LABEL ATTACHMENT EI
Description :
Total length : 225 mm
Useful length : 205 mm
Plate : 46 x 65 mm
Material :
Polypropylen
Color : Red
Option :
Other colors on request ( 10 000 minimum )
Delivery time : Available on stock
Free samples on request
|
|
IDENTIFICATION PLASTIC PLATE
Description :
Plate : 16x26mm, 20x40mm, 25x60mm, 50x60mm, 60x100mm
Width : 1mm
Use with ties 2.5 and 4.8 mm width
Use with ties between 2.5 and 9 mm for the plate 60 x 100 mm
Material :
Polyamid 6 and polypropylen
Color :
Natural
Packaging :
Bags of 100 pieces
Delivery time :
Available on stock
Options :
laser personalization and barecodes for polypropylen plate. Possibility to have colored plate ( 25 000 pieces minimum )
Customs tariff : 39 23 90 90
Free samples on request
|
|
|
|
|
|
The computer-controlled tag feed marking system is a totally automated system for marking tags up to 150 mm in length on the standard units. Customized machines can be ordered for extremely large tags.
The tag feeder is equipped with an adjustable loading rack, which can be quickly readjusted for a wide range of tag sizes. Standard machine size is 15 mm to 75 mm for width and 20 mm to 105 mm for length.
The MC-2000 plate feed system is equipped to mark in both manual and automatic modes. The manual mode gives you the ability to perform any one of the tag system functions through a series of push buttons located on the front of the machine. By simply moving the selector switch to the manual mode you can now move the pusher bar forward to check for clearance in the systems rails or mark a single tag to check mark location and quality of mark.
The MC-2000 tag feeder is also equipped with warning signals in case of a system jam or if the machine runs out of tags. The control box can also be programmed to mark a specified number of tags or mark until the stacker is empty.
All of the same characteristics that are found in the standard MC-2000 control box are included in the tag feed system.
General Specifications:
Electrically driven pusher
Adjustable push bar
Two- (2) tag feed bars for different size tags
Four inch high stacker
One (1) tag weight with handle
Sixteen inch tag transfer table
Spring-loaded computer activated tag lock
Four-inch restacker chute
Adjustable slotted base
Manual/Automatic capabilities
Includes all wiring and software to work with the standard MC-2000
One (1) operator’s manual
Spare parts for complete machine include:
1-limit switch for tag unit
1-limit switch for MC-2000 unit
1-solenoid
1-spring
1-pin
1-oil
1-grease
1-set fuses
1-pin guide wrench
|
|
|
|
|
|
Your ideal partner for the marking of name plates!
The innovative, network-compatible CNC table marking system NetMarker® excels at marking quality, simple handling and ease of use. The NetMarker® offers unequalled opportunities. The all new NetMarker® raises the standards for high precision marking requirements within industrial production. It also offers many other further component marking opportunities with a wide range of additional features.
The competitive table marking system NetMarker® works as a stand-alone machine. With its compact design being extremely space-saving. The electro pneumatically operated dot peen marking system is suitable for durable, efficient, permanent and quick marking tasks with the ability to mark almost all kind of parts made of metal. Naturally, you can mark pressure-sensitive, thin-walled, coated or moderately curved parts as well.
The system program NetMarker® to handle the marking system is 100% operator prompted. It is designed to be transparent and self-explanatory. The system program NetMarker® offers all modern characteristics of an intuitive program creation. It enables an online help option as well as the possibility to change the marking position and text within the marking preview screen.
Furthermore, an additional rotating axis can be programmed. All established features, like continuous numbering, circle marking, date and time & batch are already enclosed in the scope of delivery. Special signs and logos are available upon request.
|
|
Robust, lightweight, portable dot peen marking units for mobile marking applications
Autonomous operation (no PC required) – all programming can be done through the integrated keyboard and controller
Variety of marking types: text, date codes, graphics, serialization and scalable fonts
Pannier's family of portable dot peen marking machines allow you to mark wherever you wish.
|
|
|
|
|
|
Emboss or deboss metal tags using a simple character selection wheel, ideal for low volume applications
Accommodates several different tag sizes
Specified in GSA Contract #GS-25F-0043L for making military dog tags
This manually operated tag embosser is an economical option for creating small quantities of embossed or debossed metal tags. Compact and lightweight, it can be used for tabletop or portable needs. Tag sizes range from .8” x 1.2” minimum to 3.4” x 4.5” maximum.
This manually operated tag embosser is an economical option for creating small quantities of embossed or debossed metal tags. Compact and lightweight, it can be used for tabletop or portable needs. Tag sizes range from .8” x 1.2” minimum to 3.4” x 4.5” maximum.
Using the manual character selection wheel, characters are embossed one at a time. The wheel has a 60-character capacity including numbers and punctuation marks. Once the character is selected, simply pull the handle and the M10 embosses the character and automatically spaces to the right. It also features a correction device that allows you to backspace and re-emboss a character.
|
|
CNC-controlled pin marking system
Compact construction for the integration into linear slides with
- 4 driving compartments
- 3 expandable interfaces
- highly-dynamic stepping motor
- fully-in-case, therefore it can be operated in a rough industrial environment
|
|
|
|
