the instrument firmly against the surface. As many non-destructive tests as you need can be carried out in seconds without the need to drill or damage the concrete.
|
|
The Aquamatic 5100 is probably the most accurate moisture meter on the market. It is based on recent research by the US Department of Agriculture and in their comparisons the new technology was about twice as accurate as one of the most commonly used grain moisture meters. In addition to moisture, the Aquamatic also determines specific weight and temperature.
Whereas previous moisture meters would need several calibrations per grain type, the Aquamatic only needs one calibration for all grains and oilseeds. And whereas previous moisture meters would need frequent calibration updates, you should never have to update the calibration in the Aquamatic. These improvements have been made possible by two important advances - the use of 150 MHz technology and the UMA (Unified Moisture Algorithm).
|
|
|
|
|
|
The Vaisala HMT360 Series for Moisture in Natural Gas incorporates Vaisala's proven HUMICAP® sensor technology.
With three probe designs to choose from, the HMT360 Series is flexible enough to suit your installation requirements. Compatible with most existing sampling systems, it is easy to replace old or malfunctioning devices. Designed for high pressure systems, these probes can be installed directly into pipelines, eliminating the need for complex and expensive sample systems. With its ball valve set, the probe can be inserted and removed in low pressure systems. The transmitter is easily configured, and delivered with a one week lead time.
The HUMICAP® sensors are not damaged by glycol, and can tolerate saturated conditions and contact with water without causing measurement drift. The sensors dry down rapidly after exposure to water in the process or ambient conditions. The HMT360 Series is rated intrinsically safe for Class I Division I environments.
The stable HMT360 Series has a one year recommended calibration interval, thus saving maintenance costs and measurement downtime. Probes can be changed in the field in just a couple of minutes!
|
|
|
|
|
|
Moisture Meter ( TECPEL 590)
Features:
1.CE-Mark approval
2.Portability and simplicity one-hand operation
3.According EN50081-1(97)
4.According EN50082-1(97)
5.Automatic power shut off for maximum battery life.
6.Jack socket for pin extension leads
7.Three lights to indicate moisture content in wood:
Green: "air, dry"conditions
Yellow: Slightly in excess of normal
Red: Excess moisture
8.Measuring principle is electrical resistance
9.Valox housing to withstand accidental drops
10.Attached carrying case
11.Applications:IndoorAOutdoorAFurnitureAEnvironment studies
TECPEL 590
Display: 3 LEDs and 3 1/2digit liquid crystal display (LCD).
Range: 8% ~ 28%(Reading above 28 indicate increasing levels of high moisture are not percent moisture content,)
The accuracy is +/- 2% from 8% to 28%
stated accuracy at 23 deg C +/- 5 deg C, < 75% relative humidity
Low battery indication: The "battery indication"is displayed when the battery voltage drops below the operating level.
Operating environment: 0°C to 40°C, 15 to 80% R.H..
Storage environment: -20°C to 60°C, 0 to 80% R.H. with batteryremoved from meter.
Accuracy: Stated accuracy at 23°C±5°C, <75% R.H.
Dimensions: 193mm(H) x 44mm(W) x 40mm(D).
Weight: Approx. 150g including battery (1.5VX4pcs AAA size).
Temperature compensation :from 0 - 40 degree C
|
|
|
|
|
|
Pin Type Moisture Meters for Wood
The Professional is a hand-held instrument designed to take precise measurements of moisture content in wood and provide comparative readings in wood by-products and various other building materials such as roofing, insulation, plaster etc.. The meter comes with "built in" 5/16 inch pins. Optional "plug in" hand held or slide hammer electrodes with various pin length options are available. The Professional is extremely easy to use providing wood moisture content readings up to 40% in 0.1% increments over the entire measurement range. Readings are displayed on the large clear-view digital LCD display.
The Professional offers a practical and accurate way of ensuring that wood is at a correct moisture level for its intended use, proving to be a vital tool for good quality control.
The Compact is a hand-held instrument designed to instantly and accurately measure moisture content in wood and provide qualitative readings in wood by-products and various building materials such as roofing, insulation and plaster etc.. The meter comes with "built in" 5/16 inch pins. Optional "plug in" hand held or slide hammer electrodes with various pin length optionsare available. The Compact measures moisture content which is then indicated on a clearly calibrated analog dial. The Compact provides a full range of readings up to 40% moisture in wood and 0-100 on color coded comparative scale for other building materials. This pocket-size, and versatile instrument offers an accurate, fast and convenient way of moisture measurement at a low cost.
|
|
|
The moisture sensor operates in accordance to the principle of "capacitance measurement". If required, either a metal plate or the conveyor itself can be used as a counter plate in opposite position to the sensor.
|
|
|
|
|
|
The Honeywell 4112 dew point transmitter represents a technological breakthrough in moisture measurement. Absolute moisture in processes at high pressure and temperatures up to 185 degrees Celsius (365 degrees Fahrenheit) higher than existing equipment is now a reality, opening the door to better product quality, improved thermal efficiency and longer process equipment life. The probe will also stand short temperature excursions to 204 degrees Celsius.
The H4112 dew point transmitter is a direct intrusion, FM approved dew point and dry bulb temperature transmitter for industrial environments. The transmitter measures dew point and dry bulb (process temperature) simultaneously with local indication and retransmitted 4-20 mA outputs. The transmitter is designed to meet the moisture measuring requirements of a wide variety of industrial processes. End-users can now measure moisture where they had previously been unable to do so because of temperature limits, contaminants and harsh environments.
Advanced probe/sensor design virtually eliminates temperature effects and parasitic capacitance interference. New advanced materials and sensor assembly techniques enhance performance in high process temperature conditions. H4112 also has superior tolerance to contaminants. Common solvents, dirt, oil and other pollutants do not affect the stability or accuracy of the sensor. Polymer coatings on the sensor have excellent environmental tolerance ensuring accurate and repeatable dew point measurements
|
|
SKYWATCH Agros
Features :
This device can measure the temperature and humidity in the bales of forage, straw, Andean and others, but can also be used in air, vegetation and granular materials (cereals). The device is equipped with a probe extrèmenent resistant stainless steel with a plastic sleeve and an ergonomic stainless steel tip. Can not be used in a liquid.
|
|
|
|
|
|
A Hand Held Instrument for Fast Accurate Measurement of Moisture Content in Solid Materials.
The James Instruments Moisture Master utilizes the latest electronic technology to measure the quantity of water within its sensing field. The unit has two modes of operation the pin mode, and search mode. In the pin mode, two pins are pushed into the material and a high frequency field is created between these two pins. In the search mode the unit uses a high frequency capacitive sensor to sample a large volume of the material, instantaneously. Changes in this electromagnetic field are directly proportional to the dielectric constant of the material through which it passes. As the dielectric constant of water is almost two orders of magnitude greater than most non-metallic materials, variations in this parameter can be correlated to the moisture content. After extensive testing of various materials, relationships between the change in this field and moisture content have been determined. These relationships have been digitized and implemented using the latest in micro-computer technology, thereby allowing the user the direct readout of moisture content for concrete, masonry, hard wood, soft wood, gypsum, and brick. The pin method has been found to be most effective in low density materials such as fir wood or pine wood. The search mode has been found to be most effective for higher density materials such as brick, masonry, gypsum and concrete.
|
|
|
|
|
|
Portable instrument ms1 Set AM
- Optimal for portable application
- Robust stick sensor for material measurement
- Accurate electrolytic measuring technology
- Hysteresis-free, repeatable meaured values
- Integrated climate parameter processor
Measurement instrument ms1 Set AM
Precision portbale measuring device for the determination of the relative humidity %rh in materials via the special SARK-sensor. Thanks to the integrated processor the instrument is capable to calculate further climate parameter of the Mollier-hx-diagramm (absolute humidity, dew point, temperature etc.).
Large and clear LC display with %rh, temperature and stable value signal. For the ms1 Set AM the established electrolyte measuring cell is used. This enables an accurate, hysteresis-free and long term stable operating of the device.
The ms1 Set M offers an optimal cost efficiency and is well suited for the on site measurement in materials.
Application areas:
Determination of concrete and paper humidity, textile and food industry
|
|
Provides actual moisture content readings in the range of 6 % to 40 % for wood and 0.2 % to 50 % for gypsum. A reference scale and colored LED indicators provide qualitative dry to wet readings on other materials.
- 3 separate scales for plaster/concrete, wood and gypsum/sheet rock
- Audible set point indicator alerts you when pre-selected MC is reached
- Averages up to 100 accumulated readings
- Digital LCD readout with auto-timer shut off
- Easy one hand operation using the integral electrodes
The integral electrodes penetrate a maximum of 5/16 inches. The PM-9622 accessory electrode is for testing roofing, insulation, or other soft materials. For greater versatility, any other BYK-Gardner electrodes can be attached via the built in connector; please order separately.
|
|
|
|
|
|
Protimeter Aquant Non-Invasive Moisture Meter
The Aquant has a digital display that is synchronized with a color-coded LED scale. The display shows the relative moisture level of the material under investigation on a scale of 0-999 and the color coded LED scale indicates the material%u2019s moisture condition. To use, the Aquant is simply held against the surface of the material under investigation. The relative moisture level is measured by radio frequency to a nominal depth of 10-20mm. There are no needles to mark the surface and the Aquant is not adversely affected by moisture.
Range 0 - 999 Relative
Display 12 - Digital LCD
Display 2 - 60 LED%u2019s
Hold Reading Feature
Depth of measurement-Up to ¾"
Case-Pouch with belt loop.
Power-9v (supplied)
Warranty-1 Year parts and labor
Features & Benefits:
Detects moisture directly in materials and below wall and floor coverings such as tile, wood and vinyl.
Reset reading for sensitivity adjustment
Not adversely affected by surface moisture such as condensation.
Dual Display LCD and LED.
Color changing LED's to show moisture condition.
|
|
|
Our digital moisture measurement method with a watch-dog function guarantees the highest accuracy by eliminating transmission errors. All measurements are shown in large digital and analog read-outs on the high resolution LCD. Soft-keys and a graphical user interface allow for easy and comfortable operation. Automatic temperature and long-term drift compensation as well as digital, and analog and alarm outputs are standard.
|
|
The MM710e is NDC Infrared Engineering's 8th generation on-line analyzer for the Foods Industry. It has been developed to give highly accurate real-time measurements of:
- Moisture
- Fat or Oil
- Protein
in a variety of foods applications. To view these, please click on "Applications".
The MM710e makes a complete measurement every 7.5 milliseconds which means that on a moving conveyor transporting food products, optimum measurement resolution is achieved, enabling the user to use the MM710e measurement output in closed loop process control.
What's more, the MM710e has been engineered to measure even when there are changes to the process or ambient conditions such as:
- Ambient lighting
- Relative humidity
- Product temperature
- Product height fluctuation
|
|
Integrated moisture and temperature measurement.
The Protimeter Grainmaster i is a highly versatile instrument to measure the moisture and temperature of crops. The meter is pre-programmed with 15 crop calibrations, each of which can be adjusted individually, if required, for matching with respect to commercially used instruments.
It is supplied with an integrated grinder-compressor unit that enables the user to take moisture readings in ground samples very quickly and simply. There is also a range of optional probes for measuring temperature in stored grain (GRN6046) and moisture levels in baled hay and straw (GRN6138).
The Grainmaster i is supplied in a pouch with grinder-compressor unit, grain cup, sample spoon, brush and 'Quickcheck'. In addition to the 0-100 relative scale, the 15 pre-programmed calibrations include: Wheat, Barley, Oats, Oilseed Rape, Canola, Linseed, Peas, Corn, Sunflower, Coffee, Soya, Rice, Sorghum, Paddy and Beans
|
|
HM8-PMC – Paper moisture measurement
pinless, quick and precise
The pocket-sized paper moisture meter HM8-PMC offers the ideal solution for mobile quality control in particular of kraft paper, packaging paper and coated paper.
Ideal for measuring the absolute paper moisture content and storage-related change of moisture in paper stacks and paper rolls.
A selector switch for the classification of different papers is located on the front end of the meter.
|
|
|
|
|
|
The Moistrex MX8000 Portable Paper Analyzer provides paper and board makers and paper converters with a fast, accurate measurement of moisture at-line or in the QC laboratory.
Its moisture range of 1-15% makes it ideal for testing finished papers and boards or measuring moisture at critical stages in paper converting such as pre-lamination of pressure sensitive adhesive materials or following re-moisturising.
The Moistrex MX8000 is very easy to implement: simply place a sheet of paper in the waveguide, close the lid and an accurate result is displayed within a few seconds.
MX8000 is available in two configurations, depending on the basis weight of the paper or board:
- MX8000-T80 for lighter papers 30-400 gsm
- MX8000-T20 for heavier papers and boards 150-1200 gsm
Features
- 1-15% moisture range for paper and board between 30-1200 gsm
- Ideal for use in ISO9000:2001 quality procedures
- Supplied pre-calibrated
- Calibration is unaffected by color, surface finish, sizing, conductive salts or fibre length
|
|
|
The hand closes naturally around the ergonomic form of the housing so that the pins on the end of the instrument can be pressed into the material to be measured. The thin pins make it easy to measure the moisture content of sawn timber, chipboard and fibreboard materials up to a maximum thickness of 25 mm as well as normal gypsum or mixed plaster.
|
|
Surveymaster
Surveymaster is a moisture meter that displays the moisture level values on a digital display along side a scale of color-coded lights. This digital moisture meter helps in accurate building material moisture measurement [mini]. This combined presentation of moisture measurement helps the user to map the extent of problems and monitor changes in condition precisely and reliably.
Features & Benefits:
Surveymaster moisture meter is supplied with pouch, moisture probe, deep wall probes, calibration check device and wood calibration table.
|
|
|
Electronic moisture meter with 3-line LCD for diverse wood species, soft building materials and insulating materials. Its pins are pressed into the respective material and allow for the measurement of the moisture content of sawn timber, chipboard, veneer and fibreboard materials up to a maximum thickness of 25 mm as well as normal gypsum or mixed plasters.
|
|
HM8-BF30
Expensive repair costs and major expenses for customer compensation can be the result of excessive moisture content in building materials. By quickly determining the exact moisture content such hassles can be avoided.
|
|
PM1 – nondestructive wood moisture meter
with datastore and external sensor
Wood Species:
preprogrammed in 20 groups
Density Range:
densitiy settings for measurements from 0.30–1.10 g/m3
Timber Thikness:
free adjustable from 2–40 mm (0.09–1.57 inch)
This unique electronically Moisture Meter PM1-E and its easy to use functions is a professional instrument for quick and accurat readings of wood moisture content. Because of its solid construction (Aluminium Housing and Rubberprotector) it is ideal for the daily us in rough working conditions.
|
|
For measurement of the water content in solid and pasty samples, the Sartorius Water Detection System 400 is the ideal alternative to classic Karl-Fisher titration. The WDS 400 combines three reference methods – oven drying, coulometry (Karl-Fisher titration) and phosphorous pentoxide into a highly accurate measurement technique. Yet the WDS 400 is also easy to operate without having to have special training and eliminates the need for working with detection reagents, many of which are toxic and expensive.
• Detects water quantities in the trace range
• Selective differentiation among surface and capillary water and water of crystallization
• Operating range from a few ppm to approx. 40% moisture
• 1 µg detection limit
• ± 2% reproducibility of the absolute water content
|
|
To measure various climate and processes values with a handheld, user-friendly instrument requires extraordinary measurement technology. The handheld meter of the OMNIPORT 20 series meets these multiple demands.
The selection of the appropriate sensing probe and accordingly the configuration of the handheld meter allow for displaying the following values with the highest accuracy:
relative humidity RH
temperatur T
dew point temperature Td
absolute humidity dv
mixing ratio r
air velocity v
water activity (in oil) aw
water content (in oil) x
The robust housing of the OMNIPORT 20 allows usage in harsh industrial environments.The readability of the large illuminated display is excellent. The easy to understand menu and the practical thumbwheel navigation offer outstanding comfort.
An optional carrying case can accommodate the display unit, up to 5 sensing probes as well as accessories such as cables and calibration kits.
|
|
Vaisala HUMICAP® Hand-Held Moisture and Temperature Meter for Oil MM70 enables reliable detection of moisture in oil. It is ideal for the preventive maintenance of oil-filled systems. The brobe can be inserted directly into the process pipe through a ball valve - without draining the system. The measurement is independent of oil type, age and temperature.
The MM70 features the Vaisala HUMICAP® Sensor which is known for its excellent pressure, temperature and chemical tolerance.
|
|
|
|
|
|
The XM120 moisture analyzer meets the highest international quality standards. Precisa has developed an instrument which not only provides a high degree of precision, but also offers an outstanding array of additional options. XM120 will fit perfectly into your IT environment and has integrated connections to external PC’s and equipment.
Generous memory capacity, optimum control for measuring processes and state-of-the-art, user-friendly high-end weighing technology are its most impressive features. XM120 works according to the tried and tested infrared drying method, which is distinguished by a wide thermal radiation spectrum. This means that even heavy samples can be analysed accurately.
The XM60 moisture analyzer is the low-volume instrument for customers with low sample volumes and quantities. It is robust, perfectly accurate and simple to operate. Thanks to the high thermal values, it delivers quick and accurate results. Irrespective of your analysis criteria, the widest range of analysis options are at your disposal.
The XM66 delivers rapid moisture results for sewage and waste water treatment plants. The increased weighing range of 310g enables both the use of heavier tare vessels and greater specimen quantities. The moisture analyzer XM66 offers the option to store four weighing results which make it possible to calculate the ash residue after ashing of the specimen has been completed externally.
|
|
|
|
