PLUS 1D is a Bar Nesting (multing) optimization software, which helps reduce the waste in cutting any 1D (lineal) material like pipe, bar, angles, sections, flange, rod, tube, channel, frame, profiles, extrusions etc. It automatically generates the optimum cutting plans once the part list, and the available stock has been entered. It helps you save material by reducing the offcuts (drops) and reusing them. It has a simple user interface and you get the optimized result, with detailed reports at the click of a button.
There are optional Add-on modules for Miter parts (parts with angled cuts), Large parts with Joints and Bar Code Label generation and printing.
Application Area:
The software finds application in Steel fabrication and is an invaluable tool for structural steel estimation.
Features:
Simple wizard like user interface.
Import data(cutlist) from a variety of sources (tables, Comma Separated Value CSV files, spreadsheets etc.).
Support for inches and mm.
Support for cut thickness.
Support for inclined cuts.
Detailed output reports for cutting plan.
Graphical Layout drawings for more cutting details
Save and reuse offcuts (drops).
|
|
|
|
|
|
PLUS 2D - Glass: The Glass Cutting optimizer based on the PLUS 2D cutting optimization technology consistently delivers high yield layouts and is ideal for cutting glass, whether manually or using a CNC cutting table. The software not only accepts multiple sheet sizes, but also selects the best sheet for the job, generating optimum cutting patterns that not only save material, but are much simpler to cut further reducing time and cutting costs.
Application Areas:
The software can be used by Float Glass Producers, Architectural Glass Processors, Automotive Glass Manufacturers, Glass Cutting Table Manufacturers and Glass Traders.
Features:
Simple User Interface.
Multiple stocks in a single job.
Supports both Metric and English units (mm or Inches).
Supports non-rectangular parts through DXF import, Parametric Part library and standard shapes.
Integrated inventory database.
Import data from text files with CSV file wizard or simple copy / paste from spreadsheets and databases.
User defined patterns for non rectangular parts that can be combined to form nearly rectangular patterns.
Place standard filler parts or parts from other jobs in the offcut.
|
|
|
ACT/CUBE : 3D nesting software aimed at professionals specialized in cutting materials such as foam, polystyrene, polyurethane, marble, wood or deep-frozen food. From a set of raw-material blocks and a set of outputs to be produced, ACT/CUBE automatically calculates the 3D layout, for significant savings in terms of time and material. Thanks to a powerful optimization algorithm, ACT/CUBE enables you to quickly execute very compact 3D assemblies. The software optimizes the use of material not only within a block but also by choosing the best blocks to be used. ACT/CUBE also enables you to reuse offcuts as a priority. ACT/CUBE produces edge to edge cutting plans adapted to the different cutting technologies (wire, blade, saw, etc.) and offers many specialized features. ACT/CUBE can be easily coupled with Production Management and ERP systems.
|
|
| ... products without technical information |
| |
Astra R-Nesting is sheet nesting software for optimized cutting of particle board, metal, glass and plastics. Its simple and intuitive tools allow the user to do the following operations:
- Quickly create an order using standard assemblies, convenient manual entry
or import of data from other applications.
- Cut the order in accordance with the technological parameters. Unique to Astra R-Nesting is a set of parameters that let the user customize the software to the specific needs of the enterprise.
- Quickly and exactly edit cutting layouts by hand, using the functions specially designed for it.
- Calculate and save offcuts to be re-utilized later.
- Print reports and labels.
- Export cutting layouts to NC machines.
- Calculate the cost of the order and print the invoice.
|
|
