Function : Absolute and relative humidity, temperature, dew point.
Large choice of probes :
- ABS hygrometry probe (wired or wireless)
- Stainless steel hygrometry probe (wired or wireless)
- 4 thermocouple inputs
- Pt 100 temperature probe
- Storage : 8000 points of measurement
> Hygrometry : from 3 to 98%HR
> Absolute humidity : from 0 to 285 g/Kg
> Temperature : from -50 to +250C
Supplied with calibration certificate.
Join our distribution network all over the word....Contact us !
|
|
|
|
|
|
The MDM300 is a high-speed dew point portable hygrometer which uses Michells ceramic impedance sensor and state-of-the-art thin and thick film techniques. Operation of the sensor depends upon the adsorption of water vapour into a porous, non-conducting sandwich between two conductive layers built on top of a base ceramic substrate. The MDM300 provides the fastest spot check measurement of dew point or moisture content in a small portable instrument and is packed with features and intelligent engineering.
The user-friendly MDM300 offers an extremely fast response speed and an accurate and stable measurement. The hygrometer has data-logging and built in sampling components as standard and a range of optional accessories are available such as a stand-alone sampling system and a professional carry case.
The MDM300 uses the latest Bluetooth wireless technology to offer a quick and easy assembly and downloading process. With a choice of four different sampling arrangements (from fixed orifices for low pressure to high quality configurable sampling systems for high pressure), the MDM300 offers a cost effective and easily portable service to the user. The MDM300 is able to connect to external sensors to measure dew-point, temperature and pressure and also to re-calibrate other Michell Instruments such as the Easidew Transmitter. The original design and long battery life makes a perfect hygrometer for laboratory or portable use.
|
|
This compact, portable unit provides fast and accurate measurement of relative humidity and temperature of stacks of paper.
APPLICATIONS
Paper, stacks, and reams
SPECIFICATIONS
* Humidity Range: 0 to 100% RH
* Accuracy: 2%RH from 20C to 25C (68F to 77F)
* Humidity Resolution: 0.1% RH
* Certified to NAMAS humidity standards
* Temperature Range: -5C to +50C (23F to 122F)
* Temperature Accuracy: 0.5C (0.9F)
* Temperature Resolution: 0.1C or 0.1F
* Response time: less than 10 seconds at 25C
FEATURES
* Dual display of humidity and temperature
* Display hold
* Multi-position probe
* Battery test function
* Automatic power shut-off after 2 minutes
|
|
The HN-CH series is accurate palm-sized temperature/humidity meter with the measuring range of 0 to 100%RH by using a high performance and reliable humidity sensor.
Three types of sensors, sensor built-in type, probe type and separated type can be selected to meet various applications requirement.
It also has the data logging function capable to store up to 8000 readings each of temperature and humidity into memory, and communications function (RS232C or RS485) for various use such as mobile measurement, desk-top and wall-mount.
|
|
HUMIPORT 05/10/20
Handheld for the measurement of: realtive humidity, absolute humidity, dew point, mixing ratio and temperature
OMNIPORT 20
Multifunctional handheld instrument for: relative humidity, absolute humidity, dew point, mixing ratio, temperature, air velocity, water activity in oil and water content in oil
THERMOPORT 20
Handheld Thermometers
Handheld thermometers of the THERMOPORT series set new standards because of the combination of the latest technology and design. Excellent readability of the very large and illuminated display, the simple thumbwheel operation and the very robust case also allow
usage in tough industrial environments.
Two measuring channels, one to connect a PT100 probe and the other to connect a thermocouple probe (E/K/J/N/R/S/T type), provide measurements between -200...1200 C (-330...2200F).
Many different sensing probes allow the exact adjustment to the particular application.
VELOPORT 20
Handheld for the Measurement of Air Velocity and Temperature
|
|
|
|
|
|
DTM 550 FEATURES
Temp:-20~ 100
Humidity:0 ~ 100%RH
3 1/2 Digit, Back light display
Use highly accurate RTD temperature sensor
MAX, DATA, HOLD function
Automatic low battery indication
Valox housing to withstand accidental
DTM 550SPECIFICATIONS
Measurement Range: Temp:-20 ~ 100
Humidity: 0 ~ 100%RH
Temp. Accuracy: }0.5-0~50, }1-20 to 0,50 to 100
Humidity Accuracy: }2.5% RH (10% to 90% RH) ;}5% RH (90% RH)
Operating Environment: 0 to 50 at <75% relative humidity
Resolution: Temperature:0.1; Humidity:0.1% RH;
Sensor: Pt385/1000,RTD temperature sensor
General
Power Requirement: 4 pieces 1.5V (AAA size) batteries
Dimensions: 6.7"x1.7"x1.6" (170x44x40mm)
Weight: 6.3 oz(180g)
Accessories: Soft carrying case, batteries, owners manual
Q & A:
A room has an ambient room air temp of 70 Deg F, followed by a brief period at 50 Deg F for 5 seconds, then returning back to 70 Deg F again. Will the meter be able detect this temperature change and display it as a minimum reading ?.
I did an experiment on DTM-550 at the out flow gate of air conditioner from room
temperature of 78.8 deg F( 26 deg C).
The reading 59 deg F ( 15 deg C) takes 5 seconds.
The reading 50 deg F should take around 10 seconds.
There is no minimum reading button for DTM-550 but you can have " Hold" function
to read what you measure.
Please note this unit is not available for Fahrenheit display and only for Celsius.
|
|
The HM70 is a user-friendly meter for demanding spot-checking humidity measurements. The HM70 is ideal for field checking and calibration of Vaisala's fixed humidity instruments such as the new Vaisala HUMICAP Humidity and Temperature Transmitter Series HMT330.
Three probes are available:
- HMP75 general-purpose probe
- HMP76 long, stainless steel probe, especially suitable for spot-checking in ducts
- HMP77 with a small sensor head at the end of a 5-meter cable, ideal for difficult-to-reach areas and for on-site calibration of Vaisala's process transmitters.
The HM70 features a multilingual, menu-based user interface, and a clear graphical LCD display. Three measurement parameters can be displayed and logged into the meter's memory at the same time. An analog output option is also available.
|
|
|
For fast and accurate measurement of relative humidity, temperature and dew point of the environment. Useful in industries such as Mold Remediation, Water Damage Restoration, Flooring etc. where monitoring of relative humidity in the environment is important. This pocket size, fast reacting (approx 60 secs) Hygrometer measures Temperature, -20 C to 50 C (14 F to 120 F). Relative humidity 5% to 95% with Dewpoint, Min/Max and built in sensor probe.
|
|
The General Eastern product line offers portable moisture instruments that can be used in a variety of gaseous applications. Our analyzers are well balanced, compact, easy to use and come complete with all the units of measure and connectability required to keep track of the moisture critical processes in your facility.
MMY245 Moisture Analyzer For a Speedy Response
The MMY245 Moisture Analyzer is a convenient, portable instrument that can quickly spot check the performance of gas dryers for compressed air, breathing air, and pure gas supplies. The planar capacitive sensor combines accurate dew point measurement with fast response time. The sensor is stored in a very dry environment within the analyzer between measurements, which speeds response time.
|
|
TK-100 Portable Hygrometers
Model YN
User's voice as "portable Model that can be brought even by sudden business trip" was realized. Measurement range is -100 to +20 degC dp.
|
|
CENTER 313-314
Features :
Center 313/314 are data loggers enhanced from 310/311. We had built memory for 16 000 records in these testers. The sampling period is programmable and there is a real time clock in the tester. The window based software come with each unit is very easy to operate. The users only have to connect the cable and call the program and no extra setup is needed.
|
|
HI 9564 and HI 9565 are two new portable thermo-hydrometers designed to provide excellent performance in harsh environments and poorly lit areas.
A microchip built into the RH probe, HI 70602, can store calibration data. When the probe is connected to another hygrometer, the microchip transfers the stored calibration data and eliminates the need to recalibrate the instrument.
Both instruments feature auto-off after 20 minutes of inactivity, temperature readings in Celsius and Fahrenheit, and on-line help to indicate anomalies and direct procedures.
In addition to RH and temperature, HI 9565 will display the dew point with the press of a button. The dew point indicates the presence of water vapor in the air at a given temperature. With this feature HI 9565 permits useful and rapid environmental monitoring where a controlled microclimate is necessary, like greenhouses, museums, clean rooms and laboratories.
|
|
|
|
|
|
The B&B Hygrometers are available in two versions. Either with an integrated probe or with an external temperature and humidity probe:
HANDY HYGROMETER
for fast and precise measurements of temperature and humidtiy with integrated internal sensors.
- Measuring ranges: -20 to 50C, 0% bis 100% RH
- Various memory features
- Calculation of dew point
- Dual Display: temperature and humidity
ACCURATE HYGROMETER TH309 (see picture)
offers high measurement accuracy up to 1% of the relative moisture and a dew point determination down to -40C. If wished special measurement devices can be realised to best fit the requirements of the customer. Moreover different hand probes of the series TH309 can be connected to the hygrometer without need of new calibrations.
- Temperature: -20 ... 80C, depending on sensor
- Humidity: 0 ...100% RH
- Various memory features
- USB Interface
- Data recording with B B Thermo Log or Thermo View software
- Humidity readings switchable: RH, absolute humidity, dew point
For further information have a look at our temperature-shop:
www.temperature-shop.eu
Our further product range:
- Temperature Sensors
- Temperature Humidity Sensors
- Thermocouple Connectors
- Temperature Measurement Instruments
- Digital-Thermometer
- Infrared Thermometer
- Data logger
- Recorders
- Stationary Pyrometers
- Controllers
- Indicators
- Transmitters
|
|
|
|
|
|
HUMIPORT 05/10/20
Handheld Thermo Hygrometers
Handheld thermo-hygrometers of the HUMIPORT series set new standards because of the combination of the latest technology and design. HUMIPORT thermo- hygrometers offer very accurate measurement of relative humidity and temperature and also calculation of dewpoint temperature and absolute humidity.
Excellent readability of the very large and illuminated display, the simple thumbwheel operation and the very robust case also allow use in tough industrial environments.
3 models are available:
HUMIPORT 05: Compact handheld thermo / hygro- meter with fixed sensing probe
HUMIPORT 10: Handheld thermo / hygrometer with fixed sensing probe
HUMIPORT 20: Handheld thermo / hygrometer with flexible sensing probe
OMNIPORT 20
Multifunctional Handheld Instrument
To measure various climate and processes values with a handheld, user-friendly instrument requires extraordinary measurement technology. The handheld meter of the OMNIPORT 20 series meets these multiple demands.
The selection of the appropriate sensing probe and accordingly the configuration of the handheld meter allow for displaying the following values with the highest accuracy:
relative humidity RH
temperatur T
dew point temperature Td
absolute humidity dv
mixing ratio r
air velocity v
water activity (in oil) aw
water content (in oil) x
|
|
Highly accurate Temperature Humidity meter
Model DTM 550 FEATURES
Temp:-20~ 60
Humidity:0 ~ 100%RH
3 1/2 Digit, Back light display
Use highly accurate RTD temperature sensor
MAX, DATA, HOLD function
Automatic low battery indication
Valox housing to withstand accidental
|
|
|
|
|
|
Highly stable humidity measurement +/-2.5%
Processing & RH and temperature simultaneously
Two temperature sensors (NTC and K-Type) & Humidity sensor together
Wet/Dry bulb, dew point and %RH
Easy switching between K/NTC/K-DP
MAX/MIN/AVG/REL/HOLD function
Auto power off function
Specifications:
Display: 3 digit liquid crystal display (LCD) with a maximum
reading of 1999
Polarity: Automatic, positive implied, negative polarity
indication.
Low battery indication: The is displayed when the battery
voltage drops below the operating level.
Operating environment: 0C to 50C at<80% R.H.
Storage environment: -20C to 60C, 0 to 70% R.H. with
battery removed from meter.
Accuracy: Stated accuracy at 23C5C, <75% R.H.
Battery: 1.5Vx4pcs AAA size.
Dimensions: 160mm(H) x 83mm(W) x 38mm(D).
Weight: approx. 265g including batteries.
Temperature Range
Range: -50C to 1000C, -50F to 1832F
Accuracy:
(0.1% rdg+1C) on 50C to 1000C
(0.1% rdg+2F) on -50F to 1832F
Temperature
Sensor: Thermistor temperature sensor
Range: 0C to 60C, 32F to 140F
Resolution: 0.1C/F
Accuracy:
2C on 0C to 10C, 0.5C on 10C to 45C
2C on 45C to 60C
4F on 32F to 50F, 1F on 50F to 113F
4F on 113F to 140F
Relative Humidity
Sensor: Capacitive humidity sensor
Range: 0% to 100% RH
Accuracy:
2.5% at 25C(77F), 10% to 90% RH
5% at 25C(77F), 0% to 10% RH, 90% to 100% RH
Sensor Response Time for 90% of Total Range:
60 sec typical.
|
|
The ROTRONIC HygroPalm handheld instrument of the AirChip3000 generation are the perfect instruments for climatic measurements. They are extremely precise and feature many practical functions, but are easy to use.
HygroPalms are adjusted and configured during production and are therefore ready for immediate use. They can be configured for specific applications with userfriendly HW4 software or directly on the keypad. A large range of interchangeable probes enables easy and flexible use, straightforward maintenance and simple calibration.
The HP23 version can be used for the in-situ adjustment of transmitters and for system validation.
Applications
For HVAC technicians and inspectors, the pharmaceutical industry, building management systems, the paper industry, research and many others.
|
|
The Protimeter product line offers handheld moisture meters and hygrometers for professionals. The primary markets for these products are in the building and construction, wood, agriculture and civil engineering sectors. Building surveyors and inspectors use Protimeter products to measure moisture levels in buildings and to diagnose the cause of moisture related problems. Farmers measure the moisture and temperature levels in harvested crops using our grain moisture meters and civil engineers use the Speedy(tm) moisture testers for establishing the moisture level in soils.
|
|
Protected by a shockproof sheath in a compact case, the Physics Line C.A 846 thermo-hygrometer with its built-in sensor can measure ambient temperatures between -20 and +60C inclusive, as well as humidity between 0 and 100%.
# 3-digit display (2,000 counts)
# functions: MAX / HOLD / C or F / Backlighting
# measurement range: -20C to +60C; -0 to 100%RH
# temperature accuracy: 0.5C from 0 to 60C, 1C from -20C to 0C
# hygrometric accuracy: 7.5%RH from 10 to 90%RH, 10%RH from 0 to 10%RH and from 90 to 100%RH
# resolution: 0.1C and 0.1%RH
# shockproof protective sheath
# dimensions: 173 x 60.5 x 38mm - Weight: 185g
|
|
DTM-321: Dual Input.Temperature and humdity meter.
DTM-322: Dual Input + Data Recorder.+RS-232 interface (optional USB cable)
DTM-321:
Temp:-20C ~ 60C (-4F ~ 140F ); K-type: -200C ~ 1,370C (-328F ~ 2,498F); Humidity: 0 ~ 100% RH
4 Digit, Triple display.
K-type Termocouple.
Reading hold C or F annunciators.
MAX, MIN. function.
Auto power off.
REL function.
Automatic low battery indication.
RS-232 computer interface.
RS-232 cable and software for Windows (Options).
DTM-322:
Temp:-20C ~ 60C (-4F ~ 140F ); K-type: -200C ~ 1,370C (-328F ~ 2,498F); Humidity: 0 ~ 100% RH
Data Logging capacity 16,000 records.
4 Digit, Triple display.
K-type Termocouple.
Reading hold, C or F annunciators.
MAX, MIN function.
Auto power off.
Time function.
Automatic low battery indication.
RS-232 computer interface.
RS-232 cable and software for Windows.
Optional USB Cable
|
|
The measuring instrument for ambient air conditions, for assessing Indoor Air Quality and adjusting and inspecting VAC systems. testo 435-1 is an affordable introduction to measurement engineering for ambient air conditions. The new IAQ probe measures Indoor Air Quality by measuring CO2 level, air moisture and air temperature. Temperature and humidity measurement is integrated in the new thermal probe. In addition, it is also possible to connect additional temperature probes. Readings from up to 3 temperature probes can be displayed in the clearly laid-out measuring instrument display; data transmission is radio-controlled, therefore wireless. Measurement data is printed on site on the Testo printer.
* IAQ probe for assessment of Indoor Air Quality
* Vane measurement and thermal probes
* Radio probe for temperature
* Testo printer for documentation
* Protection class IP54
|
|
testo 454/350
Control unit displays measurement data and controls the measurement system, incl. built-in printer, pressure measurement 40/200 hPa, 1 user defined probe socket, programmable measurements and memory space for 250,000 readings, connection for Testo data bus, incl. terminal plug
* Testo databus controller to read and control loggers via laptop/PC
* Control unit
|
|
Description:
The model H300 is an ideal meter for taking Temperature, Humidity and DEW Point measurements. All three measurements are important for maintaining optimal levels during environmentally sensitive manufacturing of items such as; cosmetics, pharmaceuticals, paints, chemicals, foods etc... They are also important indicators of good indoor air quality in hospitals, hotels or office buildings. Lightweight and easy to use, the model H300 is the perfect tool for HVAC and IAQ monitoring.
Features:
* Humidity, Temperature and Dew Point measurements
* 0.01 Resolution for Temperature and RH measurements
* Fast response time
* High level of accuracy
* Large LCD display
* Two year warranty
* RH Range: 5% to 95%
* Temperature range: 32 to 122 degrees F (0 to 50 degrees C)
Applications:
* HVAC
* Manufacturing processes
* Quality control in production and manufacturing
* Science experiments
* Plant maintenance
* Agriculture
* Hygrometer measurements
|
|
