Optimum performance for industrial applications - this is what the Temposonics R-Series offers. As a high-end product, the series is the racehorse of MTS. Powerful electronics and unrivalled immunity against interference are a warranty of high-accuracy measurement results.
|
|
|
The E-Series is the basic sensor in the product range of magnetostrictive position sensors. An excellent price/performance ratio is an unbeatable asset even for traditional users of different position measurement technologies.
|
|
POSICHRON is an absolute, contact-free and wear-free position measuring system. It is extremely sturdy making it suitable even for applications where other measuring principles would fail. The availability of various constructions - quad profile housing, flat profile, stick design, rod profile - means that the system can be adapted to suit all kinds of installation conditions.
Technical advantages:
Absolute measuring principle, totally wear- and maintenance-free, resistant to dirt humidity and dust, protection category to IP68, highly resistant to vibration and shock, resolution is virtually unlimited, linearity of up to 0.01%, no energy feed for positional magnets, measuring lengths of up to 5,750 mm.
The areas of application for POSICHRON positional sensors are wide and varied. They are used in e.g. injection-moulding equipment, dosing and mixing systems, die-casting machines, road vehicle tests, hydraulic cylinders and presses, fill-level measuring equipment etc.
|
|
|
Optimum performance for industrial applications - this is what the Temposonics R-Series offers. As a high-end product, the series is the racehorse of MTS. Powerful electronics and unrivalled immunity against interference are a warranty of high-accuracy measurement results.
|
|
|
Optimum performance for industrial applications - this is what the Temposonics R-Series offers. As a high-end product, the series is the racehorse of MTS. Powerful electronics and unrivalled immunity against interference are a warranty of high-accuracy measurement results.
|
|
|
Compact construction, a reasonable price for large-series production, complete functionality and modularity: the C-Series sensors provide persuading solutions for all requirements of the OEM-market.
|
|
Magnetostrictive Position Sensors for Mobile Hydraulics: PCST25
Technical advantages:
Protection class IP69K
Compression-proof up to 400 bar
Measurement range 0 ... 100 to 0 ... 5750 mm
Position sensor manufacturer ASM has extended its successful family of magnetostrictive Position Sensors POSICHRON® with a new sensor series PCST25, which has been designed for special requirements in the field of mobile hydraulics.
The PCST25 series with measurement ranges up to 5,750mm and linearity up to 0.02% for high accuracy, can be used in an operation pressure zone up to 400bar and is already available at ASM.
The extremely robust construction of POSICHRON® sensors with up to an IP69K rating guarantees years of trouble-free operation. Due to their high electrical compatibility and extremely high resistance against shock and vibrations, POSICHRON® sensors are best suited for applications in extreme hostile environments, such as with off-road construction equipment.
|
|
MTS has developed the Temposonics M series especially for integration into hydraulic cylinders. The sensor is protected against shock, vibration and extreme environmental conditions and offers an unrivalled measurement rate, outstanding repeatability (better than +/- 0.005%) and stable linearity (better than 0.04%). External effects on the measurement signal are virtually excluded by interference suppression for HF electric fields up to 200 V/m, vibration resistance up to 30gav and shock resistance of more than 100g. Changes of the hydraulic oil during operation are without effect on the measurement. The magnetostrictive technology of Temposonics sensors was invented by MTS and widely used and well proven in stationary industrial applications for many years. The magnetostrictive measurement principle is a warranty for wear and maintenance free absolute, contactless position measurement.
Temposonics MH offers continuous measurement of both - position and speed - during the position change. The integrated sensor electronics permits parameter adjustment for evaluation of the cylinder piston speed and end position attenuation can be omitted. Due to the output of a velocity signal, highly dynamic control of the movement profile of several independent hydraulic cylinders is possible for the first time. It enables the power actuators to be developed into complex movement axes and permits realization of high-quality control systems. With electro hydraulic parallel guidance of excavators or loaders, for example, Temposonics offer high signal quality and simple analogue transmission due to screening and a short signal lead.
|
|
PCFP24: a magnetostrictive Position Sensor as flat as a ruler
Position sensor manufacturer ASM introduces a new magnetostrictive position sensor with a unique extremely flat housing: the POSICHRON® model PCFP24. With a height of only 12 mm, the “flat pack” is suited for numerous applications in narrow installation environments.
POSICHRON® is an absolute, contact-free and wear-free measuring system designed for almost all industrial applications. The PCFP24 has absolutely no protrusion in form of screws, connectors or probes jutting out of the 12 mm construction. This feature makes PCFP24 best suited for applications in narrow installation environments.
The sensor can be installed easily by means of mounting brackets. With this design the sensor position can be adjusted over its whole mechanical length without any mechanical collision. The system is wear- and maintenance-free and features high shock and vibration resistance.
The PCFP24 is available with analog interfaces for voltage (10V) or current (4-20mA) output as well as with SSI or digital pulse output Start/Stop, which makes it possible to bind the sensor into subsequent electronics for bus systems. The sensors measurement range is up to 5750 mm.
|
|
Magnetostriction - A Milestone in Measurement Technology
The heart of MTS sensors is the ferromagnetic measuring element, also known as the waveguide, and a movable position magnet that generates a
direct-axis magnetic field in the waveguide. When a current or interrogation pulse passes through the waveguide, a second magnetic field is created radially around the waveguide. The interaction between the magnetic field in the waveguide and the magnetic field produced by the position magnet generates a strain pulse which travels at a constant ultrasonic speed from its point of generation, the measurement point, to the end of the waveguide where it is transformed into an electric pulse in the sensor element. The resulting signal is processed by the specialized electronics of the Temposonics sensor. With our extensive know-how of ferromagnetic materials, magnetic effects and ultrasonic processes, MTS remains unrivalled in performance standards for non-contacting position measurement of the highest precision.
|
|
Designed specifically for use in hydraulic and pneumatic actuator applications, where the sensor is fitted inside the pressurised environment.
Available in a choice of two mounting styles (Internal or External), these sensors can be supplied in lengths to suit actuator strokes up to 1100mm.
|
|
What is a laser?
Laser light consists of light waves of identical length which have a defined phase relation (coherence).
Laser systems also have a relatively small angle of radiation.
What are the distinctive features of laser systems?
Laser systems are used where detection of small objects or precise positioning is required. Due to the small angle of divergence this can be achieved over long ranges.
How dangerous are laser sensors?
Due to the small angle of divergence laser beams are focussed on a small area. The energy and power density on this area is extremely high. Depending on the technical data of the laser transmitter, this is a risk for human health, specially for the eye. ifm laser sensors conform to the Euro standard EN60825 and the international standard IEC60825. These standards describe the operation of laser systems. In the standard laser systems are divided in 5 classes.
ifm laser sensors are classified in the laser protection class 2. Thus the laser power, also in the setting mode is max. 1 mW. When the laser beam hits the human eye the eyelid is instinctively closed. When hitting the unprotected eye the laser beam must cause no damage within a time of 0.25 s.
|
|
“POTENTIOMETRIC” linear transducers, with resistive element made of conductive plastic, are suitable for applications on hydraulic and pneumatic cylinders, plastic moulding-, packaging, textile machines etc.
The available lengths are from 10 cm to 100 cm (according to the choosen model) with infinite resolution.
|
|
|
A comprehensive range of linear potentiometers covering strokes from 10mm to 1600mm. See information on the models SLS095; SLS130; MLS130; SLS190; SLS220; SLS320
|
|
Designed specifically for use in hydraulic and pneumatic actuator
applications, where the transducer is fitted inside the pressurised
environment. Can operate at pressures of 670 Bar and temperatures of +200C.
Seperate electronics module operates from 10-60Vdc.
Available in a choice of mounting styles (Internal or External), these
transducers can be supplied to suit actuator strokes up to 2000mm.
|
|
The POSIMAG length measuring system comprises an MR scanning head and a magnetic dimensional scale. The position is determined without contact and thus without wear or tear. This measuring setup supports resolutions in the µm range.
POSIMAG is suitable for linear, angluar and speed measurements.
Technical advantages:
Sturdy construction, contact-free and wear-free, shielded metal housing, protection category up to IP67, signal processing as standard with encoders, distance between the MR sensor head and the magentic strip up to 2 mm, measuring lengths of up to 30,000 mm.
Thanks to its special properties, POSIMAG is ideal for many industrial applications in the production of machinery, plants and precision equipment as well as research. For example: Metal and wood processing, manual tasks in handling systems, positional checks for linear units, quality-control systems for sheet metal, punches and presses.
|
|
IK1A Displacement transducer contactless measurement using magnetostriction (ANALOG OUTPUT)
Absolute type transducer
Displacements from 100 to 4000mm
Working temperature range: -40...70°C
Vibration resistant (DIN IEC68T2/6 12g)
Rod, nipple, exagonal flange AISI 316
IP67 Protection
EMI CE compatible (EN 50081-2 50082-1)
Power supply 24Vdc ±20%
Optional galvanic isolation between the power supply and the output
|
|
Highly dynamic NOVOSTRICTIVE measuring system. Secure data transfer with 16 kHz update rate.
Also versions for integration in pneumatic and hydraulic cylinders.
|
|
The S953 VMAX Linear Displacement Transducer is the ideal solution for automation solutions requiring accurate
feedback of continuous position. It is especially recommended in environments where vibrations, extreme temperature
and contaminants are present. The S953 is an ideal solution when velocity and position need to be incorporated into the
automation control system process.
The S955 Brik linear displacement transducer is an economical solution for monitoring continuous position. It is
designed for OEM users wishing to opt for a cost effective alternative to limit switches, proximity sensors or linear
potentiometers. The streamlined anodized aluminium extrusion houses the sensing element and the electronics. The
position is determined by the magnet which is linearly guided over the sensing element.
|
|
Highly dynamic NOVOSTRICTIVE measuring system. Secure data transfer with 16 kHz update rate.
Also versions for integration in pneumatic and hydraulic cylinders.
|
|
|
The Microtrak II is a state of the art CMOS laser triangulation sensor for precise measurements of displacement, position, vibration and thickness. It is unaffected by surface texture, color or stray light. Measurement ranges are up to 40 mm at a standoff distance of 120 mm.
|
|
PC Selfloading rectilinear displacement transducer with cylindrical case
50 to 750 mm stroke
Mechanical fixing and selfaligning linkage using 2 ball-joints
Maximum angular movement up to ± 30°
Independent linearity ± 0.05%
Repetibility 0.01 mm
Infinite resolution
No variation of electrical signal outside theoretical electrical stroke
Displacement speed up to 5 m/s
Working temperature: -30...+100°C
Electrical connections:
PC H 3-pole connector
PC M 4-pole connector to standard DIN43650-ISO4400
PC B 5-pole connector (DIN43322)
PC F 3-pole screened cable (1 m length)
Life duration: > 25x106 meters or > 100x106 operations, whichever is the smaller (within C.E.U.)
Grade of protection IP65
|
|
Honeywell linear and rotary potentiometers measure linear, rotary position or displacement. Use a tried and true potentiometric technology originally developed for military applications and more recently applied to industrial markets. The proprietary MystR® conductive plastic has extensive temperature range, infinite resolution and provides absolute position measurement on power-up. Intermediate signal conditioning is not required for normal ratiometric position sensing. Very small stroke units (5 mm [0.2 in]), and units required to withstand exposure to harsh chemicals, function immersed in different oils or water, are available.
Best Used For:
Applications requiring sensing response to the movement or location of a target, such as a molding press slide or a pulley shaft.
|
|
|
Position transdcuers for exact, reliable operation under harsh environmental conditions and at high positioning speeds. Potentiometric or non-contact - complete systems or components.
|
|
Spectrum’s Linear Precision Sensors offer smaller sizes (0.312” diameter sizes), the best output smoothness (0.1% max.) and infinite resolution. Our linear potentiometers are co-molded conductive plastic element for a hard smooth surface and greater long-term reliability. Linear position sensors are available with special custom strokes and various mounting and shaft-end options and Spectrum will customize any of these sensors for specific applications.
Features
• Greater Reliability & Longest Life – 100 million cycles min.
• Various Stroke Lengths (0.500 – 2.500”)
• 0.312” & .0500” diameter housing standard (custom available)
• 5/64” & 1/8” diameter stainless steel shafts
• Shock & vibration per MIL-R-39023
|
|
CLWG Series • In Stock!
3-in. to 30-inch full stroke ranges
0.04 % - 0.1 % linearity
5k - 1k ohms
50+ million cycles
The CLWG series was designed for a wide range of demanding automation and robotic applications.
Outstanding linearity and accuracy are acheived using a conductive plastic resistive element. The wiper system is mounted on the actuating rod and is free of backlash for a long life and trouble free operation.
|
|
|
Electrical travel : 25 -100 mm Linearity 0,1% RECTI H12 ; Electrical travel : 10 -300 mm Linearity 0,1% RECTI P12 ; Electrical travel : 100 -1000 mm Linearity 0,05% RECTI H28 Electrical travel : 10 mm Linearity 0,5% RECTI H20-10
|
|
The UltraSensor has been designed as a next generation replacement of Proximity and Micro switch systems for monitoring spool movement in progressive divider elements.
A single model will work with all standard SMX and SMP divider blocks as a screw-on accessory without requiring special arrangement or modification to the spool.
The patented concept works by monitoring magnetic flux variations through a hall-effect sensor as the spool enters the sensing range. There are no moving parts which means the solid state device is completely wear free.
NPN and PNP connection options are standard within the same sensor.
|
|
The Microtrak II high speed stand-alone laser head utilizes the latest CMOS / CCD technologies and is ideal for industrial/process automation and quality control applications. With the new Microtrak Stand-alone Laser Heads, a
controller is no longer required to obtain fast, accurate and
reliable measurements from a laser triangulation sensor.
|
|
With our new Laser-Distance Sensors DLS-B you measure absolute distances up to 500 meters. Thanks to state of the art laser technology the DLS-B device measures with a precision of 1.5 millimeters. It represents a cost efficient solution even at extreme environment temperatures as low as -40° C.
The DLS-B is an optical measuring device. You can measure, maintenance-free, distances on natural and reflective surfaces. You determine positions on objects difficult to access or with very high surface temperatures. Just as well you can measure distances in an aggressive environment in an easy and accurate way.
Serial, analog and digital interfaces are standard features for the complete DLS-B product line. This enables you to easily connect the DLS-B to a control system (SPS, IPC or PC)
The DLS-B device runs in a “Stand-alone-mode” and independently executes all programmed functions. Thanks to the flexible range of functions an external display can be connected directly to the DLS-B device via interface RS232 or RS422. Via a digital input, measurements can also be activated from an external button or switch.
For easy configuration of the DLS-B devices, the necessary software is at your disposal
|
|
|
|
