Among the TEEM PHOTONICS offer, our High energy picosecond laser Powerchip and Picospark families allow to achieve respectively up to 250uJ of Energy per pulse and ultra high peak power up to 280KW, with pulses down to 300ps and repetition rates up to 40KHz.
They are proposed with outputs at infrared(1064nm) , green (532nm), or UV (355nm for Powerchip family only).
They are specialized for utilization in applications as Marking, Micro Machining, drilling, scribing, trenching, Laser Induced Fluorescence (LIF), Laser Induced Breakdown Spectroscopy (LIBS), Light Detection and Ranging (LIDAR), etc..
Features & Benefits:
- Ultrashort picosecond Nd:Yag pulses (As low as 300ps durations)
- High Energy (Up to 250uJ/pulse)
- Ultra high peak power (Up to 280KW at 25KHz)
- Variety of frequency options
(Up to 40KHz in free running, triggerable up to 4KHz)
- Excellent beam quality (Gaussian, TEM00, M2<1.3)
- Efficient, air cooled
- Long UV life (lifetimes expected to exceed 5k hours)
- Licensed Technology
Passively Q-switched pico-second laser:US Patent 5394413
Fiber amplifier: 4 US patents with IMRA
Optional features:
- Photodiode output for synchronization
- Manual controls for CDRH compliance
|
|
|
SL300 series lasers are an excellent solution for applications where high energy picosecond pulses are needed. Backward-stimulated Brillouin scattering (SBS), used as pulse compression method, is simple and cost-effective. In addition, SBS compression allows generation of pulses within exceptional duration range: from few nanoseconds to 150 ps.
|
|
|
|
|
|
|
The new green diode laser ("LDH-P-FA-530") is based on a master-oscillator fibre-amplifier (MOFA) concept with frequency conversion. The master oscillator generates spectral narrow picosecond pulses at 1064 nm at a variable repetition rate from 10 kHz to 80 MHz using the proven gain-switching technique from PicoQuant. The output of this laser is directly connected to a Ytterbium-doped fibre amplifier (YDFA), which boosts the output from the seed laser by more than 10dB. This output is then directly connected to a fibre-coupled SHG waveguide, which converts the infrared laser emission to green emission (531 ± 3 nm) with a very high conversion efficiency. The final output of the LDH-P-FA-530 reaches up to 1 mW average output power at 40 MHz repetition rate. The pulse width is <100 ps FWHM. The laser emits from a FC/APC fibre connector and can be either collimated or directly connected to suited optical fibres. The laser head can be driven by the PDL 828 'Sepia II', the PDL 800-D or the PDL 800-B. The all-fibre setup makes a topology with a several couplings and interfaces completely maintenance-free.
|
|
|
PicoQuant GmbH and TOPTICA Photonics AG have jointly developed a new high power picosecond diode laser head for the near infrared wavelength range. The system combines a pulsed seed-laser (PicoQuant's special heads of the LDH Series driven by the PDL 800-B / PDL 800-D / PDL 808 / PDL 828 diode laser drivers) and TOPTICA's tapered amplifier technology in a Master Oscillator Power Amplifier (MOPA) arrangement. The PicoTA produces light pulses shorter than 100 ps at an adjustable repetition rate between 1 MHz and 80 MHz, with amplification of the master laser peak power by more than a factor of 10. Systems are available at 730, 780, 980 and 1060 nm.
|
|
