planetary servo-gearbox / coaxial / precision / high-performance
planetary servo-gearbox
SRP series

Torque: 350 Nm - 18,590 Nm

High-tech servo-reducer combined with a preloaded split pinion output (PDP) PDP is the first range of “Preloaded Double Pinion” for high-precision rack and pinions applications. PDP is made of 2 ground ...

hypoid servo-gearbox / precision / industrial
hypoid servo-gearbox
HC Series

Torque: 2,160 Nm

planetary servo-gearbox / coaxial / precision / low-backlash
planetary servo-gearbox
PL80, 80mm

Torque: 60 Nm
Rotational speed: 3,000 rpm
Power: 0.75 kW

This is our PL series servo gearbox, the most economic but reliable model. The modular design allows engineers to select from single stage,two stages and three stages of planetary gearing to achieve ...

See the other products
Newstart Planetary Gear Boxes Co.,Ltd.
planetary servo-gearbox / coaxial / precision / low-backlash
planetary servo-gearbox
PL120 120mm

Torque: 150 Nm
Rotational speed: 3,000 rpm
Power: 1 kW

This is our PL series servo gearbox, the most economic but reliable model. The modular design allows engineers to select from single stage,two stages and three stages of planetary gearing to achieve ...

See the other products
Newstart Planetary Gear Boxes Co.,Ltd.
planetary servo-gearbox / coaxial / high-precision / low-backlash
planetary servo-gearbox
AB60

Torque: 55 Nm
Rotational speed: 4,000 rpm

AB Series is the ideal combination of precision planetary gearbox and efficient bearing technology. It has been developed specifically for delivering the maximum performance at high speeds. Its helical ...

See the other products
Newstart Planetary Gear Boxes Co.,Ltd.
helical servo-gearbox / coaxial / high-precision / low-backlash
helical servo-gearbox
AB Sereis

Torque: 15 Nm - 2,000 Nm
Rotational speed: 1 rpm - 10,000 rpm
Power: 750 kW

Newstart's value AB series gearbox family consists of in-line, NEMA, that offer exceptional torque ratings, precision cutting helical gears running more smooth in low noise. The modular concept allows ...

See the other products
Newstart Planetary Gear Boxes Co.,Ltd.
custom servo-gearbox / planetary / coaxial / precision
custom servo-gearbox

Torque: 100 Nm
Rotational speed: 6,000 rpm
Power: 1.5 kW

See the other products
Newstart Planetary Gear Boxes Co.,Ltd.
worm servo-gearbox / perpendicular / precision / high-rigidity
worm servo-gearbox
98 HT Series

Torque: 90 Nm - 1,200 Nm

... manufactured by Atlanta, and is a high-torque worm gear unit that is especially intended for utilize with the three-phase and DC servo-motors. It is available in 4 sizes in center distance of 50, 63, 80 and 100 mm, which ...

worm servo-gearbox / perpendicular / high-precision / high-rigidity
worm servo-gearbox
HP series

Torque: 60 Nm - 1,500 Nm

... manufactured by Atlanta, and is a high-performance worm gear unit that is especially intended for utilize with the three-phase and DC servo-motors. It is available in 5 sizes in center distance of 50, 63, 80, 100 and ...

worm servo-gearbox / perpendicular / high-precision / high-rigidity
worm servo-gearbox
59 E series

Torque: 15 Nm - 800 Nm

ATLANTA E-servo worm gear units have been developed especially for use with the latest three-phase and DC servomotors. The units come in 5 sizes with centre distance 32, 50, 63,80 and 100 mm. They have an output torque ...

worm servo-gearbox / perpendicular / precision / for servo motors
worm servo-gearbox
57 B series

Torque: 50 Nm - 720 Nm

The B-Servo Worm Gear Units are developed for use with three-phase and DC servomotors. The use of ground, right-hand worms, a worm gear made of worm-gear bronze and dip-feed lubrication, ensures the units’ smooth running ...

bevel servo-gearbox / hypoid / orthogonal / high-precision
bevel servo-gearbox
51 BG series

Torque: 100 Nm - 450 Nm

... available with key connection or for clamp connection. BG-Servo units are very sturdy and provide excellent precision. Their sizes and gear ratios are in accordance with the current series of servo ...

worm servo-gearbox / perpendicular / high-torque / precision
worm servo-gearbox
HT series

Torque: 165 Nm - 3,650 Nm
Rotational speed: 500 rpm - 5,000 rpm

This standard range of Servo-Worm Reducers is suitable for applications requiring high performance, positioning that is precise and repeatability. The range is also ideally suited for use with servo ...

bevel servo-gearbox / orthogonal / precision / for servo motors
bevel servo-gearbox
BG series

Torque: 99 ft.lb - 666 ft.lb
Rotational speed: 500 rpm - 5,000 rpm

ATLANTA's Bevel-Gear (BG) Servo Reducers are perfect for use in applications that demand good performance, positioning and repeatability. Typical applications for these reducers include precision rotary ...

hypoid servo-gearbox / high-precision / low-backlash / compact
hypoid servo-gearbox
RPC+ series

Torque: 1,400 Nm - 7,535 Nm
Rotational speed: 4,500 rpm

High precision and low ratios around the corner The RPC+ is primarily characterized by low gear ratios (ratio 1 and 2) in the right-angle section. Consequently, right-angle and planetary gear­head combinations can achieve ...

worm servo-gearbox / orthogonal / precision / low-backlash
worm servo-gearbox
V-Drive series

Torque: 26 Nm - 1,505 Nm
Rotational speed: 6,000 rpm

The Servo Worm Gear Head has a solid shaft, hallow shaft and hallow shaft flange outputs. It has consistently high positioning accuracy and low torsional backlash under 3arcmin. The servo worm gear head ...

planetary servo-gearbox / coaxial / high-precision / low-backlash
planetary servo-gearbox
GTM series

Torque: 0.5 Nm - 6,000 Nm
Rotational speed: 100 rpm - 10,000 rpm

The GTM model of servo gear boxes by Bosch are built with a highly precise gearing for maximum positioning accuracy. It is also designed with an enhanced gear tooth forming for reduced noise and power overuse during continuous ...

planetary servo-gearbox / coaxial / precision
planetary servo-gearbox
PPG series

Torque: 330 Nm - 550 Nm
Rotational speed: 6,000 rpm

... torque up to 330 Nm Acceleration torque up to 550 Nm Circumferential backlash < 6 arc min (optional < 3, < 1) The PPG precision planetary gear is characterized by three major design advantages: PPG load compensation ...

helical servo-gearbox / coaxial / high-precision / for servo motors
helical servo-gearbox
PS series

Torque: 27 Nm - 230 Nm
Rotational speed: 6,000 rpm

... than 3 arc minutes backlash with multiple ratios of 3:1-100:1. For reference, use Parker Mounting Kit Reference List and Gearhead Mounting Kit Search Tool. Shipping would be 3 to 5 days (standard type)

planetary servo-gearbox / perpendicular / high-precision / for servo motors
planetary servo-gearbox
RS series

Torque: 13 Nm - 220 Nm
Rotational speed: 6,000 rpm

The Stealth Gen II Gearhead "Advanced Right Angle" RS from Parker has a compact, durable design with Plasma Nitriting for a high gear wear resistance. The unit comes in 7 frame sizes and 9 gear ratios. It offers high ...

worm servo-gearbox / perpendicular / high-torque / high-precision
worm servo-gearbox
HP series

Rotational speed: 500 rpm - 3,000 rpm

As servo motor capacity increases, Cone Drive is meeting the needs of the marketplace by offering reducers capable of higher torque demands. Only in the Accudrive HP Servo will you get ...

See the other products
Cone Drive Operations, Inc.
planetary servo-gearbox / coaxial / precision / high-torque
planetary servo-gearbox
P series

Torque: 1,500 Nm - 2,400 Nm
Rotational speed: 10,000 rpm

Accudrive Series P high precision inline planetary servo drive will satisfy your most demanding automation applications. The compact design, universal housing with precision bearings ...

See the other products
Cone Drive Operations, Inc.
planetary servo-gearbox / coaxial / precision / industrial
planetary servo-gearbox
SP series

Torque: 31.53 Nm - 75.69 Nm
Rotational speed: 1,500 rpm - 5,000 rpm

All units are precision ground planetary gear sets capable of sustained servo input speed. They can be ordered by themselves, or pre-mounted to the SmartMotor™ prior to shipment. Animatics provides three ...

planetary servo-gearbox / orthogonal / precision / industrial
planetary servo-gearbox
RAP series

Torque: 53.67 Nm - 74.1 Nm
Rotational speed: 5,000 rpm

All units are precision ground planetary gear sets capable of sustained servo input speed. They can be ordered by themselves, or pre-mounted to the SmartMotor™ prior to shipment. Animatics provides three ...

planetary servo-gearbox / orthogonal / precision / compact
planetary servo-gearbox
ServoFit® PHKX series

Torque: 50 Nm - 7,500 Nm

... right-angle gear unit and a robust PH planetary output stage with oversized bearings. Highest torsional rigidity and high precision for tightest spaces. Flange output shaft acc. to ISO 9409 Gear sizes: PH3KX3 ...

See the other products
STÖBER
planetary servo-gearbox / coaxial / precision / compact
planetary servo-gearbox
ServoFit® PHV series

Torque: 7,500, 4,250 Nm

Highly stiff precision gear unit in a compact design for high Ratios (> 60) by means of a power branched gear step. Flange output shaft according to ISO 9409 Gear sizes: PHV9 – PHV10 Gear ratio range: 61 – 121 Acceleration ...

See the other products
STÖBER
planetary servo-gearbox / coaxial / precision / low-backlash
planetary servo-gearbox
GBX series

Torque: 14 Nm - 2,000 Nm

Gearboxes The GBX servo gearbox family has been designed for direct attachment to servomotors. It is a high precision low backlash servo gearbox for ...

hypoid servo-gearbox / precision / compact / transmission
hypoid servo-gearbox
HT-series

Torque: 38 Nm - 1,080 Nm

... robust design of the hypoid precision gear boxes is suitable for specific and highly dynamic applications. Our specially developed monobloc housing distinguishes this series with extreme stability and provides maximum ...

hypoid servo-gearbox / high-precision / compact / transmission
hypoid servo-gearbox
PT-series

Rotational speed: 2,000 rpm - 10,000 rpm

... BENEFITS The servo gearboxes PT complete the whole range of our servo gearboxes that consist of high-end planetary gearboxes, right angle gearboxes, hypoid gearboxes, cycloid gearboxes as well as various ...

worm servo-gearbox / orthogonal / precision / for servo motors
worm servo-gearbox
B series

Torque: 38 Nm - 198 Nm
Rotational speed: 500 rpm - 5,000 rpm

ATLANTA B-Basic Servo Worm Gear Units have been specially developed for use with the latest three-phase and DC servo-motors.The following are typical features of our B-Servo Gear Units: ...

bevel servo-gearbox / orthogonal / high-precision / high-rigidity
bevel servo-gearbox
BG series

Torque: 100 Nm - 450 Nm
Rotational speed: 500 rpm - 5,000 rpm

ATLANTA BG-Servo Bevel Gear Units have been specially developed for use with the latest three-phase and DC servo-motors.The following are typical features of our BG-Servo Gear Units: ...

cycloidal servo-gearbox / coaxial / high-precision / low-backlash
cycloidal servo-gearbox
AKIM

Torque: 80 Nm - 4,000 Nm

AKIM Servo-Two-Disc-Gears are highly dynamic cycloid gears of the highest precision. What AKIM Servogears especially characterized. • Compact construction • Adjustable backlash < 0.02° • Ratios up ...

helical servo-gearbox / coaxial / precision / combined
helical servo-gearbox
SRP

High-tech servo-reducer combined with a preloaded split pinion output (PDP) PDP is the first range of “Preloaded Double Pinion” for high-precision rack and pinions applications. PDP is made of 2 ground ...
