Superior to hydraulic or piezoelectric nozzles, Sprayvectors accelerate air-liquid interaction and produce defined spray patterns that can be widely diffused or highly directed. These unique nozzles introduce low pressure (0,14-1,4 Bar) liquids into large internal passages to eliminate clogging. Three models are available; Atomizing or Fogging styles deliver a dense, directable, high velocity spray for viscosities up to 1100 CPS, while the Humidifying model produces a very diffused, low velocity spray for viscosities up to 100 CPS. All styles feature a control knob for precise, fingertip adjustment of liquid flow rates. Water, chemicals, rust inhibitors, cleaners, solvents, preservatives, insecticides, lubricants and a wide diversity of other fluids can be dispensed.
|
|
|
Energy Saving Safety Nozzles from Meech can save up to 70% of compressed air demand whilst dramatically reducing noise levels. The innovative nozzle design forces compressed air through an adjustable circular slot and then directs it at high velocity over the outside of the nozzle cone. The design amplifies the output airflow by entraining the ambient air at a 25:1 ratio.
|
|
|
Jet nozzles are used for preference where the supply air from the diffuser has to travel a large distance to the occupied zone. This is the case in large rooms (halls, assembly rooms etc.), particularly when the distribution of air via ceiling diffusers is not possible or not practical. Here jet diffusers are arranged in the side wall areas. The direction of the air stream from the type DUK-V jet nozzle can be easily adjusted manually to suit particular on site conditions. Also the pivoting movement can be motorised within the range of ± 30°. The electric actuators for this can be externally or internally mounted.
|
|
Loc-Line® Acid Resistant Hose is excellent for rinsing cycles in plating operations.
Acid environments won't corrode the Loc-Line® Acid Resistant Hose because of its polyester composition.
CAUTION: Loc-Line® Acid Resistant Hose is not intended for conveying acids or high pressure applications.
Common Compatability with Polyester Products Acid Resistant Loc-Line® Yellow Color
No Acetone Yes Acids, (Less than 150° F)
No Acids, (Greater than 150° F) Yes Alcohols
Yes Aromatic Solvents No Chlorinated Hydrocarbon
No Bases, Strong No Ethyl Acetate
Yes Gasoline Yes Greases
Yes Hydrocarbons Yes Oils
Yes Salt Solutions No Water (Greater than 150° F)
|
|
TYPICAL APPLICATIONS
Chemical processing, continuous casting, cooling castings and moulds, curing concrete products, evaporative coolers, foam control,
incineration, quenching, spray coating, spray drying, flue gas desulfurisation.
|
|
CENTRIFUGAL PRESSURE NOZZLES
The most widespread pressure atomizer , where the energy for atomization is supplied exclusively by the feed liquid pressure. In this type nozzle the liquid enters the whirl chamber through a slot in the side of the chamber itself, follows a tangential path around the inner chamber profile, and is then fed to the outlet orifice at high speed. Nozzle orifice, whirl chamber and nozzle top plate are made out of tungsten carbide or other wear resistant materials, to avoid rapid wear and consequent performance degradation. Bodies are manufactured from high quality Aisi 316 stainless steel.
These nozzles are well suited for atomizing high viscosity liquids with viscosities values up to several hundred centipoises. They are successfully used in countercurrent spraydryers, and in systems using multiple nozzle lances. Capacities range up to several thousands of kgph for a single nozzle.
|
|
Nex Flow™ nozzles are designed to fit into small spaces. We have an adjustable nozzle for some applications and then a few different nozzles with varying force, depending on the application.
Model 47001 - is a small brass nozzle to fit into small spots and used by many machine builders for blow-off applications.
Model 47002 - is the small Model 47001 brass nozzle added to a copper tube. Machine builders can bend the copper tube and aim the nozzles to where ever it suits. The copper tube is simply press fit into the customer's system.
Model 47003 - This is a common standard strength nozzle with a 1/8" male NPT connection and ideal for most blow-off applications involving liquids. It is made of aluminum and is partially anodized for longer life. The coanda profile is made for excellent noise reduction and blow-off force at a good distance.
Other products:
|
|
TYPICAL APPLICATIONS
Aerating water, brine sprays, chemical processing, coil defrosting, dust control, evaporative condensers, evaporative coolers, industrial
washers, roof cooling, spray ponds, spray coating, gas scrubbing and washing, humidification, gas cooling, cooling towers, coal washing,
degreasing, gravel washing, dishwashing, foam control, industrial washing and water fountains.
|
|
Nex Flow™ removes the confusion from air jets and nozzles. You do NOT need hundreds of different nozzles. All air amplifying nozzles produce air flows up to 25 times the compressed air consumed. Different nozzles have different outlet sizes and the more air used, the greater the force produced. Noise reduction u t 10 dBA is typil as well as reduced air consumption when compared to open jets and tubes.
The most important reason to use air nozzles or jets is safety All Nex Flow air nozzles and jets meet OSHA standard CFR 1910.242(b) for dead end pressure. Noise levels are dramatically lower with air nozzles and jets in addition to lower energy use.
|
|
Water jet cutting technology has asserted itself to an ever increasing degree against competing technologies. Highly wear resistant carbide nozzles are a major fact for the cutting result. The main areas of application are the automotive, packaging and aerospace industries, mechanical engineering and electronics.
Water jet cutting has a number of advantages:
- cutting takes place at room temperature (thermal stress is avoided)
- only one tool is used: the water jet
- no limits as to materials that can be cut: ranging from stone, composites, plastics, metals ... up to a thickness of 150 mm.
- a clean job: as opposed to thermal procedures, water jet cutting is emission-free
|
|
|
|
|
|
Gas Cutting Tip: Only the original Koike oxy fuel cutting tips: 102, 102HC, 102-D7, 103, 103-D7, 106, 106HC, 106-D7, 107 and 107-D7 are designed and manufactured to provide high quality cutting, safe operation, longer cutting life, high speed cutting and save gas costs. In addition our 100 series cutting tip can be used to replace Airco® style cutting tips.
All Koike 100 Series cutting tips are designed to mix the fuel and the oxygen used for preheating inside the cutting tip. This is recognized as one of the safest methods. Koike 100 series torches carry a lifetime warranty against a damaging sustained flashback while using genuine Koike cutting tips (excludes IK-82).
The Koike D7 cutting tips are one of the most technically advanced cutting tips available, providing safety and accuracy while saving money in time and gas costs. Our high speed D7 Series of Cutting tips with a divergent tip increase cutting speed 20-28% over standard tips and Gas consumption is reduced up to 26%. A stainless steel liner helps them last up to 5 times longer than other tips.
|
|
TYPICAL APPLICATIONS
Asphalt or tar laying, bottle washing, coal and gravel washing, degreasing, dishwashing, foam control, industrial washers, metal
cleaning-rinsing and washing, spray coating, vehicle washing, water misting and water fountains.
|
|
Aerating water, brine sprays, chemical processing, coil defrosting, dust control, evaporative condensers, evaporative coolers, industrial
washers, roof cooling, spray coating, gas scrubbing and washing, cooling towers, coal washing, degreasing, gravel washing, dishwashing,
foam control, industrial washing and water fountains.
|
|
SpiralAirTM (SA)
High-flow Air Atomizing Spray Nozzles
Design Features
* A two-fluid nozzle using any gas as the atomizing fluid
* Three-stage process that uses atomizing air more efficiently than conventional designs
* Two-phase atomization for highest performance
* Designed for high reliability in extremely hostile environments
* Efficient design reduces compressed air consumption
* Standard and custom lance designs are available for any application
* U.S. Patent #5,240,183
Spray Patterns: Full Cone and Flat Fan
Spray Angles: 20° to 90° (Other angles available by special order)
Flow rates: 0.33 to 26 gpm (2.0 to 80 L/min)
|
|
|
|
|
|
Air Jets are larger than nozzles and used when a wider area needs to be hit with the amplified air. They are significantly more efficient than nozzles although often use as much compressed air. Their best use is to replace pairs of nozzles that are used for part ejection or for blow-off applications that require greater force than that provided by air knives or air movers. Nozzles are for point use while air jets can fan out somewhat for better continuous blow-off when a row of them are made. Nex Flow air jets are all made adjustable with a lock ring to assure the security of any gap setting. They have a female 1/8" NPT and made lightweight with anodized aluminum.
From Left to right is the Mini Air Jet, then the High Force Air Jet then the High Flow Air Jet
Model 45001 - High Flow Air Jet and Model 45002 High Force Air Jet are physically the same size. The only difference is a larger exit opening for the amplified air flow. The high flow system is used more for cooling and light blow-off while the high force version is sued mainly for heavier blow-off applications.
Model 45003 - Mini Air Jet is the most compact air jet with high force, is adjustable and ideal for tight spaces. This is unique to Nex Flow and there is no equivalent competitive system.
|
|
TYPICAL APPLICATIONS
Aerating water, brine sprays, chemical processing, coil defrosting, dust control, evaporative condensers, evaporative coolers, industrial
washers, roof cooling, spray ponds, spray coating, gas scrubbing and washing, humidification, gas cooling, cooling towers, coal washing,
degreasing, gravel washing, dishwashing, foam control, industrial washing and water fountains.
|
|
Design Features
* Large free passage
* Clog-resistant; nozzles have no internal parts
* One-piece casting
* Female connection
* Flanged connection available
* U.S. Patent 4,231,524
* Inlet and outlet are in-line
Silicon Carbide requests require review prior to quote/order acceptance - restrictions may apply
Spray Characteristics
* Most even spray distribution of any tangential whirl nozzle in the industry
Spray Patterns: Hollow Cone
Spray Angles: Narrow to Medium
Flow rates: 4.11 to 564 gpm (15.3 to 2230 L/min)
|
|
Air nozzles, flat jet
16 orifices. Uniform layer of air. Limited noise. Flow rate range: 9 - 33 cfm @ 15 - 75 psi. Material: polyacetal resin.
Typical applications: blow off, cooling, drying cleaning.
|
|
According to occupational health and safety standards (in Germany), a sound level of 85dB(A) may only be exceeded in case of justifiable exceptions. Excessive noise presents a health hazard to workers as well as impairing communication and performance. Elring multi-channel nozzles serve to achieve a major reduction in sound levels.
Enhanded Effectiveness Using Pinpointed Blowing Power
Aerodynamically adapted air supply to the nozzle channels increases effectiveness, while the laminar air flow of Elring multi-channel nozzles also produces a strong effect beyond the delivery end of the nozzles. This results in a further efficiency increase as well as allowing conveyance of heavier production parts.
Benefits
- cost savings in work environments requiring noise protection
- cost savings through reduced consumption of compressed air
- enhanced performance through optimized compressed air delivery at the nozzles
- pinpointed blowing action through adjustable compressed air nozzles
|
|
TYPICAL APPLICATIONS
Asphalt or tar laying, bottle washing, coal and gravel washing, degreasing, dishwashing, foam control, industrial washers, metal
cleaning-rinsing and washing, spray coating, vehicle washing, water misting and water fountains.
|
|
|
The design of the tubes of Drying by Atomization DELAVAN, refers of it in the field of the Manufacture of Powder. We to you propose a complete range of Haute-Pression tubes (SDX) and Bi-Fluids (Swirl-Air)
|
|
In any dryer good mixing and efficient liquid-gas contact are of basic importance to assure rapid drying. The height of the dryer system is largely determined by the time required to dry the largest particle produced by the atomizer, while other important parameters are represented by the inlet-air temperature and the properties of the product being processed.
Spray drying has several advantages, the main one being the ability to handle heat-sensitive products such as food and pharmaceuticals. This is due to the fact that the drying process of a drop happens by loosing water on the external layers, and this keeps the inside material in the drop cool or at least protected against excessive heat.
|
|
These units are purposely designed items for use in paint spraying and coating applications. Additional special
purpose air assisted tips are also shown for reference.
|
|
OUR RANGE INCLUDES
FULL CONE PATTERN:
Full cone flange connection / full cone vaneless - off line / full cone three piece nozzles / full cone square spray / square spray - large flow / full cone injector nozzles / full cone off line spray / full cone nozzle tips / multiple full cone - standard spray angles / multiple full cone wide spray angle / full cone spiral nozzles / full cone spiral - extra wide angle.
FLAT JET PATTERN:
Flat jet high pressure washing nozzles / flat jet standard flow rates / flat jet large flow rates, flat jet low flow rates / flat jet tips - standard flow / flat jet tips / large flow / dove-tail tips - standard flow / dovetail tips - large flow / flat jet - large spray angles / flat jet - high impact (spoon nozzles). Also pencil jets.
HOLLOW CONE PATTERN:
Hollow cone - wide spray angle / hollow cone moulded plastic nozzles / hollow cone large flow rates / hollow cone - in line spray / hollow cone deflected spray / hollow cone - low pressure nozzles.
|
|
Various types of fixed and rotating spray heads are specified in this section and are designed to suit a wide range of
applications and installations.
|
|
|
|
|
|
This comprehensive range of tank washing devices have been developed for a number reasons. Primarily this is due to the quest for greater efficiency in all kinds of industrial procedures, but it is also the continuous requirement to assure a constant and higher quality level of product. Environmental considerations are also influential; the need to reduce energy use and the increasing costs involved in the disposal of effluents are also factors. Thus resulting in the need for a cleaning process that produces a totally satisfactory result and is completed using the lowest possible volume of cleaning solution; the right tank washing head can also be energy efficient.
Our range from the classic fixed head to the more sophisticated models has been developed to cope with the most demanding applications. The following basic concepts should be given proper consideration in order to determine the correct washing cycle for each single application, and consequently the most suitable type of tank cleaning device.
|
|
URACA%u2019s tank cleaning heads TWK125-1600 are driven by high pressure water. The characteristic features are compact water jet, minimum displacement circle and minimal pressure losses. For use free on hose or via fixed positioning.
- Operating pressure max:1,600 bar
- Recommended flow rate: 30 - 150 l/min
- Displacement circle min. Ø: 125 mm
- Weight: 10.5 kg
|
|
TW
Tank Washing Nozzles, Clog Resistant Nozzles
Design Features
* Clog-resistant spiral design
* Energy efficient; uses less water than conventional designs
* Compact design; fits small openings
Spray Characteristics
* Easy to maintain
* Unique patterns that spray in opposing directions
* See LEM for other tank-washing applications
Flow rates: 3.0 to 163 gpm (11.4 to 260 L/min)
|
|
Twist & DryTM (TD)
Spray Drying, Hollow Cone Nozzles
Design Features
* Patented locking mechanism for quick and easy change-out and maintenance
* Choose TD-K to operate at high pressures for greater yield capacity
* PEEK backup ring with Viton® 90 or Silicone O-rings (for higher temperatures)
* Female-threaded or butt weld pipe connections
* Easy assembly, no special tools required
* Orifice size: 0.034" through 0.157" (0.864 mm through 3.99 mm)
* Interchangeable swirl and orifice discs for variable patterns and flow rates
* More information on the TD-K nozzle
Spray Characteristics:
Spray pattern: Hollow Cone
Spray angles: 50°, 55°, 60°, 65°, 70°, 75° and 80°
Flow rates: 8.94 to 1570 gph (35.3 to 5970 L/h)
|
|
|
|
