A significant demonstration of the specialised capacity of the Graphic Division is the new generation of highly versatile multiple ejector pumps, capable of blowing or sucking as required. This is a real revolution compared with traditional rotary blade pumps, with performance that unites improved power with more personalized operation:
- Powered with compressed air with pressure variable from 1 to 6 bar.
- Maximum vacuum 90%.
- Suction capacity from 40 to 180 m3/h.
- Maximum blowing pressure 0.8 bar, with capacity from 50 to 250 m3/h.
- Low air consumption and limited weight.
- Surprisingly quiet and complete absence of heat.
- Maximum respect for the environment and minimum maintenance.
- 5 year guarantee.
|
|
Pneumatic conveying is a core technology of Gericke since more than 60 years! Suction conveyors are very compact, easy to install and simple to operate. The suction unit with its integrated receiving hopper can be placed on feeders, mixers, vessels.
Combined with a weighing sysem, the units work as suction weigher, meaning that batches can be measured during conveying cycle.
The system operate purely pneumatically and are therefore suitable for hazardous areas too.
|
|
Features:
- easy material aspiration and dust-free loading of machines
- gentle conveying, no seperation of material mixtures
- optimum hygiene conditions
- reliable filter systems in GMP quality
- simple to install and to operate
- low energy consumption
- favorable investment- and operating costs
|
|
|
ANVER TT Series Transfer Tubes instantly provide air movement the moment compressed air is applied and their transfer speed and output flow can be infinitely adjusted by regulating the input pressure. Made from aluminum with a durable anodized finish, they come in a wide variety of bore sizes from 0.375” to 1” (9.5 to 25.4 mm) I.D., with air flows from 15 to 145 SCFM.
|
|
They exploit the principle of the Coanda effect
They were originally designed for sucking and transporting products like dust, granulates, sawdust, grit, metal shavings, but are also suitable for oil spray and welding fumes
Characterised by their low head and very high volumetric yield
They can also be used as blowers, or for cooling surfaces
Maintenance free, good filtering of the compressed air supply is recommended
Available with intake diameters from Ø 7 to Ø 50 mm
|
|
* Patented COAX® technology.
* Available with a three-stage COAX® cartridge MIDI. Choose an Si cartridge for extra vacuum flow, a Pi cartridge for high performance at low feed pressure or an Xi cartridge when high flow and deep vacuum is needed.
* Substantially lower air consumption as compared to conventional ejectors.
* Modular design.
* Available with multiple connection alternatives.
* Low noise level.
* Short evacuation time.
Supplied with a vacuum gauge.
|
|
Positive Displacement Vacuum Pumps
Vacuum pump packages are recommended for the higher rates over longer distances and continuous service. They are also used on many applications where a venturi unit would be adequate but sufficient compressed air is not available. They feature a positive displacement lobe-type blower and are complete packages with motor and blower, secondary material filter on the inlet and muffler on the outlet. These units are mounted on a heavy duty, forkliftable base and are equipped with belt guards conforming to current OSHA standards. Included are a glycerin-filled vacuum gauge and a vacuum relief valve. The secondary filter protects the pump from any carryover of material from the material receiver. Cartridges are easily changed by removing the end cover. Optional differential pressure gauge and/or switch can be furnished to indicate or shut down if filter should become restricted.
|
|
|
|
|
|
With a wide range of granule receivers ranging from 1,5 to 140 dm3, Piovan is able to offer the ideal solution for all conveying requirements. Three versions of vacuum receivers are available: granule receiver entirely in stainless steel (C models), version with 3 sight glasses (SR models) and in the configuration with glass section (GR units).
Maintenance:
> Effective and rapid cleaning operations
> wide filtering surface and solid steel frame, to guarantee continuous functioning of the system with no production stop for maintenance operations or replacement of the filter
> anti-wearing materials
Design: magnetic sensor integrated in the control box and factory pre-set. A led allows the operator to monitor when the sensor is activated.
Simplified and rapid installation: The possibility to adjust at 360° the adoptor ring as well as the material and vacuum lines, not constrained one another, simplifies the installation of the receiver in line with the plant configuration.
SIMPLIFIED AND ENHANCED OPERATOR INTERFACE: Easy3System
Plug&Play: The receivers are immediately ready for operation once connected, with factory pre-set loading cycles for optimal functioning. The working status and possible alarms are signalled in a user-friendly way with bright green and yellow leds positioned on the upper part of the control box, in a visible position.
The KEYPAD permits to customise the hopper loader’s functioning, setting the conveying times, the pause time between the loading cycles, the maximum number fo unsuccessful loading cycles, the modes of filter cleaning, and the functioning of the proportional valve.
Easy3System is compatible with the previous versions.
|
|
|
|
|
|
FEEDMAX B and BS/4 Series Loaders
The FEEDMAX B and BS/4 series loaders are built for highest functionality and demanding applications. The modular design of these vacuum loaders guarantees specific adjustment to meet individual customer requirements, as well as for simple cleaning.
- Complete flexibility – Stainless steel line size reducers can be easily interchanged to maximize flexibility.
- Superior wear resistance – Pneumatically actuated cast stainless steel material and vacuum valves for highly abrasive feeding applications.
- Low Maintenance – Interchangeable mirror finish stainless steel center section offers low maintenance and allows hopper capacity to be easily changed.
- Completely dustproof – Pneumatic discharge shut-off valve design permits clean
room operation for standard loaders.
- Highest operational reliability – Dustproof and pneumatically controlled material shut-off discharge valve.
- Ergonomic design – A hinged lid without valves or hose connections offers unmatched accessibility
for simple cleaning.
- Simple cleaning – One self-locking toggle latch is easily accessible and opens towards the operator.
- Easy operation – Modular assemblies with fully accessible quick release band clamps can be easily cleaned and interchanged.
- Easily visible – Status LED`s and pluggable control cable for all network control systems.
- Reliable – Material demand via proximity sensor standard with high heat execution.
|
|
ALD130P-18F is a double diaphragm air micro pump which well suited for compressing air.
Technical Features:
1.Double diaphragm air pump.
2.Uncontaminated flow.
3.Non-metallic construction.
4.Compact size.
5.Maintaince free.
6.Can operate in any installed position.
|
|
CMP30 vacuum(air,gas) micro pump are well suited for transferring,evacuating and compressing air and neutral or corrosive gases as well as vapors.
Technical Features:
1.Uncontaminated flow.
2.Non-metallic construction.
3.Compact size.
4.Maintaince free.
5.High level of gas tightness thanks to the closed diaphragm surface and special sealing system.
6.Can operate in any installed position.
|
|
CMP-11 vacuum(ari,gas) micro pump are well suited for transferring,evacuating and compressing air and neutral or corrosive gases as well as vapors.
Technical Features:
1.Uncontaminated flow.
2.Non-metallic construction.
3.Compact size.
4.Maintaince free.
5.High level of gas tightness thanks to the closed diaphragm surface and special sealing system.
6.Can operate in any installed position.
|
|
CMP-17 vacuum(ari,gas) micro pump are well suited for transferring,evacuating and compressing air and neutral or corrosive gases as well as vapors.
Technical Features:
1.Uncontaminated flow.
2.Non-metallic construction.
3.Compact size.
4.Maintaince free.
5.High level of gas tightness thanks to the closed diaphragm surface and special sealing system.
6.Can operate in any installed position.
|
|
CMP40 vacuum(air,gas) micro pump are well suited for transferring,evacuating and compressing air and neutral or corrosive gases as well as vapors.
Technical Features:
1.Uncontaminated flow.
2.Non-metallic construction.
3.Compact size.
4.Maintaince free.
5.High level of gas tightness thanks to the closed diaphragm surface and special sealing system.
6.Can operate in any installed position.
|
|
CMP-25 vacuum(ari,gas) micro pump are well suited for transferring,evacuating and compressing air and neutral or corrosive gases as well as vapors.
Technical Features:
1.Uncontaminated flow.
2.Non-metallic construction.
3.Compact size.
4.Maintaince free.
5.High level of gas tightness thanks to the closed diaphragm surface and special sealing system.
6.Can operate in any installed position.
|
|
Con-Evator , PGT Vacuum receiver
High performance, environmentally-friendly vacuum hopper loaders covering all aspects of modern conveying technology for plastic materials. The PGT series is based on the vacuum principle and gives a clean, low-noise conveying of materials. No compressed air is required because of a unique non-polluting filter cleaning system. The specially engineered blowers also ensures optimum reliability and consistency..
|
|
ADI’s Standard and Mini Size Dia-Vac® pumps are available with Air driven motors….an ideal choice for extreme hazardous or remote sampling applications. Maximum performance 1-150 LPM, 0-29.9”HG or 0-75 PSIG.
Single Head Mini Diaphragm Sampling Pump (M161-FT-DX0 shown here)
|
|
| ... products without technical information |
| |
The SludgeMaster submersible, air-powered trash pump handles mud, leaves, twigs, sand, sludge, trash-laden water and soft solids to 1.5" (3.8cm). High capacity - low head. It weighs only 59 pounds (26kg), and can fit through an opening as small as 14" (35cm). Sturdy construction for rough handling and long life. Optional rock screen available.
Pipe Size: 3" / 80mm
Displacement Per Stroke: - gal / - ltr
Max. Flow per Minute: 300 gal / 1140 ltr
Max. Solids Handling: 1.5" / 38mm
Max. Discharge Pressure: - PSI / - BAR
The PortaPump submersible, battery-powered pump operates using any 12-volt car or truck battery. It comes equipped with cables and battery clips. Extremely portable, the pump weights only 33 pounds (15kg) and can fit through openings as small as 10" (25cm). Electrically safe and whisper quiet.
Pipe Size: 1.5" / 40mm
Displacement Per Stroke: - gal / - ltr
Max. Flow per Minute: 43 gal / 163 ltr
Max. Solids Handling: 1/16" / 1mm
Max. Discharge Pressure: - PSI / - BAR
|
|
|
|
