Y type globe valve
ND (nominal diameter): 15-400
other diameters or pressures under request
NP (nominal pressure): 16-420
MAIN TECHNICALS SPECIFICATIONS
Execution: A105, AISI 316, AISI 304
Waterproofness PTFE or the other joint in the demand
Can have risen with any types of actuators
Connection of actuators following one ISO 5211
Fixation to reins or to weld
Technology: Molded or Forged
|
|
This type of valve is actuated by pressure acting on a piston or diaphragm. The fluid is usually neutral e.g. air, water, hydraulic oil. The pressure range varies and is specified accordingly in a data table.
"Normally Closed" (N/C) valves of this type remain closed under spring pressure, when de-activated.
"Normally Open" (N/O) valves of this type remain open under spring pressure, when de-activated.
When pressure is connected to port "Z" the valves open or close according to type.
A separate 3/2 pilot valve is used to supply pressure to port "Z", it is mounted either directly on the actuator or remotely.
In some cases a 4/2 or 5/2 pilot valve will be required. The main valve position can be N/C or N/O. The basic position is determined by connecting the pilot valve output lines accordingly. (The direction of flow is usually indicated by an arrow or shown schematically on the body).
|
|
ASCO/JOUCOMATIC has developed a wide range of valves for all fluids, whether neutral or aggressive, made out of brass, bronze, cast iron or 316L stainless steel.
Reliability is ensured by:
* A monobloc rod, with stainless steel from the reed to the piston
* Guidance by 2 extra-large PTFE bearings.
Pilot solutions: solenoid valves on valves or mounted on subbases and valve islands.
|
|
PNEUMATIC VALVE 2/2 NC ANGLE HEAD
TECHNICAL SPECIFICATIONS
Media: air - water - steam - light oil
Pressure range : 0 to 25 bar max
Media temperature : -30° to +180° C max
Ambient temperature : -10° to +70° C max
Media viscosity : 600 centistokes max
Pilot media : filtered air or water
Pilot pressure : 4 to 10 bar max
|
|
General description
M&M piston actuated valves are manufactured with high performing components as a standard.
PTFE and FKM seals together with internals in AISI 316 offer outstanding compatibility and cover a wide variety of industrial applications.
Added features as position indicator, built-in exhaust filter, wide choice of connections and optional versions, long life cycles even in severe conditions represent our competitive advantage.
|
|
ASCO/JOUCOMATIC has developed a wide range of valves for all fluids, whether neutral or aggressive, made out of brass, bronze, cast iron or 316L stainless steel.
Reliability is ensured by:
* A monobloc rod, with stainless steel from the reed to the piston
* Guidance by 2 extra-large PTFE bearings.
Pilot solutions: solenoid valves on valves or mounted on subbases and valve islands.
|
|
|
|
|
|
TORK T-PV Series ,pneumatic piston valve
application: water,air,steam,gas,natural gas,chimicals,petroleum products,food,sterilazation,water treatment,dyeing,cleaning plant,aggressive liquids,vacuum application,oil,petrol,alcohole,hydroulic liquids,salt solutions,acids,organic solvent
All body is AISI316 Stainless Steel,high flow rate,high quality,compact,suitable vacuum application,normally open and normally closed position.
advantage of TORK pneumatic piston valves:less pressure drop than globe valve,
short open-close time
high flow rate
body and actuator AISI 316
screwed,flanged and welding connection
on-off and proportional control
TORK T-PV Series ,pneumatic piston valve series range
T-PV.S700 Serie; Screwed connection, 1/2"......2" G( BSP ), on request NPT connection..
T-PV.W700 Serie; welding connection, size :from 1/2"......up to 2" .
T-PV.F700 Serie; Flange connection,size:from NW15.....up to .NW50 .
T-G.3W Serie: Solenoid valve,1/4"-3/2 way.it is used on-off control pneumatic piston valves
T-SW Serie: Proximity switch limit switch box ,gives signal when valve open-closed.
|
|
Description:
The RPDA Rotary Piston Double Acting Actuator is designed for heavy duty control applications that require optimum performance. The RPDA is typically utilized when applications require a "lock last" failure mode. The RPDA incorporates a “crank-arm” mechanism specifically designed for the rigors of throttling control valve applications. The RPDA can accept high pressure power supply gas up to 500 psig (3447 kPa) enabling the use of smaller actuators or Becker’s exclusive Bleed to Pressure System (BPS) feature.
|
|
Description:
The RPSR Rotary Piston Spring Return Actuator is designed for heavy duty control applications the require optimum performance. The RPSR is typically utilized when applications require the control valve to “fail open” or “fail closed” upon loss of power supply gas. The RPSR incorporates a “crank-arm” mechanism specifically designed for the rigors of throttling control valve applications. The RPSR can accept high pressure power supply gas up to 500 psig (3447 kPa) enabling the use of smaller actuators or Becker’s exclusive Bleed to Pressure System (BPS) feature.
|
|
TORK T-RPA ..SR Single acting pneumatic rotary actuator ,90 degree turn rack and pinion type pneumatic rotary actuator . it is recommend 6 bar supply pressed air and out put torque value from 12Nm.upto 1150Nm
applications :ball valves,butterfly valve,plug valves,dampers
TORK pneumatic actuators work on-off with namur solenoid valves and proportional rotary positioners
|
|
| ... products without technical information |
| |
Novafix VD-...GR
Mechanical Flow Switch for liquids or gaseous media, with contactless triggering of an adjustable reed switch.
Rugged design in brass / bronze combination.
good repeatability
dirt-resistant
exact setting of switch via scale
|
|
Novafix VD-...GR
Mechanical Flow Switch for liquids or gaseous media, with contactless triggering of an adjustable reed switch.
Rugged design in brass / bronze combination.
good repeatability
dirt-resistant
exact setting of switch via scale
|
|
|
|
