The Model 3800 is a handheld condensation particle counter that detects ultrafine particles in many applications. With this advanced technology, users can implement nano-sized particle research in occupation and working areas. The Model 3800 is appropriate as a screening tool to evaluate filter performance and gasket leakage. It is also an optimal tool to detect black carbons, such as soot and smog, which are normal constituents of exhaust contaminants from combustion.
|
|
|
Kanomax handheld particle counters are designed for cleanroom certifications. The Model 3887 3-channel particle counter is CE certified and ensures compliance with industry standards, such as ISO 14644-1. It is also perfect for initial assessment of indoor particulate levels and provides instant, repeatable levels of toxic parameters, VOCs and particulates.
|
|
|
Kanomax handheld particle counters are designed for cleanroom certifications. The Model 3886 measures 5 particle sizes simultaneously with optional multi-functions, such as air velocity, temperature, and humidity. Its low air velocity measuring function is suitable for laminar flow units.
|
|
|
The Model 3900 is a CE certified 6-Channel Portable Laser Particle Counter with a high flow rate of 1.0 cfm. The Model 3900 has a large color touch screen and its user-friendly interface makes operation easy. In addition the Model 3900 offers multi-parameter measurements including airflow, air temperature, humidity, and differential pressure. It also includes a multi-standard operation mode to ensure compliance with industry standards, such as ISO 14644-1, Federal Standard 209E, British Standard 5295 and EC GMP.
|
|
Features the sensitivity of larger instruments and easy handheld operation. Counts two sizes of particles; the second size is user-selectable. Configure sample times from one second up to 24 hours. Automatic shutoff when the battery charge drops below a safe operating level to maintain power to preserve data.
-0.3 micron sensitivity (227B) or a 0.5 micron sensitivity (227A)
-Counts two sizes of particles
-Compatible with PortAll Version 2 software
|
|
From the MET ONE legacy, Hach Ultra continues providing superior sampling with high reliability for electronics and pharmaceutical cleanroom applications
|
|
|
|
|
|
AEROTRAK™ HANDHELD PARTICLE COUNTER
The TSI AEROTRAK™ 9303 Handheld Particle Counter offers the most features and flexibility for customers interested in low cost and versatile handheld particle contamination monitoring. The 9303 features a sturdy and yet lightweight high-impact injection-molded plastic design for easy handling. The instrument is easy to configure using an intuitive keypad. The internal memory can store up to 1,500 sample records of particle count data which can be conveniently viewed on screen or downloaded using a USB port.
Features and Benefits:
- Size range 0.3 - 10 μm
- 0.1 CFM (2.83 LPM) flow rate
- Up to 3 channels of simultaneous data
I- SO 21501 compliant
- USB serial output
- 1,500 sample record storage
- 999 location labels
- Large 3.6-inch display
- On screen data review
- User selectable middle size channel
- Removable Li-ion battery
- Internal audible alarm
- Intuitive keypad menus
- High impact injection molded plastic
- Lightweight - only weighs 1.3 lbs (0.58 kg)
Applications:
- Particle contamination monitoring
|
|
|
|
|
|
P-TRAK® ULTRAFINE PARTICLE COUNTER
The TSI's P-TRAK® Ultrafine Particle Counter (UPC) - Model 8525 is a totally new approach to eliminating IAQ problems. This portable instrument detects and counts ultrafine or nanoparticles (smaller than 1 micrometer in aerodynamic diameter) that often accompany or signal the presence of a pollutant that is the root cause of complaints. It is now being used to track down some of the most difficult IAQ problems imaginable.
The P-TRAK UPC locates obvious pollutant sources such as boilers, furnaces, vehicles and also detects the not-so-obvious sources such as photocopy machines and printers. Use this instrument to detect the migration of toxic exhaust gases, malfunctioning office equipment, pinhole gasket leaks in boilers and a wide variety of other problems.
Features and Benefits:
- Real-time ultrafine particle counter
- Solves tough IAQ problems
- Easy to use
- Data log information
Applications:
- Check office equipment
- Clean room containment checks
- Filter checks
- Check fume hoods
- Check safety cabinets
- Vehicle emission migration
- Combustion leaks
- Control smoking areas
|
|
PC 2400 PS Portable Sampler
The PC 2400 PS Particle Counter provides the user unequaled flexibility. The instrument operates as a Grab-Sampler for analysis of individual samples, and in continuous, On-Line mode for real time process monitoring. Windows based software provides instrument configuration, data acquisition, and reporting capabilities to meet the user's specific needs.
BENEFITS/FEATURES
- Laboratory or On-Line use
- Fully portable with carrying case
- Low maintenance sample cell
- User adjustable size ranges
- Automatic sample purge
- Up to 16 size ranges
- Easy to use Windows based software
|
|
|
|
|
|
Characteristics
The new STAUFF Laser Particle Counter I is a microprocessor-controlled 8-channel particle counter designed for monitoring the degree of contamination of mineral based hydraulic fluids. In contrast to other commercially available particle counters, the LasPaC I is characterized by a few special features. The readings from the LasPaC I will immediately indicate the condition of the hydraulic system, the data will be documented, and you will be able to intervene at an early stage in order to prevent wear and damage to the components in the hydraulic system. This does not only minimize repair costs, but also reduces overall equipment downtime.
Technical Data
* Microprocessor-controlled 8-channel particle counter for contamination monitoring of mineral based hydraulic fluids
* Laser sensor cross-section: 500 x 500 %u03BCm
* Maximum concentration: 24,000 p/ml at a flow rate of 25 ml/min (ISO 4406 Code 23)
* Calibration according to ISO 11 171 (1999):
4 to 70 %u03BCm(c) relating to ISO 4406 (1999) and SAE AS4059 Rev. D (2001)
* Calibration according to ISO 4402 (1991):
2 to 100 %u03BCm relating to ISO 4406 (1987) and NAS 1638 (1964)
|
|
| ... products without technical information |
| |
|
|
|
|
Portable Particle Counting System for Oil and Hydraulic Fluid
PAMAS S40
- 8 channel high resolution digital system for analysis
- According to ISO 4406:1999 4µm(c), 6µm(c), 14µm(c) based on ISO 11171:1999 calibration
- According to ISO 4406:1987 (2µm), 5µm, 15µm based on ISO 4402 calibration
- Pressureless sampling as well as pressurized up to 420 bar (6000 psi)
- User friendly operation using touch screen with graphic display
- Compatible with ISO 4406:1999, SAE AS 4059D, ISO 4406:1987, NAS 1638
- Real portability with lab system accuracy
- User can configure the system to their needs in profiles
- Pressurized sensor avoids degassing
- Display and printout provide triple ISO codes, NAS- and SAE cleanliness classes, measurement volumes and particle numbers
- Highest repeatability and accuracy
- Password protected user levels
- Storage of more than 500 measurement data sets
- Built in battery for data backup
- Viscosity independent up to 200 cSt
- Pressurized sampling up to 350 cSt
- Minimess M16x2 and standard connectors (DIN ISO 2353) or user specific
- Operates on 90 - 230 V AC (50/60 Hz), 12 - 30 V DC or internal battery
|
|
Parker's IQ200 particle counter is specifically designed to provide continuous, on-line monitoring of the particulate contamination level of hydraulic and lubrication fluids. This compact, affordable particle counter can connect to virtually any system to give the user real-time data at the specified interval. Other features include:
• Remote and multiple system monitoring from one location
• Completely automatic
• Laser accuracy and repeatability
• Programmable test intervals from 3 seconds to 24 hours
• Adjustable contamination level alarms
• Integral flow and calibration check
• ISO 4406-1999 reporting format (4, 6, 14 micron) and correlation to NAS 1638
• User friendly Windows-based software
• Data displayed instantly in chronological or graphic form
|
|
|
|
|
|
· Rugged portable unit for quick and simple particle
analysis on site
· Simple menu-driven operation
· Laser sensor with 12 channels for exact and reproducible
results
· Possibility of suction and pressure side operation
· Integrated suction pump with new system. Flow
regulation independent from viscosity and pressure
· Prior to each measurement automatic flushing of
the gauge head
· Adjustable measuring mode (single and cyclic
measurements
· Long term measurements up to 330 hours
· Memory bank for 1400 measurement values (up to
99 series).
· Calibration according to ISO 11171:1999 (NIST)
· Analysis according to ISO 4406:1999
Analysis according to ISO 4406:1987
Class 1 up to 24
· Analysis according to NAS 1638
Class 0 up to 12
· Measuring range ISO 4402: 2 - 100 µm
Measuring range ISO 11171: 4 - 50 µm
· Indication of the absolute numbers of particles in all
channels
· Serial interface for further data processing via PC
· Integrated printer
· Threshold function contact for preset min. and
max. classes
|
|
Precision optics and advanced electronics make Chemtrac Particle Counters perform with unparalleled accuracy. Chemtrac's patented sensor flow cell is externally mounted to eliminate any possibility of water damage to counter electronics. A constant head, flow controller with low flow alarm provides a simple, reliable, sample system. The PC 2400 D communicates digitally using a nonproprietary serial interface which emulates the Optomux Opto 22 protocol. Ninety six (96) counters can be multi-dropped on a single RS485 serial communications loop up to 4,000 feet
BENEFITS
- Optimize Crypto and Giardia removal
- Provides Particle Size & Quantity Information
- Immediate Response To Process Changes
- Maintain High Quality Finished Water
- Optimize Filter Backwash
- Improve Filter Performance
- External Sensor Simplifies Sensor Maintenance
- Network or Stand-alone Operation
|
|
General description:
Portable system for the measurement of particle number and size in liquids and super-viscose media. The available sensors include a measuring range of less than 1 µm - 150 µm. It is possible to measure directly at pressure pipes up to 10 bar (optional 315 bar). Results are shown immediately on the LCD screen. For additional data processing there is also the Log and Show 3.1 (water) or 3.2 (Oil) evaluation software available.
The protocol printer integrated in the device provides printout of measuring sequences and sensor response lines.
The measuring system is available in either the oil or water version.
Optional DPS-1 pump system: self-priming pump for measuring volumes of more than 10 ml.
|
|
|
|
|
|
Micromeritics Elzone II 5390 Particle and Cell Size & Count Analyzer – Combining Modern Technology with a Proven Method
Unlike other measurement techniques, the electrical sensing zone method is capable of accurately sizing and counting samples of varying optical properties, densities, colors, and shapes. Micromeritics’ new Elzone® II 5390 particle size analyzer utilizes this powerful particle characterization technique to determine quickly and accurately the size, number, concentration, and mass of a wide variety Biological and Industrial materials. Automated features include: start-up, run and shut-down routines; blockage detection and clearing; flushing/rinsing; and calibration. The Elzone determines particle / cell size in a range suitable for a wide variety of industrial and biological specimens down to 0.4 µm. A high level of accuracy and resolution, speed, ease of use, and its compact size make the Elzone equally suitable for industry, quality control, and research and development laboratories.
Extensive statistical analysis features are included. In addition, optional Confirm™ 21 CFR Part 11 software assists with compliance to FDA regulations. Combined with Micromeritics' IQ and OQ services, the user can be assured that the Elzone system is validated for accuracy, reliability, consistent intended performance, and provides safeguards to protect the integrity of analysis records.
|
|
|
|
|
|
Basic specifications
1. Size range:1-3000um
2. Max.Ampl.1600
3. Max.Resol.0.1um
4. Repeatability:<3%(error due to sample not considered)
5. Digital Imaging Camera(CCD):300M pixels
6. Microscope:Biological microscope(made in China)
7. Biological microscope(import)
8. Metallagraphic microscope(made in China)
9. Ruler scale:10um
10. Output Results:Particle Size Distribution,Aspect Ratio,Circularity distribution
11. Auto cut speed:93%
13. Operating System:Windows2000,XP
14. Data port:by RS232 or USD
Brief introduction
BT-1600 Image Particle Analysis System was a muti-functional particle analysis system analyzing particle size distribution and other imaging information.It consists of optical microscope,digital imaging camera(CCD),image acquisition card,computer and printer.When in operation,it firstly shot particle by special video camera and microscope then transmit to the computer,after that processing and analyzing by image analysis program, finally show and print by monitor and printer.It is characterized by intuitive,visualized and accurate analysis not only observing morphology of particles but also generating particle size distribution and aspect ratio etc therefore provide a high-performance tool for fields of scientific research and productions.
|
|
Multifunctional Particle Counting System for Liquids
Mobile System for Particle Counting Filtertest
and Cleaning Control PAMAS 3108 FM
Portable integrated system with sensor and sampling system
- Compact analysing System for liquids:
Water, drinking water and organic fluids
- Utmost repeatability and accuracy
- Size range: 1 – 200 µm:
calibration according to ANSI/NFPA T2.9.6R1-1990, ASTM F 658-80
- Software in English, German, French, Polish, Finnish and Spanish
- Pressureless sampling as well as under pressure up to 210 (420) bar
- Viscosity independent up to 160 cStokes
(pressurized sampling up to 300 cStokes)
Remote control with PAMAS PMA program
- Automatic storage and documentation in readable format
- Classification of particle number and size within the sensor size ranges
- highest flexibility
- Printout including all sample parameters, numerical and graphical
presentation and all main cleanliness classes
|
|
General description:
Measuring of particle number and particle sizes in liquid media specifically designed for lab and pharmaceutical applications. The system includes the syringe device illustrated in the photo and a PC measuring card (PCI). You can use any syringes ranging from 1 ml - 25 ml. The system is available with various sensors for particle sizes of less than 1 µm - 500 µm.
Optional: sample-changer for up to 20 sample vessels.
Software SW-PE: Size classes freely definable, great variety of evaluation options, high-performance Excel Export, for Windows 95/98 and NT 4.0./2000/XP.
Software SW-CA: special software for the pharmaceutical sector. Windows 95/98 and NT 4.0/2000/XP.
|
|
|
|
