Phosphatasing plants are multi-tank machines covered by hooks and surmounted by one or more translation carts. The complete treatment generally consists of: degreasing, rinsing, pickling, rinsing, activating, phosphatising and in the end oiling or drying. The translation carts picks up the baskets containing the workpieces and convey them into the treatment tanks, generally according to the first-in first-out logic, which means that the first basket to enter is the first basket to come out. Once the production speed has been set, the plant conveys all the baskets inside the several treatment tanks step by step. Alternatives and options that may be applied to this series of machines are many and various. Here are some examples:
1 automatic load and unload
2 deoiler
3 flue gas scrubber
4 check rinsing liquids
5 integrated cleaning systems
6 analysis and supervision for the process certification.
For artisan and non-industrialized applications, single - tank machines of our “Agito” series may be supplied.
|
|
|
|
|
|
In order to improve the adhesion of the lacquer on the construction unit, the construction unit must be degreased and treated with a Phoshatierung. Thus also a higher corrosion resistance is reached.
For the different treatment steps there are solutions, with which the parts over spraying technology are treated or with large parts over dipping technology.
The main treatment steps needed for it can look as follows:
Degrease
Pickle
Activate
Phosphatize
Drying systems
Between each step single-step or two-stage rinsing takes place for neutralization.
All medium-affecting parts are manufactured made of stainless and acid-proof high-grade steel. The water consumption is minimized by an optimal filtration and cascade control. The heating of the baths can be brought in electrically, by means of gas or as technical warmth.
Complete and unloading in more automatic or part automatic variant can be taken over by us.
The plants are individually planned, designed and installed at the customer. Security gives you decades long experience in this area of getting a solution adapted to their needs.
|
|
|
|
