The ifm pressure sensors are based on a ceramic measuring pressure cell which converts the measured quantity of pressure into a capacitive signal as a result of the deflection of a diaphragm. A microprocessor controls the evaluation of the electrical signal. For the efector 500 the system pressure is directly indicated on the unit by an LED display.
|
|
From low price to high tech
Our pressure and differential pressure measurement systems in gases, vapors and liquids have been successful in the market for 15 years.
A wide variety of products are available; depending on process conditions you can choose ceramic or metal sensors.
|
|
|
|
|
|
The differential pressure transmitters of the 985M series are used for measuring differential pressure, positive pressure and vacuum.
They offer 2 pressure ranges which can alternatively be selected by a jumper. The IP65 body protects the pressure transducer even in difficult environments.
Monitoring gaseous, non-aggressive media. Possible areas of application are:
air-conditioning and clean rooms
building automation
environmental protection
fan and blower control
valve and flap control
filter and blower monitoring
fluid and level monitoring
control of air flows
For optimum adaptation to the pressure application, the
transmitter can be switched between two pressure ranges.
The factory setting is the sensitive range 1, which is selected
by fitting a jumper. Removing the jumper activates the
non-sensitive range 2.
The output signal of the 3-wire version is configurable. The
factory setting is for a 0 ...10 Volt output signal, but this can be
changed to 4 ... 20 mA by removing the jumper. The 2-wire
version is only available with a 4 ... 20 mA output signal.
|
|
The 984M differential pressure measuring transmitters cover a pressure range from 0...100 Pa to max. 0...250 kPa. To ensure optimum adjustment to the respective pressure-related application, the models are equipped with multiple jumpers.
A new feature is the selectable output signal of 0…10 Volt or 4…20mA, which the user himself can set by means of a jumper on site during the installation.
The new model can also be automatically zeroed quite easily by the user himself. This is done by simply disconnecting the measuring transmitter from the pressure and pressing a button.
The ability to select between two different pressure ranges is already known from the previous model. Version 984M.323104b, for example, allows the user to select between the pressure ranges 0...250 and 0...500 Pascal.
A key advantage offered by the 984M.3x3114b model is the option of equipping it with a 3.5-digit LED display, whose brightly illuminated red figures can also be easily read in difficult conditions.
|
|
DPT Flow provides a new and easy way of measuring a flow rate of a centrifugal fan.
DPT Flow is designed for centrifugal fans, and the flow rate is based on differential pressure value measured directly from the fan.
DPT Flow can be used to display the flow value on-site and to send the out-put value to control system.
|
|
• Ranges from 0/+100 Pa to -2000 mbar/+2000 mbar (according to model)
• Configurable intermediate and centre zero ranges
• Air velocity and airflow functions (optional)
• Simultaneous display of 2 parameters
• 2 outputs 4-20 mA or 0-10 V (4 wires), RS 232, 2 RCR relays 6 A / 230 Vac
• 2 visual (dual color LED) and audible (buzzer) alarms
• Output diagnostics
• ABS IP 65 housing, with or without 2-line backlit display
• Quick and easy mounting using the “1/4 turn” system with wall-mounting plate
Join our distribution network all over the word....Contact us !
|
|
PS 27
Basic sensor for simple applications - mounting on top-hat rails,
very little hysteresis, contact points, IP65 protection class.
The PS 27 differential pressure transducer is a basic sensor for simple applications with very little hysteresis, temperature dependence or zero-point drift.
In addition to differential pressure data, the PS 27 also records positive and negative overpressures, and is suitable for measuring air and all non-aggressive gases. Zero-point calibration can be performed via an external control signal. A jumper is available for selecting the output signal.
A built-in adapter for top-hat rails allows the PS 27 to be mounted on top-hat rails (e.g., in a control cabinet) with no additional accessories required. With the optional switching output, a visual or audible alarm can be triggered whenever values fall above or below a threshold parameter. The PS 27 is a simple, precise pressure transducer for applicati
|
|
|
|
|
|
PUC 24 Process monitoring device for clean rooms
Sensitive measurement technology
Demands for increased quality in nearly every area of industry have led to more and more processes being conducted under clean-room conditions. Ensuring these conditions means monitoring room pressure, temperature and humidity. The new PUC 24 process monitoring device from halstrup-walcher has been specially designed for just such applications.
In essence, the PUC 24 is a differential pressure transducer that utilizes an inductive measurement principle to provide very high resolution of 0.1 Pa at a retest precision of 0.1%. Cyclical self-calibration of the zero point ensures proper measurement stability. The measurement range of ±100 Pa is freely scalable. Also available are inputs for temperature and humidity sensors; these can be set from 0-10 V or from 0/4-20 mA. All measurement values can be clearly read on a graphic LCD. Additional contact outputs are available for separate alarm signals. The device communicates with the master control module via a Profibus. The housing designed for front-flush installation is particularly innovative. Function keys are integrated into a stainless-steel keypad that forms a single smooth surface along the front of the housing. A mounting frame put in place when setting up the clean room makes the PUC 24 easier to install – four screws are all you need. This solution is the product of practical experience and simplifies more than just installation: the simple mounting system makes it possible to remove units quickly and effortlessly for calibration purposes or when switching units to accommodate changes in the process.
|
|
VEGABAR series 60 pressure transmitters are developed for pressure as well as level applications. Their universal use is characterised by a user-optimised housing concept, resistant instruments and high accuracy. The suspension pressure transmitter VEGAWELL 72 with the proven and versatile technology is the completion for all standard applications.
The heart of VEGABAR 60 series and VEGAWELL is the CERTEC® measuring cell of sapphire ceramic® developed and manufactured by VEGA. For higher temperatures and/or aggressive products, the metal METEC® measuring cell, also developed by VEGA, is available for series 60 transmitters.
Advantages
- High accurate measuring system
- Temperatures up to +250°C
- Optimised versions for hygienic applications
Applications
- Level measurement of liquids
|
|
Hydrostatic pressure cell for liquids in the range of 0.1 to 100 MPa.
This new product is used for studying samples in the pressure range between 1 and 1000 bar (0.1 and 100 Mpa). Measuring phase transitions of lipids or a sample's structural changes under differing pressures are only a few examples where the HP-Cell will bring interesting results.
|
|
|
|
|
|
Measuring range : from 0/+10 Pa to -10 000/+10 000 Pa
Configurable intermediary and central zero ranges
Air velocity and airflow functions
Interchangeable measuring sensor (SPI technology)
Simultaneous display of 1 to 4 parameters
External transmitter unputs (KIMO class 200 and 300) and thermocouple K
2 output 4-20 mA or 0-10 V (4 wires), RS 232, 2 RCR relays 6A/230 Vac
2 visual (dual color LED) and audible (buzzer) alarms
Software, keypad or remote control configuration
MODBUS network RS 485 system (optional)
ABS or ALU IP 65 housing, with or without backlit gaphic display
Mounting with the 1/4 turn system with wall-mount plate
CP301 : -100/+100 Pa (resolution : 0.1 Pa)
CP302 : -500/+500 Pa
CP303 : -1000/+1000 mbar
CP304 : -10 000/+10 000 mbar
• Barbed fittings Ø 5,2 mm
• Unit of measurement : Pa, mmH2O, mbar, inWG, mmHG
• Power supply : 24 Vac /Vdc, 115 Vac or 230 Vac
• Outputs : 2 x 4-20 mA or 2 x 0-10 V
• Functions : pressure, air velocity, airflow with Pitot tubes, Debimo and other coefficients, integration of measure, self-calibration, measuring correction factor, temperature compensation : manual or automatic (thermocouple K input).
Join our distribution network all over the word....Contact us !
|
|
|
|
|
|
ComfortSense
Thermal comfort measurement according to EN 13182, ISO 7736 and ASHRAE standard 113
Dantec Dynamics’ ComfortSense system is designed for research and development of heating and air conditioning systems requiring multi-point measurements of air velocity and temperature. Draught measurements require omnidirectional sensors with a frequency response of at least 2 Hz, which is fulfilled by the present system.
ComfortSense elements
The ComfortSense system consists of a main frame with anemometer circuits for up to 16 probes. The omnidirectional probes measure both air velocity and temperature. Six frames can be connected so that up to 96 probes can be monitored simultaneously. The ComfortSense main frame has a built-in A/D converter with USB 2.0 interface.
Easy-to-use
It is easy for the user to setup a measurement sequence and make a measurement grid with selection of probes from a user library. The software delivers statistical results based on user-defined measurement cycles. The ruggedly designed probes and cables are perfectly suited for large test rooms.
|
|
Piezo-resistive OEM pressure cells (40.4410)
The pressure cell is used to measure pressures in liquids and gases. The parts in contact with the medium are in stainless steel.
The measured pressure is converted into a proportional voltage.
Further information on request
|
|
|
|
|
|
Piezo-resistive Pressure Sensor DS-1-A-400 fluid-Check®
for oil and water devices
Installation ONLY 3 Minutes, with the help of the measuring connection SERVCLIP (NO NEED TO CUT PIPES) www.servclip.com
DS-1-A-400-1/4" combinable with serv-Clip® Type 1
(for mounting on pressurized pipes)
DS-1-A-400-3/8" combinable with serv-Clip® Type 2
(for mounting on non-pressurized pipes)
Description
In addition to its robust and compact design, this sensor stands out by its high accuracy and its extensive measurement range. As a standard, the housing and all parts exposed to the liquid are made of stainless steel (Type 1.4571). The standard connection is G1/4“, with soft seals made of Viton (up to 200°C).
With the measuring connection serv Clip® type 1 or 2 (for mounting on pressurized pipes and on non-pressurized pipes) you can install other SENSORS like (Temperature, Flow rate, Leakage, Water), MANOMETERS, PARTICLE COUNTERS and more (DIN Norms). SERVCLIP can only used for HYDRAULIC OIL (no water).
Technical data
- Pressure range 0 ... 400 bar
- Output signal 4 ... 20 mA / 2 wires
- Operating temperature –20 ... 80°C
- Protection mode IP 65
- Right-angle plug connection DIN 43650 A
- Robust stainless steel housing
- Fully encased sensor element made of stainless steel
|
|
All-Fluid Sensor
Universal pressure sensor SDET for monitoring a wide range of gaseous and liquid media
Flexibility: pressure monitoring for a wide range of media, resistant to water and oil
Stable stainless steel housing, media-resistant fluoro-rubber sealing ring and ceramic sensor based on thick-film technology
Fast installation, thanks to standard interfaces and easy linking of the mounting attachments
|
|
Honeywell manufactures a complete selection of gauge, true gauge, absolute, differential, vacuum, and barometric pressure sensors. Constructed from stainless steel and fully welded, these rugged units deliver accuracy to 0.05% over ranges from 10 inches of water to 200,000 psi. Amplified, unamplified and digital outputs are offered, as well as a variety of pressure ports and electrical connections. Custom engineering and design solutions available.
Contact us for a copy of our Sensors for Test and Measurement catalog.
|
|
|
|
|
|
SSI Technologies Inc. a leading OEM supplier of automotive sensors - having delivered more than 100 million to its customers offers pressure sensors with a wide variety of standard connector options. The pressure sensors have electrical output in the following forms - millivolt (MediaNugget Family), voltage and 4-20 mA (MediaSensor Family).
The MediaNugget family is targeted at industrial and commercial applications where cost, size and performance are critical. This family of micro-machined, absolute pressure sensors have an all laser-welded stainless steel design for optimum media isolation for use with both harsh and benign media.
MediaNugget sensors are designed for operation in the range from -40 degrees C to +105 degrees C and offer superior stability and thermal performance, based on their original design for automotive applications.
The MediaNugget absolute pressure sensors come without signal conditioning and represents a significant cost savings over currently available pressure sensors for low-cost OEM applications
The MediaSensor family of Absolute Pressure Sensors, Gage and Sealed Gage Pressure Transducers and Transmitters are for both harsh and benign media with superior accuracy of <+/-.5% from -40 degrees C to 105 degrees C.
The MediaSensors includes internal signal conditioning for calibration and temperature compensation. These compact, cost competitive transducers measure pressure from 15 psia to 3,000 psia and are well suited for a variety of automotive, industrial and commercial applications.
|
|
Sensortechnics is a leading manufacturer and distributor of a wide range of sensors and fluid control devices. The product portfolio includes basic pressure sensors, rugged transmitters, submersible level sensors and customised pressure sensing systems from 1 mbar up to 1000 bar as well as liquid level sensors and switches, flow, oxygen and force sensors. Additionally, Sensortechnics offers ultrasonic air bubble, air-in-line, liquid level and fluid monitoring detectors. Fluid control devices include miniature solenoid valves, diaphragm pumps and electronic pressure controllers.
Sensortechnics has more than 25 years of experience in providing highly customised sensing products and in the development of complex integrated fluid control systems for OEM customers worldwide.
|
|
|
|
|
|
Measurement Specialties’ surface mounted device (SMD) pressure sensors are intended for high volume applications where small size, light weight, and low cost are needed. These pressure sensors are offered in a plastic tube, or metal ring with an optional gel fill. Uncompensated mV, 16-bit digital, and room calibration outputs are available.
Pressure Sensor - Model 1471
Description: The Model 1471 is a piezoresistive silicon pressure sensor, calibrated at room temperature. Packaged in a surface mount configuration, it is intended for high volume applications where small size, light weight, low cost, and compatibility with automated assembly equipment are required. The pressure sensor is available with a gage or absolute pressure sensing chip that is attached to a surface mountable ceramic substrate. A cap is attached to the ceramic substrate, protecting the chip and providing the pressure port. The devices are shipped in plastic antistatic shipping tubes for use with automated production equipment. Caps are also available with a narrow hole or a large hole to interface with the pressure media.
|
|
The diaphragm-free piezoelectric sensor. Unisens technology allows an easy configuration of the measuring systems. The sensor Type 6157BC... is a coated variation of the sensor Type 6157BA... .
Applications
Suitable for thermoplastics, thermoset materials, elastomers LSR at a pressure of more than 200 bar.
|
|
|
|
|
|
Kavlico’s P265 pressure transducer has a rugged, 316 stainless steel housing. The robust design utilizes a ceramic diaphragm assembly that can withstand exposure to a wide array of compatible liquid and gaseous process media.
Specifically designed for pressure measurements of 0 – 15 through 0 – 1,000 PSI, the P265 is excited by 5 Vdc and provides a linear amplified output of 0.5 through 4.5 Vdc that is proportional to pressure. The sensor has low power consumption, superior long-term stability, and excellent repeatability and hysteresis. Other features include over-voltage, reverse polarity, and short circuit protection.
The excellent shock and vibration tolerance of the P265 makes it an ideal fit for applications such as steam sterilizers, natural gas pressure, CNG and propane engines, marine, agricultural chemical equipment, refrigeration and HVAC systems, hydraulic systems, diesel and gasoline engines, coolant pressures, industrial compressors, and a variety of other industrial applications.
The model P265 pressure transducer is available in many standard off-the-shelf configurations or it can be custom designed to fit your OEM specific application.
|
|
0–15psi to 0–500psi Zinc–plated carbon steel housing Weatherproof integral electrical connector Absolute, gage, and sealed gage options Low total error; ±1.5% full–scale accuracy (-20°C to 85°C) Wide operating temperature range (-40°C to 135°C) Weathertight connector
Small size EMI Protected to 100V/m Low cost solution Wide range of applications Rugged and reliable Several mounting options
High reliability in noisy environments
|
|
165855 Cylinder Pressure Transducer
Intended specifically for use with the Bently Nevada 3500/77M Recip Cylinder Pressure Monitor when real-time, continuous monitoring of cylinder performance is required on reciprocating compressors. It is able to withstand the extreme temperatures and pressure cycling of reciprocating compressor cylinders while providing reliable measurements. It also incorporates innovative materials and construction techniques that allow it to survive in the harsh chemical environments typically encountered in reciprocating compressor applications, such as hydrogen sulfide (H2S). The transducer has undergone extensive testing and is unique in the industry, carrying a 3-year warranty. It is available with a number of adapters, allowing it to be used with many existing pressure indicator valves (e.g., Kiene* valves).
|
|
The mature model P2000 is based on Kavlico's ceramic capacitive technology. It can endure high vibration and broad temperature ranges while withstanding high over-pressures and pressure pulsations without damage or degradation. The P2000 package has a built-in Metri-Pack 150 electrical connector.
Kavlico recommends the newly released P4055/P4056 be used in the place of the P2000 for applications that are not subject to significant overpressure spikes. It supports a similar pressure range and has the added benefit of RoHS and CE compliance. Please contact the factory for information on the P2000.
|
|
|
|
|
|
MSI sensor interface IC
The MSI integrated interface IC is a multi-channel Sensor interface IC. It generates dynamically to a maximum of 3 Sensor signals by means of current- and voltage- controlled resistance bridges (among other things switch- selectable input sensitivity) and provides subse-quent evaluation systems with A/D- converted signals via digital interface.
Furthermore, the IC enables the equalization of temperature due to an on Chip integrated temperature measurement or loadable reference charts. As well it supplies connected Sensors also with power supply. The IC in particular distinguishes itself besides the on Chip integrated functionality by a high signal solution in the case of simultaneous stability as well as a low power consumption.
The IC is suitable for evaluation of differential Sensor signals, as those that are supplied by pressure Sensors, Hall Sensors and Sensors, that work according to the principle of a resistance bridge (e.g. extension bridges, Piezo or Magneto-resistive Sensors).
|
|
|
|
|
|
Kavlico P992 and P993 Low Range Differential Pressure Sensors are ideal for Variable Air Volume (VAV) systems, filter pressure monitoring, duct air flow, static pressure monitoring, gaseous leak detection, pneumatic controls, and medical equipment applications. Supplied by a regulated 5 Vdc power supply, the P992 and P993 provide an amplified linear output proportional to differential pressure.
The P992 replaces existing Kavlico models P582, P592, P593, P792, and P892 and can be ordered in any configuration to match those footprints. For many years, those Kavlico products have set the industry standard for low range differential pressure measurements for a wide variety of HVAC applications. Additionally, the P992 and P993 can be specified for PCB mounting with a small footprint. The P993 is specifically configured for control systems that are integrated into damper actuators.
Features:
* Low Power Consumption
* Amplified Output
* Frequency Output Option
* Temperature Compensated
* Multiple Mounting Options
* PC Board Mount
* P592/P593 & P792/P892 Footprint Compatible
* Pressure Ranges from +/-1" H20 through 10" H20
* No Position Sensitivity
* Superior Output Signal Stability
* EMI/RFI & ESD Protection
* Made in USA
* RoHS Compliant
|
|
Honeywell manufactures a wide range of wet/wet and wet/dry differential pressure sensors. Rugged stainless steel construction with mechanical overload stops can handle the most demanding applications. These units cover ranges from 0.5 psid to 10,000 psid and deliver accuracies up to 0.1%. Outputs include 4-20mA, 0-20mA, 0-5V, 1-10V, 0-2VDC, and ±5VDC. RS-232 and RS-485 digital output is also available. Custom engineering and design solutions available.
Contact us for a copy of our Sensors for Test and Measurement catalog.
|
|
Sensortechnics is a leading manufacturer and distributor of a wide range of sensors and fluid control devices. The product portfolio includes basic pressure sensors, rugged transmitters, submersible level sensors and customised pressure sensing systems from 1 mbar up to 1000 bar as well as liquid level sensors and switches, flow, oxygen and force sensors. Additionally, Sensortechnics offers ultrasonic air bubble, air-in-line, liquid level and fluid monitoring detectors. Fluid control devices include miniature solenoid valves, diaphragm pumps and electronic pressure controllers.
Sensortechnics has more than 25 years of experience in providing highly customised sensing products and in the development of complex integrated fluid control systems for OEM customers worldwide.
|
|
Differantial Pressure Transducers
Model 8310, 8311, 8313, 8314, 8315, 8316
|
|
|
|
|
|
The Digital Output pressure sensors are based upon a proprietary surface mapping technology to produce a fully digital output that virtually eliminates all repeatable errors over temperature and pressure. This series provides a 12 bit digital serial output (14 bit in High Resolution Mode) with superior offset, span and linearity characteristics. The output is SPI and MICROWIRE/PLUS® compatible as well as fully compatible with the All Sensors GA142 Series sensors.
In addition to synchronous communications, the Digital Output pressure sensors incorporates a bi-directional, TTL level, asynchronous serial interfaces mode (hardware selectable 9,600 or 19,200 baud). This mode includes a command set that allows the host to interrogate the sensor for model information, pressure range, serial number, pressure units and conversion factor. The command set also allows the host to select a high resolution output mode, make minor adjustments to offset and has an addressable feature that allows multiple sensors to be tied to the same interface buss.
This series is intended for use with non-corrosive, non-ionic working fluids such as air, dry gases and the like. All signals are 5V TTL/CMOS compatible.
|
|
|
|
