The EL-PRESS series digital electronic Pressure Meters and Controllers have a well-proven compact thru-flow design and are available in pressure ranges from 2-100 mbar up to 8-400 bar, both in absolute and relative (gauge) pressure. A differential pressure transducer can also be supplied in the ranges of 2-100 mbar up to 0,3-15 bar. The pressure controller performs with high accuracy and repeatability and should be specified for forward or backward pressure control. Todays EL-PRESS series are equipped with a diaphragm type piezoresistive pressure sensor and a digital pc-board as standard and offer high accuracy, stability and reliability. The basic digital pc-board contains all of the general functions needed for measurement and control. In addition to the standard RS232 output, the instruments also offer analog I/O. As an option, an integrated interface board provides DeviceNet, PROFIBUS-DP, Modbus-RTU or
FLOW-BUS protocols.
|
|
WITT Regulators for pipelines, Outlet points and High Flow Application. The design allows constant flow over the whole pressure range even with flow fluctuation on the inlet side.
Benefits
- applicable for almost technical gases
- inlet pressures up to max. 200 bar
- regulating from 100 mbar up to 60 bar
- process reliability by high pressure stability in case of withdrawal fluctuations
- high flow rate
- compact design, small mounting dimensions
- warranted high reliability by integrated inlet filter (without 737LE ND)
- integrated pilot pressure and manometer connections
- remote control by extern pilot pressure regulator or proportional valve
- several gas supply can be central regulated to the same working pressure
|
|
|
The Type-700BP Back Pressure Regulator is a high flow, highly accurate pneumatic relief valve with an adjustable set point. It's primary function is to provide protection against over pressurization in the downstream portion of a pneumatic system. This precision unit is capable of handling flows up to 50 SCFM. A rolling diaphragm provides the sensitivity that causes the Type-700BP to vent to atmosphere in response to the slightest upstream changes.
|
|
26-1700 Series: Versatile
Extremely sensitive
Ideal for both gas & liquid service
High temperature versions available
Accuracy: ±1% of relief pressure range
26-2300 Series: High Accuracy
Precise pressure control
Diaphragm sensed - highly sensitive
Crack to reseat: 2% of set pressure
Bubble-tight shutoff at all reseating pressures
26-2500 Series: High Flow
Large diaphragm for excellent sensitivity
Bubble-tight shutoff at all reseating pressures
1/2", 3/4" and 1" NPT inlet and outlet port sizes
26-2900 Series: Tracking
High Flow
Negative spring bias
Designed for BIBS application
Diaphragm sensed - highly sensitive
44-2300 Series: Economical
Hand adjustable
Diaphragm sensed
Dome loaded
Four relief pressure ranges
44-4700 Series: Sub-atmospheric
Metal to metal diaphragm assures minimum inboard/outboard leakage
Controls sub-atmospheric to positive pressures
High flow capacity
Negative spring bias
|
|
|
The Type 350/360/370SS series of stainless steel regulators, filter regulators and filters are designed to stand up to the harshest environments while providing highly accurate pressure regulation. Proven 316 stainless steel housing and filter assemblies along with fluorocarbon diaphragm construction make the 350/360/370SS compatible with sour gas and adaptable to off shore environments. This quality instrument is economical to buy as well as operate, and provides extremely stable and repeatable control of gas pressure. Oversized valving helps the unit achieve high flow rates with minimal pressure drop.
|
|
44-2200 Series: General Purpose/Compact-Reducing
1/4" inlet and outlet ports
Diaphragm sensed - highly sensitive
Various trim options available
44-2600 Series: General Purpose/Large Diaphragm
Increased sensitivity, minimal droop
Repeatability: ±1/2% of outlet pressure range
Accuracy: ±1% of outlet pressure
44-2800 Series: Accurate/Positive Seal-Reducing
Mechanical link between diaphragm & main valve prevents pressure creep
Positionable captured vent bonnet
44-3400 Series: Two Stage-Reducing
Decaying inlet characteristic: .04 per 100 PSIG inlet pressure change
Various trim options available
|
|
Pneumatic Controller
With more than one million BARTON DPU-based instruments in service around the world today, Cameron's Measurement Systems division is a premier supplier of reliable and accurate chart recorders, indicators, switches and pneumatic controllers. Originally developed in the early 1920s, our differential pressure technology features a welded bellows assembly that increases accuracy while dramatically reducing the effects of wear. To facilitate quick and easy repairs all DPU based instruments are supported with pre-calibrated exchange or repaired sub-module bellows assemblies.
|
|
26-1100 Series: High Flow Cv=1.3 or .46 - Reducing
Diaphragm sensed - highly sensitive
Modular construction - easy service
External sensing available for improved accuracy
Balanced main valve increases seat life
26-1200 Series: High Flow Cv=3.3 - Reducing
Similar to 26-1100 with higher flow capacity
44-4200 Series: Economical
Dome loaded
Piston sensed - highly reliable
Compatible with TESCOM electronic pressure controllers
|
|
The Type-9OOX l/P, E/P transducers are a series of compact electronic pressure regulators that convert an electrical signal (current or voltage) to a proportional pneumatic output. Utilizing internal solid-state feedback circuitry, the Type-9OOX provides precise, stable pressure outputs to final control elements. Immunity to the effects of vibration or mounting position, high tolerance to impure air, and low air consumption make this unit ideal for use in demanding applications.
The heart of this unique technology is a bimorph piezo actuator that is encapsulated in a protective skin. This protective skin provides defense against the humidity and contaminants often found in process operating environments.
|
|
|
The Type-550X is an electronic pressure regulator that converts a variable signal (current or voltage) to a proportional pneumatic output. Its compact housing, accessible ports and easy adjustments provide an ideal answer to applications that are space-constrained. This economical instrument provides precision air pressure regulation to actuators, valves, positioners and other final control elements. An integral volume booster provides high flow capacity, increasing control speed in critical applications.
|
|
|
|
|
|
VAV control, 90° quarter turn actuators and differential sensors, explosion proof
Electrical, explosion proof quarter turn actuators series ExMax and RedMax, for VAV dampers, from 5 Nm to 100 Nm, in acc. with ATEX 94/9/EC for installation in hazardous areas zone 1, 2, 21 and 22, for all kind of gas, vapours, mixtures and dust. Actuators with or without fail safe spring return function. 24 to 230 VAC/DC multivoltage supply, 5 motor running times adjustable on site, on-off, 3-pos, 0...10 VDC, 4...20 mA mode, 100 % overload protected. Robust aluminium housing with IP 66 protection, optional stainless steel version, integrated heater for use from -40°C to +40°C/+50°C, cable connection, approx. 1 m cable, manual override, squared shaft connection 12 × 12 mm (size S) and 16 × 16 mm (size M). Series ExMax-... for use in zone 1, 2, 21 and 22. Series RedMax-... for use in zone 2 and 22. Optional accessories like external adaptable aux. switches, terminal boxes and mounting brackets available.
Differentail pressure sensor series ExCos-P and RedCos-P, in acc. with ATEX 94/9/EC for installation in hazardous areas zone 1, 2, 21 and 22, for all kind of gas, vapours, mixtures and dust. 24 VAC/DC supply, measuring ranges +/- 100 Pa, +/- 250 Pa,+/- 600 Pa,+/- 1250 Pa,+/- 2500 Pa,+/- 5000 Pa, +/- 7500 Pa. Series ExCos-P for use in zone 1, 2, 21, 22. Series RedCos-P for use in zone 2, 22.
|
|
20-1000 Series: Compressed Natural Gas
Balanced main valve minimizes inlet pressure fluctuations
Piston sensed – highly reliable
Water heat jacket standard
20-1200 Series: High Pressure Hydrogen
Nickel-plated aluminum
Large piston sensor
All regulators tamper-proof
20-1400 Series: High Flow / Low Pressure
Diaphragm sensed – highly sensitive
Dome load spring bias ± 2 PSIG
Captured bonnet design for safety
44-6000 Series: In-Line High Pressure
Balanced main valve design
Positive shutoff seal
Captured bonnet available
Patent pending
44-7400 Series: Pressure Reducing
Ideal for CNG dispensing applications
Several porting configurations available
Spring adjust, high outlet, high flow
|
|
|
|
|
|
The gas pressure regulators (RTP) are designed to reduce natural gas pressure from medium to low one, and to keep the gas pressure rate independent on input pressure and flow changes. The regulators are suitable for domestic as well as for industrial installations.
Description
Single stage
Single stage gas pressure regulators have diaphragm - spring single stage pressure regulator with the lever system control element.
Double stage
Double-stage gas pressure regulators have two stages of pressure reduction, both with diaphragm-spring control.
The RTP gas pressure regulators are equipped with the following safety devices:
* The over-pressure and under-pressure shut-off
* The relief valve
Our regulators meet requirements of standard EN 12 279
We are producing various versions and sizes, as an example we are presenting double stage regulator
RTP 10-M..-..
Technical data
Inlet pressure: 0,1 - 0,5 [MPa]
Adjusted output pressure: 2 [kPa]
Regulation deviation: ¡À0,1 [kPa]
Outlet pressure at no consumption: max 2,6 [kPa]
Safety pressure: 3 - 0,1 [kPa]
O.P.S.O.: 4,5 [kPa]
U.P.S.O.: 1 [kPa]
Volumetric flow: 10 [m3/h]
Volumetric flow: 10 [m3/h]
Relief valve size: Rp 3/8 [inch]
Weight: 1,12 [kg]
Ambient temperature range: -30 to +60 [¡ãC]
Response time: ¡Ü 5 [s]
|
|
R230
high sensitivity
many options and pressure ranges, G1/4
outlet 0 - 0.15 / 28 bar, 900 l/min
|
|
|
The Type 700 is designed for applications that require high flow capacity and accurate process control. A poppet valve which is balanced by utilizing a rolling diaphragm insures a constant output pressure even during wide supply pressure variations. Stability of regulated pressure is maintained under varying flow conditions through the use of an aspirator tube which adjusts the air supply in accordance with the flow velocity.
|
|
44-2600 Series: General Purpose/Large Diaphragm
Increased sensitivity, minimal droop
Repeatability: ±1/2% of outlet pressure range
Accuracy: ±1% of outlet pressure
44-3200 Series: High Flow/Purge
Ideal purge regulator
High pressure inlet version incorporates a balanced main valve to minimize inlet pressure fluctuation
26-1500 Series: Sensitive/Non Venting-Reducing
Compact design
Elastomeric diaphragm - highly sensitive
Dome loading available
For liquid or gas service
26-1600 Series: Sensitive/Self Venting-Reducing
Elastomeric diaphragm - highly sensitive
Controls up to 500 PSIG
Dome loading available
For liquid or gas service
Works with TESCOM motorized actuator for remote control
DH Series: Low Pressure
Diaphragm sensed - highly sensitive
Excellent repeatability
Very high flows at low pressures
DK Series: Improves sensing, control & resolution at medium flows & pressures
Diaphragm sensed
Captured & segregated vent
Remote controlled
High flow capacity
Dome and air load available
|
|
54-2100 Series: High Pressure-Back Pressure
Accuracy: ±1% of pressure range
Hardened metal to metal seats for heavy duty service
Eight pressure ranges up to 15,000 PSIG
54-2300 Series: High Flow/High Pressure-Back Pressure
Control pressures to 10,000 PSIG
Flow capacity: Cv = 1.6
Excellent crack to reseat ratio
Hardened metal to metal seats for heavy duty service
54-2700 Series: High Flow/Back Pressure
Flow capacity: Cv = 5.0
Choice of dome loaded, spring loaded, or air ratio device
|
|
54-2000 Series: Low Flow/High Pressure-Reducing
Rugged design, high pressure service
Hardened metal to metal seats for heavy duty service
System pressures to 20,000 PSIG
Captured venting standard
54-2200 Series: Medium Flow/High Pressure-Reducing
High flow capacity: Cv = 2.0
Hardened metal to metal seats for heavy duty service
Self-venting is standard
54-2800 Series: High Flow/High Pressure-Reducing
Flow capacity: Cv = 8.0
Inlet & outlet pressures up to 5,000 PSIG
Choice of air ratio or dome loading
Hardened metal to metal seats for heavy duty service
26-2000 Series: High Pressure Reducing
Designed for both hydraulic and pneumatic service
Captured vent standard
Designed for heavy duty shock and vibration service
Choice of metal to metal or soft seat
Compatible with TESCOM Electronic Controllers
|
|
Pressure relief valves and pressure reducing valves
Flange-, sandwich- and screw-in cartridge construction
Nominal sizes NG3-Mini, NG4-Mini, NG6 and NG10
Screw-in cartridges in accordance with ISO 7789, nominal sizes M18x1,5, M22x1,5 and M33x2
Manual valves
Proportional valves
Maximum pressures up to 350 bar
Volume flows up to 100 l/min
|
|
R160
for various media
supply max. 6 bar, G1/2 - G2
outlet 18 - 70 / 3000 mbar, 8000 l/min
|
|
Features
* Very low pressure output ranges
* Excellent set point stability
* Adjustable DC motor speed
* Output pressure locks in last position in event of power failure.
* Standard commercial enclosure or Explosion-proof NEMA 4X housing
* End of travel limit switches
|
|
DOPAG material pressure regulators (MPR) reduce the pressure of the incoming material to the optimum operating pressure.
As well as accurately regulating material pressure, these valves will also compensate for pulsations that occur as a result of the reciprocating action of piston pumps.
|
|
|
|
|
|
Beswick Engineering’s "PCFCD" Pressure Compensated Flow Control Valve was selected as the Best Product Winner, in the Motion Control category, of Design News magazine’s 2008 Golden Mousetrap Awards. This accolade was just announced to the public in the September 22nd, 2008 issue of Design News.
The PCFCD-1N1 is designed to maintain a constant flow rate, which the customer can adjust, regardless of upstream or downstream pressure variations. It works with both liquids (incompressible fluids) and gasses (compressible fluids) but is primarily intended for the control of liquids. The pressure regulation is accomplished with a low friction diaphragm mechanism. Beswick has applied for patent protection on this unique valve.
The PCFCD-1N1 sets an industry standard for miniaturization. It is lightweight….tipping the scales at only 48 grams. Customers will find it particularly useful when space, weight, and precise liquid flow control are critical.
The PCFCD-1N1 controls flow rates of 0 to 4.2 gallons per hour of Water (0 to 20 cubic feet/hour of Air). It is especially suited for the control of low flow rates. The maximum rated inlet supply pressure is 500 psig. Both the inlet and outlet ports are tapped 10-32. The valve body is both small and lightweight allowing for convenient in-line mounting without the need for a panel mount thread. The PCFCD-1N1 is currently available in brass. Buna-N is the standard seal material. Fluorocarbon (Vitonâ) is optional.
|
|
12 Series: Miniature Pressure Reducing Regulator
Product of choice for state of the art OEM gas systems. 10 Ra or 5 Ra microinch surface finish. Available in VCR, tube stubs or surface mount, "C" or "W" seal.
|
|
|
The Type-800 is a compact air regulator that supplies precise air pressure control for applications where space is limited. This high quality unit, available in five pressure ranges up to 100 psig (700 kPa), offers the same dependable performance as ControlAir's larger precision air pressure regulators. An oversized supply valve provides the Type 800 with significantly higher flow capacities than competitive units of similar size. The Type 800 is also available with a variety of convenient port sizes and mounting options. Corrosion resistant materials, lightweight construction and low cost, combine to make the Type 800 ideal for any application where space is at a premium.
|
|
|
|
|
|
PRD - Single-Stage Diaphragm Pressure Regulator
Description: The PRD-ANB-C-DEF regulator sets an industry standard for miniaturization as well as lightweight. It is an excellent choice for gas and pneumatic pressure regulation applications and is particularly useful when space and weight are critical. The PRD-ANB-C-DEF weighs approx. 25 grams in brass & stainless steel and about 15 grams in aluminum. The PRD-ANB-C-DEF non-relieving regulator controls output pressures from 0 to 30 psig and is especially suited to low pressure regulation such as ½ psig. Maximum inlet supply pressure is 500 psig. Both the inlet and outlet ports are tapped 10-32 UNF. Its lightweight design allows convenient in-line mounting however a 10-32 threaded panel mount option is also offered. Applications include hydrogen fuel cells, medical equipment, instruments, laboratory equipment, ink jet print engines, and semiconductor manufacturing equipment.
Material: Brass, aluminum, 303 & 316 stainless steel.
Seals: Buna-N. Optional materials: EPDM and Viton®.
|
|
|
|
|
|
Description: The new PRD2 –ANB-C-DEF two-stage nonrelieving diaphragm regulator sets an industry standard for both miniaturization and light weight. It weighs approx. 50 grams in brass and stainless steel, and about 23 grams in aluminum. It accurately reduces high-pressure inputs (up to 500 psi) down to 0 to 20 psi (and is especially suited to low pressure regulation such as ½ psi.) with minimal droop or rise even with wide swings in inlet pressure. The Beswick two-stage diaphragm regulator is an excellent choice if the inlet pressure will decay over time such as with hydrogen storage tanks commonly used in hydrogen fuel cell applications. Both the inlet and outlet ports are tapped M3. Its lightweight design allows convenient in-line mounting however a 10-32 threaded panel mount option is also offered.
Beswick Engineering designs and manufactures high-performance miniature fluid power components, such as: fittings, valves, quick disconnects, pressure regulators/gauges, cylinders, filters, orifices, shock absorbers, pressure electric switches, tubing, etc. Applications include: medical and dental equipment, instruments, laboratory equipment, semiconductor manufacturing equipment, aerospace equipment, packaging machinery, industrial robots and many more.
|
|
The modular subminiature precision pressure regulators are ideal for instrumentation, medical and industrial applications. They provide the ultimate in regulation of pressure and feature excellent repeatability, a sensitive 20 turn adjustment and miniature size.
Balancing of the valve seat gives an output that is virtually unaffected by changes in supply pressure. Only 0.1 PSI output change with a 10 PSI supply change.
|
|
R119J
high-duty and low-cost
0.2 - 18 bar, ratio 1:1
G1/4 - G2 1/2, 44 000 l/min
|
|
Pressure Regulator
Sizes Available: Miniature Series 1/8", 1/4" NPT, Compact Series 1/4", 3/8", 1/2" NPT, Large Series 1", 1-1/2" NPT
Relieving diaphragm air pressure regulator reduces system pressure to level.
Includes a non-rising plastic knob adjustment.
Maximum Inlet Pressure: Miniature 250 psig, Compact 300 psig, Large 300 psig
Regulated Secondary Outlet Pressure Ranges: Miniature: 5 to 50 psig and 10 to 100 psig; Compact: 6 to 60 psig, 12 to 125 psig, 15-150 psig; Large: 5 to 50 psig and 15 to 150 psig.
|
|
|
|
