Machines need control systems with the same level of sophistication, flexibility and fieldbus networking of large plants. Systems need compact devices able to incorporate functions such as PID algorithm, floating point, sequencing functions of a PLC and the flexibility of a PC. This is now possible without facing excessive costs and without using cumbersome equipment. This device has been termed a PAC. The Ascon's “Sigma microPAC”, is a small but powerful PAC sized to cover the applications for industries such as food and beverage, plastic and rubber, chemicals and pharmaceutics and for machines such as boilers, furnaces, kilns, chillers, autoclaves, plastic extruders, cold rooms. With the basic unit of the Sigma microPAC it is possible to control a process with: eight analogic variables from any type of transducer or sensor directly connected as inputs; four analogic outputs to command control valves or power controllers; eight digital inputs and eight digital outputs to manage interlocks, sequences and commands to pumps, shut-off valves. Expansion units for 32 DI + 32 DO fit applications requiring more sequencing of discrete signals. The 5 programming languages comply with IEC 61131-3 and are aided by the Ascon’s libraries with a large selection of function blocks. Processor is 32 bit, Flash Memory is 4Mbyte (2Mbyte for programming), RAM is 16Mb, 128 Kb retentive. Connectivity is by one RS 232/485 with Master/Slave Modbus RTU or ASCII, one RS 485 with Master/Slave Modbus RTU and one Ethernet port with Modbus TCP/IP. Advantages include being able to meet requirements that PLCs require extra components to do, reduce panel dimensions, lower hardware and development cost
|
|
|
|
|
|
Vision130™ Connects!
PLC, HMI & onboard I/Os plus ETHERNET, SMS/GPRS, CANopen, MODBUS...
The Vision130™ is a palm-sized PLC with a built-in Operator Panel. The panel offers a graphic display screen and keypad. This small, powerful device supports up to 166 I/Os (onboard plus expansion modules). A rich range of embedded features include multiple auto-tuned PID loops, internal 120K structured database, loadcell support, and communication options such as Ethernet, GSM/SMS, MODBUS, CANbus, function blocks that enable Vision to communicate with devices using proprietary COM protocols, plus remote access and data export software utilities.
The Graphic HMI display screen can show images, text, and graphs according to real-time parameters. It can also display graphs based on historical values, to reflect trends of recorded data. Vision130™ supports up to 1024 user-designed screens, and up to 500 images per application.
The Vision130™ is unique: it enables engineers and systems designers to benefit from a powerful PLC and a graphic HMI – within a bare minimum of budget, cabinet space, and wiring.
Our PLC/HMI integrated devices:
save our customers’ programming time, wiring, and cabinet space.
cut budget by reducing requirements for additional hardware
prevent you from wasting time setting up Panel-PLC communication
|
|
|
|
|
|
Jazz™ PLC HMI:
Much more than a "smart relay"
The new Jazz™ by Unitronics is a PLC that includes on-board I/Os plus a full-function Operator Panel with numeric keypad. It enables users to replace the "smart relays" with a smarter, more powerful device, while keeping the same low budget.Jazz's™ PLC capabilities include 24K (virtual) of Ladder programming, functions such as math, store/load, compare, interrupt and loops.
The Jazz's™ fully-functioning HMI provides 60 user-designed screens, an alpha-numeric keypad and a multi-lingual display. The HMI helps our customers boost productivity by displaying operating instructions, system-fault messages and conditional data.
Jazz™ features a variety of communication options, including SMS messaging, Remote Access utilities, and PC access via MODBUS or OPC/DDE servers.
This unique combination of features, along with the Jazz's™ remarkably low price make it perfect for any application- from simple electric boards to complex production lines. Its High-speed inputs, combined with remote communication options make it the right choice for water and agriculture applications. Industrial lighting, automatic barriers/doors and air conditioning can also be easily and economically controlled by the Jazz™.
|
|
|
|
|
|
The core of this PLC 7001 Chip is based on the PLC 7000 which has already been in use for two years. With its simplified memory interface the PLC 7001 can be easily integrated as embedded PLC into div. customer applications.
The peripheral interface offers the possibility to realize up to 56 in- and outputs, pulse duration modulation functions as well as stepper motor controls from integrated modules. For the application of decentral peripherals, the chip offers a serial I/O bus which allows operation of up to 32 digital and analog I/O modules.
In connection with an Arm9 processor there is also the possibility to operate Ethernet-based communication like TCP/IP, EtherCAT, Powerlink and Profinet.
At an operating voltage of 1.8V the power loss amounts to only 1.2W. For this reason the design is optimally suitable for the application in higher temp. ranges.
Single-Chip CPU
For users wishing to integrate a high-performance hard PLC into their application, there is a prefabricated PLC module which lead through all digital/analog and other communication interfaces to a SO-200 PinConnector. These modules can be easily integrated into various applications like board controllers, HMIs etc.
The modules as well as the chip models can be equipped with a PLC user memory of up to 2MB.
|
|
|
PLC with a built-in graphic display and keypad. With a rich variety of onboard I/Os, including direct temperature and weight measurement inputs.
|
|
Concept and characteristics:
Models: HB
Power supply: 24V DC ± 10%
Functions available:
•Inversion of the direction of rotation of the motors
•Synchronized variable speed control
•Constant and stable torque in relation to the load
•Accumulation without pressure in singulation or train mode
•Transportation of loads with variable lengths
•Spacing out loads
•Constant and stable speed in relation to the load
•Retrieval of the error signal in case of overload activation by the motor or the circuit board
•Full electronic protection of the motor and the circuit board
•Etc…
|
|
|
|
|
|
The programmable logic valve control type PLVC is intended for the control
of complex hydraulic circuits. Movements with various pressure, speed, and acceleration profiles, within predefined ranges, can be controlled and saved. It can be descirbed as a user programmable PLC with built-in amplifiers for proportional valves.
Analogical, digital and components connected via CAN-Bus (e.g. pressure sensors, joysticks, etc.) can be utilized for control or closed loop tasks, connected via cable or wireless. This high degree of flexibility is achieved by:
* Modular concept with various extensions and add-on's (basic and extension module, diagnosis display, CAN-Bus-power relays)
* Flexible programming
* Various interfaces (RS 232, CAN-Bus, Profi-Bus)
* Free parameter setting of all in- and out-puts
* Remote diagnosis via modem and mobile telephone
* Software function blocks (PLC programs)
* Remote control module
Main field of application is with machines for construction, lifting, logging, machine tools, and presses.
|
|
|
|
|
|
Color me Beautiful! Vision350™ is the smallest PLC with an embedded COLOR touchpanel
This palm-size PLC offers exceptional capabilities and diverse I/O options. Its 3.5” TFT touchscreen can show over 1000 displays, with 3.5MB for images & fonts. The Vision350™ supports up to 166 I/Os via on-board and I/O expansion modules.
The Vision350™ offers a rich range of embedded features such as multiple auto-tuned PID loops, and internal 120K database for datalogging and recipe programming. Communication options include TCP/IP Ethernet, GSM/SMS, MODBUS and CANopen networking plus remote access for data acquisition and program download.
1MB Ladder code application memory (plus 3MB for images and 512K for fonts) enable the Vision350™ to run complex control and automation tasks.
The 256-color touchscreen HMI enables the display of color-coded operator instructions and red, attention-grabbing alarm screens. It can also display graphs according to historical values—to reflect trends of recorded data. Display options are almost endless with more than 1000 user-designed screens, and up to 250 images per application.
The Vision PLC/Graphic HMI series introduces an unbeatable price-performance ratio, enabling users to enjoy the advanced features of both the operator panel and the PLC, while maintaining low budget, reduced programming time and minimum wiring.
|
|
|
|
|
|
|
Ascon is pleased to announce the release of the sigmaPAC complete control system. Power and innovation paired with exceptional modularity and flexibility allow the sigmaPAC to be used in the most diverse and demanding applications. Features of the sigmaPAC include a multi function platform equipped with control functions for many types of variables (temperature, pressure, flow, level, position…), logic and sequence functions, and process calculations. The sigmaPAC is targeted for applications with multiple parallel tasks to be managed by the same control unit. The various available interface ports include RS232 and RS485, Ethernet and major Fieldbuses to guarantee maximum connectivity. The sigmaPAC Control Unit is compact in size (110mm x 152mm), mounts on standard DIN rail and connects to remote modules using standard Ethernet cables with RJ45 connectors. The processor features 32 bit ARM architecture, 4 MB flash memory, 16 MB DRAM and 128 kB SRAM with battery back-up. Default interfaces include CANopen port, Ethernet 10baseT port and RS232 port, while optional interfaces include RS232/485 serial ports with Modbus RTU protocol, Profibus DP slave, CANopen slave, and DeviceNet slave. A configurable alarm relay digital output, Watchdog and Wake Up digital output and one digital input are part of the onboard I/O package. A wide variety of analog, digital and mixed I/O modules provides the flexibility to create the optimal complete control system for every application. The sigmaPAC system with Control Unit and I/O modules allows for the development of centralized or distributed solutions without modifying or adding components
|
|
|
|
|
|
The FPSC Fiessler Programmable Safety Center is a programmable electronic safety for personal protection, i.e. for safety functions. The FPSC complies with the highest safety requirements:
- SK1 through SK 4 according to EN 954-1
- SIL 1 through SIL 3 according to EN IEC 61508
- PL a through PL e according to prEN 13849-1
The product family FPSC provides maximum flexibility within its hardware and software structure. The FPSC - AD version offers the possibility to connect decentralized I/O modules via the implemented safety bus. This guarantees a modular system design that offers flexibility therefore reducing the costly and often elaborate configuration of the safe system bus.
The safety-related functions are programmable by using pre-assembled and tested software modules. The chaining
is made by simple assignment of input , i.e. output adresses. Intermediate data are stored in the temporary storage. There are various ready-to-use software modules at your disposal. For the communication with a superior control, i.e. for the operating sequence control or technology control, a serial interface is provided. The transfer of data for visualizing as well as the transfer of machine-relevant data can de realised via this interface.
The simple snap-on mechanism for fastening the items on the DIN rail in the switch cabinet considerably reduces the installation expenditure of the items of the product family.
|
|
Complete machine control – Standard-compliant and safe
.. for complex and distributed plants with up to 8 064 inputs/outputs
On complex, distributed plants, PSS programmable control systems monitor safety-related functions and/or undertake complete control of the machine - whether centralised or decentralised via the safe, open bus system SafetyBUS p.
You put together your own individual solution and can rely on a system that's completely compatible :
- Modular control systems PSSmodular
- Compact control systems PSScompact
- PSSuniversal decentralised control platform
- Decentralised input/output units, PSSdio
- PSSnet network components for SafetyBUS p
- System software and programming guides
- Fast, safe communication via SafetyBUS p
|
|
|
|
|
|
Vision570™ : PLC with Color Touchscreen HMI & Snap-in I/Os
The Vision570™ is a powerful PLC with a built-in HMI Operator Panel, comprising a 5.7” color touchscreen display. On-board I/Os can be added by simply snapping a module onto the back of the PLC; Snap-in I/O Modules come in several configurations. I/O Expansion modules enable integrating up to 171 I/Os per Vision PLC.
The Vision570™ offers a rich range of embedded features such as multiple auto-tuned PID loops, and internal 120K database for datalogging and recipe programming. Communication options include TCP/IP Ethernet, GSM/SMS, MODBUS and CANopen networking plus remote access for data acquisition and program download.
2MB Ladder code application memory (plus 6MB for images and 1MB for fonts) enable the Vision570™ to run complex control and automation tasks.
The 256-color touchscreen HMI enables the display of color-coded operator instructions and red, attention-grabbing alarm screens. It can also display graphs according to historical values—to reflect trends of recorded data. Display options are almost endless with more than 1000 user-designed screens, and up to 500 images per application.
The Vision PLC/Graphic HMI series introduces an unbeatable price-performance ratio, enabling users to enjoy the advanced features of both the operator panel and the PLC, while maintaining low budget, reduced programming time and minimum wiring.
|
|
|
|
|
|
Full PLC performance in a tiny package
The FX family includes four independent but fully mutually-compatible product lines:
FX3U
• Safe investment
• Tailored configurations
• Powerful positioning control
• Fast installation and configuration
• Integrated automation
• Outstanding value for money
• 16 up to 384 In-/Outputs
FX3G
• 14 to 256 inputs and outputs
• High processing speed
• Ample program storage capacity
• Can be expanded with up to eight special-function modules
• User-friendly programming
• Integrated positioning controller
FX1N
• 14 to 128 inputs and outputs
• High processing speed
• Ample program storage capacity
• Integrated positioning controller
• Comprehensive range of special function for individual requirements
• Integrated PID controller
• Support for connection to open networks Integrated real-time clock
• User-friendly programming
• Analogue signal processing
FX1S
• 10 to 30 inputs and outputs
• High processing speed
• Ample program storage space and large device ranges
• Integrated positioning controller
• Serial communications options
• Analogue signal processing with optional expansion adapters
• User-friendly programming
• Expandable with adapters or display modules
|
|
Base Models with 10 to 14 I/O, Expandable to 256
Half the Size of Most PLCs
1-, 4-, 8-, 16-and 32-Bit Instructions
DIN Rail Mountable, No Rack Required
Built-in Integral LCD Display
High-level Network Access - Modbus TCP, DeviceNet and Profibus
Plug-In Modules for Analogue I/O, Thermocouples and Pt100 RTDs
|
|
The Saia®PCD product range reflects the values, characteristics and standards of Programmable Logic Controller (PLC). However, in their form, openness and functionality these products far exceed the traditional PLC. With Web and IT functions included, the Saia®PCD automation platforms is simply the best choice for every modern project.
All-in-one and robustness : Compact Saia®PCD are a safe investment for the automation of building, infrastructure, water, energy, logistics and machines.
With 38 on-board I/O, extendable with 4 modules taken out of our standard range of over 50 different I/O modules and a broad selection of communication protocols (TCP/IP, Modbus, Profibus, LON, Bacnet and many more) make the compact Saia®PCD automation platform an easy solution for smaller projects.
|
|
|
The VIPA system 100V is a Micro-PLC system programmable with Step®7 from Siemens or WinPLC7 - a programming tool from VIPA. With a compact design, system 100V provides a maximum expansion of up to 160 I/O points by plugging in expansion modules. These Micro-PLCs are especially suitable for use in smaller and cost-conscious applications.
|
|
AutoLog® 2000S
AutoLog® PLC is designed for large size projects where large quantity of I/Os are needed. Modular, freely selectable plug-in I/O modules are inserted into metal rack. CPU card and power is also inserted into same rack. CPU card doesn't have own I/O. P-model CPU has build-in power, so it can be used in small MR3 rack.
|
|
Compact PLC – The open and closed-loop control system
Compact PLCs are all-in-one devices that, even in their basic version are equipped with a comprehensive set of hardware and software functions and thus suitable for use in many control, regulating and measuring applications. Where the integrated functions do not suffice, the devices can be simply expanded either locally or via network.
The range includes:
* Compact PLC – PS4
* LE4 – local expansion units
* EM4 – distributed expansion units.
All the compact PLC are networkable and programmable via integrated fieldbus. The programming software applicable to all is Sucosoft S40, an easy-to-use programming package to IEC 61131-3.
|
|
|
The package-type SYSMAC CPM PLCs feature a space-saving design to contribute to integration in small machines and wiring panel downsizing.
|
|
|
|
|
|
The world’s smallest controller with a built-in touch screen, I/O and networking, plus removable mass data storage.
Built on the highly successful XLe chassis and feature set, the XLt is equipped with a larger, high-resolution resistive touch screen. Its advanced transflective readable display means the XLt is ideally suited both for indoor AND outdoor use even in direct sunlight!
Supported by the latest CScape 8.6 software there are four models available featuring flexible levels of I/O. The XLt duplicates the extensive communications options of the XLe - which currently boasts support for Ethernet, PSTN Telephone modem, GPS receiver and GSM/GPRS Modem technology.
-160x128 pixel graphical display, with a high-resolution resistive touch screen for detailed user interface
-Four programmable function keys plus system button
-Philips ARM7 Core with 1.2 ms/k scan time
-256 kB internal memory with up to 2GB MicroSDT mass-memory storage
-Two RS232/485 Serial Ports as standard
-CsCAN standard
-Add-on Ethernet, GSM/GPRS, PSTN Modem, even a GPS receiver
-Designed for IP65/NEMA 4X environment; panel or DIN-rail mountable (1/4 DIN Package 96x96mm)
-XLt supports a wide temperature range (0 to 60°C)
-9 - 30 VDC supply range
-Available in Grey/Black&Blue or with Custom colours
~ Cscape™: All Units are programmable with a Free Software ~
|
|
|
|
|
|
The XL6 All-in-One controller with a built-in 32,000 colour TFT touch screen, I/O-Modules, networking options, removable MicroSDTM Card and USB ports. It’s programmable by Horner APG’s industry recognised CscapeTM software and can control a wide range of different processes and machines from small to medium applications.
-Touch-based screen
(1/4 VGA), 32,000 colour touch screen with Screen Operating Temperature from -10 to +60 degrees centigrade.
-Programmable hard keys
5 fully programmable function keys plus system key for easy diagnostics
-Capable controller
256KB Logic Space, Screen Update Speed is Adjustable with Logic Scan upto 0.2mSec/K logic.
-Single Programming Software
One software for logic and screen development. IEC61131 Compliant
-Wide Range Power Supply
Suitable for Mobile and Industrial Applications.
-Integrated I/O
4 different combination of built-in I/O available with Colour Coded Connectors
-2 serial ports
Connect to a choice of many serial protocols for PLC, Drives and other devices or our Serial I/O System
-CANOpen port
For connecting with other devices, OCS products or remote CsCAN I/O’s to expand system capabilities
-USB Transfer
New data transfer available with XL6.
~ Cscape™: All Units are programmable with a Free Software ~
|
|
OCSXL Series - Programmable Logic Controller and Operater Interface
Quality Graphics Display for Better Process Visualisation and Machine Indication
More Compact and Affordable than Separate PLC and Operator Interface
Built-In I/O with Removable Terminal Blocks for Easy Wiring
Removable Mass Data Storage Memory Card - Supports Data Logging
|
|
|
Programmable Logic Controllers, along with easy-to-use Support Software, are available to flexibly handle applications from small-scale equipment to entire production lines with Programmable Logic Controllers such as those in the SYSMAC CJ1, CS1 and other series.
|
|
|
|
|
|
Alto RIOM is designed to become integrated into TCMS and embedded architectures. It can control local automatisms, command gateways or supervision functions : air conditioning, doors, brakes, auxilliaries, fire security.
Alto RIOM provides the monitoring of equipments on serial or CAN networks.
The connection to the upper level is MVB (Main Vehicle Bus) or EtherNet/IP.
Alto RIOM has been designed following a SIL2 level process with the conformity to EN50155 norm.
For example, Alto RIOM MVB contributes for the brakes monitoring of the Barcelona metro cars, included in the Alstom AGATE Link system.
More than 5000 products sold worldwide.
Mechanical presentation : 2.5 kg min, IP30, Fixation by screw
Robustness
- Electrical, mechanical, thermical, climatic characteristics : EN50155
- Electronic Compatibility : EN 50121-3-2 and EN50022
Power supply :
* 24 V or 72-110V -30% +25% , Tests according to the EN50155 Norm
Basic CPU with :
* 1 MVB channel + 1 Ethernet channel + 1 CAN channel
* 2 asynchronous serial links : HPTS, ASCII
Basic digital IO board
32 digital inputs + 16 digital relay outputs.
Alto RIOM can accept 2 IO boards.
* Digital input : 24V or 72-110V -30% + 25% 10 mA
* Relay output :
Tension on the contact : 16 to 160 Vcc
Max switching power : 8A 30Vcc to 0.4A 110Vcc
Option : Peripheral board
* 4 asynchronous RS232/RS485 serial links.
* 4 analog inputs +-10V, +-20mA , 12 bits, 2%
* 4 analog outputs 0-10V, 0-20mA, 12 bits , 2%
|
|
|
|
|
|
LT200 : PLC for harsh environments
1/ HARDWARE DESCRIPTION
- ROBUSTNESS : each module is enclosed in a aluminium cabinet which allows a protection against electro-magnetic interference and a good thermal dissipation.
- COMPACITY: Height x Depth : 105 mm x 84 mm ; Width = 25mm x Number of modules
- MODULARITY : supports up to 15 I/O blocks. A block has between 2 and 5 modules.
The base is fixed by brackets for screwing to a grid or a plate. The width of the base is on demand.
The LT200 CPU starts at -40°C.
The Ethernet connector is suitable for vibratory environments.
* Memories : SDRAM : 32Mo (16Mo for user); FLASH : 16Mo (4Mo for user)
I/O blocks connectors are screw terminals for standard industrial use or SubD connectors for harsh environment where shocks, vibrations are more intensive (transportation systems).
2/ SOFTWARE USES
Three different embedded kernels for three different uses :
* quick parametrable system with OPAL V4 tool
* or IEC61131-3 PLC with Isagraf V5 workbench
* or C programming with SDK (Linux, GCC, GDB, Eclipse IDE)
|
|
|
|
|
|
High-end Performance in a Compact Package
PLC systems from Mitsubishi Electric are pioneering technology leaders delivering exceptional reliability and performance. We close the gap between the automation and the IT levels.
The iQ Platform MELSEC System Q –
Tomorrow’s Controller Platform Today
• Flexible and scalable automation architecture
• PLC, motion, robot and NC technology on a single platform
• PLC CPU with a cycle time of just 9.5ns
• Integrated Ethernet port
• Self-diagnostics with error history integrated in the CPU
• Supports memory expansion up to 32MB
• Supports remote diagnostics and programming
• Flexible, cycle-oriented data management with a data logger module
• Smooth communication with the management IT level via MES and MES IT Interface Module
• Application-oriented Safety PLC solutions with safety relay module and safety PLC, including a secure network
• Caters to special requirements of process and hybrid applications with process PLC and ready-to-use closed-loop control algorithms
• Enhanced system availability with redundant PLC architecture using standard components
• Remote I/O systems with hot swap functionality
• Comprehensive portfolio of I/O modules
• Programmable with IEC 1131.3/EN 61131-3 compatible software, or in high-level languages like C++ and Visual Basic with a PC CPU
• Soft PLC available for the PC CPU
|
|
The Saia®PCD product range reflects the values, characteristics and standards of Programmable Logic Controller (PLC). However, in their form, openness and functionality these products far exceed the traditional PLC. With Web and IT functions included, the Saia®PCD automation platforms is simply the best choice for every modern project.
Modularity, flexibility and robustness : Saia®PCD are a safe investment for the automation of building, infrastructure, water, energy, logistics and machines.
Several CPUs, over 50 different I/O modules and a broad selection of communication protocols (TCP/IP, Modbus, Profibus, LON, Bacnet and many more) make the Saia®PCD automation platform a versatile tool able to fit in any projects from 10 to 10’000 I/Os.
|
|
|
|
|
|
Modular control system programmable with STEP7 from Siemens
The VIPA System 200V is a highly compact and modular control system for centralized and decentralized applications. Due to the variety of modules available, it can be used for nearly all mid-range applications.
Features of VIPA System 200V:
• Programmable with STEP®7 from Siemens
• Programmable with WinPLC7 from VIPA
• Integrated work memory – operation possible without additional memory card!
• Integrated ROM memory for continuous saving of programme and data
• Integrated accumulator backed RAM memory
• Supporting standard MMC cards for saving of programme and data
• MPI Interface on board
• Centralized and decentralized applications are possible
• Modular expansion possible
• MMC Slot
• Real-time clock
• Centralized application with the possibility of up to 32 modules on the CPU rack
• Compact design
• Maintenance free cage clamps
• Front connector included
• 35mm DIN rail mounting
• 24 months warranty
• UL-standard certification
|
|
|
AL10SP has five (5) 16-bit analog inputs. Analog input ranges are 0-800mVDC, 0-3.2VDC, 0-50VDC and 0-100VDC. Input ranges can be configured using PC software. Analog inputs are surge protected against lightning etc.
|
|
Modular PLC – tailored to the application
The modular PLCs are characterised by having a wide spectrum of applications with freely scalable structure to suit. The user thus has the flexibility of designing his automation system precisely to his requirement.
Access via the Ethernet for example, is absolutely essential for many applications, for efficient communication between the PLCs within the system on the one hand, and for data exchange with primary level control systems via communication standards such as OPC on the other.
|
|
|
|
