8335 with MN93-BK Three-Phase Power Quality Analyzers
The PowerPad® Model 8335 with MN93-BK is a three-phase power quality analyzer that is easy-to-use, compact and shock-resistant. It is intended for technicians and engineers to measure and carry out diagnostic work and power quality work on one, two or three phase low voltage networks.
The PowerPad®’s 2GB of memory is conveniently partitioned to let you store four different types of data, synchronized or independent of each other. You can store up to 50 screen snapshots, up to 300 captured transients that contain four cycles for each active input, and 10,000 alarm events from up to 40 different parameters. You can also record trend data for days, weeks or even months.
The Model 8335 with MN93-BK is supplied with a set of four color-coded 240A current probes.
|
|
The 4500B Peak Power Analyzer has been totally redesigned from the inside out. This meter is taking performance to a new peak and changing the way the industry views and analyzes RF data.
• 8.4” TFT color LCD display
• 100 ps timebase resolution
• Automatic peak-to-peak, delay-by-time and delay-by-events triggering
• GPIB, USB and LAN
• Text view of 15 time and power measurements per channel
• Envelope, persistence and roll mode displays
• Gated CCDF and PDF with log display (optional)
• Compatible with industry leading 56xxx and 57xxx series peak power sensors
• Familiar user interface
|
|
4530 Power Meter
4540 Series Datasheet
Application Notes
Related News
The Boonton model 4540 Series RF Power Meter is the instrument of choice for capturing, displaying and analyzing RF power in both the time and statistical domains. Applications include pulsed RF signals such as radar, TDMA and GSM, pseudorandom or noise-like signals such as CDMA, WLAN and WiMAX.
The 4540 Series is a single or dual channel RF Power Meter that can measure modulated or CW signals using peak and average Boonton Power sensors.
The 4540 Series has three operating modes: Pulse, Statistical, and Modulated/CW. Features include:
• High Bandwidth Wide Dynamic Range Sensors
• Intuitive User Interface
• 4" color LCD display
• 200 psec time resolution
• Statistical analysis including CCDF
• Text view of 15 time and power measurements per
channel
• GPIB, USB and LAN
|
|
|
The PQM II is an ideal choice when continuous monitoring of a three phase system is required. It provides metering for current, voltage, real and reactive power, energy use, cost of power, power factor and frequency. Programmable setpoints and 4 assignable output relays allow control functions to be added for specific applications. This includes basic alarm on over/under current or voltage, unbalance, demand based load shedding, and capacitor power factor correction control. More complex control is possible using the 4 switch inputs which also can be used for status such as breaker open/closed, flow information etc.
|
|
|
|
|
|
The SATEC ezPAC SA300 Power Intelligence Unit is an advanced power analysis and control device unmatched in the utility and industrial environments. The ezPAC unites advanced control and automation functions, intelligent fault-recorder, power quality and sequence of events (SOE) with automatic analysis and reports. It also offers revenue metering, back-up protection equipment and control devices to provide a complete solution for substation and industrial automation.
FAULT RECORDER
- Up to 150A fault currents
- Fault distance calculations
- Up to 48 fast (1 ms) digital inputs
- Sequence of events with 1 ms accuracy
EVENT/DATA LOG
- Up to 57 channel simultaneous recording
- Built-in 4 Mb logging memory, up to 128 Mb (option)
MULTI-TARIFF REVENUE METER
- IEC 62053-22 class 0.2S
ADVANCED POWER QUALITY ANALYSIS
- IEC 61000-4-30 Class A power quality
- IEEE 1159 or EN50160 power quality analysis, statistics & reports
- Sags/swells/interruptions detection
- Pulsed transients detection (pulse width >150 ms)
- IEC 61000-4-7 harmonics & inter-harmonics
- Directional power harmonics
- IEC 61000-4-15 flicker
CONTROL & ALARM FUNCTIONS
- 32 programmable set points
- 5 slots for plug-in I/O modules
- Up to three modules of 16-channel digital inputs
- Up to four 8-channel relay output modules
- Up to four combined 4-channel analog input/output modules
- Up to two 8-channel fast (1 ms) analog input modules
COMMUNICATION
- Three independent serial communication ports
- Infrared port
- Built-in modem
- Ethernet
- USB port
- Protocols: Modbus RTU & ASCII, DNP 3.0, TCP/IP
- Optional IEC 61850 protocol
|
|
|
|
|
|
The Advanced Power Quality Analyzer PM175 is a compact, multifunctional 3- phase power and revenue meter equipped with advanced power quality analysis capabilities. The PM175 serves a wide range of users within the IEC Market: substation operators, electrical energy system integrators, generator users, industrial and commercial energy consumers.
MULTIFUNCTIONAL 3-PHASE POWER METER
- Voltage, current (including neutral current), power, energy, power factor, frequency, voltage/current unbalance, load profile
MULTI-TARIFF REVENUE METER
- IEC 62053-22 class 0.2S
- Built-in Time of Use tariffs
- Sealing option
- Built-in clock and calendar functions with back-up battery
- Time synchronization via communication port or digital input
ADVANCED POWER QUALITY ANALYSIS
- Monitoring, statistics & reports according to EN50160 specifications
- Event statistics complemented by waveform recording
- Waveform recording with 6 channels (3 voltage inputs, 3 current inputs)
- IEC 61000-4-7 Harmonics & inter-harmonics
- Directional power harmonics
- Voltage and current THD coefficients
- IEC 61000-4-15 flicker
EVENT/DATA LOG
- Power quality event/data logging
- Logging capability for more than 100 parameters
- Logging parameters with real-time stamps
ALARM AND CONTROL FUNCTIONS
- 16 programmable set points
- 2 programmable relay outputs 3A, 250V
- 2 digital inputs
- 2 optional analog inputs or outputs
COMMUNICATION
- 2 independent communication ports
(RS232, RS422, RS485, modem, Ethernet, Profibus DP)
- Protocols: Modbus RTU, ASCII, DNP 3.0
ISOLATION
- Full galvanic isolation 6 kV Impulse
|
|
|
|
|
|
The Advanced Power Quality Analyzer PM174 is a compact, multifunctional 3- phase power and revenue meter equipped with advanced power quality analysis capabilities. The PM174 answers the needs of a wide range of users within the ANSI Market: substation operators, electrical energy system integrators, generator users. The PM174 provides the full range of power quality monitoring capabilities, compliant with IEEE1159 specifications. The PM174 allows both suppliers and consumers to monitor the quality of outgoing or incoming electric power.
MULTIFUNCTIONAL 3-PHASE POWER METER
MULTI-TARIFF REVENUE METER
- ANSI C12.20, Class 10 0.2% precision
- Built-in Time of Use tariffs to meet any billing requirements
- Sealing option
- Built-in clock and calendar functions with back-up battery
- Time synchronization via communication port or digital input
ADVANCED POWER QUALITY ANALYSIS
- IEEE1159 monitoring, statistics & reports
- Event statistics complimented by waveform recording
- Waveform recording with 6 channels (3 voltage inputs, 3 current inputs)
- Harmonics & inter-harmonics
- Directional power harmonics
- Voltage and current THD coefficients
- IEC 61000-4-15 flicker
EVENT/DATA LOG
- Power quality event/data logging
- Logging for more than 100 parameters
ALARM AND CONTROL FUNCTIONS
- 16 programmable set points
- 2 programmable relay outputs 3A, 250V
- 2 digital inputs
- 2 optional analog inputs or outputs
COMMUNICATION
- 2 independent communication ports
(RS232, RS422, RS485, modem, Ethernet, Profibus DP)
- Protocols: Modbus RTU, ASCII, DNP 3.0
ISOLATION
- Full galvanic isolation 6 kV Impulse
|
|
|
|
|
|
PORTABLE NETWORK & POWER QUALITY ANALYZER EDL175/EDL174XR
The Ideal Tool for Power Quality Tests
The EDL Portable Analyzer is a multifunction power meter, from 3-phase AC to power quality to fault recorder. This power meter uses a large setpoint programming suitable for all AC nework applications, to meet any analysis requirement. The portable analyzer complies with IEC61000-4-30 standard class A, as well as with EN50160, with built-in automatic compliance reports.
The EDL Portable Analyzer measures, records and analyzes events and data of electrical network parameters. The EDL meets the requirements of a wide range of applications, from events analysis to energy auditing and load profile recording over a period of time. This instrument incorporates all the measurement, logging and power quality capabilities of the PM175/PM174 power meters in a convenient portable package, and includes the PAS software package which provides graphic data display and analysis capabilities. The EDL includes a data backup battery and offers a selection of current measuring probes.
|
|
Wide range of panel, power analyzers (in different sizes and functions), allowing connection to a PC using RS-232 or RS-485 systems, according to type. Option to connect peripheral equipment to extend its functions, according to the type of analyzer. This may be internal memory, relays, digital and/or analogue outputs, etc. It has powerful SCADA software to manage and control electrical parameters and other analogue and digital parameters.
Power quality analyzers to detect disturbance in the electrical system (in panel or portable versions). According to the type of equipment, they can detect: slow voltage variations, rapid voltage variations, interruptions, dips, overvoltages, microcuts, etc., that are reasons for machine stoppages, resets in PLC, etc.
|
|
|
|
|
|
|
SIRIUS89N is a complete model to perform all safety tests in compliance to VDE 0413, measure of values of environmental parameters (temperature/humidity, illuminance, sound level with optional probes), leakage current with optional clamp and to perform a network power quality of single phase in compliance to EN50160 guideline.RCDs which suddenly trip out, transformers which overheat, motors which burn out, voltage sags and surges which create problems, all these problems could be easily solved with SIRIUS89N. The meter permits to perform a Loop impedance measurement (P-P, P-N, P-PE) also with high resolution (0.1mOhms) with the use of IMP57 optional accessory and five predefined recording settings are integrated in order to to help the user on the most common situation which are present on the network quality (EN50160, Voltage Anomalies, Harmonics, Start-Up and Power & Energy). SIRIUS89N can perform current measurements up to 3000A AC also by using a flexible clamp type in order to perform measurements on big cables or bars also. Thanks to the PC interface and the powerful software you will create accurate documents qualifying your professionalism more and more.
|
|
Powerful solutions for today's needs
Circuit breakers that trip, transformers that overheat, motors that burn out, machines that don't function properly; whatever the problem, you can quickly and easily identify the cause with the Fluke 43B Power Quality Analyzer.
As a Power Quality Analyzer it is optimized for industrial measurements on the 50 Hz fundamental frequency. Because its frequency range extends from 10 to 400 Hz, it's also ideal for aviation, marine and railway applications.
Besides the unique extended frequency range, the Fluke 43B is the only instrument that combines the capabilities of a Power Quality Analyzer, a 20 MHz oscilloscope, a multimeter and data recorder in a single tool.
|
|
|
|
|
|
A new approach to measuring, recording, troubleshooting and analysing the power quality, this is what the new 800 series made by HT ITALIA is. PQA823 and PQA824, completely designed under Windows CE, permit an easy, wide and fast analysis of a huge quantity of data. Thanks to the graphic TFT touch screen colour display, the very user-friendly icon menu, the typical Windows tree structure and the help on line available for each function, PQAs meet the requests of the most exigent electrical verifier and simplify the user to set the instrument and read the measured data. PQAs are very easy to set, just a click to load your favourite settings.
PQAs display and record all the parameters at the same time, the user could surf the windows of parameters without affecting the recording in progress. Data are displayed in numeric and graphic modes (waveforms, histograms, vector diagrams) both.
PQAs could store voltages, currents and related harmonics, powers (active, reactive, apparent) and power factors, voltage anomalies (sag and swell), flicker, unbalance, start-up currents of the motors and (PQA824 only) the fast voltage transients. The EN50160 analysis routine provides the results by just a click. No hard settings to do, everything within a click.
To troubleshoot the installation under test and do a power quality analysis according to the EN50160, recording all the parameters at the same time is mandatory. 800 series simply does it.
Wide internal memory, USB connection to the PC, USB memory sticks socket, 4 flexible current clamps, 5 voltage probes, a rechargeable Li-Ion battery, an external AC adaptor/battery recharger, are some extra features of PQA823 and PQA824.
|
|
One of our most popular PNA (power network analyzers) is the DEWE-560-PNA. With 4 x voltage and 4 x current inputs, and packaged in a rugged high-impact enclosure, we have pushed the envelope tremendously in putting a powerful analyzer into an incredibly convenient and portable box!
Isolation? Of course. The DEWE-560-PNA meets and exceeds all of the international norms and specifications that you need and expect. In one incredible package we have put a powerful 3-phase analyzer capable of handling any base frequency - including variable base frequencies - up to 800 Hz!
|
|
Offering a new approach to energy-related measurement such as energy conservation, ISO14001 testing, equipment diagnosis, and harmonics measurement, to support programs !
Measure up to two 3-phase, 3-wire systems
Measure up to four single-phase, 2-wire systems
5A to 5000A range, PC card data storage
Power recording for individual waveforms
Simultaneous recording of demand values and harmonics
D/A output with 3169-21
|
|
The MC660 / MC666 network analyzer is used for permanent analysis of electricity supply quality in compliance with the SIST EN 50160 standard. Reports are stored in the internal memory for the period of the last 7 years.
Moreover, more than 170,000 deviations of the measurements from the standard values are stored, which enables finding eventual reasons for the problems in network. Optional limits and required quality in a monitored period can be defined for each monitored characteristic.
The following characteristics are measured and recorded:
- Frequency deviations
- Voltage deviations
- Voltage dips
- Voltage interruptions
- Voltage unbalances
- Over-voltages
- Fast voltage changes
- Flicker intensity
THD
Harmonics
|
|
* The price of a low cost instrument, the features and performance of a middle class instrument, the weight and form of portable instrument.
* Addresses the entire market for design, production, service and installation.
* Universal RF analysis. The most important instruments in one box;
o bidirectional 2-port vector network analyzer to characterize all 4 S-parameters,
o optional spectrum analyzer,
o optional power meter (with an R&S NRP power sensor)
* Fully portable; weighs less than 7 kg, optional battery power
* Frequency ranges from 9 kHz to 3 GHz / 6 GHz
|
|
Not only the reliability of supply, but also the quality of electrical power is of prime importance for the smooth operation of hightechnology plants in the areas of industry, medicine and electronic data processing.
For this reason power quality is increasingly being brought into play as one of a number of key price criteria. In recent times this trend has gained considerably in importance due to the liberalisation of international electricity markets.
It is therefore imperative for both energy providers and end users to monitor and log power quality constantly.
The need to record a very large number of electrical parameters exactly, simultaneously and continuously over what are sometimes very long time periods calls for an extremely sophisticated measurement technology solution.
At the same time a power quality measuring system must provide convenient, automated tools to support the user in assessing the measured parameters in relation to a wide variety of national standards.
|
|
Insulation resistance 50 V, 100 V, 250 V,
500 V, 1000 V DC
VDE 0413 part 2/EN 61557-2
Loop and line impedance, display of short
circuit current Ik
VDE 0413 part 3/EN 61557-3
Low ohm measurement with > 200 mA DC
VDE 0413 part 4/EN 61557-4
RCD testing: tripping time, tripping current,
touch leakage voltage Ub
VDE 0413 Teil 6/EN 61557-6
Measurement of earth resistance and
ground resistivity
VDE 0413 part 5/EN 61557-5
Phase sequence
VDE 0413 part 7/EN 61557-7
Additional Power Analyzer Function:
Current, Voltage
Apparent power, reactive power, active power, cos ø
Power consumption, energy
Harmonic analysis of voltages and currents
Residual voltage, voltage drops
Voltage peaks
Additional Adapter Function:
The GSC-53 is equipped with 3 analog inputs that allows measurement (with adapters) and storage of the following environmental parameters:
Temperature
Humidity
Lux
Noise and Leq (dB) Type 1
|
|
8230 with AmpFlex SR193-36 Single-Phase Power Quality Analyzers
The PowerPad® Jr. Model 8230 is a single-phase power quality analyzer that is easy-to-use, compact and shock-resistant. It is intended for technicians and engineers to measure and carry out diagnostic work and power quality work on single- or three-phase balanced load networks. Users are able to obtain instant waveforms of an electrical network’s principal characteristics, and also monitor their variation over a period of time. The multi-tasking measurement system simultaneously handles all the measurement functions and waveform display of the various magnitudes, detection, continuous recordings and their display without any constraints.
The PowerPad® Jr. Model 8230 with 36" AmpFlex® 193-36 is supplied with a black 6500A current probe
|
|
Monitor and record the quality of power to analyze the cause of trouble when it occurs !
The 3196 is your most reliable and complete instrument for power quality troubleshooting !
Measure power factor
Sags
Swells
Flicker
Transients
Harmonics to the 50th
High Frequency transient
Detection and waveform display
Four current and Four voltage channels
Let the HIOKI 3196 see what you have been missing.
|
|
Capabilities
AC current/voltage, DC voltage, Watts, VARs, Watt/VAR, Watt/Watt-hour, VAR/VAR-hour, and combination models
Standard analog mA and V outputs and fieldbus (MODBUS RTU) outputs
Measure true RMS power
Single and multi-channel models
Self- and auxiliary-powered
Alarm trip capabilities
|
|
The PX 120 is designed for use in general or technical secondary schools and by installers and industrial maintenance departments. It measures power on 3-wire balanced triple phase (T3FB) and on single phase.
Although it offers complex functions, this TRMS powermeter is very simple to operate. It has INRUSH functions for loads which draw large amounts of current and a SMOOTH function, extremely useful in unstable measurement conditions.
It is extremely readable: 14mm-digits, 999-count display capacity (4 digits) on three lines, simultaneous display of three values: voltage, current and active power or active, reactive and apparent power.
A special feature of this new wattmeter is its infrared transmission mode. The link is established using a magnetised optical head simply positioned on the front panel of the unit.
|
|
