8021 - Pneumatic Hold Down Clamp - Enclosed
Patented enclosed linkage makes clamp ideal for dirty environments such as welding and machining.
1. 390 lb. Capacity
2. Double-acting pneumatic system required to operate
3. Available with magnetic ring for position sensing as an option. Switches are also available
4. Can be equipped with Viton seals for high temperature applications
035 - SELECT Pneumatic Swing/Pull Clamp
StrongHold SELECT pneumatic swing/pull clamps are designed for applications not requiring hydraulic power. They are a rugged and simple design suitable for harsher applications.
1. Double acting in threaded body or lower flange mount styles
2. Range of sizes for maximum clamping forces from 50 to 430 lbs.
3. Swing motions in right, left or straight guided pull
4. Avaiable in 0, 45, 60 or 90 degrees of swing
|
|
The high performance toggle action clamps are used to clamp mid to large size vehicle parts in Body-in-White operations. The oblong design of the cylinder and the narrow clamp head allow optimal access for weld guns and the fully enclosed mechanics provide a shield from welding slag.
The units are designed for over 3 Million work cycles.
Optionally available in steel or aluminum design.
Integrated inductive position sensors mounted in a cartridge (Patented)
|
|
