L Pins are removable locating pins, precision ground for accurately aligning holes. The pin is inset into the handle and silver soldered to create a sturdy assembly. The handle is drilled for attaching a cable.
|
|
Beta pins (bichromate galvanized steel & stainless steel AISI 316L)
Double beta pins (bichromate galvanized steel)
Safety beta pins (bichromate galvanized steel)
use in industrial supplies, DIY, entertainment industry, agriculture
|
|
Coiled Spring Pins are shock-absorbing fastening elements that provide flexibility, uniform strength, equal stress distribution, closer diameter tolerances, no interlocking, trouble-free automatic feeding, and they reduce costs. Heavy, standard, and light duty coiled spring pins provide combinations of strength and flexibility to meet the specific engineering objectives of your pinning applications.
SPIROL invented the coiled spring pin and its production technology 60 years ago.
|
|
Hardened Stainless Steel Pins
Material: Stainless steel
DIN : 1.4034 S (X 40 Cr 13)
AISI: 420 F
This quality remains corrosion-resistant after hardening and super finishing
Ra = 0.05 - 0.10
Hardness:
55 HRC (600 HV) centerless ground, lapped and polished
Diameter tolerances: /- 0.002 mm
Measuring Pins
Standard sizes:
In steps of 0.01 mm from 0.50 to 10.00 mm
Material: Steel
as per DIN : 1.3505 (100 Cr 6)
as per AISI: E 52100
Hardness: 62 - 64 HRC (771 - 840 HV)
Diameter tolerances: +/- 0.002 mm
Finish: Centerless ground; lapped and polished; 2 ends flat
|
|
The Grooved Pin has three longitudinal grooves swaged or formed into a cylinder of material, this has the effect of increasing its diameter. In each application, installation of the grooved pin causes the grooves to compress, this compression produces outward pressure on the walls of the hole and in so doing secures location of the pin. The pin is held in position under elastic tension and therefore cannot be easily dislodged in harsh environments.
A wide variety of standard pin types are available for many applications eliminating the need for more labour intensive or complex fasteners.
The Grooved Pin range has provided fastening solutions in a number of industry sectors including: machine building, chemical equipment, manufacture, precision engineering, automotive and electrical engineering.
|
|
|
A SLOTTED SPRING PIN is a headless hollow cylindrical tube having a longitudinal slot down the entire length with chamfered or round ends to aid installation. This type of pin is produced to a controlled outside diameter slightly greater than the hole in which it will be installed. Compressed as it is installed, the pin applies continuous pressure towards the sides of the hole wall. The pressure provides tension in a radial manner to prevent loosening created by vibration or shock.
|
|
Our more than 36 years’ experience on the market for stainless steel fasteners is brought to bear with particular force in this product segment.
All of the articles with relevance to fastening technology – from the traditional screws and nuts in thousands of individual models, through washers, retaining rings and keys in many versions, right up to bolts, split pins and rivets in just as many variations – can be delivered.
Both the parts standardized in accordance with DIN or ISO and the non-standardized fastening elements (e.g. chipboard screws, mushroom head screws, washers) are available.
Stainless steel remains the material of choice for most of the Lederer customers. Hardly any other material can boast its defining properties, such as corrosion resistance, long lifespan and non-magnetizability. And not least, the optical impression made by a mirror-fi nished stainless steel fastener infl uences the choice of material more often than one would suppose.
|
|
Our more than 36 years’ experience on the market for stainless steel fasteners is brought to bear with particular force in this product segment.
All of the articles with relevance to fastening technology – from the traditional screws and nuts in thousands of individual models, through washers, retaining rings and keys in many versions, right up to bolts, split pins and rivets in just as many variations – can be delivered.
Both the parts standardized in accordance with DIN or ISO and the non-standardized fastening elements (e.g. chipboard screws, mushroom head screws, washers) are available.
Stainless steel remains the material of choice for most of the Lederer customers. Hardly any other material can boast its defining properties, such as corrosion resistance, long lifespan and non-magnetizability. And not least, the optical impression made by a mirror-fi nished stainless steel fastener infl uences the choice of material more often than one would suppose.
|
|
Our more than 36 years’ experience on the market for stainless steel fasteners is brought to bear with particular force in this product segment.
All of the articles with relevance to fastening technology – from the traditional screws and nuts in thousands of individual models, through washers, retaining rings and keys in many versions, right up to bolts, split pins and rivets in just as many variations – can be delivered.
Both the parts standardized in accordance with DIN or ISO and the non-standardized fastening elements (e.g. chipboard screws, mushroom head screws, washers) are available.
Stainless steel remains the material of choice for most of the Lederer customers. Hardly any other material can boast its defining properties, such as corrosion resistance, long lifespan and non-magnetizability. And not least, the optical impression made by a mirror-fi nished stainless steel fastener infl uences the choice of material more often than one would suppose.
|
|
Description Extractable dowel pin stainless steel RINOX GR®
Reference 523-6-12
Material Stainless steel 17% Cr (52-55 HRC)
|
|
Linchpins for pipes (bichromate galvanized steel)
Linchpins (galvanized & stainless steel AISI 316L)
Safety linchpins (bichromate galvanized steel)
use in industrial supplies, DIY, entertainment industry, agriculture
|
|
Button Handle (Metric)
Kwik-LokTM Pins are manufactured in a wide range of sizes to meet any application. We offer short lead times for special sizes. Available in 5 handle styles, inch or metric, and in carbon steel and stainless steel. Button Handle configuration is ideal for applications that have limited space.
Handle is black anodized, machined aluminum.
Button is blue anodized aluminum.
Material: Carbon Steel or Stainless Steel
Handle Finish: Black anodized
Includes a ring for easy attachment of option lanyard.
|
|
Heavy Duty Button Handle (Metric)
Kwik-LokTM Pins are manufactured in a wide range of sizes to meet any application. We offer short lead times for special sizes or features. Available in various handle styles, inch or metric sizes, and in carbon steel and stainless steel. Button Handle configuration provides a firm, even grip for smooth comfortable operation.
Heavy Duty solid handle provides additional impact resistance.
Material: Stainless Steel provides additional corrosion resistance
Handle Finish: Stainless Steel
Meets or exceeds NASM 23460 specifications
Includes a ring for easy attachment of option lanyard.
2D, 3D, 3D solid model drawings available for download.
|
|
Ring Handle (Metric)
Kwik-LokTM Pins are manufactured in a wide range of sizes to meet any application. We offer short lead times for special sizes. Available in 5 handle styles, inch or metric, and in carbon steel and stainless steel. The Ring Handle configuration is designed for applications which require a small clearance area around the pin.
Handle is machined aluminum.
Button is blue anodized aluminum.
Material: Carbon Steel or Stainless Steel
Includes ring for easy attachment of option lanyard.
2D, 3D, and 3D solid model drawings available for download. (1 inch grip length)
|
|
Double Acting T-Handle (Metric)
Double Acting Pins are activated by push or pull motion
All stainless steel construction provides additional corrosion resistance
Ideal for quick insertion and removal
Four ball options available upon request
Meets or exceeds NASM 23460 specifications
Meets or exceeds design specifications MS17988, MS17989, MS 17990
Drive Out feature available upon request
|
|
Precision alignment pin with a ground shank. This popular single-acting type is positive locking until released by pushing the button, which moves the centre spindle forward to allow the locking balls to retract into a radial groove. This type has the widest range of types and sizes. Available in steel or stainless steel.
|
|
|
|
|
|
This product family covers the following article groups:
- EH 2235. Lifting Pins (Steel / Stainless Steel 1.4305)
- EH 2235. Locating Bushes for lifting pins
Ball Lock Pins
- EH 2237. / 2238. simple finish (Stainless Steel 1.4305 / 1.4542)
- EH 2237. / 2238. with elastic grip (Stainless Steel 1.4305 / 1.4542)
- EH 2237. / 2238. with plastic grip (Stainless Steel 1.4305 / 1.4542)
- EH 2236. Clamping Pins (Stainless Steel 1.4305)
- EH 2240. Socket Pins (Stainless Steel 1.4305)
- EH 2240. Retaining Cables
- EH 2240. Locating Bushes for ball lock pins (Stainless Steel 1.4305)
The Ball Lock Pins by Halder for Connecting, Attaching, Positioning, Fixing, Holding, Securing, Lifting, Bolting, Interlocking, Adjusting …
With a wide product range and many years' experience in manufacturing including made to order, Halder offers the right solution for many applications in virtually every sector of industry:
- Mechanical engineering, tool-making and automotive
- Prefabrication and tank construction
- Fixtures and workshop fittings
- Industrial handling
- Hoists, platforms, racks and scaffolding
- Sport and rehab devices and equipment
- Medial applications
- Aviation…
In addition to the metric version we have also the product line “Flight-Pins”. This Ball Lock Pins in inch dimensions are according to aviation standard NASM (MS 17984 – MS 17990)
single acting
- EH 4210. with Button Handle (MS17984)
- EH 4211. with T-Handle (MS17985)
- EH 4212. with L-Handle (MS17986)
- EH 4213. with Ring (MS17987)
double acting
- EH 4214. with T-Handle (MS17988)
- EH 4215. with L-Handle (MS17989)
- EH 4216. with Ring (MS17990)
|
|
|
|
|
|
Material:
- Bolt stainless steel 1.4542.
- Mushroom knob and push button Stainless steel 1.4305.
- Balls Stainless steel 1.4125.
- Compression spring Stainless steel.
Surface finish:
- Bolt, hardened min. 40 HRC and passivated.
- Passivated mushroom knob and push button.
- Balls hardened HRC 58+4 and passivated.
- Passivated compression spring
Note:
Ball locking bolts are used for fast and easy fixing and joining of parts and workpieces. The two balls can be disengaged by depressing the push button, so that the parts to be joined can be pegged. When the push button is released the balls lock the connection safely and permanently. If required, the ball locking bolts can be provided with a holding rope.
The bolt made of high-strength, hardened stainless steel is suitable for extreme loads and provides a very high level of wear protection. Thanks to the high corrosion and acid resistance, they are mainly used in the foodstuff industry, in the chemical and petrochemical industry and as constructional elements in the aerospace industry.
Shearing force double-edged (F) = S · Tau aB max.
Accessory:
Key Ring 03199-15/19/23
Restraining Cable with eye 03199-....
|
|
Jergens offers a wide range standard pins made to order in various sizes and configurations.
Jergens is also capable of making special pins in large and small quantities to meet your unique design requirements.
A wide range of Mil-Spec pins are available from MS 17984 - MS 17990, MIL-P-45952/1
|
|
Kwik-LokTM Pins are manufactured in a wide range of sizes to meet any application. We offer short lead times for special sizes. Available in 5 handle styles, inch or metric, and in carbon steel and stainless steel. Button Handle configuration is ideal for applications that have limited space.
Handle is black anodized, machined aluminum.
Button is blue anodized aluminum.
Material: Carbon Steel or Stainless Steel
Handle Finish: Black anodized
Includes a ring for easy attachment of option lanyard.
2D, 3D, and 3D solid model drawings available for download. Click here to select and download solid models/drawings
Note: For best results downloading files, press your right mouse button and select 'Save Target As' or 'Save Link As'
|
|
Recessed Button Handle (Metric)
Kwik-LokTM Pins are manufactured in a wide range of sizes to meet any application.We offer short lead times for special sizes. Available in 5 handle styles, inch or metric, and in stainless steel.
The Recessed Button Handle design helps prevent accidental actuation of the button.
Handle is stainless steel.
Button is stainless steel.
Material: Stainless Steel
Includes ring for easy attachment of option lanyard.
|
|
Ball type pins
The ball type pins are used for all applications requiring the hand to be quickly removed after insertion or shifting.
The ball type pins are fitted and removed quickly, without tools and using one hand only.
Numerous dimensions are available in metric or American units.
5 types of head are available: T or L shapes, knob, protected knob or ring.
|
|
Quick Release Pins - Metric
WDS250
Black cast aluminium T-handle
Blue anodised aluminium buttonStainless Steel Body
(SAE AMS 5643)
Includes hole and ring for easy attachment of optional chain or lanyard.
Other styles available
Carbon steel available
Quick Release Pins - Imperial
WDS250
Black cast aluminium T-handle
Blue anodised aluminium button Stainless Steel Body
(SAE AM5 5643)
Includes hole and ring for easy attachment of optional chain or lanyard.
Other styles available
Carbon steel available
|
|
