Label Printing Machines - LPM75
This machine is a 3-Color Narrow Web Dry Offset Printing Machine. It is a rugged machine for high speed and high quality printing. It is used for printing on different materials such as Fabrics, Nylon, Plastic films, paper etc. This machine is very suitable for printing logo labels, wash-care labels for the garment industry on different kinds of fabrics.
Features :
- Sturdy well designed machine
- Electronic drive for speed variation
- Inching mode for setting
- Revolution / RPM counter
- Auto lubrication system
- Heater for quick drying
- Options for printing on elastic bands
- Provision for reverse printing
|
|
|
|
|
|
OC 200
Cutting-edge, modular offset printing technology for printing single cards and very small formats on a variety of materials and thicknesses.
It is a pioneering engineering achievement and is suitable for printing on very small formats and single cards. Demand for phone cards, loyalty cards, access cards and advertising cards from telecommunications service providers, department stores and a wide range of other institutions
continues to increase. The quality of the cards must be excellent, but the costs must remain low.
The KBA-Metronic AG OC 200 can easily handle all standard plastics (ABS, PVC, PET, PS, etc.) and cards with chip cavity up to a thickness of 1.2 mm.
This economic, flexible system with four print units is the ideal, userfriendly
solution for CMYK print runs.
There is a low-cost version of the OC 200 with only two print units, which
can be used for two-pass, four-color printing on one side to produce brilliant, photorealistic quality.
The system features waterless offset printing, a “zoneless” short inking unit and UV-hardening ink. Even printers who do not have special qualifications can quickly learn how to use this system. In contrast to conventional offset printing, there is no need to adjust ink zones, dampening units and inking rollers or regulate the ink-water balance, etc. Printing quality remains constant even when different operators take over at the start of a new shift.
If required, the system can be modified to meet the order profile. It can then be upgraded at minimal cost at a later time, for example by adding a 5th or 6th print unit for special colors or a rotation unit for two-sided printing (optional).
|
|
|
|
|
|
Matthews was one of the early Pioneers that designed and manufactured industrial quality, offset printers. This term offset printing means that a mark made by ink is transferred from a solid rubber covered roll, commonly referred to as a blanket roll. Offset printers are three roll systems that incorporate an ink roll, type wheel, and blanket roll. The type does not come into contact with the product on an offset system.
This system minimizes the amount of type wear while producing a permanent, consistent quality mark. The Print-A-Mark Offset Printer line, furnished by Matthews are available in 1", 2" and 3" wide roll units. Our standard printers are generally friction driven, obtaining their power from coming into contact with the product causing the product to revolve the printer.
Motor drive package options are available for applications that require an assist to revolve the offset printer. This is sometimes necessary when the product has a small diameter, or too little friction available at the blanket roll contact point.
|
|
ATN is designing and manufacturing high precision printing presses rotogravure/offset/flexo.The main markets are in the cigarettes packaging, liquid boxes and food packaging.
EMERA
Web offset press combined with roto rotogravure/flexo units.
|
|
| ... products without technical information |
| |
|
|
|
|
Premius
Brilliant print results and high gloss effects with waterless offset printing
and UV technology. High-speed printing on a wide range of media
including DVD, CD, MiniDisc, Optical Business Card and special formats.
The Premius offset printing machine from KBA-Metronic AG helps your business thrive. You get brilliant print quality combined with excellent performance and perfect reproduction of photorealistic images on DVDs, CDs, MiniDiscs and Optical Business Cards from the first piece to the last even on large print runs.
The consistency of print results on the Premius is simply outstanding. Mature, field-proven technology from KBAMetronic is your guarantee of exceptional print quality. Waterless offset printing,
short inking units without ink keys and an efficient four-cylinder print unit design all enhance ease of operation, reliability and availability. UV varnishes can be applied to some or all of the media surface to add a high gloss appearance.
The speeds are equally impressive. You can print up to 7,200 pieces an hour, change printing plates semi-automatically in less than 5 minutes, and there is no need to adjust registration. All of this adds up to short setup times and high machine utilization, even when you are running more than one shift.
KBA-Metronic AG has many years of experience with short inking units that
work without ink keys. Temperature is used to control the color tones which
remain constant across the entire width of the print surface. Many adjustments that are necessary with conventional offset printing such as setting ink keys are not needed on the Premius.
|
|
|
|
|
|
Genius 52 UV
Standardized sheetfed offset with waterless and UV technology without ink zones for printing on plastic and carton.
The economic strengths of the Genius 52 UV lie in small and medium-size print runs. Its most striking advantage is the small amount of setup work and the short period of time until the first "good sheet" is produced. It is inked up more quickly than other machines.
Specifications
General
Printing system: waterless offset printing
Printing units: 4 standard (or 5 optional)
Inks: UV-curing inks
Print substrates: from 0.1 to 0.8 mm (0.004 to 0.03"), (depending on substrate) PVC, ABS, PS, PE, PET, PC, carton and paper
Performance: max. 8,000 sheets/hour (depending on print substrate)
Stack height:
Sheet feeding 600 mm (23.62") max.
Sheet delivery 400 mm (15.75") max.
Formats:
Max. sheet format 360 x 520 mm (14.2 x 20.47")
Min. sheet format 210 x 297 mm (8.27 x 11.69")
Max. printing format 350 x 500 mm (13.78 x 19.69")
Gripper edge: 10 mm (0.39")
Printing plates: waterless, analog or digital
Format / thickness: 404 x 540 x 0.3 mm (15.91 x 21.26 x 0.0118")
Plate change: semi-automatic, register-true, complete plate change in less than 5 minutes
Length x Width x Height: 3,825 x 3,278 x 1,906 mm (150.6 x 129.1 x 75.0")
Footprint: approx. 12 m2 (129.2 sq.ft.)
Total weight: 6.2 tons (approx. 13,700 lbs)
Air consumption: 800 l/min (7 bar / 101.5 psi)
Power connection:
Connected load: 3 x 400 V / 230 V (± 10 %) TN-S-net, 50 Hz
Electric power: 50 kVA
Amperage: 84 A
Backup fuse: 100 A
Technical alterations reserved.
|
|
|
|
|
|
CD-Print
CD, DVD and Blu-ray (BD) printing in photorealistic quality using waterless offset printing and UV technology. Also suitable for small print runs.
CD-Print from KBA-Metronic AG gives manufacturers and service providers in
the CD, DVD and BD sector the efficiency, flexibility and quality differentiation that they need to deliver what customers are looking for. CD-Print is ideal for small to medium print runs. It offers professionals a very efficient professional solution, which novices also find easy to use.
6,000 photorealistic prints per hours, minimal startup waste and fast changeover make CD-Print the superior choice. The system features relatively low operating costs, which are made possible by waterless offset printing using short inking technology, one-man operation and reproducible print runs. Because CD-Print uses UV technology combined with a high-performance drying system, the discs can flow into downstream operations right after printing to avoid unwanted idle time.
CD-Print features a practical compact, modular design. It is designed for
tomorrow’s applications. Two additional print stations for decorative colors can be added to CMYK printing. In addition to the white basic unit which comes as standard equipment, a varnish unit can be supplied as optional equipment which gives the disc an appealing finish.
CD-Print is the ideal partner wherever space, cost and time are crucial
production parameters.
|
|
6 Colors Offset Printer
4 Colors in 1 line plate to ensure the average printing roller pressure from start to end.
Model: HS-480WD
- Computer to Film system.
- Motor driving conveyor loading/unloading type according to CE required, no moving parts outside.
- Linear indexing printing conveyor table.
- 4 colors in one line plate to ensure the average printing roller pressure from start to end.
- Alternative or combination for screen and offset printing.
- Quick plate change
- Fully compatible integration with ldent code and print label check. (optional)
- Special printing table design, no ink contamination.
- Quick change from CD to DVD printing.
|
|
Overview
Discproducer (PP-100) is ideal for a wide range of markets including retail photo centers, photographers, service bureaus, church groups, education and more. It has all the features you need to print and burn up to 100 customized CDs or DVDs at a time. From its vibrant six-color inkjet printing and precision AcuGrip™ robotic arm to its easy-to-use software and unmatched reliability, with the Discproducer you'll get the high quality results you're looking for every time.
Product Features
- 100 disc capacity
- AcuGrip™ technology minimizes two-disc feeding
- Highest quality printing in its class with MicroPiezo technology
- Six individual, high capacity ink cartridges
- Low-ink sensor and LED for each cartridge
- Publishing speeds of up to 30 CDs and 13 DVDs/hour
- Compact, dust-proof rugged construction for top reliability
- Easy-to-use software with label templates
- Economical to operate and maintain
|
|
|
|
