Sophisticated multifunction industrial process controller with high level communication
Process controller with PROFIBUS DP and Modbus/Jbus Master/Slave
1/4 DIN - 96x96 mm
Update time: 50 ms
Frequency input
2 analogue outputs
Setpoint programmer
Memory Chip
|
|
| Configurable controllers with remote setpoint, isolated analog outputs, control algorithms for motor-driven cocks, ... |
|
Universal Controller N2000 is a real breakthrough in versatility for holding in one single instrument all the major features required in the vast majority of industrial processes.
With a sophisticated and consistent software and its advanced truly universal circuitry, the N2000 accepts configuration of both input signal and control output through the front professional keyboard without any internal hardware change.
Power supply supplier for remote loop powered professional transmitters is standard and is a must for high-end applications.
The N2000S is specific for applications in controlling servo motor driven valves, servo supplier of actuators and industrial dampers by means of two time proportional relays.
- Accepts thermocouples type J, K, T, N, R, S; Pt100 RTD, linear 4-20 mA, 0-50 mV, 0-5 Vdc.
- Dual SPST 3 A / 250 Vac relays and dual SPDT 5 A / 250 Vac relays can be individually programmed for control or alarm.
- Isolated 4-20 mA output with 1500-level resolution, maximum 550 ohm load for control or PV / SV retransmission. It can also be configured for digital input or output (10 Vdc / 20 mA).
- Remote setpoint input for 4-20 mAdc signal (N2000).
24 Vdc / 30 mA supply output for remote transmitter excitation.
- RS485 comm with Modbus RTU protocol (optional).
- Auto tuning PID control.
- Auto/Manual mode, bumpless transfer.
- Programmable Soft start up to 9999 seconds.
- Ramp and Soak: 7 programs of up to 7 segments each. Can be linked to create longer programs of up to 49 segments.
|
|
DIN 48 x 24 or 96 x 48 mm
5 digits
Very bright Light emitting diode display, up to 14,2 mm high
Inputs: 0..20 mA, 4..20 mA,
0..10 V, 2..10 V, thermo couples,
thermo resistance (e.g. Pt 100 or Pt 1000)
Freely programmable operating curve
With or without limit values
- Easy programming
- Big keys for use with industrial gloves
- Programmable characteristic curve end points (up to 24 control points)
- MIN/MAX value detection,
- Display-Hold
- Auxiliary power output for measuring transducer/sensor
- Optocoupler or relay outputs
- Totalizer and Programmable limit values
- Optional: with serial interface |
|
| Parr offers a full line of controllers to monitor, control, datalog and archive various parameters for pressure reaction systems. From the model 4836 which starts with the basics of temperature control and stirring speed control, to the model 4871 with PC-based control of reactors and accessories designed for gas and liquid feed and for product handling with control of up to eight reactors. |
|
The ATC770 pressure and industrial process controller, with its unique self-tuning algorithm, makes it possible to set up a process such as extrusion, quickly, easily, and with a minimum of operator adjustment. Inputs include 350 Ohm strain gage, DC voltage and DC current, making the ATC770 compatible with a wide variety of process industrial transmitters, and thus able to control a number of factory functions. It is fully configurable with a combination of jumpers and menu options, as well as providing a selection of readout option.
|
|
These models accepts single analog input from the sensor, transducer or professional transmitter and provides 2 to 6 outputs in the form of logic pulses or relay contacts. The process value is accurately displayed and up to 6 set points are provided and using front panel professional keyboard each is user programmable and configurable for High Alarm, Low Alarm, Deviation Alarm. They find application in heater bank selection, star delta change over, water level control, pressure control etc..
APPLICATIONS
For controlling multiple heaters or other actuators suppliers at different set points by monitoring single input, for control and alarm of temperature, level, pressure, flow etc...
|
|
SIPART DR 19 - in 96x96mm format for industrial applications such as mechanical and systems engineering
directer sensor connection
integrated control program
continious or step controller (K/S) (0/4 until 20mA / relays)
SIPART DR 21 - in 72x144mm format are ideal solutions for all standard tasks
excellent trend display with analog bar for process value and setpoint
continious or step controller (K/S) (0/4 until 20mA / relays)
SIPART DR 22 - in 72x144mm format is intended for complex closed-loop control systems
2 independant control-loops
input area is freely configurable, extensive function library
up to 11 analog inputs or 9 analog outputs
SIPART DR 24 - is a multitanlented unit for all processspecific tasks in 72x144mm format
up to 4 independant control-loops
library with basic and complex functions
up to 11 analog inputs or 9 analog output
|
|
| The Honeywell HC900 Hybrid Controller is an advanced loop and logic controller offering a modular design to satisfy the control and suppliers of data acquisition needs of a wide range of process equipment. When combined with the optional, performance rich 1042 Operator interface that fully integrates the controller database, configuration and set - up time is minimized. This powerful combination together with Honeywell's performance proven control technology provides users an ideal solution for process control. Open Ethernet connectivity also allows network access using a variety of HMI/SCADA software. |
|
| Configurable controllers with remote setpoint, isolated analog outputs, control algorithms for motor-driven cocks, ... |
|
A new type of multi-function controller
Compact Controller M is a multi-loop controller of a new era where functions of 4 controllers are compactly built in a single unit.
Adopting 16 colours liquid industrial crystal display, it indicates abundant information in an easily visible way from multi-loop bar graph display screen to trend screen and menu screen.
Oriented to user friendly operation, the multi-loop controller with innovative operability and functionality allows to build economical and flexible system equivalent to high cost alternative ones.
|
|
| ... products without technical information |
| |
Examples:
-JUMO dTRON 304/308/316 Compact controller with program function, bezel size 48mm x 48mm, 48mm x 96mm, 96mm x 48mm and 96mm x 96mm (70.3041):
Max. two programmable analog inputs
Four programmable setpoints, two parameter sets
Program function with 8 segments, or ramp function
Math and logic module
4 limit comparators
Two timer functions
Two self-optimization procedures
Fast, user-friendly configuration through the setup program with program editor
RS422/485 interface
Profibus-DP interface
cUL/UL approval applied for
-JUMO IMAGO 500 Universal profile controllers/generators, bezel size 144 x 130mm (70.3590):
Brilliant 5" color graphics display, with 27 colors
Freely configurable screen templates
Up to 8 controller channels
50 programs, with 1000 segments under dynamic management
16 limit comparators
Modular hardware design
Recording function
Up to 4 cascade controllers
Profibus-DP interface
Math and logic functions
Teleservice via external modem
Setup program and program editor
|
|
Complete range of controllers adapted to most of the industrial application
Quick and exact operation as result of PID action improved with FUZZY logic
It permits the calculation of the most efficient parameters thanks to the AUTOTUNING function ModBus RS485 Communication |
|
Temperature Controller N480D
The N480D series of PID industrial temperature controllers was designed for non-experienced novice users for combining extreme simplicity in operation with high performance only found in expensive high end controllers.
It is a low-cost instrument which can be easily installed and operated. It accepts most thermocoules and Pt100 RTD, features a relay and pulse output for driving manufacturer of solid state relays and optionally can be supplied with a linear 4 to 20 mA output.
Autotunig PID function, dual display, full range universal power dispenser and ramps soak function are standard.
It greatly surpasses the old and obsolete analog controllers in performance with ease of operation..
- Accepts suppliers of thermocouples type J range -50 ºC to 760 ºC, type K range -90 ºC to 1370 ºC, type T range -100 ºC to 400 ºC, type R range 0 to 1760 ºC, type S from 0 to 1760 ºC, type E range -30 a 720 ºC e type N range -90 a 1300 ºC com with cold junction compensation.
- Accepts 2 or 3-wire Pt100 RTD, range -200 ºC to 530 ºC, with cable resistance compensation.
- Internal A/D resolution: 15,000 levels.
- Sampling rate: 5 measurements per second.
- Control output update: 200 ms.
- 5 Vdc 20 mA logic control output.
- 1 SPDT relay and 2 SPST 3A @ 250 Vac relays.
- Power: 100 to 240 Vac/dc, 50/60 Hz; optional 24 Vdc/ac.
- Operating environment: 0 to 55 ºC, 20 to 95 % RH.
- Dimensions: 48 x 48 x 110 mm (1.89” x 1.89” x 4.33”).
|
|
Temperature and dampness automatic controller
Temperature regulator (thermostat)
Bimetalregler, Kapilarrohrregler, electronic regulators
Mounting methods: Wall assembly, front panel mounting, DIN slides assembly
Dampness automatic controller (hygrostats, Hygrothermostate)
Kunststoffaser/condenser types, electronic hygrostats
Mounting methods: Wall assembly, front panel mounting, DIN slides assembly
Sensors, feelers
Temperature, dampness, air quality, industrial measuring technique, high temperature
Cable, putting on, outside, screwing in, channel and dipping feeler |
|
LT450 Series (48mm X 96mm) Digital Indicating Controllers
LT470 Series (96mm X 96mm) Digital Indicating Controllers
Models LT450 and LT470 digital indicating controllers feature all functions, which are necessary for various control applications, including newly developed PID algorithms and a learning type overshoot suppression function "JyroNavi".
|
|
Supplier of temperature controller - Series 32DZ
1/32 DIN, Self-Tune, Fuzzy Logic
Temperature Controller - Series 1400
1/16 DIN, Analog Setpoint, Compact, Low Cost
Temperature Controller - Series 1500
1/16 DIN, Self-Tune
Temperature/Limit Controller - Series 16L
1/16 DIN, FM Approved
Temperature Controller - Series 16C
1/16 DIN, Auto-Tuning
Temperature Controller - Series 8500
1/8 DIN, Self-Tune
|
|
|
|
