* Reliable and rugged industrial PC/104 and PC/104-Plus boards
* Solutions with PC cards, FireWire, USB, Ethernet, switch, digital and analog I/O, serial lines, CAN ...
* Remote man-machine interface solutions (REMMI)
* IDE based storage solutions ( CF and PCC)
* Cable kits for all PC/104 modules for easy installation
* Free available drivers
|
|
Today, the PC assumes a key position in automation technology. Together with a real-time operating system, e.g. Windows® NT, it creates an ideal hardware platform for control and visualisation of process data. By using so called SoftPLCs the PC penetrates into application areas that have been the domain of classical programmable controllers.
Fieldbus systems with remote input and output modules are used for the data transfer between the PC and the automation equipment. We offer special interface cards since the PC does not feature a direct link to the fieldbus.These intelligent cards manage the entire data transfer. Only useful data are passed onto the user applications.
|
|
|
|
|
|
Addi-Data presents the new 32-bit digital input/output board PC104-PLUS1500 which has 32 I/O. The PC104-PLUS1500 is equipped with both PCI and ISA connectors on the circuit board. The direct connection to SPS controls is guaranteed because the I/O channels correspond to the industrial standard +24 V for “logic 1”. The input voltage is designed precisely so that the PC104-PLUS1500 switches reliably to „0“ or „1“, even in the case of disturbances. With 0-14 V as “low” and 19-30 V as “high” the ranges are set very high. In order to ensure that the board is interference-free and thus the flawless use in applications, the 32 digital inputs/outputs are isolated up to 1000 V and protected against fast transients, electrostatic discharge and high-frequency EMI.
Two digital inputs are interruptible and thus the main programs are relieved of the standard monitoring and evaluation tasks. In order to avoid undefined states the outputs stay on “status 0” when the PC is started.
The High-Side switch outputs that are available on the PC104-PLUS1500 are designed for inductive loads and PTC resistors, in contrast to the open collector outputs. They work with a nominal voltage of 24 V and an output current of 150 mA and are protected against short-circuit, overtemperature and undervoltage. Additionally, 3 timers or counters are available, whereas Timer1 can work as programmable watchdog for resetting the outputs. A status register that can be read out allows to detect short-circuit or overtemperature.
|
|
Product Range:
AIM104-IN16 16 opto-isolated inputs
AIM104-IO32 32 TTL compatible digital I/O
AIM104-RELAY8-IN8 8 changeover relays and 8 opto-isolated inputs
AIM104-OUT16 16 opto-isolated Darlington driver outputs
AIM104-OPTO-IN8/OUT8 8 opto-isolated inputs and 8 opto-isolated outputs
AIM104-ADC16/IN8 Isolated 16 channel 12 bit ADC and 8 channel digital input
AIM104-MULTI-IO Isolated 16 channel 12-bit ADC, 2 channel 12 DAC and 8 channel digital input
AIM104-MOTION-1 8-bit PC/104 module providing single axis stepper / DC servo motor control with on-board drivers
AIM104-MULTI-IO Isolated 16 channel 12-bit ADC, 2 channel 12 DAC and 8 channel digital input
CTR-1462 Galvanically isolated DIO, 24 inputs and 24 outputs
DAQ-1278 Cardbus controller with 1 x 32-bit slot for type I, II and III card support
|
|
Micronix PC/104 boards is European manufactured expansion modules for the PC/104 bus, designed for industrial and process control systems and for automotive applications.
|
|
MOPS PC/104 CPU Modules
MOPS PC/104 family present the largest consistent single board family - full accessory re-use is a fact - making easiest up and downgrades very easy and extremely cost effective. Choose from lowest power up to Pentium® M.
MOPS serve every performance class highly reliable - full featured.
PC/104 SBC and Peripherals
Kontron Standalone Single Board Computers serve in every format,even with consistent product families that allow full accessory and chassis re-use. Kontron is your best choice for standalone boards - off-the-shelf - in all performance classes, in all formats. Time to market is zero - don't wait, start today!
|
|
Eurotech offers a comprehensive range of industrial PC104, embedded PC and single board computer products. These are supported by a wide selection of Development Kits for the leading embedded operating systems. The functionality of the processor boards can be expanded using PC/104 and/or PCI I/O and comms modules.
Products
GEMINI
5.25" Embedded Intel Core 2 Duo/Solo SBC
SBC-GX533
EBX AMD Geode GX 533 SBC
APOLLO
EBX format Intel Pentium M/Celeron M based SBC
PEGASUS
PC/104 format 133MHz AMD ELAN SC520 SBC
TITAN
PC/104 format 520MHz PXA270 XScale SBC
QUANTUM
PXA270 based SO-DIMM format SBC
ZEUS
EPIC format 520MHz Intel PXA270 XScale SBC
VIPER
PC/104 format 400MHz Intel PXA255 XScale SBC
VIPER-Lite
PC/104 format 200MHz Intel PXA255 XScale SBC
VULCAN
PC/104 format 533MHz Intel IXP425 XScale communications controller
VULCAN-Lite
PC/104 format 66MHz Intel IXP420 XScale communications controller
|
|
PC/104-SK-PLUS2, Starter-Kit for PC/104 incl. PC/104-PCI/ISA adapter.
Please use PC/104-SK-PLUS3 !
The basic single boards contain:
A PC/104, ISA and PCI-Bus slots electrically coupled, a plug for power supply and a keyboard connection.
3.5“ fl oppy drive interface
Mains adapter 110-230 V AC
|
|
Analog Input & I/O
12-bit or less resolution
14 and 16 bit resolution
Analog Output
12-bit or less resolution
Digital I/O
Counter-Timer
Parallel
Special purpose
Serial Communications
LPT Port and 2
|
|
| ... products without technical information |
| |
|
|
|
|
Addi-Data presents the new 32-bit digital input/output board PC104-PLUS1500 which has 32 I/O. The PC104-PLUS1500 is equipped with both PCI and ISA connectors on the circuit board. The direct connection to SPS controls is guaranteed because the I/O channels correspond to the industrial standard +24 V for “logic 1”. The input voltage is designed precisely so that the PC104-PLUS1500 switches reliably to „0“ or „1“, even in the case of disturbances. With 0-14 V as “low” and 19-30 V as “high” the ranges are set very high. In order to ensure that the board is interference-free and thus the flawless use in applications, the 32 digital inputs/outputs are isolated up to 1000 V and protected against fast transients, electrostatic discharge and high-frequency EMI.
Two digital inputs are interruptible and thus the main programs are relieved of the standard monitoring and evaluation tasks. In order to avoid undefined states the outputs stay on “status 0” when the PC is started.
The High-Side switch outputs that are available on the PC104-PLUS1500 are designed for inductive loads and PTC resistors, in contrast to the open collector outputs. They work with a nominal voltage of 24 V and an output current of 150 mA and are protected against short-circuit, overtemperature and undervoltage. Additionally, 3 timers or counters are available, whereas Timer1 can work as programmable watchdog for resetting the outputs. A status register that can be read out allows to detect short-circuit or overtemperature.
|
|
Product Range:
AIM104-IN16 16 opto-isolated inputs
AIM104-IO32 32 TTL compatible digital I/O
AIM104-RELAY8-IN8 8 changeover relays and 8 opto-isolated inputs
AIM104-OUT16 16 opto-isolated Darlington driver outputs
AIM104-OPTO-IN8/OUT8 8 opto-isolated inputs and 8 opto-isolated outputs
AIM104-ADC16/IN8 Isolated 16 channel 12 bit ADC and 8 channel digital input
AIM104-MULTI-IO Isolated 16 channel 12-bit ADC, 2 channel 12 DAC and 8 channel digital input
AIM104-MOTION-1 8-bit PC/104 module providing single axis stepper / DC servo motor control with on-board drivers
AIM104-MULTI-IO Isolated 16 channel 12-bit ADC, 2 channel 12 DAC and 8 channel digital input
CTR-1462 Galvanically isolated DIO, 24 inputs and 24 outputs
DAQ-1278 Cardbus controller with 1 x 32-bit slot for type I, II and III card support
|
|
Micronix PC/104 boards is European manufactured expansion modules for the PC/104 bus, designed for industrial and process control systems and for automotive applications.
|
|
Analog Input & I/O
12-bit or less resolution
14 and 16 bit resolution
Analog Output
12-bit or less resolution
Digital I/O
Counter-Timer
Parallel
Special purpose
Serial Communications
LPT Port and 2
|
|
| ... products without technical information |
| |
|
Galil offers a complete line of single and multi-axis controllers for stepper and servo motors. Interfaces include PCI, ISA, PC/104, cPCI, VME, USB, RS232 and Ethernet. Modes of motion include point-to-point positioning, jogging, linear and circular interpolation, contouring, ecam and electronic gearing. Also programmable I/O for interface to external sensors.
|
|
|
|
|
|
The POSYS® 3104 (Designed & Made in Germany) is a PC/104 form factor board dedicated to high performance motion control applications with extensive interpolation functionality. The POSYS® 3104 is designed to control up to 4 axes of servo and stepper motors and provides hardware linear, circular, Bit Pattern and continuous interpolation which allow to perform the most complex motion profiles. Update rates per axis do not exist as each axis runs in absolute real-time mode simultaneously which makes these boards to one of the best performing motion controllers for up to 4 axes in the market.
The POSYS® 3104 is a low-cost PC104 motion controller offering a wide range of possibilities. The controller is dedicated to pulse & direction output which allows to control any type of motor provided the driver/amplifier is capable to accept pulse & direction signals. Many amplifiers on the market exist for this purpose (we supply versions from AMC) which can even be configured for either brushed or brushless servo motors.
The usage of one controller type throughout the system, but still keeping it open for various motor types, depending on your customer's demands, enhances this controller to be your first choice. Software written for this controller does not need to be re-written again. Time-to-market design is done once. Equip your machine with steppers or servos or combine them to any configuration you desire.
Due to its possibilities there are practically no limitations to where this controller can be used. Robotics, semi-conductor, medical and harsh industrial environments - where ever you need precise control of your motors the POSYS® 3104 is ready.
|
|
|
|
|
|
The POSYS® 800-B (Designed & Made in Germany) is a state-of-the-art 1 to 4 axes PC/104-Bus motion controller supporting multiple host connection modes and motor types. The POSYS® 800-B supports parallel-bus via PC/104-Bus and serial communication RS232. Motor types supported are DC brushed servo, brushless servo, microstepping and stepper motors depending on model each axis individually configurable. Other features are the fast servo loop update rates of 100 µs/1 axis to 400 µsec/4 axes, 5 Mcounts/sec quadrature encoder input and on-board trace capabilities.
Motion profiles include S-curve, trapezoidal (with smoothing factor), velocity contouring, and electronic gearing, linear interpolation for 4 axes. In addition they also support external profile mode which allows the user to download complex motion profiles directly in to the controllers memory reliefing the host from extensive calculation tasks.
With up to 164 commands, depending on model, the POSYS® instruction set offers flexibility and versatility to software application programmers. Instructions are used to initialize and control the motion processor. User selectable profiling modes supported by the motion processor include S-curve, trapezoidal, velocity contouring and electronic gearing. The POSYS® 8xx-B accepts input parameters such as position, velocity, and acceleration from the host and generates a corresponding trajectory. The POSYS® 8xx-B accepts input parameters such as position, velocity, and acceleration from the host and generates a corresponding trajectory within 12.5 µs.
|
|
