Facing with the management of increasingly important flow in the distribution centers, logistic platforms or in production sites, the "PALLET LIFT MONTEPAL®" is indispensable to the circulation of your pallet between the different levels of production and storage.
* Mechanical welded chassis in several parts which allows one or more changes of floors without making works of civil engineering
* Deposit and pick up of pallets can be made with a pallet truck and/or with a fork lift truck
* Autonomous utilization or integration in a conveying line
* Palletised loads until 2000 kg
* Cadence until 150 pallets/hour
* Energy : hydraulic or electric
* Long-lived material : sensitive parts of the machine distant from handling engines
|
|
Innovative solutions for heavy load handling from 0.1 to 100t
The heart of our lift systems are the original WINKEL Combined Bearings, proven for more than 28 years in heavy load handling up to 100 t. Rigid, low maintenance and cost effective
- More than 28 years experience in the design of rigid and cost effective lift systems
- Economical unit construction system, proven for many years
- State of the art design in 3-D with PRO-ENGINEER
- High qualified staff in designing and production
- All systems designed for continuous use and low maintenance
- Complete lifting systems from a single supplier
- Deliveries incl. documentation and fast spare parts delivery
- You have the task – we have the quick solution
- High flexibility on customer demand
|
|
If you use open bottom containers or skids, now you can transport and palletize with a single unit. Loads can be adjusted up and down at the touch of a button. They feature:
- Extra rugged construction
- 1,600 pound first stage capacity
- Infinite height adjustment within the working range
- Internal battery charger and battery discharge indicator
- Ergonomic contoured handle and group controls for operator convenience
- Dual front casters to absorb the shock of uneven surfaces
- Auto locking casters to prevent movement when unit is in the raised position
|
|
Pallet lifters are versatile tools for loading, unloading, and transporting materials of various kinds and sizes. Pallet lifters maximize the efficiency of overhead material handling systems and are especially helpful in areas that have narrow storage aisles or are inaccessible with fork lift trucks.
Bushman AvonTec pallet lifters hang level when empty and when properly loaded. They feature high strength steel forks and welded steel construction that provide maximum strength, low unit weight and years of reliable service. All Bushman AvonTec pallet lifters meet or exceed the requirements of the ASME B30.20 and ASME BTH-1 Standards.
|
|
1055 Crane fork "German style"
Stepless manual adjustment of prong spread between 450mm and 950mm. Height predefined.
The quoted loading capacities are valid when the centre of gravity of the load is 680mm from the crossbeam. Prong length 1000mm.
Options:
with steplessly adjustable (manual) bearing ring as weight compensation
with sprung lifting lug for automatic weight compensation
|
|
1054 Crane fork
Width adjustable steplessly between 450 and 950mm by manual adjustment of prongs. Height can be adjusted between 1150 and 1750mm using cotter pins. Automatic weight compensation via compression spring. Safety chain included.
The quoted loading capacities assume a distance of 680mm between the crossbar and the centre of gravity of the load.
Options:
* with protective basket in special sizes
* with loading box in special sizes
* available in any size
|
|
Survey pallets of type NIVO PIK ref. VNF
Apparatus allowing the loading of a pallet the level of the ground per transpallet or lifting truck and to have a movement of rise to keep an ergonomic position lasting the loading or unloading of the pallet
Charge with 250 to 1500 kg
Order rise/descent by button with maintained contact
Side or frontal loading
Electrohydraulic rise
Électropiloté valve fixed on the jack
EC normalizes
Option:
dimensions of the plate or the forks
|
|
MODEL: ECO HLS SERIES (HIGH-LIFT) SELF-PROPELLED STACKER
(Also available with adjustable straddle Legs)
Key Feature: Triple Mast
TWO MODELS: HLS15-45 AND HLS15-53
Capacity: 1500 kg.
Fork Length: 1150mm
Overall Length: 1955mm
Raised Fork Height: 4500mm / 5300mm
Mast Height (Collapsed): 2100mm / 2350mm
Mast Height (Raised): 5070mm / 5820mm
Turning Radius: 1629mm
Drive Wheel: 250mm dia
Travel Speed (With load): 4.5 km/h
Travel Speed (without load): 5.6 km/h
Battery: 24 V / 210 Ah
Lift Motor Power: 2.2 kw
Charger: 12V / 10A
Dead Man Brake
Weight: 915 kg / 955 kg
|
|
SV – HIGH, HIGHER, HIGHEST!
Unique features of the new SV12:
The STILL SV12 stand-on high lift pallet truck is designed for a high turn round of goods up to 1,200 kg
Individual possibilities for use, due to its multi-functionality: Serving racking, horizontal transport, loading and unloading lorries, block stacking (truck < 800 mm wide), order picking of goods, working / lifting table
The operating philosophy, which conforms to that of a forklift truck, means greater safety: right hand driving, lifting / lowering and holding; left hand steering
In day to day use the comprehensive ergonomic studies pay off: with the SV12, even after many hours, the operator can still concentrate on work.
|
|
QUICK LIFT (Q.L.) PALLET TRUCK
(Lifts 200 kg. in only 5 strokes)
From 200-2000 kg in normal 10 strokes
MODEL: ECO Q.L. (" Quick-Lift ")
Capacity: 2000 Kg
Overall Fork Width: 520 / 540 mm
Overall Fork Length: 1150mm
Rasied Height: 190mm / 200mm
Lowered Height: 75mm / 85mm
Available in Single and Tandem Rollers
|
|
Stainless steel high-lift truck
Optimum stability and safety.
Manual synchronous telescopic hydraulics.
With serial rapid lift and soft lowering.
Hygienic, rust-free stainless steel design.
Material: stainless steel 1.4301.
Surface: glass bead-blasted.
Serial polyamide rollers.
Dimensions: 1570 x 730 x 1463 mm
Lift, manual: 720 mm
Lift height: up to 1090 mm
Fork length: 1120 mm
Fork height, lowered: 90 mm
External fork separation: 560 mm
Fork width: 160 mm
2 castor rollers: Ø 200 mm
2 tandem rollers: Ø 85 mm
2 polyurethane supporting rollers: Ø 100 mm
Weight: 190 kg
Load-bearing capacity: up to 600 kg
|
|
BT High Lifter HHM100/HHL100
BT High Lifter allows for ergonomic handling of goods. The ergonomical working height - fully adjustable - is ideal for distribution and sorting operations. Maximum lift capacity 1000kg, maximum lift height 810mm.
HHM100 - Manual
Quicklift-function as standard with automatic transfer to normal lift with loads over 250kg.
Short truck length provides narrow turning radius.
HHL100 - Electric
Can be pumped manually when the battery is discharged.
Maintenance free battery and secure battery compartement.
Integrated battery charger with LED indicator. Separate charging cable.
Emergency brake, which can be used as a key.
|
|
Bishamon skid lifts are rugged high-rise,
fork style lifts that provide improved
ergonomics and a functional ease of access for your workforce. By raising the top of the load to a convenient working height and providing easy mobility, skid lifts improve material handling productivity, increase efficiency and reduce potential worker injury adding profit to your bottom line.
|
|
Vehicles from Linde are unsurpassed in safety, handling performance, and ease of use. The best example of this is the Pallet Stacker, which has all operating functions located on the top of the tiller. The innovative Linde Load Control provides heightened precision and sensitiveness.
Compact construction, use of tandem rolling, and powerful drives guarantee high-performance operation on loading docks and throughout the entire warehouse.
|
|
The scissor lift truck that leaves nothing to be desired.
Multifunctional with battery-driven synchronised telescopic hydraulics.
Load-independent light height and lifting speed!
Hygienic, rust-free stainless steel design.
Material: stainless steel 1.4301.
Surface: glass bead-blasted.
Serial polyamide rollers.
GMP-compliant.
Dimensions: 1780 x 540 x 1200 mm
Electrical lift: 720 mm
Fork length: 1180 mm
Fork width: 178 mm
Run-in width: 540 mm
2 castor rollers: Ø 200 mm
2 load-bearing rollers: Ø 85 mm
Weight: 165 kg
Load-bearing capacity: 1000 kg
|
|
Whatever the goods, whatever the warehouse, you'll find Cat Lift Trucks Power Pallets at the very heart of day-to-day operations.
Compact, powerful, versatile and extremely hard working, our extensive range is sure to meet your needs, whether you require a simple pallet truck for light usage, a versatile and efficient power pallet for medium level shift work or the comfort and power of a stand-on or sit-on truck for more intensive applications, Cat Lift Trucks has the solution for your business.
|
|
MODEL: EBSL10
MANUAL PUSH-BATTERY LIFT SCISSOR LIFT
Capacity: Kg 1000
Raised Height: mm 800
Lowered Height: mm 85
Fork Length : mm 1245
Fork Width: mm 550 / 685
Steer Wheel: mm 180 dia. Polyurethane
Load Rollers: mm 74 dia. Polyurethane
Battery Voltage: V 12 / 125 Ah
Charger : V/A 12V / 10A
Weight: kg 181 kg
|
|
Standard Features:
• Can be used with standard GMA
pallets and/or skids
• Dual-purpose product allows for
both transport and load positioning
• Handles and steers like a standard
pallet jack
• Lifting fork height up to 34”
• Lift capacity of 2000# (see chart)
• On-board, automatic battery charger
• Efficient 24 VDC battery system
powers lift operation
• Electro-mechanical outrigger
actuation with position sensors
• Electronic operator console with
“Raise” and “Lower” push buttons,
dual function key / battery disconnect
switch, outrigger position LEDs and
battery status LED
• 8” diameter polyurethane steering
wheels
• 3” diameter polyurethane load wheels
• Durable powder coated finish
|
|
Walk behind, Step-on, Stand-on, Sit-on, our pallet movers gives operators flexible operation modes. Designed to offer more capacity over various distances and heights, these Electric Pallet Movers are an excellent solution for the compact warehouse.
- Pedestrian Power Pallet Trucks - 1.3 ~ 2.0 ton Capacity
- Stand-On Power Pallet Trucks - 2.0 ton Capacity
- Platform Power Pallet Trucks - 2.0 - 2.5 ton Capacity
- Sit-On Power Pallet Trucks - 2.0 ton Capacity
|
|
General description
Electric and Manual Walkies
5.000lb Capacity Hand pallet Truck
Designed for reliable performance to maximize productivity and minimize downtime, our electric and manual walkies have many value-added premium features delivered as standard equipment.
Our electric walkies are built tough. To ensure dependable performance, the frames are rigorously tested and fully loaded at 100 percent of their rated capacity for 60,000 cycles. And with one of the shortest head lengths in the industry, the 2WP4500-2WP6000 series offers an extremely tight turning radius allowing for ease of operability and better productivity
Model Multiple
- Type Hand Pallet Truck
- Power voltage N/A
- Capacity (lb) 5000
- Top speed (mph) N/Q
|
|
MODEL: EMSL10
MANUAL PUSH - MANUAL LIFT SCISSOR LIFT
Capacity: Kg 1000
Raised Height: mm 800
Lowered Height: mm 85
Fork Length : mm 1150
Fork Width: mm 550 / 685
Ind. Fork Width: mm 160
Steer Wheels : mm 180 dia. Polyurethane
Load Rollers: mm 74mm dia. Polyurethane
3-Position Control Handle (Raise-Neutral-Lower)
Weight: kg 100 kg
|
|
Electric and Manual Walkies
5.000lb Capacity Hand pallet Truck
Model Multiple
Type Hand Pallet Truck
Power voltage N/A
Capacity (lb) 5000
Top speed (mph) N/Q
|
|
For a durable, economical hand pallet truck, nobody beats Presto. Our HPT Trucks are loaded with features that most more expensive models can't claim.
Features:
- 5500 lb capacity
- Powder coated paint finish
- Solid steel formed forks and chassis with reinforced frame and gusset
- Highest quality pump with special lowering valves and an overload by-pass
- Steer wheels 7" x 2", load wheels 2 7/8" x 3 1/2"
- Nylon steer wheels and load wheels
- All pivot points come with sealed bearings
- 9 strokes to full raised height
- Fork tip roller system for smooth transition in and out of pallets
- Articulating steer axle
- Ergonomic cushioned handle with 3 function trigger for raise, lower and neutral operation
- Polyurethane wheels available
|
|
|
We equip every AC electric end-rider walkie with the fork length best suited to your specific requirements. Standard lengths include our shortest 36-inch forks, popular for beverage handling; 48-inch forks, for use with standard GMA pallets; 96-inch "long-john" forks; and 144-inch forks, designed for handling double and triple pallets and ideal for fast-moving environments
|
|
Lifter QX22 S4 1150x680
Main features
Nominal load capacity : 2200 kg
Driving system : Pedestrian or stand-on platform
Fork length : 1150 mm
Fork width : 170 mm
Traction motor nominal power : 2 kW
Minimum admitted battery capacity : 230 Ah
QX22 Series
The QX22 is the ideal machine where high speed movement of goods over long distances are required. Its high load capacity (2.2T), its excellent translation speed(10km/h), its high battery capacity(315Ah) and mobile battery change station makes the QX22 the best choice for multi-shift operations.
|
|
Lifter GS 25S4 950x525
Main features
Nominal load capacity : 2500 kg
Frame material : Painted steel
Fork length : 950 mm
Fork width : 150 mm
Stowage passage : 1632 mm
Turning radius : 1167 mm
GS PRO Series
The GS Pro Series, is an excellent tool for lifting and carrying loads on pallets or size-standardised containers. Thanks to its light weight, smooth movement and manoeuvrability, all the GS Series models are an ideal working tool for use on smooth floors and other kinds of surfaces.
|
|
Lifter PX 20 20S4 1185x555
Main features
Nominal load capacity : 2000 kg
Frame material : Painted steel
Fork length : 1185 mm
Fork width : 180 mm
Accuracy : 0,1 %
Division : 1 kg
Scale Series
The Scale Series is available in two different models, both with an intelligent weighing device with several options. Suitable for lifting and carrying heavy loads, this Series is not designed for "official" weighing but is extremely helpful for internal use.
|
|
Lifter PX 20 20S4 1185x555
Main features
Nominal load capacity : 2000 kg
Frame material : Painted steel
Fork length : 1185 mm
Fork width : 180 mm
Accuracy : 0,1 %
Division : 1 kg
Scale Series
The Scale Series is available in two different models, both with an intelligent weighing device with several options. Suitable for lifting and carrying heavy loads, this Series is not designed for "official" weighing but is extremely helpful for internal use.
|
|
|
|
