CNE III and CNE V, are broadband noise generators with a usable output power from 9kHz to 2GHz, and 30MHz to 1GHz respectively.
Three monopole antennae are available with the CNE III which may be attached to the BNC connector on the top of the unit enabling it to act as a radiating field source. The CNE V has a single monopole antenna available.
|
|
The PNG7000A Series instruments generate white Gaussian noise and provide a summing input to control signal-to-noise (SNR) or carrier-to-noise (CNR) for bit-error-ratio (BER) testing. The output can also be used as a source for Jitter applications. A key feature of this instrument is its low distortion signal path that sums the user-supplied signal with the internal precision white noise source. Standard units can be modified for specific customer requirements. Please consult the factory for pricing and availability of these requests.
- Type N, BNC, or SMA connectors available
- 127 dB attenuation in 1 dB, or optional 0.1 dB steps*
- Summing input for CNR, or Eb/No measurements
- 0 dB signal path insertion loss
- +/- 0.25 dB per 40 MHz noise band smoothing
- SP6T switch allows four internal/external filter paths
- Standard Ethernet, or optional GPIB remote control
- Optional rear panel connectors
|
|
Automated Noise Generators
The ANG Series is the most flexible architecture available for automated noise generators. This rack mountable noise generator can be remote controlled via RS-232 or GPIB interfaces. A long list of options including; Input Signal Combiner, Monitoring Ports, and Noise Path Filtering give you the ability to design the ideal system for your application.
|
|
|
|
