20,000 ohms/volt DC
28 ranges
3 1/2" mirrored scale
Tests batteries under load
Tests Transistors
Includes batteries and test leads
|
|
The C.A 5001 is a competitively-priced analogue multimeter, designed to satisfy all the current measurement requirements of electricians and electrotechnicians.
# DC voltage: 100mV to 1,000V (8 cal.)
# accuracy 1.5% except 100mV cal.(2.5%)
# AC voltage: 10V to 1,000V (5 cal.),
# bandwidth [20Hz-100kHz] at 10V,[20Hz-1kHz] at 300V and 1,000V
# accuracy 2.5% except 100mV cal.(3%)
# DC intensity: 5µ to 5A (5 cal.)
# AC intensity: 5mA to 5A (4 cal.)
# bandwidth [40Hz-5kHz], Accuracy 2.5% except 5A cal.(5%)
# typical accuracy: 1.5%. Impedance: 20kΩ/V
# resistance: 10kΩ and 1MΩ
# audible continuity test: R < 50Ω
# dB scale (AC voltages). Fuse LED
# dimensions: 160 x 105 x 56mm. Weight: 500g
# IEC 1010-1 600V Cat III
|
|
Analog Multimeter, Basic Model for Hobby & Work
Compact time-tested design
* Voltage measurement: 0 .. 0.15 / 0 .. 0.5 V=,
0 .. 1.5 / 5 / 15 / 50 / 150 / 500 V= / ~, 0 .. 1000 V=
* Input resistance: 20 kOhm / V=, 4 kOhm / V~
* Current measurement: 0 .. 50 mA=,
0 .. 0.5 / 5 / 50 / 500 mA / 5 A= / ~
* Resistance measurement: 1 Ohm .. 1 MOhm (4 ranges)
* Level: –15 .. +56 dB (6 ranges)
* Dimensions: 92 x 126 x 45 mm
* Weight: approx. 0.25 kg without battery
* Battery: 1.5 V IEC LR 6 (AA mignon)
|
|
The Model 325 AC/DC True RMS Power Clamp Meter provides safe, non-invasive measurements of up to 400KW, 400 Amps AC, and measures up to 600 Volts AC/DC utilizing the pair of standard test leads. The lightweight, portable, battery powered clamp meter measures the most common ACV, DCV, ACA & DCA needed to troubleshoot residential and small commercial electrical systems. Back light 3 ¾ digit LCD display
# Auto range
# Auto power off
# Data Hold
# High speed bargraph
# Test ranges: ACV, ACA, DCV, DCA, Ohms, WATT, Frequency & Continuity
# Jaw opening 1.37%u201D (35mm)
|
|
# B+K Precision offers a wide variety of current clamps for safe non-invasive current measurement. Measure up to 2000A with these reliable, rugged instruments. All of B K Precision clamps are much more than a current clamp offering the ability to measure, voltage resistance, capacitance and even frequency. Additionally, special features allow for the recording of minimum and maximum values, peak values, test diodes and for continuity. Any one of these products can be a total measurement solution. Measures up to 1000A
# Measures up to 1000VDC & 750Vac
# Jaw openings 2.24"
# Low battery indication
|
|
F129T
Dual Display True-RMS ClampDMM™ with Detachable Current Head
The MAXIMA Series ClampDMM™ is a hand-held, battery powered digital multimeter with clamp-on current measuring capability, backlight and worklight.
Features:
- 3-3/4 digit, 4000 count LCD display
- Auto-ranging measurement with manual ranging (Amps or adapters only) capability
- MIN/MAX (Peak Hold) (all ranges except Frequency)
- Frequency/Duty Cycle/Data Hold
- Auto power off with manual override
- Detachable current probe makes the meter
compatible with all kinds of DC mV output
adapters
- Built-in test leads storage & magnetic mount
- Backlit display & Work light
- Temperature
- Non-Contact Voltage
- Dual display
- TRMS Measurement
|
|
3999 Count Clamp Meter ( DCM-033)
DCM-033 Features:
DC Voltage 400mV~ 600V (0.8%+1)
AC Voltage 4V ~ 600V (1%+5)
DC Current 40A/400A (2%+3)
AC Current 40A/400A (2.5%+5)
Resistance 400 ~40M Ohm (1%+2)
Frequency
Duty Cycle
Special Functions
Auto Ranging
Diode
Continuity Buzzer
Data Hold
Full Icon Display
Sleep Mode
Low Battery Display
Input Impedance for
DC Voltage Measurement
Around 10MW
Max. Display 3999
|
|
Need the perfect tool to troubleshoot a system?
The ACD-16’s provide a full range of measurements, enhanced with data logging capabilities, to catch what the eye can’t see. Double the efficiency, with an optional PC interface kit.
TRMS & Backlight Screen (ACD-16 TRMS Pro only)
Measurements: AC/DC Voltage up to 600V, AC
Current up to 1000A, Resistance, Frequency and
Temperature
Data-logging 5400 points
Optional PC interface capability (RS-232 KIT2)
Audible continuity
Auto power off
Automatic polarity
Low battery indication
Data hold
Large, easy to read LCD display
Accommodates conductors up to 1.77” (45mm) in
diameter
Carrying case, thermocouple, test leads, batteries
(installed) and user manual included
Voltage overload protection for all functions up to
600V AC/DC
Safety CAT III 600V
|
|
200A AC Mini Clamp Meter/Voltage Detector
Convenient compact size clamp meter with built-in AC Voltage detector
3-1/2 digit (2000 count) backlit LCD display
Measures AC Current up to 200A with 100mA resolution
2% basic ACA accuracy
0.9" (23mm) jaw opening
Built-in non-contact AC Voltage detector (120/240VAC, 50/60Hz) via clamp tip plus flashlight
|
|
Key Features
4000 count digital display
Backlit, large scale display
Analogue bar graph
AC current up to 600A
AC Voltage up to 600V
DC Voltage up to 600V
Resistance up to 400W
Continuity beeper
Display hold
Peak hold
Min Max hold
Frequency counter
Conductor size: up to 34mm dia.
CAT III 600V safety standard
Auto Power Off
|
|
The F09 is a new pocket-size, all-purpose, small-diameter clamp, operated with one hand.
Ideal for U1000RO2V-1X185 2and H07RNF-1x70 cables2 or 20mmx5mm bars, it is a professional measurement tool (600V Cat.III). Fully automatic, TRMS AC+DC, the F09 is a must for all your measurements
# clamping: ø26mm
# AC and DC intensity: 0.20 to 40/400A (600A peak)
# AC and DC voltage: 0.20 to 40/400/600V (900V peak)
# phase rotation (2-wire)
# inrush current
# power (single & three phased): 5W to 240kW ; 5 to 240kvar ; 5 to 240kVA
# power factor
# Hz frequency
# auto AC/DC - Hold
# automatic DC zero
# resistance: 0 to 40kΩ
# continuity / buzzer
# diode test
# min/max/peak
# automatic lead compensation
# backlit display
# range overrun buzzer
# battery charge level
# automatic stop
# dangerous voltage signal
# dimensions: 70 x 193 x 37mm - weight: 260g
|
|
- 30mm Jaw capacity
- Auto ranging
- AC/DC amps to 400A
- AC/DC volts to 600V
- Resistance
- Continuity buzzer
- AC amps peak hold function
- Data hold function
- Auto power off
- Protected to 600V Cat III
- Includes test leads, alligator clips and protective holster
|
|
F170
True RMS Digital Power Meter (3-phase)
The F170 is a True-RMS digital power meter including the energy integration function. This user friendly meter has many applications; appliance testing, checking industrial and commercial power systems, plant maintenance and inspection, and electric utility testing, etc.
Features
- CE-mark Certificated.
- 3 ¨ú digits, 4000 count display for power,
updates 4 times/sec. (6 digits display for
energy integrator.)
- True power, apparent power and reactive power.
- (AC to 750kW/kVA/kVAR) measurement.
- Power Factor (Cos ¥õ) [0.3 Cap... 1 ...
0.3 Ind] measurement.
- Energy (kWh, kVAh, kVARh) Integrator for
maximum 80 hours.
- 3-Phase adaptor (Optional Accessory).
- IEC 1010-1, CATIII600V safety protection.
- Time Stamp for the Energy Integrator.
- True-RMS reading.
- Auto ranging.
- MAX/MIN Record mode.
- Data hold.
- Auto-power-off.
|
|
The 2709B is a full featured auto ranging true RMS DMM that combines performance, value and functionality. The 6600 count LCD has a green back light that allows the meter to be used in dimly lit environments. The 2709B can measure resistance values up to 66 Mohm and capacitance to 66 uF. With the auto power off feature you won't have to worry about accidental battery consumption. Value-packed features make this meter a must in every "Tool Kit®".
# Features Magnetic hanger
# One-handed operation
# True RMS
# Large easy-to-read LCD with backlight
# Auto/manual ranging
# Auto power off
# DC voltage to 1000 V
# Measures up to 10 A (AC & DC)
# AC voltage to 750 V
# Resistance to 66 Mohm
# Capacitance to 66 uF
# Frequency counter to 66 MHz
# Diode test
# Continuity test
|
|
The model 5491A is a very accurate 50,000 count, dual display, true RMS bench multimeter.
Low cost and high performance
True RMS (AC, AC + DC)
Resistance measurements up to 50M ohms
Measures frequency to 500KHz
DBm measurement
RS 232 Interface
|
|
Combining the two tools frequently used by every instrumentation technician,the ecom 789 Process Meter will be at home in every instrumentation technician ’s toolbox.The ecom Process Meter combine a DMM and a Loop Calibrator in one rugged,handheld tool. With its built-in 24 V loop supply it reduces the need for taking a separate power supply when doing off-line transmitter testing.
|
|
Features:
- Calculates the current demand.
- 4 displays with red LED´s of 3 digits with 7 segments for easy reading.
- 3 membrane push-buttons.
- Automatic scale of units.
- Suitable for all electrical switchboards used in the industrial field for instruments, motors, generators, etc.
- With active and reactive energy meter.
- 4 displays with red LED´s of 3 digits with 7 segments for easy reading.
- 3 membrane push-buttons.
- Automatic scale of units.
- Suitable for all electrical switchboards used in the industrial field for instruments, motors, generators, etc.
|
|
|
|
|
|
METERING INSTRUMENTS AND CURRENT TRANSFORMERS
- Digital voltmeters, ammeters, wattmeters, frequency meters and cosphi meters
- Digital multimeters, expandable, with graphic LCD
- Connection to single, two, three phase systems
- Ideal for distribution systems, co-generation energy systems, stand-by generating sets and on-board machinery installations
- High measurement accuracy
- Totally programmable digital outputs
- RS485, RS232, USB, Ethernet, serial interface for remote control and data-logger.
PROGRAMMABLE LOGIC RELAYS
- 10, 12 and 20 Input-Output base units
- Expansion modules with 4 Inputs and 4 Outputs
- Maximum configuration: 44 Inputs/Outputs
- RS232 serial interface port for PC or program backup memory connection
- On-board programming languages: Italian, English, Spanish, French, German, Portuguese and Chinese
- PC programming languages: Italian, English and Spanish.
SWITCHING POWER SUPPLIES
- Versions: modular and 35mm DIN rail mount
- Output voltage adjustment by front potentiometer
- Short-circuit protection
- Built-in input voltage surge suppressor
- Used as power supply for DC electromechanical and electronic equipment.
|
|
|
|
|
|
732 Series Digital Multimeters
73201 Digital Multimeter
Accuracy 0.5% at DC voltage and 4300 count digital display. Compact sized body with large display provides good viewing. Our safety design allows you to measure up to AC/DC 20A
73202 Digital Multimeter
Accuracy 0.5% at DC voltage and 4300 count digital display. Compact sized body with large display provides good viewing. Our safety design allows you to measure up to AC/DC 20A. Also, capacitor check function is available for this model.
73203 Digital Multimeter
Accuracy 0.3% at DC voltage and 4300 count digital display. Compact sized body with large display provides good viewing. Our safety design allows you to measure up to AC/DC 20A. Also capacitor check function is available for this model.
73204 Digital Multimeter
73204 is exclusive model for voltage measurement. Accuracy 0.5% at DC voltage and 4300 count large digital display for good viewing. Elimination of current measurement function provides safe voltage measurement of distribution board at heavy electric machinery.
|
|
|
The NEW Agilent U1250A Series handheld digital multimeters are 4 ½ digit, dual display and packed with many advanced functionalities. Get accurate readings with error rate as low as 0.025% and true RMS measurement. You can perform high-speed automated data logging to detect event anomalies with the optional IR-USB cable and free GUI data logging software.
|
|
As soon as it came on the market, the MX 24B became the reference 5000-count TRMS digital multimeter.
It has an ADP input and can be connected to a wide range of accessory probes: luxmeter, ammeter clamp, thermometer, etc.
- 5000-counts
- Backlit display, 34-segment bargraph
- 500kΩ low impedance measurement input
- Voltage up to 1000VDC and 750VAC impedance 10MΩ
- Direct intensity up to 10ADC and 6A AC
- Resistance up to 50MΩ
- Audio continuity test, diode test
- Capacitance meter function up to 50µF
- Frequency meter function up to 500kHz
- MEM/AUTOMEM key
- Dimensions 170 x 80 x 35mm, weight 300g.
|
|
Digital multimeters (DMM): GPIB, USB, Ethernet, LXI-based, audio analysis/THD, switch integrated dataloggers.
- Airbag/Automotive Source/Switch Modules
- Airbag/Automotive Source/Switch Systems
- Audio Analyzing and Total Harmonic Distortion DMMs
- DMMs
- Integra Series Integrated Switching/Measurement/Datalogging Systems
- Integra Series Software
- Integra Series Switch/Control Modules
|
|
|
National Instruments digital multimeters/voltmeters and LCR meters achieve remarkable throughput rates while maintaining precision and stable measurements. These digital multimeters accurately measure voltage, resistance, current, capacitance, inductance, and temperature. You can build a high-channel-count system by integrating these digital multimeters with a single or multiple NI switch modules.
|
|
Multimeters are capable of measuring a number of variables. Each instrument can measure voltage and resistance, as well as performing continuity and diode testing as standard.
In addition, the individual multimeters also feature extra measuring options such as current, frequency, capacitance and temperature. Digital multimeters have the advantage of a clear display which can be read easily and directly. With these instruments, mistakes arising from faulty calculations of the measuring ranges or misreading the display are a thing of the past.
|
|
|
|
|
|
PCI 7.5 Digit DMM
Features:
* DC a AC Volts a Current
* 2-Wlre & 4-Wlre Resistance Measurement
* True AC RMS Measurements, 10Hz to 10OkHz
* Measure 1uV to 330V
* Self-Calibrating
* 330V Isolation Barrier
* Precise Triggering Capabilities
* Frequency Counter 1 Hz to 300kHz
* 20,000 Readings/Second
* Extensive Windows Support
* Visual Basic, MS Visual C++, Borland C++
* LabView & LabWindows/CVI
Two versions of the digit DMM are available and both plug into any PCI motherboard. Both have all the functionality and performance expected of high quality bench top DMMs, and a lot more. Both versions feature external triggering and programmable level trigger. The 51 -210-064 version provides additional capability to measure Offset Ohms, make RTD Temperature measurements, supports Thermocouples (8 types) and provides frequency, timing, capacitance and temperature measurements, as well as event counting. The 51 -210-064 version also measures Peak-to-Peak AC, Inductance, and provides a torce/guard 6-wire Ohms capability for making in-clrcuit resistance measurements. Leakage current can be measured using an In-built programmable voltage source. Resistance measurements to 1,000M can be performed.
|
|
Combination Autoranging multimeter with IR Thermometer
* Non-contact InfraRed thermometer measures surface temperature of objects unsafe to contact or difficult to reach
* InfraRed features 8:1 distance to target ratio with 0.95 fixed emissivity
* Input fuse protection and mis-connection warnings with audible and visible signals
* Auto power off, Data Hold
|
|
Basic multimeters with 8 functions and choice of True RMS model
* Easy to read large backlit display
* True RMS AC measurements (EX411)
* Type K thermometer built-in for surface or air temperature measurements
* Input fuse protection and mis-connection warnings with audible and visible signals
* Data hold freezes display reading
* Ergonomically designed to fit comfortably in your hand
|
|
The 2880B is a Dual Display 51,000 Count DMMs with exceptional accuracy and functionality. It offers superb performance with many features that are useful for trouble shooting electronic and electrical circuits or to test and evaluate circuits in a field service application.
# Features: True RMSACV and ACA
# 5 Digit LCD for both the primary and secondary displays
# 21 Segment analog bar graph
# Automatic polarity indicator
# 0.025% Basic DCV accuracy (0.03% for 2880B)
# Resistance measurements up to 500Mohm
# Conductance measurements up to 50nS with 0.01nS resolution
# Capacitance measurement
# Frequency with ACV measurement
# Data Hold
# dBm Measurement
# REL Mode
# 1ms Peak Hold for glitch capture
# Conforms to IEC-1010-1 600V CAT III and 1000V CAT II
# CE Approve
|
|
Multimeter
87V Ex - Intrinsically safe digital multimeter
Measuring technology inside the Ex-hazardous area is always a critical subject. This digital multimeter from ecom instruments GmbH offers a safe, compact solution, as the 87V Ex allows safe measurements both inside and outside (maximum of 10 A/1000 V) the Ex-hazardous area. With the robust holster the unit is well protected - even in the toughest conditions.
Features
- CAT III 1000 V/CAT IV 600 V
- Min/Max/Avg function
- 4 ½" digit display with bar indicator
- Temperature measurement using thermocouple, type K
- Measurements up to 1000 V/10 A (outside the Ex-hazardous area)
- Background lighting
|
|
|
|
